Motorola ROKR 600 User manual

ROKR 600
Wireless Portable Speaker
For: ROKR 600
User Guide

Safety instructions
DANGER
To avoid hearing damage, limit the time you use speaker at
high volume and set the volume to a safe level. The louder
the volume, the shorter the safe listening time is.
WARNING
This speaker is compliant with all relevant standards regarding
electromagnetic fields and are, when handled as described in the User Guide,
safe to use. Therefore, always read the instructions in this User Guide carefully
before using the device.
• Listen at reasonable volumes for reasonable periods of time.
• Be careful not to adjust the volume continuously upwards as your hearing
adapts.
• Do not turn up the volume so high that you can't hear what is around you.
• You should use caution or temporarily discontinue use in potentially
hazardous situations.
•Excessive sound pressure from the speaker can cause hearing loss.
• For your safety, avoid distractions from music or phone calls while in trac
or other potentially dangerous environments.
• Replacement with incorrect type batteries may cause an explosion. Make
sure to use original batteries.
• Do not replace a battery with an incorrect type that can defeat a safeguard
(for example, in the case of some lithium battery types).
• Disposal of a battery into fire or a hot oven, or mechanically crushing or
cutting of a battery can result in an explosion.
• Leaving a battery in an extremely high temperature surrounding
environment can result in an explosion or the leakage of flammable liquid
or gas.
• The battery subjected to extremely low air pressure may result in an
explosion or the leakage of flammable liquid or gas. Do not shock the
battery at a high altitude.

CAUTION
•Do not expose the speaker to excessive heat.
•Do not drop your speaker.
•The speaker shall not be exposed to dripping, splashing water.
•Do not allow your speaker to be submerged in water.
• Do not use any cleaning agents containing, alcohol, ammonia, benzene, or
abrasives.
• If cleaning is required use a soft cloth, if necessary dampened with a
minimum amount of water or diluted with a minimum amount of water or
diluted mild soap, to clean the earbuds.
• The integrated battery shall not be exposed to excessive heat such as
sunshine, fire or the like.
• Danger of explosion if battery is incorrectly replaced. Replace only with the
same or equivalent type.
• Disposal of a battery into fire or a hot oven, or mechanically crushing or
cutting of a battery, can result in an explosion.
• Leaving a battery in an extremely high temperature surrounding
environment can result in an explosion or the leakage of ammable liquid or
gas.
• A battery subjected to extremely low air pressure that may result in an
explosion or the leakage of ammable liquid or gas.
• Replacement of a battery with an incorrect type that can defeat a
safeguard (for example, in the case of some lithium battery types).
Operating temperature and humidity
•Store in a place where temperature is between -20°C (-4°F) to 70°C
(158°F) (up to 90% relative humidity with no condensation).
• Operate in a place where temperature is between 0°C (32°F) to 45°C
(113°F) (up to 90% relative humidity with no condensation).
• Battery life may be shorter in high or low temperature conditions.

Welcome...
to your new ROKR 600 wireless portable speaker!.
• Up to 6hours total playtime.
•Button control for powering on/off and music play/pause.
•Sweat resistant (IP67).
•Bluetooth 5.3
• Simpler Bluetooth pairing with the Motorola smart phone or an Andriod
phone.
Need help?
If you have any problems setting up or using your ROKR 600, please
visit us at motorolasound.com/support
Alternatively, you may find the answer in the ‘Help’ section at the back of
this guide.
•Speaker driver (Tweeter and Woofer)

This User Guide provides you with all the
information you need to get the most from your
wireless portable speaker.
Before you listen to music you will need to set up
your wireless portable speaker. Follow the
simple instructions in ‘Getting started’, on the
next few pages.
Got everything?
•Wireless portable speaker
• USB-C charging cable (300 mm in length)
• Quick start guide
• Warranty

6
1. Getting started ................................................................... 7
2. Getting to know your wireless portable speaker...9
3. Using the wireless portable speaker ........................ 10
3.1 Operation ........................................................................................................... 10
3.2 LED status indication .................................................................................... 10
4. Help........................................................................................11
5. Technical Specifications................................................ 12
6. General information.........................................................13

7
1. Getting started
Location
Important
The speaker is resistant to dripping and splashing water, but the USB-C
charging cable is not waterproof. Make sure you wipe off any moisture on
the cable thoroughly before plugging for charging.
Range of earbuds and the Bluetooth device
Make sure the speaker and Bluetooth device are placed within range of
each other.
Charging the battery
Important
Warning! Use only the approved rechargeable Lithium polymer
battery supplied with your ROKR 600.
Charging case
Connect one side of the supplied USB-C charging cable to the Type-C
charging port, and the other side to the USB AC adaptor.
The LED indicator flashes orange 1 second ON/1 second OFF during charging
the battery. It turns solid orange for 10 seconds when charging is complete.
For the first time use, charge the battery for at least 4 hours continuously.
Battery performance
In ideal conditions, a fully charged battery should give up to 6hours
usage time at 75% volume setting.
The charge capacity of the rechargeable battery will reduce with time as it
wears out, giving the earbuds less usage / standby time.
Battery low warning
If the LED indicator blinks orange at 0.5 seconds ON/0.5 seconds OFF,
recharge the battery.
Getting started
Charging case
Fig.2a

8
Connecting your wireless portable speaker
Pair your speaker with the Bluetooth device for the first time
1. Press and hold for 2 seconds. The speaker enters Bluetooth pairing
2. Make sure the Bluetooth function of your device is activated. The
speaker will do pairing automatically.
Note
Make sure your device is compatible with Bluetooth and the speaker.
Your ROKR 600 are now ready for use.
ROKR 600
Getting started
mode and the LED indicator blinks blue at 0.5 seconds ON/0.5 seconds
OFF.

9
2. Getting to know your wireless portable
speaker
Overview
8
7
Getting to know your true wireless portable speaker
6
1
5
234
1.Hand belt
2.Power OnOff buttonoer reset
3.Charging/Battery status/Pairing LED indication
4.Bluetooth Pairing/Broadcasting mode/Factory Reset
5. Voulme down/Skip forward
6. Play/Pause
7. Volume up/Skip backward
8. USB-C charging port and system reset hole
9.Passive radiator

10
3. Using the wireless portable speaker
Fig.4c
Using the wireless portable speaker
3.1 Operation
3.2 LED status indication
- Press and hold 2s for Power On/Off.
- Press and hold 8s for Power Reset and remote.
- Press and hold 2s for Force Bluetooth Pairing mode.
- Press once for TWS Pairing mode.
- Press once during TWS connected to exit TWS mode.
- Press and hold 8s for Factory Reset.
Play/Pause
Press once for Volume Up
Press once for Volume Down
Slow blink
(1s on/
1s off)
Blink
(0.5s on/
0.5s off)
Fast Blink
(0.25s on/
0.25s off)
LED
Orange LED for
battery low &
Charging status
indication
Charging in
progress
Low
battery
Charging
error
Blue LED
for Pairing Mode &
TWS mode
indication
TWS pairing Bluetooth
force
pairing
Factory
reset
White LED
for Bluetooth/TWS
connection status
Bluetooth/
TWS
reconnection
Factory
reset

11
Help
4. Help
The wireless portable speaker does not turn on.
•The battery level is too low. Recharge your speaker.
The wireless portable speaker does not connect with the Bluetooth device.
• Ensure the Bluetooth function of the Bluetooth device has been turned on.
• Ensure the Bluetooth function of the previous connected device has been
turned o.
•Ensure you follow the instructions in this user manual to connect
the speaker (see page 8).
The wireless portable speaker keeps disconnecting.
•The battery level is too low. Recharge your speaker.
•Ensure the speaker and Bluetooth device are operated within range.
• Remove the speaker from the pairing list and connect them with
the Bluetooth device again.
Poor audio quality.
• Ensure the speaker and Bluetooth device are operated within
range.
•Remove the speaker from the pairing list and connect them with
the Bluetooth device again.
Music plays on my Bluetooth device not through the speaker.
• Check on your Bluetooth device if you have selected to listen to music
through the speaker.

12
5. Technical Specifications
Note
Specifications are subject to change without prior notice.
Technical Specifications
FCC ID 2ARRB-ROKR600
IC 20353-ROKR600
Frequency range 2.402 – 2.480 GHz
Transmission power 9 dBm (only for CE)
Bluetooth version 5.3 (only support BDR and EDR)
Battery Type and capacity: Lithium polymer,
2450mAh 7.2 V rechargeable battery
Battery play time 6hours (75% volume)
Battery charging time 3 to 4 hours
Speaker driver output power 30 watts
Operating range > 15 meters
Operating temperature 0°C ~ +45°C
Storage temperature -20°C ~ +70°C

13
6. General information
Cleaning and care
Important
Always switch off and disconnect the power adaptor before cleaning your
wireless portable speaker.
•Clean your speaker with a slightly damp cloth or with an anti-static
cloth. Never use cleaning agents or abrasive solvents.
•Do not clean any part of the speaker with thinners or other
solvents and chemicals - this may cause permanent damage to the
product which is not covered by the warranty.
• Keep your speaker away from hot, humid areas or strong
sunlight, and do not let it get wet.
•Every effort has been made to ensure high standards of reliability of your
speaker. However, if something does go wrong, please do not try to
repair it yourself - contact Customer Service for assistance.
Disposal of the Device (environment)
At the end of the product life cycle, you should not dispose
of this product with normal household waste. Take this
product to a collection point for the recycling of electrical and
electronic equipment. The symbol on the product, user guide
and/or box indicates this. Some of the product materials can
be re-used if you take them to a recycling point. By reusing
some parts or raw materials from used products you make an
important contribution to the protection of the environment.
Please contact your local authorities in case you need more information
on the collection points in your area. Dispose of the battery pack in an
environmentally-friendly manner according to your local regulations.
Consumer Products and Accessories Warranty
Thank you for purchasing this Motorola branded product manufactured under
license by Meizhou Guo Wei Electronics Co. LTD., AD1 section, The economy
exploitation area, Meizhou, Guangdong, P.R.China . (“MZGW”)
What Does this Warranty Cover?
Subject to the exclusions contained below, MZGW warrants that this Motorola
branded product (“Product”) or certified accessory (“Accessory”) sold for use
with this product that it manufactured to be free from defects in materials and
workmanship under normal consumer usage for the period outlined below.
This Limited Warranty is your exclusive warranty and is not transferable.
Who is covered?
This warranty extends only to the first consumer purchaser, and is not
transferable.
General Information

14
What will MZGW do?
MZGW or its authorized distributor at its option and within a commercially
reasonable time, will at no charge repair or replace any Products or
Accessories that do not conform to this limited warranty. We may use
functionally equivalent reconditioned / refurbished / pre-owned or new
Products, Accessories or parts.
What Other Limitations Are There?
ANY IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, SHALL BE LIMITED TO THE DURATION OF
THIS LIMITED WARRANTY, OTHERWISE THE REPAIR OR REPLACEMENT
PROVIDED UNDER THIS EXPRESS LIMITED WARRANTY IS THE EXCLUSIVE
REMEDY OF THE CONSUMER, AND IS PROVIDED IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OF IMPLIED. IN NO EVENT SHALL MOTOROLA
OR MZGW BE LIABLE, WHETHER IN CONTRACT OR TORT (INCLUDING
NEGLIGENCE) FOR DAMAGES IN EXCESS OF THE PURCHASE PRICE OF THE
PRODUCT OR ACCESSORY, OR FOR ANY INDIRECT, INCIDENTAL, SPECIAL
OR CONSEQUENTIAL DAMAGES OF ANY KIND, OR LOSS OF REVENUE
OR PROFITS, LOSS OF BUSINESS, LOSS OF INFORMATION OR OTHER
FINANCIAL LOSS ARISING OUT OF OR IN CONNECTION WITH THE ABILITY
OR INABILITY TO USE THE PRODUCTS OR ACCESSORIES TO THE FULL
EXTENT THESE DAMAGES MAY BE DISCLAIMED BY LAW.
Some jurisdictions do not allow the limitation or exclusion of incidental or
consequential damages, or limitation on the length of an implied warranty, so
the above limitations or exclusions may not apply to you. This warranty gives
you specific legal rights, and you may also have other rights that vary from one
jurisdiction to another.
Products Covered Length of Coverage
Consumer Products One (1) year from the date of the
products original purchase by the
first consumer purchaser of the
product.
Consumer Accessories Ninety (90) days from the date of
the accessories original purchase by
the first consumer purchaser of the
product.
Consumer Products and Accessories
that are Repaired or Replaced
The balance of the original warranty
or for ninety (90) days from the date
returned to the consumer, whichever
is longer.
Exclusions
Normal Wear and Tear. Periodic maintenance, repair and replacement of parts
due to normal wear and tear are excluded from coverage.
Batteries. Only batteries whose fully charged capacity falls below 80% of their
rated capacity and batteries that leak are covered by this limited warranty.
Abuse & Misuse. Defects or damage that result from: (a) improper operation,
General Information

15
General Information
storage, misuse or abuse, accident or neglect, such as physical damage
(cracks, scratches, etc.) to the surface of the product resulting from misuse; (b)
contact with liquid, water, rain, extreme humidity or heavy perspiration, sand,
dirt or the like, extreme heat, or food; (c) use of the Products or Accessories
for commercial purposes or subjecting the Product or Accessory to abnormal
usage or conditions; or (d) other acts which are not the fault of Motorola or
MZGW are excluded from coverage.
Use of Non-Motorola branded Products and Accessories. Defects or damage
that result from the use of Non-Motorola branded or certified Products or
Accessories or other peripheral equipment are excluded from coverage.
Unauthorized Service or Modification. Defects or damages resulting
from service, testing, adjustment, installation, maintenance, alteration, or
modification in any way by someone other than Motorola, MZGW or its
authorized service centers, are excluded from coverage.
Altered Products. Products or Accessories with (a) serial numbers or date
tags that have been removed, altered or obliterated; (b) broken seals or that
show evidence of tampering; (c) mismatched board serial numbers; or (d)
nonconforming or non-Motorola branded housings, or parts, are excluded from
coverage.
Communication Services. Defects, damages, or the failure of Products or
Accessories due to any communication service or signal you may subscribe to
or use with the Products or Accessories is excluded from coverage.
How to Obtain Warranty Service or Other Information?
To obtain service or information, please visit us at:
motorolasound.com/support
You will receive instructions on how to ship the Products or Accessories at
your expense and risk, to a MZGW Authorized Repair Center.
To obtain service, you must include: (a) the Product or Accessory; (b) the
original proof of purchase (receipt) which includes the date, place and seller
of the Product; (c) if a warranty card was included in your box, a completed
warranty card showing the serial number of the Product; (d) a written
description of the problem; and, most Importantly; (e) your address and
telephone number.
These terms and conditions constitute the complete warranty agreement
between you and MZGW regarding the Products or Accessories purchased
by you, and supersede any prior agreement or representations, including
representations made in any literature publications or promotional materials
issued by MZGW or representations made by any agent, employee or sta of
MZGW, that may have been made in connection with the said purchase.
EU Declaration of Conformity (DoC)
Hereby, MZGW declares that the radio equipment type is in compliance with
RE Directive 2014/53/EU. The full text of the EU declaration of conformity is
available on the website: motorolasound.com

16
EU exposure:
RF exposure information: The EIRP power of the device at maximal case is
below the exempt condition, 20mW specified in EN62479: 2010. RF exposure
assessment has been performed to prove that this unit will not generate the
harmful EM emission above the reference level as specified in EC Council
Recommendation(1999/519/EC).
FCC regulatory conformance:
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference
that may cause undesired operation.
NOTE:
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation.
This equipment generates uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
NOTE:
The manufacturer is not responsible for any radio or TV interference caused by
unauthorized modifications to this equipment. Such modifications could void
the user’s authority to operate the equipment.
This equipment complies with FCC radiation exposure limits set forth for
an uncontrolled environment.
General Information

17
General Information
IC regulatory conformance
This device complies with CAN ICES-003 (B)/NMB-003(B) and
CAN RSS-216 / CNR-216.
This device contains licence-exempt transmitter(s)/receiver(s) that comply
with Innovation, Science and Economic Development Canada's licence-exempt
RSS(s). Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference, including interference that may
cause undesired operation of the device.
Cet appareil est conforme à la norme CAN ICES-003 (B)/NMB-003 (B) et
CAN RSS-216 / CNR-216.
Cet appareil contient des émetteurs / récepteurs exempt (s) de licence
qui sont conformes aux RSS exemptes de licence d'Innovation, Sciences et
Développement économique Canada. Son fonctionnement est soumis aux
deux conditions suivantes:
(1) Cet appareil ne doit pas provoquer d'interférences.
(2) Cet appareil doit accepter toute interférence, y compris les interférences
susceptibles de provoquer un fonctionnement indésirable de l'appareil.
The device is compliance with RF exposure guidelines, users can obtain
Canadian information on RF exposure and compliance.
Le présent appareil est conforme Après examen de ce matériel aux
conformité ou aux limites d’intensité de champ RF, les utilisateurs peuvent
sur l’exposition aux radiofréquences et la conformité and compliance
d’acquérir les informations correspondantes.

Manufactured, distributed or sold by Meizhou
Guo Wei Electronics Co. LTD., ocial
licensee for this product. MOTOROLA and
the Stylized M Logo are trademarks or
registered trademarks of Motorola Trademark
Holdings, LLC. and are used under license. All
other trademarks are the property of their
respective owners. © 2023 Motorola Mobility
LLC. All rights reserved.
Version 2.0 (EN)
