Moxa Technologies NPort 5600-8-DT User manual

NPort 5600-8-DT/DTL Series
User’s Manual
Seventh Edition, February 2014
www.moxa.com/product
© 2014 Moxa Inc. All rights reserved.
Reproduction without permission is prohibited.
www.ipc2u.ru
www.moxa.pro

NPort 5600-8-DT/DTL Series
User’s Manual
The software described in this manual is furnished under a license agreement and may be used only in accordance with
the terms of that agreement.
Copyright Notice
Copyright ©2014 Moxa Inc.
All rights reserved.
Reproduction without permission is prohibited.
Trademarks
The MOXA logo is a registered trademark of Moxa Inc.
All other trademarks or registered marks in this manual belong to their respective manufacturers.
Disclaimer
Information in this document is subject to change without notice and does not represent a commitment on the part of
Moxa.
Moxa provides this document as is, without warranty of any kind, either expressed or implied, including, but not limited
to, its particular purpose. Moxa reserves the right to make improvements and/or changes to this manual, or to the
products and/or the programs described in this manual, at any time.
Information provided in this manual is intended to be accurate and reliable. However, Moxa assumes no responsibility for
its use, or for any infringements on the rights of third parties that may result from its use.
This product might include unintentional technical or typographical errors. Changes are periodically made to the
information herein to correct such errors, and these changes are incorporated into new editions of the publication.
Technical Support Contact Information
www.moxa.com/support
Moxa Americas
Toll
-free: 1-888-669-2872
Tel:
[phone]
Fax:
[phone]
Moxa China (Shanghai office)
Toll
-free: 800-820-5036
Tel:
[phone]
Fax:
[phone]
Moxa Europe
Tel:
[phone]
Fax:
[phone]
Moxa Asia
-Pacific
Tel:
[phone]
Fax:
[phone]
www.ipc2u.ru
www.moxa.pro

Table of Contents
1. Introduction...................................................................................................................................... 1-1
Overview...........................................................................................................................................1-2
Product Features ................................................................................................................................1-2
Package Checklist...............................................................................................................................1-2
2. Overview of Hardware ...................................................................................................................... 2-1
Panel Layout (DT and DT-J models) ......................................................................................................2-2
Top and Rear Views.....................................................................................................................2-2
Front Views ................................................................................................................................2-2
Bottom View...............................................................................................................................2-3
Panel Layout (DTL and DTL-T models)...................................................................................................2-4
Top and Rear Views.....................................................................................................................2-4
Front View..................................................................................................................................2-4
Bottom View...............................................................................................................................2-5
LED Indicators....................................................................................................................................2-5
Top Panel Indicators ....................................................................................................................2-5
Ethernet Port Indicators ...............................................................................................................2-6
Pin Assignments .................................................................................................................................2-6
Ethernet Port Pinouts...................................................................................................................2-6
Device Port Pinouts......................................................................................................................2-6
Console Port Pinouts (applies only to DT models) ............................................................................2-7
Product Specifications .........................................................................................................................2-7
NPort 5600-8-DT.........................................................................................................................2-7
NPort 5600-8-DTL .......................................................................................................................2-9
3. Basic Installation .............................................................................................................................. 3-1
Before You Begin................................................................................................................................3-2
Required Items ...........................................................................................................................3-2
Wiring Guidelines ........................................................................................................................3-2
STEP 1: Connect network, serial device, and power ................................................................................3-3
Connect to Network.....................................................................................................................3-3
Attach Serial Device ....................................................................................................................3-3
Connect Power............................................................................................................................3-4
STEP 2: Configure the device server’s general settings............................................................................3-4
Install NPort Administrator ...........................................................................................................3-4
Search for Device Server on LAN...................................................................................................3-5
Adjust General Settings................................................................................................................3-5
Verify Network Settings................................................................................................................3-6
STEP 3: Configure device port operation mode.......................................................................................3-6
Adjust Operation Mode Settings ....................................................................................................3-6
STEP 4: Configure serial communication parameters...............................................................................3-9
Review Serial Parameters.............................................................................................................3-9
Adjust Serial Parameters..............................................................................................................3-9
STEP 5: Map COM port to device.........................................................................................................3-10
Specify Target Device Server......................................................................................................3-11
Assign COM Port Number to Device Port.......................................................................................3-11
Apply Change ...........................................................................................................................3-12
4. General Settings................................................................................................................................ 4-1
Overview...........................................................................................................................................4-2
Basic Settings ....................................................................................................................................4-2
Network Settings................................................................................................................................4-3
Serial Settings....................................................................................................................................4-5
Operating Settings..............................................................................................................................4-6
Accessible IP Settings..........................................................................................................................4-6
Auto Warning Settings.........................................................................................................................4-7
Email and SNMP trap ...................................................................................................................4-7
Event Type.................................................................................................................................4-8
Change Password ...............................................................................................................................4-9
5. Introduction to Operation Modes ...................................................................................................... 5-1
Overview...........................................................................................................................................5-2
Real COM Mode ..................................................................................................................................5-2
RFC2217 Mode ...................................................................................................................................5-3
TCP Server Mode................................................................................................................................5-3
TCP Client Mode .................................................................................................................................5-3
UDP Mode..........................................................................................................................................5-4
Pair Connection Modes ........................................................................................................................5-4
Reverse Telnet Mode...........................................................................................................................5-4
Disabled Mode....................................................................................................................................5-4
www.ipc2u.ru
www.moxa.pro

6. Operation Mode Advanced Settings................................................................................................... 6-1
Overview...........................................................................................................................................6-2
List of Parameters .......................................................................................................................6-2
When to Make Adjustments ..........................................................................................................6-2
Using Pair Connection Modes................................................................................................................6-3
Parameter Details...............................................................................................................................6-3
Connection Management Parameters .............................................................................................6-3
Data Packing Parameters .............................................................................................................6-4
Other Parameters........................................................................................................................6-6
7. Using the Web Console...................................................................................................................... 7-1
Overview...........................................................................................................................................7-2
Web Browser Settings .........................................................................................................................7-2
Basic Navigation.................................................................................................................................7-3
Device Server Settings........................................................................................................................7-4
Special Functions................................................................................................................................7-4
Monitor ......................................................................................................................................7-4
Load Factory Defaults ..................................................................................................................7-5
8. Using NPort Administrator ................................................................................................................ 8-1
Overview...........................................................................................................................................8-2
Installing NPort Administrator ..............................................................................................................8-2
Basic Navigation.................................................................................................................................8-5
Window Layout ...........................................................................................................................8-5
Activating a Function ...................................................................................................................8-5
Configuration .....................................................................................................................................8-6
Finding Your Device Server...........................................................................................................8-6
Status........................................................................................................................................8-7
Device Server Parameters ............................................................................................................8-8
Firmware and Configuration Management.....................................................................................8-10
Monitor............................................................................................................................................8-11
Finding Your Device Server.........................................................................................................8-11
Monitoring Parameters...............................................................................................................8-12
Activating the Monitor................................................................................................................8-13
Port Monitor.....................................................................................................................................8-15
COM Mapping................................................................................................................................... 8-15
Finding Your Device Server.........................................................................................................8-16
COM Mapping Settings...............................................................................................................8-17
Saving COM Mapping Settings.....................................................................................................8-19
COM Grouping..................................................................................................................................8-20
Creating a COM Group ...............................................................................................................8-20
Deleting a COM Group................................................................................................................8-22
Adding a Port to a COM Group ....................................................................................................8-23
Removing a Port from a COM Group ............................................................................................8-24
Modifying Ports in a COM Group ..................................................................................................8-25
IP Address Report............................................................................................................................. 8-28
Automatic Message Log.....................................................................................................................8-29
9. NPort CE Driver Manager for Windows CE......................................................................................... 9-1
Overview...........................................................................................................................................9-2
Installing NPort CE Driver Manager .......................................................................................................9-2
Using NPort CE Driver Manager ............................................................................................................9-2
10. Other Configuration Interfaces ....................................................................................................... 10-1
Overview.........................................................................................................................................10-2
LCM Console (applies to DT models only).............................................................................................10-2
Main Menu Server setting .......................................................................................................10-2
Main Menu Network setting.....................................................................................................10-2
Main Menu Serial set..............................................................................................................10-2
Main Menu Op Mode set .........................................................................................................10-3
Main Menu Console................................................................................................................10-3
Main Menu LCM passwd prot ...................................................................................................10-3
Main Menu Reset btn prot....................................................................................................... 10-3
Main Menu Ping.....................................................................................................................10-3
Main Menu Save/Restart.........................................................................................................10-3
Telnet Console .................................................................................................................................10-3
Serial Console (NPort 5600-8-DT).......................................................................................................10-3
Serial Console (NPort 5600-8-DTL) .....................................................................................................10-4
11. TTY Drivers for Linux and UNIX....................................................................................................... 11-1
Linux Real TTY Drivers ......................................................................................................................11-2
Basic Steps............................................................................................................................... 11-2
Installing Linux Real TTY Driver Files ...........................................................................................11-2
Mapping TTY Ports.....................................................................................................................11-2
www.ipc2u.ru
www.moxa.pro

Removing Mapped TTY Ports.......................................................................................................11-3
Removing Linux Driver Files........................................................................................................11-3
UNIX Fixed TTY Drivers .....................................................................................................................11-4
Installing the UNIX Driver...........................................................................................................11-4
Configuring the UNIX Driver .......................................................................................................11-4
12. The IP Serial Library ....................................................................................................................... 12-1
Overview.........................................................................................................................................12-2
IP Serial Library Function Groups........................................................................................................12-2
Example Program ............................................................................................................................. 12-3
13. Troubleshooting.............................................................................................................................. 13-1
Connection Problems.........................................................................................................................13-1
Operation Mode Problems.................................................................................................................. 13-1
Real COM Mode.........................................................................................................................13-1
TCP Server Mode.......................................................................................................................13-2
TCP Client Mode........................................................................................................................13-2
UDP Mode ................................................................................................................................ 13-2
Serial Data Problems.........................................................................................................................13-3
A. Cable Wiring...................................................................................................................................... A-1
RS-232 Cables ...................................................................................................................................A-2
RS-422, 4-wire RS-485 Cables .............................................................................................................A-2
2-wire RS-485 Cables..........................................................................................................................A-2
B. SNMP Agent with MIB II & RS-232-Like Group ................................................................................. B-1
C. IP Report Protocol............................................................................................................................. C-1
IP Address Report Structure.................................................................................................................C-1
Hardware and AP ID............................................................................................................................C-2
Example ............................................................................................................................................C-2
D. Compliance Notice.............................................................................................................................D-1
www.ipc2u.ru
www.moxa.pro

1
1. Introduction
The Moxa NPort 5600-8-DT/DTL, a line of advanced serial device servers, makes it easy to enable your serial
devices for network operation. The NPort 5600-8-DT/DTL includes the following eleven models:
RS-232 models
•NPort 5610-8-DT
•NPort 5610-8-DT-J
•NPort 5610-8-DTL
•NPort 5610-8-DTL-T
RS-232/422/485 models
•NPort 5650-8-DT
•NPort 5650-8-DT-J
•NPort 5650I-8-DT
•NPort 5650-8-DTL
•NPort 5650-8-DTL-T
•NPort 5650I-8-DTL
•NPort 5650I-8-DTL-T
The following topics are covered in this chapter:

Overview

Product Features

Package Checklist
www.ipc2u.ru
www.moxa.pro

NPort 5600-8-DT/DTL Series Introduction
1-2
Overview
Your NPort 5600-8-DT/DTL device server provides instant Ethernet network access to industrial devices
through a serial connection. Devices such as PLCs, meters, and sensors can use the device server to connect
to an IP-based Ethernet LAN, making the devices accessible from anywhere over a local LAN or the Internet.
The device server’s space-saving design makes it ideal for many applications:
•Central monitoring and control of card readers, alarms, and electronic gate security systems in campus
dormitories
•Dial-up access to private company servers
•Management of server farm devices (routers, hubs, switches) through serial console ports
•Network access to medical diagnostic equipment
The device server provides different operation modes, such as TCP Server mode or UDP mode, to ensure
compatibility with software using standard network APIs (Winsock or BSD Sockets). Real COM and Real TTY
drivers are included to allow easy, transparent operation using virtual COM/TTY ports over a TCP/IP network.
The drivers help preserve your software investment by providing instant network access with minimum
disruption to existing systems.
Configuration can be done manually or using automatic IP protocols (DHCP or BOOTP) through the web console.
NPort Administrator, a Windows utility, is provided for straightforward installation as well as storage and
retrieval of all system parameters.
Product Features
The device server includes the following features:
•Compact desktop size
•Eight ports supporting RS-232, RS-422, or RS-485 operation
•Socket operation modes including TCP Server mode, TCP Client mode, and UDP mode
•10/100 Mbps Ethernet port(s) with auto-speed detection
•Multiple device ports with independent selection of serial interface
•Built-in 15 KV ESD protection for all serial signals
•Supports SNMP MIB-II for network management
•Changeable voice alarm for exceptions (this feature is only available for HW Rev. 1.2 and earlier of the
NPort 5600-8-DT)
Package Checklist
•NPort 5600-8-DT or NPort 5600-8-DTL device server
•Wall mounting and Din-Rail kits
•Stick-on pads
•Documentation and software CD
•Quick installation guide (printed)
•Warranty card
Optional Accessories
•DK-35A: DIN-rail mounting kit (35 mm)
•CBL-RJ45M9-150: 8-pin RJ45 to male DB9 cable, 150 cm
•CBL-RJ45F9-150: 8-pin RJ45 to female DB9 cable, 150 cm
•CBL-RJ45M25-150: 8-pin RJ45 to male DB25 cable, 150 cm
•CBL-RJ45F25-150: 8-pin RJ45 to female DB25 cable, 150 cm
•NP21101: Male DB25 to female DB9 RS-232 cable, 30 cm
Note: Optional Accessories can be ordered separately.
www.ipc2u.ru
www.moxa.pro

NPort 5600-8-DT/DTL Series Introduction
1-3
NOTE
Please notify your sales representative if any of the above items are missing or damaged
www.ipc2u.ru
www.moxa.pro

2
2. Overview of Hardware
NPort 5600-8-DT/DTL device servers are rugged and easy-to-use device networking products. Use this chapter
to familiarize yourself with the hardware and specifications.
The following topics are covered in this chapter:

Panel Layout (DT and DT-J models)
Top and Rear Views
Front Views
Bottom View

Panel Layout (DTL and DTL-T models)
Top and Rear Views
Front View
Bottom View

LED Indicators
Top Panel Indicators
Ethernet Port Indicators

Pin Assignments
Ethernet Port Pinouts
Device Port Pinouts
Console Port Pinouts (applies only to DT models)

Product Specifications
NPort 5600-8-DT
NPort 5600-8-DTL
www.ipc2u.ru
www.moxa.pro

NPort 5600-8-DT/DTL Series Overview of Hardware
2-2
Panel Layout (DT and DT-J models)
NOTE
The figures in this section apply to the following
DT and DT-J models:
•
NPort 5610-8-DT
•
NPort 5610-8-DT-J
•
NPort 5650-8-DT
•
NPort 5650-8-DT-J
•
NPort 5650I-8-DT
Top and Rear Views
Front Views
NPort 5610-8-DT, 5650-8-DT, 5650I-8-DT
www.ipc2u.ru
www.moxa.pro

NPort 5600-8-DT/DTL Series Overview of Hardware
2-3
NPort 5610-8-DT-J, 5650-8-DT-J
Bottom View
Item Description
PWR LED Indicates power input status (red)
Ready and Fault LEDs Indicates normal operation (green) or IP conflict (red)
Link LED Flashes when Ethernet is connected
InUse LEDs Flashes when device port is transmitting or receiving data (green)
Device port Tx LEDs Flashes when device port is transmitting data (green)
Device port Rx LEDs Flashes when device port is receiving data (orange)
Power input For power jack connection to AC power source here
Ethernet port For Ethernet network cable connection
DB9(M) serial ports For attachment of serial devices
Reset button Press and hold with a pointed object for 5 seconds to load factory defaults
www.ipc2u.ru
www.moxa.pro

NPort 5600-8-DT/DTL Series Overview of Hardware
2-4
Panel Layout (DTL and DTL-T models)
NOTE
The figures in this section apply to the following
DTL and DTL-T models:
•
NPort 5610-8-DTL
•
NPort 5650-8-DTL
•
NPort 5650I-8-DTL
•
NPort 5610-8-DTL-T
•
NPort 5650-8-DTL-T
•
NPort 5650I-8-DTL-T
Top and Rear Views
Front View
www.ipc2u.ru
www.moxa.pro

NPort 5600-8-DT/DTL Series Overview of Hardware
2-5
Bottom View
Item Description
PWR LED Indicates power input status (red)
Ready and Fault LEDs Indicates normal operation (green) or IP conflict (red)
Link LED Flashes when Ethernet is connected
InUse LEDs Flashes when device port is transmitting or receiving data (green)
Device port Tx LEDs Flashes when device port is transmitting data (green)
Device port Rx LEDs Flashes when device port is receiving data (orange)
Power input For power jack connection to AC power source here
Ethernet port For Ethernet network cable connection
DB9(M) serial ports For attachment of serial devices
Reset button Press and hold with a pointed object for 5 seconds to load factory defaults
LED Indicators
Top Panel Indicators
Name Color Function
PWR red Power is on.
off Power is off.
Ready green Steady: The NPort is operational.
Blinking: The NPort is responding to NPort Administrator’s “Locate” function
or the NPort is resetting to the factory default.
off Power is off or fault condition exists.
Fault red IP conflict or DHCP or BOOTP server did not respond properly.
off No fault condition detected.
Link green Steady: Network is connected, no data is being transmitted.
Blinking: Network is connected, data is being transmitted.
off Ethernet cable is disconnected or has a short.
InUse
(P1 to P8) green Serial port has been opened by server side software.
off Serial port is not currently opened by server side software.
Tx/Rx
(P1 to P8) green (Tx) Serial device is transmitting data.
orange (Rx) Serial device is receiving data.
off No data is flowing to or from the serial port.
www.ipc2u.ru
www.moxa.pro

NPort 5600-8-DT/DTL Series Overview of Hardware
2-6
Ethernet Port Indicators
Two LED indicators are built into each 10/100M Ethernet connector. A valid network connection will be
indicated as follows:
A green LED indicates a valid connection to a 100 Mbps Ethernet network.
An orange LED indicates a valid connection to a 10 Mbps Ethernet network.
Pin Assignments
Ethernet Port Pinouts
RJ45 Connector Pin Signal
1 RXD+
2 RXD-
3 TXD+
4 –
5 –
6 TXD-
7 –
8 –
Device Port Pinouts
DB9 Ports (NPort 5610-8-DT, 5650-8-DT, 5650I-8-DT, 5610-8-DTL/DTL-T, 5650-8-DTL/DTL-T, and
5650I-8-DTL/DTL-T)
DB9 Male Connector Pin RS-232 RS-422/RS-485-4w RS-485-2w
1 DCD TxD-(A) –
2 RxD TxD+(B) –
3
TxD
RxD+(B)
Data+(B)
4 DTR RxD-(A) Data-(A)
5 GND GND GND
6 DSR – –
7 RTS – –
8 CTS – –
9 – – –
The NPort 5610-8-DT and 5610-8-DTL only support RS-232 signals.
RJ45 Ports (NPort 5610-8-DT-J, 5650-8-DT-J)
RJ45 Connector Pin RS-232 RS-422/RS-485-4w RS-485-2w
1 DSR – –
2 RTS TxD+ –
3 GND GND GND
4 TxD TxD- –
5 RxD RxD+ Data+
6
DCD
RxD-
Data-
7 CTS – –
www.ipc2u.ru
www.moxa.pro

NPort 5600-8-DT/DTL Series Overview of Hardware
2-7
8 DTR – –
The NPort 5610-8-DT-J only supports RS-232 signals.
Console Port Pinouts (applies only to DT models)
RJ45 Connector Pin RS-232
1
DSR
2 RTS
3 GND
4 TxD
5 RxD
6 DCD
7 CTS
8 DTR
Product Specifications
NPort 5600-8-DT
Ethernet Interface
Number of Ports:
2 (1 IP)
Speed:
10/100 Mbps, auto MDI/MDIX
Connector:
8-pin RJ45
Magnetic Isolation Protection:
1.5 KV built-in
Serial Interface
Number of Ports:
8
Serial Standards:
NPort 5610
-8-DT: RS-232
NPort 5650-8-DT: RS-232/422/485
Connector:
NPort
5610-8-DT/5650-8-DT/5650I-8-DT: DB9 male
NPort 5610
-8-DT-J/5650-8-DT-J: RJ45 (8 pins)
Serial Line Protection:
15 KV ESD protection for all signals
2 KV isolation protection (NPort 5650I
-8-DT only)
RS
-485 Data Direction Control: ADDC® (automatic data direction control)
Pull High/Low Resistor for RS
-485: 1 KΩ, 150 KΩ
Terminator for RS
-485: 120 Ω
Serial Communication Parameters
Data Bits:
5, 6, 7, 8
Stop Bits:
1, 1.5, 2
Parity:
None, Even, Odd, Space, Mark
Flow Control:
DSR/DTR and RTS/CTS (RS-232 only), XON/XOFF
Baudrate:
50 bps to 921.6 Kbps
Serial Signals
RS
-232: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
RS
-422: Tx+, Tx-, Rx+, Rx-, GND
RS
-485-4w: Tx+, Tx-, Rx+, Rx-, GND
RS
-485-2w: Data+, Data-, GND
Software
www.ipc2u.ru
www.moxa.pro

NPort 5600-8-DT/DTL Series Overview of Hardware
2-8
Network Protocols:
ICMP, IP, TCP, UDP, DHCP, BOOTP, Telnet, DNS, SNMP V1, HTTP, SMTP, SNTP, Rtelnet,
ARP, RFC2217
Configuration Options:
Web Console, Telnet Console, Serial Console, Windows Utility
Windows Real COM Drivers:
Windows 95/98/ME/NT/2000, Windows XP/2003/Vista/2008/7/8 x86/x64,
Windows 2012 x64, Embedded CE 5.0/6.0, XP Embedded
Fixed TTY Drivers:
SCO Unix, SCO OpenServer, UnixWare 7, UnixWare 2.1, SVR 4.2, QNX 4.25, QNX 6,
Solaris 10, FreeBSD, AIX 5.x, HP
-UX 11i
Linux Real TTY Drivers:
Linux kernel 2.4.x, 2.6.x, 3.x
Mini Screen with Push Buttons
LCD Panel:
Liquid Crystal Display on the case
Push Buttons:
Four push buttons for convenient on-site configuration
Physical Characteristics
Housing:
Metal, IP30 protection
Weight:
NPort 5610
-8-DT: 1760 g
NPort 5610
-8-DT-J: 1710 g
NPort 5650
-8-DT: 1770 g
NPort 5650
-8-DT-J: 1710 g
NPort 5650I
-8-DT: 1850 g
Dimensions:
Without ears: 197 x 44 x 125 mm (7.76 x 1.73 x 4.92 in)
With ears: 229 x 46 x 125 mm (9.01 x 1.81 x 4.92 in)
With DIN
-Rail kit on bottom panel: 197 x 53 x 125 mm (7.76 x 2.09 x 4.92 in)
Environmental Limits
Operating Temperature:
0 to 55°C (32 to 131°F)
Storage Temperature:
-20 to 70°C (-4 to 158°F)
Ambient Relative Humidity:
5 to 95% (non-condensing)
Power Requirements
Input Voltage:
12 to 48 VDC
Power Consumption:
NPort 5610
-8-DT:
611 mA @ 12 V, 300 mA @ 24 V, 140 mA @ 48 V
NPort 5610
-8-DT-J:
611 mA @ 12 V, 300 mA @ 24 V, 140 mA @ 48 V
NPort 5650
-8-DT:
615 mA @ 12 V, 300 mA @ 24 V, 156 mA @ 48 V
NPort 5650I
-8-DT:
1066 mA @ 12 V, 510 mA @ 24 V, 200 mA @ 48 V
NPort 5650
-8-DT-J:
615 mA @ 12 V, 300 mA @ 24 V, 156 mA @ 48 V
Standards and Certifications
Safety:
UL 60950-1, EN 60950-1
EMC:
CE, FCC
EMI:
EN 55022 Class A, FCC Part 15 Subpart B Class A
EMS: EN 55024
Reliability
Alert Tools:
Built-in buzzer and RTC (real-time clock)
Automatic Reboot Trigger:
Built-in WDT (watchdog timer)
MTBF (mean time between failures):
163,356 hrs
Warranty
Warranty Period: 5 years
Details:
See www.moxa.com/warranty
www.ipc2u.ru
www.moxa.pro

NPort 5600-8-DT/DTL Series Overview of Hardware
2-9
NPort 5600-8-DTL
Ethernet Interface
Number of Ports:
1
Speed:
10/100 Mbps, auto MDI/MDIX
Connector:
8-pin RJ45
Magnetic Isolation Protection:
1.5 KV built-in
Serial Interface
Number of
Ports: 8
Serial Standards:
NPort 5610
-8-DTL: RS-232
NPort 5650-8-DTL/5650I-8-DTL: RS-232/422/485
Connector:
DB9 male
Serial Line Protection:
15 KV ESD protection for all signals
2 KV isolation protection (NPort 5650I
-8-DTL only)
RS
-485 Data Direction Control: ADDC® (automatic data direction control)
Pull High/Low Resistor for RS
-485: 1 KΩ, 150 KΩ
Terminator for RS
-485: 120 Ω
Serial Communication Parameters
Data Bits:
5, 6, 7, 8
Stop Bits:
1, 1.5, 2
Parity:
None, Even, Odd, Space, Mark
Flow
Control: DSR/DTR and RTS/CTS (RS-232 only), XON/XOFF
Baudrate:
50 bps to 921.6 Kbps
Serial Signals
RS
-232: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
RS-422: Tx+, Tx-, Rx+, Rx-, GND
RS
-485-4w: Tx+, Tx-, Rx+, Rx-, GND
RS
-485-2w: Data+, Data-, GND
Software
Network Protocols:
ICMP, IP, TCP, UDP, DHCP, BOOTP, Telnet, DNS, SNMP V1, HTTP, SMTP, SNTP, Rtelnet,
ARP, RFC2217
Configuration Options:
Web Console, Telnet Console, Serial Console, Windows Utility
Windows Real COM Drivers:
Windows 95/98/ME/NT/2000, Windows XP/2003/Vista/2008/7/8 x86/x64,
Windows 2012 x64, XP Embedded
Fixed TTY Drivers:
SCO Unix, SCO OpenServer, UnixWare 7, UnixWare 2.1, SVR 4.2, QNX 4.25, QNX 6,
Solaris 10, FreeBSD, AIX 5.x, HP
-UX 11i
Linux Real TTY Drive
rs: Linux kernel 2.4.x, 2.6.x, 3.x
Physical Characteristics
Housing:
Metal, IP30 protection
Weight:
NPort 5610
-8-DTL: 1760 g
NPort 5650
-8-DTL: 1770 g
NPort 5650I-8-DTL: 1850 g
Dimensions:
Without ears: 197 x 44 x 125 mm (7.76 x 1.73 x 4.92 in)
With
ears: 229 x 46 x 125 mm (9.01 x 1.81 x 4.92 in)
With DIN
-Rail kit on bottom panel: 197 x 53 x 125 mm (7.76 x 2.09 x 4.92 in)
Environmental Limits
Operating Temperature:
Standard Models: 0 to 60°C (32 to 140°F)
Wide Temp. Models:
-40 to 75°C (-40 to 167°F)
www.ipc2u.ru
www.moxa.pro

NPort 5600-8-DT/DTL Series Overview of Hardware
2-10
Storage Temperature:
-40 to 85°C (-40 to 185°F)
Ambient Relative Humidity:
5 to 95% (non-condensing)
Power Requirements
Input Voltage:
12 to 48 VDC
Power Consumption:
NPort 5610
-8-DTL:
340 mA @ 12 V, 180 mA @ 24 V, 110 mA @ 48 V
NPort 5650
-8-DTL:
470 mA @ 12 V, 250 mA @ 24 V, 140 mA @ 48 V
NPort 5650I
-8-DTL:
740 mA @ 12 V, 370 mA @ 24 V, 220 mA @ 48 V
Standards and Certifications
Safety:
UL 60950-1, EN 60950-1
EMC:
CE, FCC
EMI:
EN 55022 Class A, FCC Part 15 Subpart B Class A
EMS:
EN 55024
Reliability
Alert Tools: Built-in buzzer and RTC (real-time clock)
Automatic Reboot Trigger:
Built-in WDT (watchdog timer)
Warranty
Warranty Period:
5 years
Details:
See www.moxa.com/warranty
www.ipc2u.ru
www.moxa.pro

3
3. Basic Installation
NPort 5600-8-DT/DTL device servers are designed to coordinate between your network, your host computer,
and your serial device. Installation of the device server should occur in stages to ensure that each connection
is recognized. This chapter will guide you through a typical installation with a Windows PC. For certain
applications or environments, you may be guided to other chapters for additional information.
The following topics are covered in this chapter:

Before You Begin
Required Items
Wiring Guidelines

STEP 1: Connect network, serial device, and power
Connect to Network
Attach Serial Device
Connect Power

STEP 2: Configure the device server’s general settings
Install NPort Administrator
Search for Device Server on LAN
Adjust General Settings
Verify Network Settings

STEP 3: Configure device port operation mode
Adjust Operation Mode Settings

STEP 4: Configure serial communication parameters
Review Serial Parameters
Adjust Serial Parameters

STEP 5: Map COM port to device
Specify Target Device Server
Assign COM Port Number to Device Port
Apply Change
www.ipc2u.ru
www.moxa.pro

NPort 5600-8-DT/DTL Series Basic Installation
3-2
Before You Begin
This chapter will walk you through the major steps of a typical installation and will offer advice on adjustments
and options for specific applications. Please note that certain procedures will vary for your specific application
and environment.
In these instructions, a Windows PC is used for configuration. For Linux or UNIX environments, please refer to
Chapter 11.
Installation of the NPort 5600-8-DT/DTL is presented in the following steps:
Step 1: Connect power, network and serial devices
Step 2: Configure the device server’s IP settings
Step 3: Configure each port’s operation mode
Step 4: Configure each port’s serial communication settings
Step 5: Map host COM ports to device ports (for Real COM mode)
Required Items
Make sure that you have the following items before beginning your installation:
•NPort 5600-8-DT/DTL device server
•Windows PC with live connection to the network (see Chapter 11 for Linux/UNIX installations)
•NPort Documentation & Software CD
•Ethernet cable
•Serial cable for device attachment
•Power adapter and power cord
•Make sure that you have the following information available before beginning your installation:
•IP address of your Windows PC
•IP address and subnet to be assigned to the device server
•TCP or UDP port number to be used for each device port
•Local COM port number to be used for each device port (for Real COM mode)
•Baudrate, parity, data bit, and stop bit settings for each device port
Wiring Guidelines
The following guidelines will help ensure trouble-free signal communication with the device server.
•Use separate paths to route wiring for power and devices to avoid interference. Do not run signal or
communication wiring and power wiring in the same wire conduit. The rule of thumb is that wiring that
shares similar electrical characteristics can be bundled together.
•If power wiring and device wiring paths must cross, make sure the wires are perpendicular at the
intersection point.
•Keep input wiring and output wiring separate.
•Label all wiring to each device in the system for easier testing and troubleshooting
www.ipc2u.ru
