Moxa Technologies PowerTrans PT-7728 Manual

2014 Moxa Inc. All rights reserved.
Reproduction without permission is prohibited.
P/N: 1802077280015
PT-7728/7828
Hardware Installation Guide
Moxa PowerTrans Switch
Seventh Edition, January 2014
www.ipc2u.ru
www.moxa.pro

- 2 -
Package Checklist
The Moxa PowerTrans switch is shipped with the following items. If any of
these items are missing or damaged, please contact your customer
service representative for assistance.
•1 Moxa PowerTrans Switch
•Hardware Installation Guide
•CD-ROM with User’s Manual and SNMP MIB file
•Moxa Product Warranty Statement
•RJ45 to DB9 console port cable
•Protective caps for unused ports
•2 rack-mount ears
Panel Layout
1. System status LEDs
2. Interface Module mode LEDs
3. Interface Module port LEDs
4. Push-button switch to select mode for Interface Module
5. Model Name
6. Fast Ethernet Interface Modules
7. Gigabit Ethernet Interface Modules
8. Serial Console port
9. 10-pin terminal block for power inputs, and relay output
10. Rack Mounting Kit
www.ipc2u.ru
www.moxa.pro

- 3 -
Dimensions (unit = mm)
Fast Ethernet Interface Modules (slots 1, 2, and 3)
www.ipc2u.ru
www.moxa.pro

- 4 -
Gigabit Ethernet Interface Modules (for slot 4)
Rack Mounting
Use four screws to attach the PT switch to a standard rack.
NOTE
Two additional rack-mount ears can be ordered as an option. Use
them to secure the rear of the chassis in
high-vibration
environments.
Wiring Requirements
WARNING
Safety First!
Be sure to disconnect the power cord before installing and/or
wiring your Moxa PowerTrans Switch.
Calculate the maximum possible current in each power wire and
common wire. Observe all electrical codes dictating the
maximum current allowable for each wire size.
If the current goes above the maximum ratings, the wiring could
overheat, causing serious damage to your equipment.
Grounding Moxa PowerTrans Switch
Grounding and wire routing help limit the effects of noise due to
electromagnetic interference (EMI). Run the ground connection from the
ground screw to the grounding surface prior to connecting devices.
Wiring the Power Inputs
The PT series of switches supports dual redundant power supplies:
“Power Supply 1 (PWR1)” and “Power Supply 2 (PWR2)”. The connections
for PWR1, PWR2 and the RELAY are located on the terminal block. The
front view of the terminal block connectors are shown below.
www.ipc2u.ru
www.moxa.pro

- 5 -
Wiring the Relay Contact
Each PT switch has one relay output. Refer to the next section for detailed
instructions on how to connect the wires to the terminal block connector,
and how to attach the terminal block connector to the terminal block
receptor.
FAULT: The relay contact of the 10-pin terminal block connector are used
to detect user-configured events. The two wires attached to the RELAY
contacts form an open circuit when a user-configured event is triggered.
If a user-configured event does not occur, the RELAY circuit will be closed.
Wiring the Redundant Power Inputs
Each PT switch has two sets of power inputs: power input 1 and power
input 2.
STEP 1: Insert the dual set positive/negative DC wires into PWR1 and
PWR2 terminals (+ →pins 1, 9; - →pins 2, 10). Or insert the L/N AC
wires into PWR1 and PWR2 terminals (L →pin 1, 9; N →pin 2,10)
STEP 2: To keep the DC or AC wires from pulling loose, use a screwdriver
to tighten the wire-clamp screws on the front of the terminal block
connector.
Note 1: The PT switch with dual power supplies uses PWR2 as the first
priority power input by default.
Note 2: For dielectric strength (HIPOT) test, users must remove the
metal jumper located on terminals 3, 4, and 7, 8 of the terminal block to
avoid damage.
www.ipc2u.ru
www.moxa.pro

- 6 -
LED Indicators
System LEDs
LED
Color
State
Description
STAT
GREEN
On System has passed self-diagnosis
test on boot-up and is ready to run.
Blinking
System is undergoing the
self-diagnosis test.
RED On
System failed self-diagnosis on
boot-up.
PWR1 AMBER
On
Power is being supplied to the main
module’s power input PWR1.
Off
Power is not being supplied to the
main module’s power input PWR1.
PWR2 AMBER
On
Power is being supplied to the main
module’s power input PWR2.
Off
Power is not being supplied to the
main module’s power input PWR2.
FAULT RED
On
The corresponding PORT alarm is
enabled and a user-configured
event has been triggered.
Off
The corresponding PORT alarm is
enabled and a user-configured
event has not been triggered, or
the corresponding PORT alarm is
disabled.
MSTR/HEAD
GREEN
On
This PT switch is set as the Master
of the Turbo Ring, or as the Head of
the Turbo Chain.
Blinking
The PT switch has become the Ring
Master of the Turbo Ring, or the
Head of the Turbo Chain, after the
Turbo Ring or the Turbo Chain went
down.
Off
The PT switch is not the Master of
this Turbo Ring or is set as a
Member of the Turbo Chain.
CPLR/TAIL GREEN
On
The PT switch coupling function is
enabled to form a back-
up path, or
it is set as the Tail of the Turbo
Chain.
Blinking
Turbo Chain is down.
Off
This PT switch disabled the
coupling function, or is set as a
Member of the Turbo Chain.
www.ipc2u.ru
www.moxa.pro

- 7 -
Mode LEDs
LED
Color
State
Description
LNK/ACT GREEN
On
The corresponding module port’s
link is active.
Blinking
The corresponding module port’s
data is being transmitted.
Off
The corresponding module port’s
link is inactive.
SPEED GREEN
Off
The corresponding module port’s
data is being transmitted at 10
Mbps.
On
The corresponding module port’s
data is being transmitted at 100
Mbps.
Blinking
The corresponding module port’s
data is being transmitted at
1000 Mbps.
FDX/HDX GREEN
On
The corresponding module port’s
data is being transmitted in full
duplex mode.
Off
The corresponding module port’s
data is being transmitted in half
duplex mode.
RING/CHAIN
PORT GREEN
On
The corresponding module’s port
is the ring or chain port of this PT
switch.
Off
The corresponding module’s port
is not the ring or chain
port of this
PT switch.
COUPLER
PORT GREEN
On
The corresponding module’s port
is the coupler port of this PT
switch.
Off
The corresponding module’s port
is not the coupler port of this PT
switch.
Specifications
Technology
Standards
IEEE 802.3, 802.3u, 802.3ab, 802.3z, 802.3x,
802.1D, 802.1w, 802.1Q, 802.1p, 802.1X, 802.3ad
Flow control
IEEE 802.3x flow control, back pressure flow control
Interface
Fast Ethernet
10/100BaseT(X) or 100BaseFX (SC/ST connector or
SFP slot)
Gigabit Ethernet
10/100/1000BaseT(X), 1000BaseSX/LX/LHX/ZX
(SFP slot, LC connector)
System LED
Indicators
STAT, PWR1, PWR2, FAULT, MSTR/HEAD, CPLR/TAIL
Module LED
Indicators
LNK/ACT, FDX/HDX, SPEED, RING /CHAIN PORT,
COUPLER PORT
Alarm Contact
One relay output with current carrying capacity of 3A
@ 30 VDC or 3A @ 240 VAC
www.ipc2u.ru
www.moxa.pro

- 8 -
Optical Fiber (100BaseFX)
Distance
Multi-mode
0 to 5 km, 1300 nm (50/125μm, 800 MHz*km)
0 to 4 km, 1300 nm (62.5/125μm, 500 MHz*km)
Single-mode
0 to 40 km, 1310 nm (9/125μm, 3.5 PS/(nm*km))
0 to 80 km, 1550 nm (9/125um, 19 PS/(nm*km))
Min. TX Output
Multi-mode: -20 dBm; Single-mode: -5 dbm
Single-mode 80 km: -5 dBm
Max. TX Output Multi-mode: -10 dBm; Single-mode: 0 dbm
Single-mode 80 km: 0 dBm
RX Sensitivity
Multi-mode: -32 dBm; Single-mode: -34 dbm
Single-mode 80 km: -34 dBm
Power
Input Voltage
24 VDC (18 to 36V)or 48 VDC (36 to 72V)or 110/220
VDC/VAC
(88 to 300 VDC and 85 to 264 VAC)
Input Current Max. 2.58A @ 24VDC
Max. 1.21A @ 48VDC
Max. 0.64/0.33A @ 110/220VDC
Max. 0.53/0.28A @ 110/220VAC
Physical Characteristics
Housing
IP 30 protection, metal case
Dimensions
(W x H x D)
440 x 44 x 325 mm (17.32 x 1.73 x 12.76 in.)
Weight
5900 g
Installation
19” rack mounting
Regulatory Approvals
Safety
UL60950-1, CSA C22.2 No. 60950-1, EN60950-1
Power Automaton
IEC61850-3, IEEE 1613
Road Traffic
NEMA TS2
Rail Traffic
EN50121-4, EN50155
EMI
FCC Part 15, CISPR (EN55022) class A
Environmental Limits
Operating Temp.
-40 to 85°C (-40 to 185°F)
Cold start of min. 100 VAC at -40°C
Storage Temp.
-40 to 85°C (-40 to 185°F)
Ambient Relative
Humidity.
5 to 95% (non-condensing)
WARRANTY
5 years
