Motorola W315 User manual

motorola.com
W315
CDMA
English

1
HELLOMOTO
Introducing your new Motorola W315 CDMA wireless phone. Here’s a quick anatomy lesson.
Left Soft Key
Volume Keys
Make &
answer calls.
Clear/Back Key
Turn on & off,
hang up, exit
menus.
Scroll up, down,
left, or right.
Right Soft Key
Select.
Smart/
Speakerphone
Key

2
Home Screen Main Menu
p
s
CONTACT
h
1:51pm 05/24-06
Gallery
n
t
SELECT EXIT
8
J
JÜ
8k
RECENT
1
23
4Press the skey
to select.
Press the skey
to open the
Main Menu .
Press and hold the
Power Key u for a
few seconds, or until
the screen lights up,
to turn on your
phone.
Press the Navigation Key
up, down, left or right ( S )
to highlight a menu feature.

3
Motorola, Inc.
Consumer Advocacy Office
1307 East Algonquin Road
Schaumburg, IL 60196
www.hellomoto.com
Certain mobile phone features are dependent on the capabilities
and settings of your service provider’s network. Additionally,
certain features may not be activated by your service provider,
and/or the provider's network settings may limit the feature’s
functionality. Always contact your service provider about feature
availability and functionality. All features, functionality, and other
product specifications, as well as the information contained in this
user's guide are based upon the latest available information and
are believed to be accurate at the time of printing. Motorola
reserves the right to change or modify any information or
specifications without notice or obligation.
MOTOROLA and the Stylized M Logo are registered in the US
Patent & Trademark Office. All other product or service names are
the property of their respective owners. Java and all other
Java-based marks are trademarks or registered trademarks of Sun
Microsystems, Inc. in the U.S. and other countries.
© Motorola, Inc., 2006.
Manual Number: 6809502A05-O

4
contents
contents
menu map . . . . . . . . . . . . 6
Use and Care . . . . . . . . . . 8
essentials . . . . . . . . . . . . . 9
about this guide. . . . . . . 9
battery . . . . . . . . . . . . . 10
turn it on & off . . . . . . . 11
make a call. . . . . . . . . . 12
answer a call . . . . . . . . 12
store a phone
number . . . . . . . . . . . . 12
call a stored phone
number . . . . . . . . . . . . 12
your phone number. . . 13
main attractions . . . . . . 14
send message. . . . . . . 14
cable connections . . . . 16
TTY operation . . . . . . . 16
basics . . . . . . . . . . . . . . . 18
display . . . . . . . . . . . . . 18
text entry. . . . . . . . . . . 20
volume. . . . . . . . . . . . . 23
navigation key . . . . . . . 24
external screen . . . . . . 24
handsfree speaker. . . . 24
codes & passwords. . . 24
lock/unlock
side keys . . . . . . . . . . . 25
lock & unlock phone . . 25
customize. . . . . . . . . . . . 26
ring style . . . . . . . . . . . 26
time & date . . . . . . . . . 27
wallpaper . . . . . . . . . . . 27
themes . . . . . . . . . . . . 28
screen appearance . . . 28
answer options . . . . . . 29
hide or show location
information . . . . . . . . . 29
AGPS limitations
& tips . . . . . . . . . . . . . . 30

contents
5
calls . . . . . . . . . . . . . . . . 31
turn off a call alert. . . . 31
recent calls . . . . . . . . . 31
redial. . . . . . . . . . . . . . 32
return a call. . . . . . . . . 32
caller ID . . . . . . . . . . . 32
emergency calls . . . . . 33
AGPS during an
emergency call . . . . . . 33
speed dial . . . . . . . . . . 34
voicemail . . . . . . . . . . 35
other features . . . . . . . . 36
advanced calling . . . . . 36
contacts . . . . . . . . . . . 38
messages. . . . . . . . . . 40
personalize . . . . . . . . . 42
call times . . . . . . . . . . 44
handsfree . . . . . . . . . . 45
data & fax calls . . . . . . 46
network . . . . . . . . . . . 46
personal organizer . . . 47
security. . . . . . . . . . . . 49
fun & games. . . . . . . . 49
service & repairs. . . . . . 50
Specific Absorption
Rate Data. . . . . . . . . . . . 51
Safety and General
Information . . . . . . . . . . 54
Motorola Limited
Warranty for the United
States and Canada . . . . 59
Hearing Aid
Compatibility with
Mobile Phones . . . . . . . 63
Information from the
World Health
Organization . . . . . . . . . 64
Smart Practices
While Driving . . . . . . . . 66
index . . . . . . . . . . . . . . . 68

6
menu map
menu map
main menu
w Settings
• (see next page)
h Gallery
•Pictures
• Sounds
t Alert Styles
•Style
•Style Detail
J Brew
Ü Voice Memo
n Contacts
8 Calendar
e Messaging
•Voicemail
• New TXT Msg
• Inbox
•Drafts
•Saved
•QuickNotes
• Sent
• Settings
k More
• Recent Calls
• Tools
This is the standard main menu layout. Your
phone’s menu may be a little different.

menu map
7
settings menu
Personalize
• Main Menu
•ScrollKeys
• Color Style
• Greeting
• Banner
• Flip Tone
• Wallpaper
• Themes
• Speed Dial
Initial Setup
• Speakerphone
• Time and Date
• Auto PIN Dial
• Auto Redial
• Backlight
• Animation
• Language
• SubLCD
• Brightness
• Contrast
• TTY Setup
•DTMF
• Master Reset
• Master Clear
Connection
• Incoming Call
In-Call Setup
• In-Call Timer
• Answer Options
Phone Info
• My Number
•NAMSetting
• Battery Meter
• Other Information
Security
• Phone Lock
• Lock Side Keys
• Lock Application
• Restrict Calls
• New Passwords
• Data Connection
Location
• Location On
• *911 Only
Network
• Current Network
• Analog Only
• Set Mode
• Service Tone
• Call Drop Tone
More
• Car Settings
• Headset

8
Use and Care
Use and Care
Use and Care
To care for your Motorola phone, please keep it away from:
liquids of any kind dust and dirt
Don’t expose your phone to water, rain,
extreme humidity, sweat, or other moisture. Don’t expose your phone to dust, dirt, sand, food, or other inappropriate materials.
extreme heat or cold cleaning solutions
Avoid temperatures below -10°C/14°F or
above 45°C/113°F. To clean your phone, use only a dry soft cloth. Don’t use alcohol or other cleaning solutions.
microwaves the ground
Don’t try to dry your phone in a microwave
oven. Don’t drop your phone.

9
essentials
essentials
about this guide
This guide shows how to locate a menu
feature as follows:
Find it: Press s > hGallery > Pictures
This means that, from the home screen:
1 Press the center key s to open the
menu.
2 Press the navigation key S to scroll to
hGallery , and press the center key s to
select it.
3 Press the navigation key S to scroll to
Pictures , and press the center key s to
select it.
CAUTION: Before using the
phone for the first time, read the
Important Safety and Legal
Information
included in the gray-
edged pages at the back of this
guide.
symbols
This means a feature is
network/subscription dependent
and may not be available in all areas.
Contact your service provider for
more information.

10
essentials
battery
battery installation
battery charging
New batteries
are not fully
charged. Plug
the battery
charger into your
phone and an
electrical outlet. Your phone might take
several seconds to start charging the battery.
Your display shows
Charge Complete when
finished.
Tip: Relax, you can’t overcharge your battery.
It will perform best after you fully charge and
discharge it a few times.
battery tips
Battery life depends on the network, signal
strength, temperature, features, and
accessories you use.
This means a feature requires an
optional accessory.
12
3
symbols

11
essentials
• Always use Motorola
Original batteries and
chargers. The warranty does
not cover damage caused by
non-Motorola batteries and/or chargers.
• New batteries or batteries stored for a
long time may take more time to
charge.
• When charging your battery, keep it
near room temperature.
When storing your battery, keep it
uncharged in a cool, dark, dry place.
• Never expose batteries to
temperatures below -10°C (14°F) or
above 45°C (113°F). Always take your
phone with you when you leave your
vehicle.
• It is normal for batteries to gradually
wear down and require longer charging
times. If you notice a change in your
battery life, it is probably time to
purchase a new battery.
Contact your local recycling center for
proper battery disposal.
Warning: Never dispose of batteries in a fire
because they may explode.
Before using your phone, read the battery
safety information in the “Safety and General
Information” section included in this guide.
turn it on & off
To turn on your phone,
press and hold
O for a
few seconds or until the
display turns on. If
prompted, enter your four-digit unlock code.
To turn off your phone, press and hold
O for
two seconds.
032375o

12
essentials
make a call
Enter a phone number and press N to make
a call.
To “hang up,” close the flip or press
O .
answer a call
When your phone rings and/or vibrates, just
open the flip or press
N to answer.
To “hang up,” close the flip or press
O .
store a phone number
You can store a phone number in Contacts :
1 Enter a phone number in the home
screen.
2 Press the Store key.
Select
Create New Contact , if necessary.
3 Enter a name and other details for the
phone number. To select a highlighted
item, press the center key
s .
4 Press the Done key to store the number.
To edit or delete a
Contacts entry, see page 40.
To store an email address, press
s > nContacts > [Create New Contact]
>
Email Address . Enter the new contact’s name
and email address information.
call a stored phone
number
Find it: Press s > nContacts
1 Scroll to the Contacts entry.
Shortcut: In Contacts , press keypad keys to
enter the first letters of an entry you want.
You can also press
* and # to see the

13
essentials
entries you use frequently, or entries in
other categories.
2 Press N to call the entry.
your phone number
Press s > wSettings > Phone Info > My Number .
Tip: Want to see your phone number while
you’re on a call? Press
Options > My Number .

14
main attractions
main attractions
You can do much more with your phone than
make and receive calls!
send message
Find it: Press s > e > Messaging
>
New TXT Message
1 Scroll to the name of a Contacts entry and
press the
s key.
or
Scroll to [New Phone Number] or [New Email
Address]
and press the s key to enter a
new phone number or email address.
2 Press the NEXT key to go to the Create
screen.
3 Enter the text of the message.
Press the
OPTIONS key to display a list of
message options (see the table following
these steps).
4 When you finish entering the message,
press the
s key.
Your phone displays the
Send screen, with
the
Call entry area highlighted.
5 To change the callback number, type a
new number, then press
OK when
finished.
6 Scroll to the Priority entry area, then scroll
left or right to select
Normal or Urgent .
7 Scroll to the Receipt entry area, then scroll
left or right to select
Yes or No .

15
main attractions
8 Press the SEND key to send the message.
or
Select OPTIONS to see details about the
message, schedule the message to be
sent later, or save the message to the
Drafts folder.
Press the
OPTIONS key from the Create screen to
display the following selections:
options
Insert Enter Quick Notes, Pictures, or
Sounds.
Previous
Go to the contact selection
screen.
Entry Mode Set the current entry mode
(see page 22).
Entry Setup Specify the default primary
and secondary entry modes
see page 22).
Cut Cut message text:
Select
Cut , scroll to highlight
the message text you wish
to cut, then press the
s key.
Copy Copy message text:
Select
Copy , scroll to
highlight the message text
you wish to copy, then press
the
s key.
Paste Paste cut or copied text into
the message, at the cursor
location.
Format Text Format message text
that you enter:
Underline ,
Bold , Italic , Color , Align .
options

16
main attractions
cable connections
Your phone
has a
mini-USB port so
you can connect it
to a computer.
If you use a USB
cable connection:
• Make sure to connect the phone to a
high-power USB port on your computer
(not a low-power one such as the USB
port on your keyboard or bus-powered
USB hub). Typically, USB high-power
ports are located directly on your
computer.
Note: If you connect your phone to a
low-power USB port, the computer
may not recognize your phone.
• Make sure both your phone and the
computer are turned on.
TTY operation
You can use an optional TTY device with your
phone to send and receive calls. You must
plug the TTY device into the phone’s headset
connector and set the phone to operate in
one of three TTY modes.
Note: Use a TSB-121 compliant cable
(provided by the TTY manufacturer) to
connect the TTY device to your phone.
Note: Set the phone to level 4 (middle setting)
for proper operation. If you experience a high
number of incorrect characters, adjust the
volume as needed to minimize the error rate.
Note: For optimal performance, your phone
should be at least 12 inches (30 centimeters)
from the TTY device. Placing the phone too

17
main attractions
close to the TTY device may cause high error
rates.
set TTY mode
ù When you set your phone to a TTY mode,
it operates in that mode whenever the TTY
device is connected:
Press
s > w > Settings > Initial Setup > TTY Setup .
TTY Setup can include these options:
When your phone is in a TTY mode, your
phone displays the international TTY mode,
the international TTY symbol, and the mode
setting during an active TTY call.
return to voice mode
To return to standard voice mode, select Voice
from the
TTY Setup menu.
option
Voice Return to standard voice mode.
TTY Transmit and receive TTY
characters.
VCO Receive TTY characters but
transmit by speaking into
microphone.
HCO Transmit TTY characters but
receive by listening to earpiece.

18
basics
basics
See page 3 for a basic phone diagram.
display
The home screen shows when you turn on
the phone. To dial a number from the home
screen, press number keys and
N .
Note: Your home screen may look different
from the one below.
Soft key labels show the current soft key
functions. For soft key locations, see page 3.
h
&O u { É
8
J
Time &
Date
Right Soft
Key Label
Left Soft
Key Label
1:51pm 05/24/06
RECENTCONTACT
