RT-1000 Multichannel
DF Control System
„MOXA NPort 5610“
for DF-Channel Network Connectivity

RT-1000 MC DF Control System
RHOTHETA Page 2 of 13 Configuration Manual
Edited by:
RHOTHETA Elektronik GmbH
Kemmelpark
Dr.-Ingeborg-Haeckel-Str. 2
82418 Murnau
Germany
Tel.: [phone] - 0
Fax: [phone] - 15
Internet: www.rhotheta.de
E-Mail: [email protected]
Copyright © RHOTHETA Elektronik GmbH
All rights reserved
-Issue: 2016/09/09 [Rev 1.00.a]
-Document-ID: 12-9-1-0015-10-11-3-60
Note
The manufacturer reserve the right to make modifications at any time and without previous
information of the here described product.

RT-1000 MC DF Control System
RHOTHETA Page 3 of 13 Configuration Manual
Content
1 Description.......................................................................................................................4
2 Initial IP Address Configuration.....................................................................................5
3 Web Console Configuration............................................................................................6
3.1 Opening Your Browser ...........................................................................................................................6
3.2 Network Settings.....................................................................................................................................7
3.3 Serial Settings.........................................................................................................................................8
3.4 Operating Settings and TCP Port No. ....................................................................................................9
3.5 Additional Information for Service & Maintenance / Troubleshooting ..................................................11
3.5.1 Monitor Line Function ..............................................................................................................11
3.5.2 Monitor Async Function...........................................................................................................12
4 Note.................................................................................................................................13

RT-1000 MC DF Control System
RHOTHETA Page 4 of 13 Configuration Manual
1 Description
The DF-Control System converts the serial data from the DF-Channels into Ethernet data for
the transmission via LAN. For the RT-1000 Multichannel direction finder system a special
configured MOXA NPort 8/16 channel device is in use, to make it possible, to access the
Direction Finder Channels anywhere over a local LAN or the Internet.
The remote control TCPIP access to one Direction Finder Channel is always defined by the
DF Control System / MOXA NPort IP address and the
Local MOXA NPort TCP port
(see chapter: 3.4 Operating Settings and TCP Port No. and the example below)
Example of one DF-Channel Setup with
RHOTHETA DF Remote Control Software “DF Commander”
Example of TCPIP connection
with DF-Channel No. 3
of MOXA device 192.168.77.222
see chapter: 3.4
Operating Settings and TCP Port No.
Please contact your network administrator if necessary.
For additional information, see also www.moxa.com and the MOXA user manual.

RT-1000 MC DF Control System
RHOTHETA Page 5 of 13 Configuration Manual
2 Initial IP Address Configuration
To access the Direction Finder Control System (MOXA NPort) from remote, it is common to
use static IP & Port addresses. For this the MOXA device itself can be configured to a static
IP address or, which is normally the better solution, to configure the router in the local network
with a DHCP reservation to allocate the Direction Finder Control System identified by its MAC
address to a fixed/static IP address.
After delivery, the IP configuration of the MOXA NPort device is set to “DHCP” mode or to the
fixed IP address given in the “IP-Address Configuration” document. If the RT-1000
Multichannel System is connected to your LAN, the actual assigned (DHCP) IP address is
shown after a few seconds at the Front Panel of the MOXA device (small LCM display < >)
and also indicated by the green LED < >.
If there is no DHCP server available or already no LAN connected, the red LED < > is
blinking, and the IP address is set to the standard default value: 192.168.127.254.
LCM Display
Push buttons for manual settings
Menu , ▲, ▼and SEL
Status LED
If no DHCP server is available, or it is intended to use static IP address, it is recommended
using the LCM display < >and the four push buttons < > on the MOXA front panel to
configure the IP address for the first time.
Manual Configuration of static known IP address
Press Menu and ▼… Display shows “Network setting”
Press SEL and ▼+ ▼… Display shows “IP config”
Press SEL and ▲… Display changes from “DHCP” to “Static”
Press SEL … to confirm change
Press ▼Display shows “IP address”
Press SEL … to edit actual static IP address …
Press ▼or ▲to change the blinking digit and SEL to continue with next digit
Press Menu + Menu … Display shows “Save Change?”
Press ▲… Display shows “Yes”
Press SEL to store the settings
The device restarts and the new setting (static IP address) is indicated.
Remark: At the “Network setting” Menu it is also possible to show the actual device MAC
address.

RT-1000 MC DF Control System
RHOTHETA Page 6 of 13 Configuration Manual
3 Web Console Configuration
A standard Web Browser/Console is the most user-friendly method available to configure and
check the actual MOXA NPort device settings and test the RT-1000 network connectivity. You
can use as example Google Chrome or the Microsoft Internet Explorer.
With the exception of custom specific IP address, the MOXA NPort 5600 device
is already correctly pre-configured by RHOTHETA for the use with
the RT-1000 Multichannel direction finder.
… It is strictly not recommended, to change any settings. …,
The following description is just for information and checking the actual settings.
3.1 Opening Your Browser
Open your browser with the cookie function enabled.
Type in the MOXA NPort IP address
The device MAC address is indicated

RT-1000 MC DF Control System
RHOTHETA Page 7 of 13 Configuration Manual
3.2 Network Settings
=
With DHCP configuration, the actual assigned IP address is shown at < >
=
With static configuration, it is possible to change the static IP address at < >
Remark:
Each change of actual settings has to be confirmed with < >

RT-1000 MC DF Control System
RHOTHETA Page 8 of 13 Configuration Manual
3.3 Serial Settings

•Baud rate = 1200
•Data bits = 7
•Stop bits = 1
•Parity = Odd
•Flow control = None
•FIFO = Disable
The settings above are valid and mandatory for all connected DF-Channels.
Remark:
Serial Port 1 is internally connected to DF-Channel No. 1,
Serial Port 2 to DF-Channel No. 2, …

RT-1000 MC DF Control System
RHOTHETA Page 9 of 13 Configuration Manual
3.4 Operating Settings and TCP Port No.

•Operation Mode = TCP Server Mode
•TCP alive check time = 1 (min)
If the connected PC software application crashes or the LAN connection is
interrupted, then the TCP is closed after 1 min automatically and so on no more
“blocking” any new connection.
•Inactivity time = 0 (ms) = Off
Every DF-Channel (with power on) is producing continuously serial data. If there
is no more serial data available, the TCP connection should be hold to show the
correct error status (Interface/TCPIP status=Ok, DF timeout status=Error)
•Max connection = 4
Each DF-Channel can be accessed in parallel by max 4 active remote control
sites.
•Ignore jammed IP = Yes
If one DF-Channel active TCP connection is interrupted, there is no influence to
other still active and connected remote sites working on the same channel.
•Allow driver control = No

RT-1000 MC DF Control System
RHOTHETA Page 10 of 13 Configuration Manual

•Packing length = 0
•Delimiter 1 = “a” and 
each DF-Channel data message ends with …[LF] = 0x0a
•Delimiter 2 = Off
•Delimiter process = Do Nothing
•Force transmit = 0
With the settings above, each RT-1000 DF-Channel serial output data message
is packed within one TCPIP data package.
(Very useful, as example for logging tools like Wireshark)

•Local TCP port = 4001 … 40xx
each DF-Channel is accessed by the MOXA NPort device IP address and
the corresponding port no.
The DF-Channel 1 is accessed by default with port no. 4001,
DF-Channel 2 with port no. 4002, DF-Channel 3 with port no. 4003, …
Example:
Access to DF-Channel:
DF-Channel
No. 1
= 192.168.77.222::4001
DF-Channel
No. 2
= 192.168.77.222::4002
DF-Channel
No. 2
= 192.168.77.222::4002
. . .

RT-1000 MC DF Control System
RHOTHETA Page 11 of 13 Configuration Manual
3.5 Additional Information for Service & Maintenance / Troubleshooting
3.5.1 Monitor Line Function
The Monitor Line page shows all actually connected remote control sites for each channel.
Please remember, that different sites can be connected to different DF-Channels.
In the example below, one remote control site PC is connected to all 4 existing DF-Channels
simultaneously and one other PC is connected to only one DF-Channel.
RT-1000 Multichannel with IP adr. 192.168.77.222
Port No. 1...4 = Port 4001…4004
▲▲▲▲
RT-1000 Multichannel with IP adr. 192.168.77.222
Port No. 2 = Port 4002
▲
Two remote control sites using RHOTHETA PC application software “DF Commander”

RT-1000 MC DF Control System
RHOTHETA Page 12 of 13 Configuration Manual
3.5.2 Monitor Async Function
When a DF-Channel is connected to a remote control site (active TCPIP connection), then the
incoming DF-Channel data are shown.

RxCnt counts only incoming DF channel data, if the connected TCPIP port is active,
which means if a remote control site is connected to this port / DF-Channel.

The counted serial bytes since last MOXA NPort Power On.

RT-1000 MC DF Control System
RHOTHETA Page 13 of 13 Configuration Manual
4 Note
