Solid State AC Motor Control
MVC4 Quick Setup Guide
Msmart

Msmart MVC4 Quick Navigation Guide Motortronics
www.motortronics.com Page 1
Startup
Status Menu
Main Menu
Setpoint Pages
The MVC setpoint pages can be
accessed by pressing the button.
Select MVC Setpoint Page
Select Parameter
Set Parameter Value
Click MVC4 Status
Startup “Splash” Screen
Select parameter
Set value press Done to Save

Msmart MVC4 Quick Navigation Guide Motortronics
www.motortronics.com Page 2
Msmart consist of a touchscreen and four membrane buttons for navigation that can be used when the
system is installed in a harsh environment.
Touch screen
Panel buttons
Navigation buttons
(Button mode)
Msmart Touch Screen
Hardware Push Button Description
Button
Resets the device on the screen only. Also resets the Msmart display by holding
button for 6 –10 sec.
Switch between touchscreen and panel buttons (button mode). Menu icon will flash
when panel buttons are active.
Button used to move between selectable items on the touchscreen (forward Tab).
The item will flash when selected.
Select flashing item.

Msmart MVC4 Quick Navigation Guide Motortronics
www.motortronics.com Page 3
MVC4 Start-up Parameters
Verify Setpoint Page 1
•Set Maximum Current
•Set Motor Full Load Amps
•Set Service Factor
•Set Overload Class
Note: Consult factory for assistance if parameters don’t match your motor.
Rev 0.02

MOTORTRONICS
TM
Solid State AC Motor Control
VMX-MS-MQSG - 04/29/19
