NPort 5600-8-DT
Quick Installation Guide
Edition 4.1, November 2018
Technical Support Contact Information
www.moxa.com/support
Moxa Americas:
Toll
-free: 1-888-669-2872
Tel:
1-714-528-6777
Fax:
1-714-528-6778
Moxa China (Shanghai office):
Toll
-free: 800-820-5036
Tel:
[phone]
Fax:
[phone]
Moxa Europe:
Tel:
[phone]
Fax:
[phone]
Moxa Asia-Pacific:
Tel:
[phone]
Fax:
[phone]
Moxa India:
Tel:
[phone]
Fax:
[phone]

2018 Moxa Inc. All rights reserved.

- 2 -
Overview
The NPort 5600-8-DT Series includes the following models:
•NPort 5610-8-DT: 8 ports, RS-232, DB9
•NPort 5610-8-DT-J: 8 ports, RS-232, RJ45
•NPort 5650-8-DT: 8 ports, RS-232/422/485, DB9
•NPort 5650-8-DT-J: 8 ports, RS-232/422/485, RJ45
•NPort 5650I-8-DT: 8 ports, RS-232/422/485, DB9, optical isolation
Package Checklist
The NPort 5600-8-DT package should contain the following items:
•NPort 5600-8-DT 8-port serial device server
•Power cord and adapter
•DIN rail kit
•NPort documentation and software CD
•NPort 5600-8-DT Quick Installation Guide
Optional Accessories:
•DK-35A: DIN rail mounting kit (35 mm)
•CBL-RJ45M9-150: 8-pin RJ45 to male DB9 cable, 150 cm
•CBL-RJ45F9-150: 8-pin RJ45 to female DB9 cable, 150 cm
•CBL-RJ45M25-150: 8-pin RJ45 to male DB25 cable, 150 cm
•CBL-RJ45F25-150: 8-pin RJ45 to female DB25 cable, 150 cm
•NP21101: DB25-M to DB9-F RS-232 cable, 30 cm
NOTE
Please notify your sales representative if any of the above
items are missing or damaged.
NOTE
The operating temperature of the power adapter in the box is
from 0 to 40°C. If your application is out of this range, please
use a power adapter supplied by U
L Listed External Power
Supply (The power output meets SELV and LPS and rated 12
-
48 VDC, minimum current 0.73 A). Moxa has power adapters
with wide temperature range (
-40 to 75°C, -40 to 167°F), the
PWR-12150-(plug type)-SA-T series, for your reference.

- 3 -
Hardware Introduction
Top and Rear View
Front View (NPort 5610-8-DT, 5650-8-DT, 5650I-8-DT)
Front View (NPort 5610-8-DT-J, 5650-8-DT-J)
Reset Button
The reset button is used to load the factory defaults. Use a pointed
object to hold the reset button down for five seconds. You may release
the reset button when the Ready LED stops blinking.

- 4 -
LED Indicators
The LED indicators on the top panel are used to display status as
follows:
Name
Color
Function
PWR
Red
Power is on.
Off
Power is off.
Ready Green
Steady:
NPort is operational
Blinking:
NPort is responding to NPort
Administrator “Locate” function
Off
Power is off or fault condition exists.
Fault Red
IP conflict or DHCP or BOOTP server did not
respond properly.
Off
No fault condition detected.
Link
Green
Steady:
Network is connected, no data is
being transmitted.
Blinking:
Network is connected, data is
being transmitted.
Off
Ethernet cable is disconnected or has a
short.
InUse
(P1 to P8)
Green
Serial port has been opened by server side
software.
Off
Serial port is not currently opened by
server side software.
Tx/Rx
(P1 to P8)
Green (Tx)
Serial device is transmitting data.
Orange (Rx)
Serial device is receiving data.
Off
No data is flowing to or from the serial
port.
Hardware Installation
STEP 1: After removing the NPort 5600-8-DT from the box, place it on
a desktop or other horizontal surface. Connect the 12-48 VDC power
adaptor to the NPort 5600-8-DT’s power input when using an AC power
source, or connect the NPort 5600-8-DT’s terminal block directly to a
DC power source.
STEP 2: Use an Ethernet cable to connect the NPort 5600-8-DT to a
network hub or switch. You can also connect directly to your computer’s
Ethernet port, which is convenient for initial configuration or testing.
STEP 3: Connect the NPort 5600-8-DT’s serial port to a serial device.
Wall or Cabinet Mounting
The NPort 5600-8-DT comes with two metal attachment plates to allow
installation on a wall or the inside of a cabinet. First, attach the
brackets to the back of the NPort with screws. Next, mount the unit on
a wall or cabinet with screws. Screws should be less than 6.0 mm in
head diameter, and less than 3.5 mm in shaft diameter.

- 5 -
DIN Rail Mounting
DIN-rail attachments can be purchased separately to attach the product
to a DIN-rail. The DIN-rail attachments should be oriented with the
metal springs on top.
Standard Attachment
DK-35A Attachment
NOTE
The operating temperature of the power adapter in the box is
from 0 to 40°C. If your
application is out of this range, please
use a power adapter supplied by UL Listed External Power
Supply (The power output meets SELV and LPS and rated 12
-
48 VDC, minimum current 0.73 A). Moxa has power adapters
with wide temperature range (
-40 to 75°C, -40 to 167°F), the
PWR-12150-(plug type)-SA-T series, for your reference.
Pull High/Low Resistors for RS-485
Use the set of DIP switches on the bottom panel to set the pull high/low
resistor values for each serial port. To access the switches, remove the
screws holding the DIP switch cover in place and flip open the cover.
There are three DIP switches for each port’s pull high/low resistors:
SW
1
2
3
Pull High
Pull Low
Terminator
ON
1KΩ
1KΩ
120Ω
Default

OFF
150KΩ
150KΩ
–
Software Installation Information
For the NPort’s configuration, the default IP address of the NPort
is:LAN: Static; IP = 192.168.127.254; netmask = 255.255.255.0
NOTE
If you have forgotten the NPort's IP address, use the Device
Search Utility (DSU) from your PC to locate the
NPort. After
searching the LAN for NPort units, the DSU will display the IP
address of each unit.
You may log in with the password moxa to change any setting to meet
your network topology (e.g., IP address) or serial device (e.g., serial
parameters). For first-time use, click the Wizard in the left navigation

- 6 -
panel. The wizard will prompt you to configure the IP address, SSID,
and security mode. For other settings, use the factory defaults or
modify the settings for your application.
For software installation, download the relative utilities from Moxa's
website:
https://www.moxa.com/support/support_home.aspx?isSearchShow=1
•Download the NPort Windows Driver Manager and install it as the
driver to run with Real COM mode of the NPort Series.
•Execute NPort Windows Driver Manager; then map the virtual COM
ports on your Windows platform.
•For Loopback Wiring:
。The NPort with RJ45 Port :
You may refer to the RJ45 Ports pin assignment section to loop
back pin 4 and pin 5 for the RS-232 interface to carry out a self test
on the device.
。The NPort with DB9 Male Serial Ports:
You may refer to the DB9 Male Ports pin assignment section to loop
back pin 2 and pin 3 for the RS-232 interface to carry out a self test
on the device.
•Use HyperTerminal or a similar program (you may download Moxa's
program, called PComm Lite) to test whether the device is good or
not.
Pin Assignments and Cable Wiring
RJ45 Ports (NPort 5610-8-DT-J, 5650-8-DT-J)
Pin RS-232 RS-422
4-wire RS-485
2-wire RS-
485
1
DSR
–
–
2
RTS
TxD+
–
3
GND
GND
GND
4
TxD
TxD-
–
5
RxD
RxD+
Data+
6
DCD
RxD-
Data-
7
CTS
–
–
8
DTR
–
–
NOTE
The NPort 5610-8-DT-J supports RS-232 only.
DB9 Male Ports (NPort 5610-8-DT, 5650-8-DT, 5650I-8-DT)
Pin RS-232
RS-422
4-wire RS-485
2-wire RS-
485
1
DCD
TxD-(A)
–
2
RxD
TxD+(B)
–
3
TxD
RxD+(B)
Data+(B)
4
DTR
RxD-(A)
Data-(A)
5
GND
GND
GND
6
DSR
–
–
7
RTS
–
–
8
CTS
–
–
9
–
–
–

- 7 -
NOTE
The NPort 5610-8-DT supports RS-232 only.
RS-232 Cables
NPort
Serial
Device
RJ45
DB9(F)
DB9(M)
DB25(M)
DB25(F)
DSR
1
6
4
6
20
DTR
RTS
2
7
8
4
5
CTS
GND
3
5
5
7
7
GND
TxD
4
3
2
2
3
RxD
RxD
5
2
3
3
2
TxD
DCD
6
1
1
8
8
DCD
CTS
7
8
7
5
4
RTS
DTR
8
4
6
20
6
DSR
RS-422, 4-wire RS-485 Cables
NPort
Serial
Device
RJ45
DB9(F)
DB9(M)
DB25(M)
DB25(F)
TxD+
2
2
3
3
2
RxD+
GND
3
5
5
7
7
GND
TxD-
4
1
1
8
8
RxD-
RxD+
5
3
2
2
3
TxD+
RxD-
6
4
6
20
6
TxD-
2-wire RS-485 Cables
NPort
Serial
Device
RJ45
DB9(F)
DB9(M)
DB25(M)
DB25(F)
GND
3
5
5
7
7
GND
Data+
5
3
2
2
3
Data+
Data-
6
4
6
20
6
Data-
Specifications
LAN
Ethernet Ports
2 × 10/100 Mbps (RJ45)
Protection
Built-in 1.5 kV magnetic isolation
Serial Interface
RS-232
NPort 5610-8-DT, 5610-8-DT-J
RS-232/422/485
NPort 5650-8-DT, 5650-8-DT-J, 5650I-8-
DT
Serial Ports
8 (DB9-M or RJ45 connectors)
Isolation
2K VDC isolation (NPort 5650I-8-DT)
Serial Signals
RS-232
TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND

- 8 -
RS-422
Tx+, Tx-, Rx+, Rx-, GND
RS-485 (2-wire)
Data+, Data-, GND
RS-485 (4-wire)
Tx+, Tx-, Rx+, Rx-, GND
Serial Line Protection
15KV ESD for all signals
RS-485 Data Direction
ADDC™ (Automatic Data Direction Control)
Serial Communication Parameters
Parity
None, Even, Odd, Space, Mark
Data Bits
5, 6, 7, 8
Stop Bit(s)
1, 1.5, 2
Flow Control
RTS/CTS, DSR/DTR (for RS-232 only),
XON/XOFF
Transmission Speed
50 bps to 921.6 Kbps
Power Requirements
Power Input
12 to 48 VDC
Mechanical
Operating Temperature
0 to 55°C (32 to 131°F), 5 to 95% RH
Storage Temperature
-20 to 70°C (-4 to 185°F), 5 to 95% RH
Material
SECC sheet metal (0.8 mm)
Dimensions (W × D × H)
With wall-mount:
With DIN-rail kit:
197 × 44 × 125 mm
229 × 46 × 125 mm
197 × 52.8 × 125 mm
Power Line Protection
2 KV Surge, EN61000-4-5
Certifications
Regulatory Approvals
FCC Class A, CE Class A, UL, CUL, LVD
Warranty
5 years
