1 Introduction
Welcome to the MOXA CP-134U Series of industrial 4-port RS-422/485 serial boards for
the PCI bus.
The following topics are covered in this chapter:
❑ Overview
❑ Features
❑ Package Checklist

Industio CP-134U Series User’s Manual
1-2
Overview
Industio—The Industrial Multiport Async Solution
Moxa Industio
IndustioIndustio
Industio products are smart, multiport serial I/O solutions for industrial applications.
The Industio
IndustioIndustio
Industio CP-134U Series boards, including CP134-UI and CP-134UL, are designed
for a 32-bit PCI bus with the Plug and Play and Universal PCI feature. The ports for these
boards can be configured independently, with ports 1 and 2 set to the RS-232, RS-422, or
RS-485 interface, and ports 3 and 4 set to the RS-422 or RS-485 interface. Industio
products provide a reliable communication link over a longer distance (up to 4000 ft for
ports set to the RS-422/485 interface), and are suitable for industrial environments.
Connections with point-to-point full-duplex (RS-422 or 4-wire RS-485)or multidrop
half-duplex (2-wire RS-485) are available to meet user’s various needs. And each RS-485
port can control up to 32 devices in a multidrop environment.
ADDC™ (Automatic Data Direction Control) for RS-485
To make it easier to manage 2-wire RS-485 half-duplex connections, ADDC™ (Automatic
Data Direction Control) intelligence is built into each CP-134U series board, eliminating
the need for software interference. This means that Windows applications can manage
RS-485 ports without needing to write extra code for controlling the half-duplex protocol.
With their well-designed and fine-tuned device driver, Industio CP-134U boards make full
use of the 64 byte Tx/Rx FIFO and on-chip H/W flow control, so that they can transfer data
without loss even at speeds as high as 230.4 Kbps, providing a reliable, high performance
solution for serial multiport communications.
Termination Resistors Ready for RS-422/485
Termination Resistors are already installed on the Industio CP-134U series boards,
eliminating the headaches involved in determining the proper impedance for the resistors.
For more details, refer to the “Connection Cable and Cable Wiring” chapter.
Surge/Isolation Protection
To prevent boards from being damaged by lightning or high potential voltage, TVSS
(Transient Voltage Surge Suppressor) technology is included in some models to protect the
board. An optical isolation option (2000V), and embedded surge protection (max. ESD of
16 KV, max. EFT of 2 KV) are also available in this series. Both of these features provide
protection when the boards are used in critical or harsh factory-type environments.
PCI Solution
The board complies with PCI Spec. 2.1 and does not require either switches or jumpers.
The hardware configuration for the IRQ and I/O address is automatically assigned by the

Introduction
Industio CP-134U Series User’s Manual
1-3
PCI BIOS. This means that the board MUST be plugged into the computer first before
installing the driver software. For more PCI information, refer to the Technical Reference
Appendix.
Universal PCI
The 32/64-bit PCI local bus specification specifies both 3.3V and 5V connector types for
the PCI hardware. Moxa’s universal PCI card allows the user to plug into both a 3.3V and
32/64-bit slot.
Operating System Support
The Industio CP-134U series is compatible with most major industrial platforms, including
Windows NT/2000/XP, Windows 95/98, and Linux. MOXA device drivers are provided
for smoother installation, configuration, and performance. In this manual, sections for
MOXA Windows NT, Windows 2000/XP, Windows 95/98, and Linux are included.
MOXA Serial Comm Tools
For application development, MOXA provides an easy-to-use serial communication library
called PComm
PCommPComm
PComm that runs under Windows NT/2000/XP and Windows 95/98. You can use this
library to develop your own applications using Visual Basic, Visual C++, Borland Delphi,
etc. Utilities, such as Data Scope, Monitor, Terminal Emulator, Diagnostics, etc., are
included for debugging or monitoring the communication status, terminal emulation, or
even file transfer.
Board Applications
The board is suitable for many industrial applications, including:
 Multipoint data acquisition
 Factory automation
 Critical industrial control
 Remote serial device control

Industio CP-134U Series User’s Manual
1-4
Features
The Industio CP-134U Series includes the following products:
CP-134U 4 RS-422/485 ports, Universal PCI interface with embedded Surge
Protection and Isolation Protection (16 KV ESD, 2 KV Isolation)
CP-134UI 4 RS-422/485 ports, Universal PCI interface with embedded Surge
Protection and Isolation Protection
Below we list the outstanding features of the Industio CP-134U Series boards:
 Supports 4 independent serial ports—2 ports for RS-232 or RS-422/485, and 2 ports
for RS-422/485
 Compact board size (half-size)
 Jumpers for selecting between RS-232 and RS-422/485
 DIP Switches for selecting between RS-422, 4-wire RS-485, and 2-wire RS-485
 DIP Switch for RS-485 data control—ADDC™ (Automatic Data Direction Control)
 Jumper for Termination Resistor selection—eliminates impedance matching headaches
 Reliability—high speed 16C550C compatible Communication Controllers with
on-chip hardware flow control to guarantee no data loss
 PComm Lite—a powerful serial Comm utility.
 Embedded Surge Protection (16 KV ESDS) for all signal lines (CP-134UI, CP-134UL)
 Supports 64 byte FiFo Driver
 Supports drivers for most major industrial platforms—Windows NT/2000/XP,
Windows 95/98, and Linux
 Supports both 3.3V and 5V connector types
Package Checklist
You should find the following items in the Industio CP-134U Series package:
 Industio CP-134U Series 4-port serial board
 MOXA software CD-ROM, which includes:
 Drivers for MOXA Multiport Async Products
 User’s Manual (PDF format)

2
22
2
2
22
2
2 Hardware Installation
You will need to install both hardware and software for Industio CP-134U Series boards.
The hardware installation procedure is given in this chapter, and the next chapter deals with
software installation for various operating systems. The following topics are covered in this
chapter:
❑ CP-134 Series Block Diagram
❑ Installing the Industio
IndustioIndustio
Industio CP-134U Series Board

Industio CP-134U Series User’s Manual
2-2
CP-134U Series Block Diagrams
Industio CP-134U Series boards’ hardware configuration for IRQ number and I/O address
is automatically assigned by the PCI BIOS. This means that the board MUST be plugged in
first before installing the driver software.
CP-134UI

Hardware Installation
Industio CP-134U Series User’s Manual
2-3
CP-134U
The Industio CP-134U Series has two 30-pin jumpers and two sets of four DIP Switches
on the board that allow the user to set the serial interface for each of the board’s four ports.
Ports 1 and 2 can be set to RS-232, RS-422, RS-485 (2-wire), or RS-485 (4-wire). Ports 3
and 4 can be set to RS-422, RS-485 (2-wire), or RS-485 (4-wire). Refer to the following
information to determine the proper settings for your board.

Industio CP-134U Series User’s Manual
2-4
Jumper Settings
The two on-board 30-pin jumpers are used to select between the RS-232 and RS-422/485
serial interfaces. If you select RS-422/485, then you will also need to set the DIP Switches
to select between RS-422, RS-485 (4-wire), and RS-485 (2-wire). Note that the two ports
can be configured independently.
Jumper pins:
Top for Port 1,
Bottom for Port 2
RS-422/485:
Cover the left two
columns of pins with the
jumper to select the
RS-422/485 option.
RS-232:
Cover the right two
columns of pins with the
jumper to select the RS-232
option.
DIP Switch Settings
Refer to the figures on the following two pages to see how to select between RS-422,
RS-485 (2-wire), and RS-485 (4-wire).

Hardware Installation
Industio CP-134U Series User’s Manual
2-5
Port 1
DIP Switch
Settings S1-1 S2-1
RS-232 — —
RS-422 — OFF
RS-485
(2-wire) ON ON
RS-485
(4-wire) OFF ON
Port 2
DIP Switch
Settings S1-2 S2-2
RS-232 — —
RS-422 — OFF
RS-485
(2-wire) ON ON
RS-485
(4-wire) OFF ON

Industio CP-134U Series User’s Manual
2-6
Port 3
DIP Switch
Settings S1-3 S2-3
RS-422 — OFF
RS-485
(2-wire) ON ON
RS-485
(4-wire) OFF ON
Port 4
DIP Switch
Settings S1-4 S2-4
RS-422 — OFF
RS-485
(2-wire) ON ON
RS-485
(4-wire) OFF ON

Hardware Installation
Industio CP-134U Series User’s Manual
2-7
Installing the Indu
InduIndu
Industio
stiostio
stio CP-134U Series Board
Step 1: Power off the PC.
Warning! To avoid damaging your system and board, make sure your computer is
turned off before installing any board.
Step 2: Remove the PC’s cover.
Step 3: Remove the slot cover bracket if there is one.
Step 4: Plug the Industio CP-134U Series control board firmly into a free 32-bit PCI slot,
or the CP-134U Series board into both a 32-bit/64-bit slot.
Step 5: Fasten the holding screw to fix the control board in place.
Step 6: Replace the system cover.
Step 7: Power on the PC. The BIOS will automatically set the IRQ and I/O address.
Note! Each board must occupy one unique IRQ and two 8-byte I/O addresses,
which are assigned automatically by the PCI BIOS. However, you can
select a free IRQ number manually via the PC’s BIOS setup for the PCI slot,
but normally this method is not available for the I/O address. The possible
IRQ numbers are 2, 3, 4, 5, 7, 10, 11, 12, and 15. The possible I/O addresses
are from 0x0000 to 0xFFFF.
Step 8: Proceed with the software installation discussed in the next chapter, “Software
Installation.”

3
33
3
3
33
3
3 Software Installation
In this chapter, the software driver installation, configuration, and driver update/removal
procedures are described for various operating systems, including Windows NT, Windows
95/98, Windows 2000/XP, and Linux. Before proceeding with the software installation,
complete the hardware installation, discussed in the previous chapter, “Hardware
Installation.”
If you need to develop your own applications, refer to the next chapter, “Serial
Programming Tools,” for programming issues.
The following topics are covered in this chapter:
❑ Windows NT
❑ Windows 95/98
❑ Windows 2000/XP
❑ Linux

Industio CP-134U Series User’s Manual
3-2
Windows NT
Windows NT supports up to 256 serial ports, from COM1 to COM256. To fully integrate
the advanced features of Windows NT, Moxa has developed multi-process and multi-thread,
pure 32-bit Windows NT device drivers for the Industio CP-134U Series multiport boards.
The driver conforms to the Win32 COMM API standard.
 To install the driver for the first time, go directly to the next section, “Installing the
Driver.”
 If the driver is already installed, and you want to re-configure the board and port(s),
add more boards, or delete boards, refer to the section “Configuring the Board and
Ports.”
 To update or remove the driver, refer to either, “Updating the Driver” or “Removing
the Driver.”

Software Installation
Industio CP-134U Series User’s Manual
3-3
Installing the Driver
The following procedure is for installing the Industio CP-134U Series driver for the first
time under Windows NT 4.0. Before taking these steps, make sure the board(s) have
already been plugged into the system’s PCI slot(s).
1. Log into NT as Administrator.
2. Open the [Control Panel], click on the [Network]icon, and select the [Adapters]tab.
3. Click on the [Add]button, then the [Have Disk...] button in the “Select Network
Adapter” dialog box.
4. Specify the exact path of the driver diskette, E:\Software\Winnt\Windows.nt for the
example shown here, and then click [OK].

Industio CP-134U Series User’s Manual
3-4
5. Select “MOXA Smartio
SmartioSmartio
Smartio/Industio
IndustioIndustio
Industio Family multiport board” from the “Select OEM
Option” dialog box, and then click [OK] to enter the “MOXA Smartio/Industio
Configuration Panel” dialog box to start the installation.
6. Click the [Add] button to open the Property dialog box to change port settings and
advanced FIFO configurations done automatically by the system.
7. In the “Property” dialog box, select the newly plugged Industio CP-134U Series
board from the Board Type pull down list. Next, click on one of the ports to highlight
it, and then click on [Port Setting] to open the port’s configuration window.
