Motorola T190 User manual

Welcome
1
Welcome
Welcome to the world of Motorola digital wireless
communications! We are pleased that you have chosen the
Motorola T190 wireless phone.
CompleteVersion.book Page 1 Friday, October 26, 2001 4:45 PM

Welcome
2
Personal Communications Sector
600 North U.S. Highway 45
Libertyville, Illinois 60048
1-800-331-6456 (United States)
1-888-390-6456 (TTY/TDD United States)
1-800-461-4575 (Canada)
www.motorola.com (United States)
www.motorola.ca (Canada)
MOTOROLA, the Stylized M Logo and all other trademarks indicated as
such herein are trademarks of Motorola, Inc. ® Reg. U.S. Pat. & Tm. Off.All
other product or service names are the property of their respective owners.
© 2001 Motorola, Inc. All rights reserved. Printed in the U.S.A.
Software Copyright Notice
The Motorola products described in this manual may include copyrighted
Motorola and third party software stored in semiconductor memories or
other media. Laws in the United States and other countries preserve for
Motorola and third party software providers certain exclusive rights for
copyrighted software, such as the exclusive rights to distribute or
reproduce the copyrighted software.Accordingly, any copyrighted software
contained in the Motorola products may not be modified, reverse-
engineered, distributed, or reproduced in any manner to the extent
allowed by law. Furthermore, the purchase of the Motorola products shall
not be deemed to grant either directly or by implication, estoppel, or
otherwise, any license under the copyrights, patents, or patent applications
of Motorola or any third party software provider, except for the normal,
non-exclusive, royalty-free license to use that arises by operation of law in
the sale of a product.
Manual number:
Cover number:
CompleteVersion.book Page 2 Friday, October 26, 2001 4:45 PM

3
Contents
Welcome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Safety and General Information . . . . . . . . . . . . . . . . . . 5
Touring Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Appearance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Idle Mode Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Your SIM Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Battery Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Using Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Turning on the Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Making a Phone Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Ending a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Answering a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Turning Off the Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
One-touch Dialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Listening to a Voicemail . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Making an International Call . . . . . . . . . . . . . . . . . . . . . . 26
Making an Emergency Call . . . . . . . . . . . . . . . . . . . . . . . . 27
Dialing an Extension Number . . . . . . . . . . . . . . . . . . . . . . 27
Last Missed, Dialed, and Received Calls . . . . . . . . . . . . . . 27
Making an Abbreviated Call . . . . . . . . . . . . . . . . . . . . . . . 28
Phone Book Directory Shortcut . . . . . . . . . . . . . . . . . . . . . 28
Messages Menu Shortcut . . . . . . . . . . . . . . . . . . . . . . . . . 29
Adding Phone Book Entries in Idle Mode . . . . . . . . . . . . . 29
Incoming Call Waiting . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Holding a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Call Options Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
CompleteVersion.book Page 3 Friday, October 26, 2001 4:45 PM

4
Adjusting the Earpiece Volume . . . . . . . . . . . . . . . . . . . . . 33
Initiating Keypad Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Input Mode Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Selecting an Input Mode . . . . . . . . . . . . . . . . . . . . . . . . . 34
Quick Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Quick Access Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Using the Quick Access Menu . . . . . . . . . . . . . . . . . . . . . 43
Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Using Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Phone Book (1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Messages (2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Call Services (3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Phone Setting (4) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Network (5) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Security (6) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Audio Setting (7) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Tools (8) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Menu Structure Map . . . . . . . . . . . . . . . . . . . . . . . . . 95
Care and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . 96
Problems and Solutions . . . . . . . . . . . . . . . . . . . . . . . 97
CompleteVersion.book Page 4 Friday, October 26, 2001 4:45 PM

Safety and General Information
5
Safety and General Information
IMPORTANT INFORMATION ON SAFE AND EFFICIENT OPERATION.
READ THIS INFORMATION BEFORE USING YOUR PHONE.
RF Operational Characteristics
Your phone contains a transmitter and receiver. When it is ON, it
receives and transmits radio frequency range of 900 MHz to 1800 MHz
and employs digital modulation techniques. When you communicate
with your phone, the system handling your call controls the power
level at which your phone transmits. The output power level typically
may vary over a range from 1mW to 2 Watts.
Exposure to Radio Frequency Energy
Your Motorola phone is designed to comply with the following
national and international standards and guidelines regarding exposure
of human beings to radio frequency electromagnetic energy:
• United States Federal Communications Commission, Code of
Federal Regulations; 47 CFR part 2 sub-part J
• American National Standards Institute (ANSI) / Institute of Electrical
and Electronic Engineers (IEEE) C95. 1-1992
• Institute of Electrical and Electronic Engineers (IEEE) C95.1-1999
Edition
• National Council on Radiation Protection and Measurements
(NCRP) of the United States, Report 86, 1986
• International Commission on Non-Ionizing Radiation Protection
(ICNIRP) 1998
• Ministry of Health (Canada) Safety Code 6. Limits of Human
Exposure to Radiofrequency Electromagnetic Fields in the Frequency
Range from 3 kHz to 300 GHz, 1999
CompleteVersion.book Page 5 Friday, October 26, 2001 4:45 PM

Safety and General Information
6
• Australian Communications Authority Radiocommunications
(Electromagnetic Radiation - Human Exposure) Standard 1999
(applicable to wireless phones only)
To assure optimal phone performance and make sure human exposure
to radio frequency electromagnetic energy is within the guidelines set
forth in the above standards, always adhere to the following
procedures:
Portable Phone Operation and EME
Exposure
Antenna Care
Use only the supplied or an approved replacement antenna.
Unauthorized antennas, modifications, or attachments could damage
the phone and may violate FCC regulations.
DO NOT hold the antenna when the phone is “IN USE”. Holding
the antenna affects call quality and may cause the phone to operate at
a higher power level than needed.
Phone Operation
When placing or receiving a phone call, hold your phone as you would
a wireline telephone. Speak directly into the microphone.
Body-worn Operation
To maintain compliance with FCC/Health Canada RF exposure
guidelines, if you wear a phone on your body when transmitting,
always place the phone in a Motorola supplied or approved clip,
holder, holster, case, or body harness for this product. Use of non-
Motorola-approved accessories may exceed FCC/Health Canada RF
exposure guidelines. If you do not use a body-worn accessory, and
are not using the phone held in the normal use position at the
ear, ensure the phone and its antenna are at least one inch (2.5
cm) from your body when transmitting.
CompleteVersion.book Page 6 Friday, October 26, 2001 4:45 PM

Safety and General Information
7
Data Operation
When using any data feature of the phone, with or without an
accessory cable, position the phone and its antenna at least one
inch (2.5 cm) from the body.
Approved Accessories
For a list of approved Motorola accessories visit our website at
www.motorola.com.
Electromagnetic Interference/
Compatibility
Note: Nearly every electronic device is susceptible to electromagnetic
interference (EMI) if inadequately shielded, designed or otherwise
configured for electromagnetic compatibility.
Facilities
To avoid electromagnetic interference and/or compatibility conflicts,
turn off your phone in any facility where posted notices instruct you to
do so. Hospitals or health care facilities may be using equipment that is
sensitive to external RF energy.
Aircraft
When instructed to do so, turn off your phone when on board an
aircraft. Any use of a phone must be in accordance with applicable
regulations per airline crew instructions.
Medical Devices
Pacemakers
The Advanced Medical Technology Association recommends that a
minimum separation of 6 inches (15 centimeters) be maintained
between a handheld wireless phone and a pacemaker.These
recommendations are consistent with the independent research by,
and recommendations of, the United States Food and Drug
Administration.
Persons with pacemakers should:
CompleteVersion.book Page 7 Friday, October 26, 2001 4:45 PM

Safety and General Information
8
• ALWAYS keep the phone more than six inches (15 centimeters)
from their pacemaker when the phone is turned ON.
• not carry the phone in the breast pocket.
• use the ear opposite the pacemaker to minimize the potential for
interference.
• turn the phone OFF immediately if you have any reason to suspect
that interference is taking place.
Hearing Aids
Some digital wireless phones may interfere with some hearing aids. In
the event of such interference, you may want to consult your hearing
aid manufacturer to discuss alternatives.
Other Medical Devices
If you use any other personal medical device, consult the manufacturer
of your device to determine if it is adequately shielded from RF energy.
Your physician may be able to assist you in obtaining this information.
Safety and General
Use While Driving
Check the laws and regulations on the use of phones in the area where
you drive. Always obey them.
When using your phone while driving, please:
• Give full attention to driving and to the road.
• Use hands-free operation, if available.
• Pull off the road and park before making or answering a call if
driving conditions so require.
CompleteVersion.book Page 8 Friday, October 26, 2001 4:45 PM

Safety and General Information
9
Operational Warnings
ForVehicles with an Air Bag
Do not place a portable phone in the area over an air bag or in the air
bag deployment area. Air bags inflate with great force. If a portable
phone is placed in the air bag deployment area and the air bag inflates,
the phone may be propelled with great force and cause serious injury
to occupants of the vehicle.
Potentially Explosive Atmospheres
Turn off your phone prior to entering any area with a potentially
explosive atmosphere, unless it is a phone type especially qualified for
use in such areas as “Intrinsically Safe.” Do not remove, install, or
charge batteries in such areas. Sparks in a potentially explosive
atmosphere can cause an explosion or fire resulting in bodily injury or
even death.
Note: The areas with potentially explosive atmospheres referred to
above include fueling areas such as below decks on boats, fuel or
chemical transfer or storage facilities, areas where the air contains
chemicals or particles, such as grain, dust or metal powders, and any
other area where you would normally be advised to turn off your
vehicle engine. Areas with potentially explosive atmospheres are often
but not always posted.
Blasting Caps and Areas
To avoid possible interference with blasting operations, turn off your
phone when you are near electrical blasting caps, in a blasting area, or
in areas posted: “Turn off two-way radio.” Obey all signs and
instructions.
CompleteVersion.book Page 9 Friday, October 26, 2001 4:45 PM

Safety and General Information
10
Operational Cautions
Antennas
Do not use any portable phone that has a damaged antenna. If a
damaged antenna comes into contact with your skin, a minor burn can
result.
Batteries
All batteries can cause property damage and/or bodily injury such as
burns if a conductive material such as jewelry, keys, or beaded chains
touch exposed terminals. The conductive material may complete an
electrical circuit (short circuit) and become quite hot. Exercise care in
handling any charged battery, particularly when placing it inside a
pocket, purse, or other container with metal objects.
CompleteVersion.book Page 10 Friday, October 26, 2001 4:45 PM

Safety and General Information
11
European Union Directives Conformance
Statement
Hereby, Motorola declares that this product is in
compliance with
•The essential requirements and other relevant provisions
of Directive 1999/5/EC
• All other relevant EU Directives
The above gives an example of a typical Product Approval Number.
You can view your product’s Declaration of Conformity (DoC) to
Directive 1999/5/EC (to R&TTE Directive) at www.motorola.com/rtte.
To find your DoC, enter the product Approval Number from your
product’s label in the “Search” bar on the web site.
IMEI: 350034/40/394721/9
0168
Type: MC2-41H14
Product Approval
Number
CompleteVersion.book Page 11 Friday, October 26, 2001 4:45 PM

Safety and General Information
12
CompleteVersion.book Page 12 Friday, October 26, 2001 4:45 PM

Touring Your Phone
13
TouringYour Phone
Appearance
Antenna
Earpiece
LCD display
Right soft key
Left soft key
Power on/off key Send/answer key
Scroll key
Alphanumeric
keys
Menu key
*For information on how to use each key, see "Function Keys" on
page 16.
Front
CompleteVersion.book Page 13 Friday, October 26, 2001 4:45 PM

Touring Your Phone
14
*For connection to the optional handsfree headset.
Headset jack*
Microphone
Lanyard hole
Battery compartment
Battery contacts
SIM card slot
SIM card slot latch
Battery
Battery latch
Charger port
Label
CompleteVersion.book Page 14 Friday, October 26, 2001 4:45 PM

Touring Your Phone
15
Idle Mode Display
Idle Display Icons
Icons are frequently shown on the idle display:
Icon Function Descriptions
h
Signal
Strength
Signal strength of your designated
network.The more bars displayed,
the stronger the signal.
b
Short
message
Receiving a short text message or
having unread messages (see page
55).
e
Voice mail
waiting
You have a new voice mail (see
page 64)
n
Call divert
All incoming calls are diverted to a
designated number (see page 68).
f
Line in use
The current line in use (see page
71).
Press +to access
the phone book
directory.
Press Mto access the menus.
Press -to access
the Messages menu.
Time and date
Status icon bar
hbfa
7 Oct Sun 08:30
jc
y
CompleteVersion.book Page 15 Friday, October 26, 2001 4:45 PM

Touring Your Phone
16
Keys
Function Keys
In this user guide, long press means “pressing and holding a key for about
2 seconds.,” while
press means “pressing and releasing a key
immediately.”
g
Vibration only
Your phone only vibrates without
ringing when a call comes in. (See
page 80).
a
Battery
Battery power level, the more the
bars, the more the battery power.
Four bars: full. No bars: Recharging
immediately. The icon scrolls during
charging until the battery is full.
l
Key lock
Key lock is activated (see page 33
and 73).
k
Roaming
When your phone is not used on
your home network, this icon will
appear.
Icon Function Descriptions
CompleteVersion.book Page 16 Friday, October 26, 2001 4:45 PM

Touring Your Phone
17
This listing does not include all operations of each key. Refer to related
sections of this manual for other key commands.
Keys Commands and functions
O
Power On/Off key
•Long press to switch your phone on/off.
•Press to end or cancel a call.
•Press to return to the previous menu.
N
Send/Answer key
•Press to send or answer a call.
•In idle mode, long press to redial the last call number.
•In idle, press to display last dialed / missed / received
numbers.
•Press to select or activate an option.
M
Menu key
•Accessing the main menu from idle.
•During a call, press to access the Call Options menu.
•During input, press to access the input mode menu.
-
Right soft key
Executes the command shown at the bottom right of the
display:
•In menus, press to select or activate an option
(as
SEL
/
OK
/
OPTION
shows).
•In idle, press to access the Messages menu. (as
c
shows).
•Confirms entered digits/text during input (as
OK
shows).
CompleteVersion.book Page 17 Friday, October 26, 2001 4:45 PM

Touring Your Phone
18
+
Left soft key
Executes the command shown at the bottom left of
the display:
•In menus, press to abort a selection/operation and return
to the previous menu or screen (as
QUIT
/
EXIT
shows).
•In idle mode, press to access the Phone Book directory
(as
y shows).
•During input, press to clear one digit/character; long
press to clear all digits/characters (as
DEL
shows).
S
Scroll key
•Scrolling the menus and options.
•Adjusting volume during a call.
•In idle mode, press to access Quick Access menu.
•In idle mode, long press to access Phone Book directory
•During input, press once to move cursor to the next/last
insertion point; long press to move the cursor
continuously.
*
Voicemail key
•In idle, long press to dial the voice mail box number.
#
Lock key
•In idle, long press to lock the keypad.
1
- 9
Number key
•In idle, long press to dial any of the first 9 phone numbers
saved in the Phone Book.
•In menus, press to access a corresponding option directly.
Keys Commands and functions
CompleteVersion.book Page 18 Friday, October 26, 2001 4:45 PM

Touring Your Phone 19
Alphanumeric Keys
Following is a list of the alphanumeric keys and their corresponding
characters and symbols in input.
Key Lower case
1
, . : 1 % ! ? ;“ ‘ < > ( ) @ &
2
A B C 2 Å A
¨å ä à ç æ β
3
D E F 3 é è E £Æ $
4
G H I 4 ı
`i ¿ ¤
5
J K L 5 ∆_ ΦΓΛΩ
6
M N O 6 N ñòööOø
7
P Q R S 7 ¥ §
8
T U V 8 ü U
¨ù
9
W X Y Z 9 ∏ψ Σ θ Ξ
0
0 (Space)
*
+ - * / =
#
# P
CompleteVersion.book Page 19 Friday, October 26, 2001 4:45 PM

Getting Started
20
Getting Started
Your SIM Card
To successfully use your phone, you must insert a SIM card (Subscriber
Identification Module) supplied by your network operator. The SIM card
contains your subscription number and your phone number as well as a
memory in which you can store phone numbers, messages, etc.
InsertingYour SIM card
Note: Scratches can easily damage the metal contacts of the SIM card.
Pay special attention to the SIM card when you handle and insert.
•Locate the SIM card slot on back of your phone. Place the entire SIM card
into the slot, with the metal contacts of the SIM card facing down and its
cut corner on the upper left.
•Slide the SIM card latch over onto the card.
SIM card
CompleteVersion.book Page 20 Friday, October 26, 2001 4:45 PM
