Motorola Nextel iDEN i2000plus User manual

Motorola
iDEN®
Digital Multi-Service Data Capable Phone
i2000plus User’s Guide
@NTN9487A@
NTN9487A

Patent and Trademark Information
i
Patent and Trademark Information
This product is protected under one or more of the following patents:
4817157, 4896361, 4857928, 5041793, 5060294, 5066923, 5134718, 5140156,
5239963, 5257411, 5287387, 5265219, 5289504, 5316168, 5317247, 5338396,
5389927, 5406588, 5424921, 5457376, 5460906, 5551063, 5557079, 5596487,
5615412, 5638403, 5559468, 5469465, 5170413, 5140615, 5519730, 5241544,
5584059, 5574992, 5396656, 5487091, 5533004, 5299199, 5343499, 5369501,
5509031, 5515379, 5528723, 5598417, 5066923, 5241650, 5278833, 5359696,
5548631, 5410632, 5440582, 5457735, 5457818, 5471670, 5477550, 5481537,
5566181, 5229767, 5208804, 5295140, 5381449, 5440590, 5467398, 5490230,
5620242, 5623523, 5655913, 5715240, 5771440, 5854578, 5675281, 5721787,
5729539, 5788523, 5869204, 5911124, 5946620, 5949774, 5949821, 5951317,
5987332, 6002948
Additional patents are pending.
MOTOROLA, the stylized M logo, and all other trademarks indicated as such
herein are trademarks of Motorola, Inc. ®Reg. U.S. Pat. & Tm. Off.
Manufactured under one or more of the U.S. patents listed in the User’s Guides.
T9 is a trademark owned by Tegic Communications, Inc.
All other trademarks mentioned in this manual are trademarks of their respective
companies.
© Copyright 2000, Motorola, Inc. All rights reserved.

ii
www.motorola.com

Contents
iii
Contents
CONTENTS
Patent and Trademark Information............................ i
Wireless Phone Safety Tips....................................... viii
Welcome ....................................................................... 11
Setting Up Your i2000plus Phone for Use................................ 12
TTY Access............................................................................... 12
Large Print Manuals.................................................................. 12
Features of Your i2000plus Phone ........................................... 13
Inserting the SIM Card.............................................................. 15
Charging and Attaching the Battery.......................................... 16
Turning On Your i2000plus Phone........................................... 17
Light Sensor .............................................................................. 18
SIM Card PIN ........................................................................... 19
Entering the PIN ................................................................... 19
Unblocking the PIN.............................................................. 19
Changing the PIN ................................................................. 20
Disabling the PIN Requirement............................................ 21
Enabling the PIN Requirement............................................. 21
Keypad Lock ............................................................................. 22
Display Icons............................................................................. 22
About Modes and Menus .......................................................... 23
Setting the Time and Date......................................................... 24
Changing the Display Language ............................................... 25
Selectable Backlight Timer....................................................... 26
Making Phone Calls .................................................... 27
International Phone Calls Using Plus Dialing...................... 27
Inserting Pauses into Phone Numbers .................................. 27
Using Other Dialing Methods ................................................... 27
Scroll..................................................................................... 28
Speed Dial ............................................................................ 28
Name Search......................................................................... 28
Last Number Redial.............................................................. 28
Turbo Dial® ......................................................................... 28
Automatic Redial.................................................................. 29
Emergency Dial .................................................................... 29
Hands-Free Speakerphone ........................................................ 29
Receiving a Phone Call ............................................................ 30

iv
www.motorola.com
Missed Call Indicator................................................................ 30
What Is My Phone Number?..................................................... 31
VibraCall®Alert....................................................................... 31
Selecting VibraCall Alert for All Incoming Calls
and Messages........................................................................ 32
Selecting VibraCall Alert for Individual Services................ 32
Setting the Ringer Volume........................................................ 33
Selecting a Ring Style ............................................................... 33
Additional Call Services ............................................. 35
Call Forwarding ........................................................................ 35
Unconditional Call Forwarding............................................ 35
Conditional Call Forwarding................................................ 36
Call Waiting .............................................................................. 37
Call Hold ................................................................................... 37
3-Way Calling ........................................................................... 37
Call Barring............................................................................... 38
Barring Incoming Calls ........................................................ 38
Barring Outgoing Calls......................................................... 39
Viewing Call Barring Status................................................. 40
Changing Your Call Barring Passcode................................. 40
Alternate Phone Line (iDEN Only) .......................................... 41
Setting the Active Line......................................................... 41
Receiving a Call ................................................................... 41
Receiving a Call on Your Alternate Line............................. 42
Phone Only Mode (iDEN Only) ............................................... 42
Creating, Editing, and Using Stored Lists................ 44
Combined Phone Number and Private ID List..................... 44
Pre-Pend Feature ....................................................................... 44
Last 10 Calls Received and Sent Lists ................................. 48
Quickstore of Phone Numbers.............................................. 49
Traveling Between Systems........................................ 51
Searching for a Network....................................................... 51
Storing Your Preferred List of Networks ............................. 52
Storing New Networks to Your Known List ............................ 53
Making Private Calls (iDEN Only) ........................... 55
Receiving a Private Call............................................................ 55
Private/Group Mode Speaker.................................................... 56
Call Alert................................................................................... 56

Contents
v
Sending a Call Alert ............................................................. 56
Receiving a Call Alert .......................................................... 56
Call Alert Queuing ............................................................... 57
Clearing or Queueing a Call Alert........................................ 57
Responding to a Queued Call Alert...................................... 57
Quickstore of Private IDs.......................................................... 57
Viewing Your Private ID .......................................................... 58
Making Group Calls (iDEN Only) ............................. 59
Receiving a Group Call............................................................. 59
Adding and Storing a Talkgroup............................................... 59
Area Selection ........................................................................... 60
Private/Group Mode Speaker.................................................... 60
Using Mail Services. .................................................... 61
Net Mail .................................................................................... 61
Voice Mail................................................................................. 62
Alert Receipt ............................................................................. 63
Message Mail ............................................................................ 63
Saving and Erasing Mail ...................................................... 64
Auto Call Back ..................................................................... 64
Mail Memory Full ................................................................ 64
Using Your Phone as a Modem .................................. 65
Setting Programming Menus...................................... 66
About Status Messages................................................ 73
Accessories.................................................................... 75
Batteries ............................................................................... 75
Charging Lithium Ion Batteries............................................ 75
Battery Operating Instructions ............................................. 76
Travel Charger .......................................................................... 76
Using the Travel Charger ..................................................... 77
Travel Charger Operating Specifications ............................. 77
Vehicular Battery Charger ........................................................ 77
Using the Vehicular Battery Charger ................................... 78
Removing the Vehicular Battery Charger ............................ 78
Vehicular Battery Charger Operating Specifications........... 79
Desktop Dual-Pocket Charger .................................................. 79
Charging a Battery................................................................ 79

vi
www.motorola.com
Audio Adapter........................................................................... 80
Using the Audio Adapter...................................................... 80
Attaching/Detaching the Earpiece Microphone ................... 80
Removing the Audio Adapter.............................................. 80
Hands-Free Car Kit .................................................... 81
Using the Hands-Free Car Kit................................................... 82
Dash Mount Holder................................................................... 83
Using the Dash Mount Holder.............................................. 84
Safety and General Information................................ 85
RF Operational Characteristics ................................................. 85
Exposure To Radio Frequency Energy ..................................... 85
Portable Radio Product Operation and EME Exposure ............ 86
Antenna Care ........................................................................ 86
Phone Operation ................................................................... 86
Two-way radio operation ..................................................... 86
Body-worn operation............................................................ 86
Data operation ...................................................................... 86
Approved Accessories .......................................................... 87
Electro Magnetic Interference/Compatibility ........................... 87
Facilities ............................................................................... 88
Aircraft ................................................................................. 88
Medical Devices........................................................................ 88
Pacemakers ........................................................................... 88
Hearing Aids......................................................................... 88
Other Medical Devices ......................................................... 88
Use While Driving .................................................................... 89
Operational Warnings................................................ 90
For Vehicles Equipped with an Air Bag ................................... 90
Potentially Explosive Atmospheres .......................................... 90
Blasting Caps and Areas ........................................................... 90
Operational Cautions ................................................. 91
Antennas.................................................................................... 91
Batteries .................................................................................... 91
Cleaning and Drying Considerations ........................................ 91
Accessory Safety Information.................................... 93
Limited Warranty Motorola Communication Products
(U.S.)............................................................................. 95

Contents
vii
Limited Warranty Motorola Communication Products
(international) .............................................................. 99
Owner’s Information................................................. 103
Private Number Directory .................................................. 104
Talkgroup Directory ........................................................... 104
European Union Directives Conformance
Statement.................................................................... 105
Index ............................................................................107

viii
www.motorola.com
Wireless Phone Safety Tips
“Safety is your most important call!”
Your Motorola wireless telephone gives you the powerful ability to
communicate by voice--almost anywhere, anytime, wherever wireless phone
service is available and safe conditions allow. But an important responsibility
accompanies that benefits of wireless phones, one that every user must uphold.
When driving a car, driving is your first responsibility. If you find it necessary to
use your wireless phone while behind the wheel of a car, practice good common
sense and remember the following tips:
1. Get to know your Motorola wireless phone and its features such as speed
dial and redial. If available, these features help you to place your call with-
out taking your attention off the road.
2. When available, use a hands-free device. If possible, add an additional
layer of convenience to your wireless phone with one of the many Motor-
ola Original hands-free accessories available today.
3. Position your wireless phone within easy reach. Be able to access your
wireless phone without removing your eyes from the road. If you receive
an incoming call at an inconvenient time, if possible, let your voice mail
answer it for you.
4. Let the person you are speaking with know you are driving; if necessary,
suspend the call in heavy traffic or hazardous weather conditions. Rain,
sleet, snow, ice, and even heavy traffic can be hazardous.
5. If you receive an incoming call at an inconvenient time do not take notes or
look up phone numbers while driving. Jotting down a “to do”list or going
through your address book takes attention away from your primary respon-
sibility--driving safely.
6. Dial sensibly and assess the traffic; if possible, place calls when you are not
moving or before pulling into traffic. Try to plan calls when your car will
be stationary. If you need to make a call while moving, dial only a few
numbers, check the road and your mirrors, then continue.
7. Do not engage in stressful or emotional conversations that may be distract-
ing. Make people you are talking with aware you are driving and suspend
conversations which have the potential to divert your attention away from
the road.
8. Use your wireless phone to call for help. Dial 9-1-1 or other local emer-
gency number in the case of fire, traffic accident or medical emergencies.*
9. Use your wireless phone to help others in emergencies. If you see an auto
accident, crime in progress or other serious emergency where lives are in
danger, call 9-1-1 or other local emergency number, as you would want
others to do for you.*
* Wherever wireless phone service is available.

Wireless Phone Safety Tips
ix
10. Call roadside assistance or a special non-emergency wireless assistance
number when necessary. If you see a broken-down vehicle posing no seri-
ous hazard, a broken traffic signal, a minor traffic accident where no one
appears injured, or a vehicle you know to be stolen, call roadside assistance
or other special non-emergency wireless number.*
* Wherever wireless phone service is available.

x
www.motorola.com
IMPORTANT!
Be sure to read “Safety and General Information” on page 85
before using your i2000plus phone.

Welcome
11
Welcome
WELCOME
ongratulations on purchasing your Motorola iDEN i2000plus
multi-service, data-capable, digital, portable global phone. The
use of two state-of-the-art technologies, iDEN and GSM (Global
System for Mobile communications), provides worldwide services to
keep you in touch with your business and personal contacts when you
travel.
A removable Subscriber Identity Module (SIM) card holds all your
personal information, including secure Personal Identification Numbers
(PINs), names, and phone numbers. Just as you protect your credit and
bank cards with PINs, you can safeguard your SIM card with a PIN.
Exciting new features include a vibration-only key, call barring, and a
missed-call indicator to help provide efficient operation of your
i2000plus phone. And, new ease-of-dialing features, such as Turbo
Dial®key and the Last Ten Received and Sent lists, as well as stored
names and numbers, help you to quickly make and return phone calls.
Your i2000plus phone offers:
•Phone Mode - for cellular phone operation. See Page 27.
•Private Mode - for two-way radio use to talk with one person in
your iDEN service area. See Page 55.
•Group Mode - for two-way radio use to talk with several people in
your iDEN service area. See Page 59.
•Messaging Services*- for message and voice mail. Page 61
•Net Mode*- for accessing the built-in mini-browser. See the Net
Mode User’s Guide.
•Fax and Data Transfer*- for circuit data faxes and file transfers.
See “Using Your Phone as a Modem”on page 65.
See the Wireless Data Services User’s Guide for information about data
calls and TTY access.
* Network dependent feature. Not available in all areas.
NOTE •Some features of your i2000plus phone are available only in
the iDEN service area, and are indicated as such in this
guide.
•This guide describes the features of the i2000plus phone as
they were set up by Motorola. However, your carrier or your
organization may have changed or added features. For more
information, check with your carrier or your organization.
C

12
www.motorola.com
Setting Up Your i2000plus Phone for Use
Before you can use your new i2000plus phone, you’ll need to:
1. Insert the SIM card—see Page 15.
2. Attach the battery—see Page 17.
3. Turn on your i2000plus phone—see Page 17.
4. Optional: Enter a PIN for your SIM card—see Page 19.
TTY Access
TTY access is available on your phone. See the Wireless Data Services
User’s Guide for complete instructions.
Large Print Manuals
A large-print version of the phone’s User’s Guide is available. For
more information on Motorola products for people with disabilities,
contact Motorola Customer Care at 1-800-453-0920 or TTY 1-877-
483-2840.

Welcome
13
Features of Your i2000plus Phone
NOTE: *These features are available in the Net Mode mini-browser.
(Subscription-dependent features are not available in all areas.)
NOTE: Remove the plastic film lens protector from the display before you use
your phone for the first time.
plus
next
7
. LED
14. Light Sensor
15. Option Keys
13. Alphanumeric Display
18. Alphanumeric Keypad
19. *Home Key
21. Speaker Key
20. *Next Key
17. Menu Key
22. Accessory and Data Cable
Connector
2
. Earpiece
16. Send/End Key
1. Antenna
4
. Push-To-
T
alk (PTT)
Button
3
. Volume
5
. Scroll
Key
6
. Mode
Key
8
. On/Off
9
. *Punctuation
10. *Back Key
11. Vibe-all Key
12. Microphone

14
www.motorola.com
1. Antenna Extend for optimal signal.
2 . Earpiece Listen to calls when the speakerphone
is off.
3 . Volume
Control
Buttons
Press to adjust volume levels in
Phone, Private, and Group modes. In
mail menus, press to scroll forward
and backward.
4 . Push-To-Talk
(PTT) Button
Transmit a Private or Group Call, or a
Call Alert. Press and hold to talk;
release to listen. (iDEN use only)
5 . Scroll Key Press the left side to scroll backward
or the right side to scroll forward
through menu options and lists. When
entering text, press to erase text or
add a space.
6 . Mode Key Press to change modes. (iDEN use
only)
7 . LED (Light
Emitting
Diode)
Check the phone’s status. See Table
on page 18 for more information.
8 . On/Off Button Press and hold to turn your i2000plus
phone on or off.
9 . Punctuation
Key*
Add punctuation in the Net Mode mini-
browser (within T9TM Text Input).
1 0 . Back*Key Return to the previous mini-browser
screen.
1 1 . Vibe-All Key Press to deactivate or turn on the
vibration alert.
1 2 . Microphone Use to speak during calls.
13. Alphanumeric
Display
View up to four lines (up to 12
characters per line) on the display.
14. Light Sensor When a key is pressed, the light
sensor will activate the backlight only
when your phone is in poor lighting
conditions.
15. Option Keys Press the right or left option key to
select the menu option that appears
directly above the key.

Welcome
15
Inserting the SIM Card
The SIM card contains all your stored names, numbers, and PINs after
you enter them in your i2000plus phone. You can make a phone call
only when the SIM card is properly placed in the phone.
Important! Insert and remove your SIM card with care so that you do
not lose it.
To insert the SIM card:
1. If your i2000plus phone is on, press and hold funtil you see the
message “Powering Off”.
2. Turn the phone over so that the antenna is at the upper left corner.
16. Send/End Key Press to answer an incoming Phone
call. After entering a phone number,
press to dial the call or to redial the
entered phone number. Press to end
Phone calls.
17. Menu Key Press to scroll through menu options.
18. Alphanumeric
Keypad
Enter telephone numbers, Private Call
IDs, and alphanumeric characters.
19. Home Key*Press to return to the mini-browser
Home menu.
20. Next Key*Press to display the next word choice
in the mini-browser (within T9 Text
Input).
21. Speaker/
Speakerphone
Key
Press to switch between the earpiece
and speaker during Private and Group
calls. (iDEN use only)
When in a phone call, press to activate
speakerphone (iDEN and GSM)
22. Accessory and
Data Cable
Connector
Use to connect accessories or the
battery charger.
* These features are available in the Net Mode mini-browser.
(Subscription-dependent features are not available in all areas.)
NOTE Depending on the network that you are on, you may be
able to make an emergency call without a SIM card.

16
www.motorola.com
3. If the battery is attached,
remove it. For information,
see “Detaching the Battery”on
page 17.
4. Slide the latch to the left
position and open the SIM
card holder.
5. If you have a full-size SIM
card, gently punch out the
mini SIM card.
6. Position the cut corner of the
SIM card as illustrated and
slide the card into the holder.
7. Close the card holder and
slide the latch to the right.
8. Now, you can attach the
battery. See “Attaching the
Battery”on page 17.
Charging and
Attaching the Battery
Remove the battery from the protective case provided in the original
packaging. When the battery is not attached to the phone or being
charged, store it in this case.
Charging the Battery
Attach the charger connector to the i2000plus phone, then flip open the
prongs and plug the charger into an electrical outlet. For m o re
information about chargers, see “Travel Charger”on page 76, “Veh ic u la r
Battery Charger”on page 77, and “Desktop Dual-Pocket Charger”on page
79.
NOTE After attaching the battery, you must charge it before
you use it for the first time. After the initial charging,
the battery can be charged more quickly.
Latch
Latch
SIM card
holder
SIM
card

Welcome
17
Attaching the Battery
To attach the battery to your
i2000plus phone, align the battery
as shown. Press down on the
battery latch until you hear a
click.
Battery and Charging Sta-
tus
A low battery is indicated by a
short, chirp-like sound through the
speaker. The battery strength icon
shows the remaining charge in the
battery. Three bars indicate full
charge. When you have less than
five minutes of talk time remaining, the indicator flashes.
Figure 1. Battery Charging Status
Detaching the Battery
To detach the battery, press the latch to release the battery and pull out
the battery.
Turning On Your i2000plus Phone
Press funtil a set of icons appears on your display. (For a description
of the icons, see Page 22.) Then a message, such as “Please Wait”,
displays while the i2000plus phone connects to your carrier’s network.
First Screen Second Screen Third Screen
Icon
Flashes
Charging Low Battery 0-30% 31-60% 61-90% 91-100%
Discharging Low Battery 0-10% 11-40% 41-70% 71-100%
NOTE Before removing the battery, make sure the phone is
turned Off.
Latch
Standard Battery 900 mAh
Slim Battery 500 mAh
(Your Carrier
(888)
555-1212
Message) Please Wait
Connecting

18
www.motorola.com
The second line of text on the Phone Ready screen displays the System
Name, which is the name of the network providing service in the iDEN
or GSM service area.
If your Home carrier is an iDEN carrier, then when you are in an iDEN
service area, the third line displays the local time and date. When you
are in the GSM service area, the third line displays the name of your
Home carrier.
The LED indicator located on the front of the i2000plus phone shows
the service state. See Table 1 .
Turning Off Your i2000plus Phone
Press and hold funtil you see the message “Powering Off”.
Light Sensor
On your i2000plus phone, when a key is pressed, the light sensor will
activate the backlight only when your phone is in low light conditions. If
illumination is needed, even when the backlight is not present, you can
manually override the sensor by pressing and holding n. This will
activate the backlight. In a charger, the backlight will always be
illuminated.
Table 1: Status Light (LED) Indicator
LED Indicator Status of Your i2000plus Phone
Flashing Red Registering—your i2000plus phone is
signing on to your carrier’s network.
Please wait.
Solid Red No service—your i2000plus phone
cannot sign on. It will continue trying to
connect every two minutes as long as
it is turned on.
Flashing Green In service—your i2000plus phone is
ready to use.
You can now place and receive calls.
Solid Green In use—your i2000plus phone is
currently being used. Check to make
sure that you ended the last call by
pressing e.
