Moxa EtherDevice™ Switch
EDS-505A/508A
Hardware Installation Guide
Eighth Edition, July 2010
©2010 Moxa Inc. All rights reserved.
Reproduction without permission is prohibited.
Fl.4, No.135, Lane 235, Pao-Chiao Rd. Shing Tien City, Taipei, Taiwan,
R.O.C.
TEL: [phone]
P/N: 1802005000017

—1 —
Package Checklist
The Moxa EDS-505A/508A is shipped with the following items. If any of
these items is missing or damaged, please contact your customer service
representative for assistance.
y1 Moxa EtherDevice Switch (EDS-505A or EDS-508A)
yHardware Installation Guide
yCD-ROM with User’s Manual and Windows Utility
yWarranty Statement
yRJ45 to DB9 Console port cable
yProtective caps for unused ports
yPanel Mounting Kit (optional—must be ordered separately)

—2 —
Panel Layout of EDS-505A/508A
(Standard)
EDS-505A
Front Panel View
EDS-508A
Front Panel View
7
6
8
9
11
10
12
13
14
15
15
2
14
15
15
MSTR/HEAD
CPLR/TAIL
MSTR/HEAD
CPLR/TAIL
V1, V2 INPUTS: 12-45 VDC
RS-232 CONSOLE
------
ON
OFF
MASTER
COUPLER
TURBO
RING
PWR1
4
3
2
1
PWR2
RELAY2
RELAY1
DI1
DI2
V2-
V2+
I1
V1-
V1+
I2
Top Panel View
1
2
3
4
1
Rear Panel View
2
17
16
16
52
1. Grounding screw
2. Terminal block for power input
PWR1/PWR2 and relay output
3. Heat dissipation orifices
4. Console port
5. DIP switches
6. Power input PWR1 LED
7. Power input PWR2 LED
8. Fault LED
9. MSTR/HEAD: LED indicator
10. CPLR/TAIL: LED indicator
11. Turbo Chain logo
12. TP port’s 100 Mbps LED
13. TP port’s 10 Mbps LED
14. Model Name
15. 10/100BaseT(X) ports
16. Screw hole for wall mounting kit
17. DIN-Rail kit

—3 —
Panel Layout of EDS-505A/508A
(SC-type)
EDS-505A-MM-SC
Front Panel View
EDS-508A-MM-SC
Front Panel View
14
15
14
16
15
7
6
8
9
11
10
12
13
2
16
17
17
MSTR/HEAD
CPLR/TAIL
MSTR/HEAD
CPLR/TAIL
V1, V2 INPUTS: 12-45 VDC
RS-232 CONSOLE
------
ON
OFF
MASTER
COUPLER
TURBO
RING
PWR1
4
3
2
1
PWR2
RELAY2
RELAY1
DI1
DI2
V2-
V2+
I1
V1-
V1+
I2
Top Panel View
1
2
3
4
1
Rear Panel View
2
19
18
18
52
NOTE: The appearance of
EDS-505A-SS-SC is identical to that
of EDS-505A-MM-SC.
The appearance of EDS-508A-SS-SC
is identical to that of
EDS-508A-MM-SC.
1. Grounding screw
2. Terminal block for power input
PWR1/PWR2 and relay output
3. Heat dissipation orifices
4. Console port
5. DIP switches
6. Power input PWR1 LED
7. Power input PWR2 LED
8. Fault LED
9. MSTR/HEAD: LED indicator
10. CPLR/TAIL: LED indicator
11. Turbo Chain logo
12. TP port’s 100 Mbps LED
13. TP port’s 10 Mbps LED
14. Model Name
15. 10/100BaseT(X) ports
16. 100BaseFX ports
17. FX port’s 100 Mbps LEDs
18. Screw hole for wall mounting kit
19. DIN-Rail kit

—4 —
Panel Layout of EDS-505A/508A
(ST-type)
EDS-505A-MM-ST
Front Panel View
EDS-508A-MM-ST
Front Panel View
14
15
14
16
15
7
6
8
9
11
10
12
13
2
16
17
17
MSTR/HEAD
CPLR/TAIL
MSTR/HEAD
CPLR/TAIL
V1, V2 INPUTS: 12-45 VDC
RS-232 CONSOLE
------
ON
OFF
MASTER
COUPLER
TURBO
RING
PWR1
43
2
1
PWR2
RELAY2
RELAY1
DI1
DI2
V2-
V2+
I1
V1-
V1+
I2
Top Panel View
1
2
3
4
1
Rear Panel View
2
19
18
18
52
1. Grounding screw
2. Terminal block for power input
PWR1/PWR2 and relay output
3. Heat dissipation orifices
4. Console port
5. DIP switches
6. Power input PWR1 LED
7. Power input PWR2 LED
8. Fault LED
9. MSTR/HEAD: LED indicator
10. CPLR/TAIL: LED indicator
11. Turbo Chain logo
12. TP port’s 100 Mbps LED
13. TP port’s 10 Mbps LED
14. Model Name
15. 10/100BaseT(X) ports
16. 100BaseFX ports
17. FX port’s 100 Mbps LEDs
18. Screw hole for wall mounting kit
19. DIN-Rail kit

—5 —
Mounting Dimensions (unit = mm)
Rear View
Side View
Front View
DlN-Rail Kit
DlN-Rail
105.00
9.00
35.00
135.00
24.324.56 46.77 39.37
135.00
Wall Mounting Kit
10
10
5
7.75 30.50 7.75
3.5
6
6
66.80
57.05
13.9 18.2 13.9
30.00 15.0
51.3 13.9
80.2
DlN-Rail Kit
7.5 55 7.5
27.20
48.30
MSTR/HEAD
CPLR/TAIL
DIN-Rail Mounting
The aluminum DIN-Rail attachment plate should already be fixed to the back
panel of the EDS-505A/508A when you take it out of the box.
STEP 1:
Insert the top of the DIN-Rail into the
slot just below the stiff metal spring.
STEP 2:
The DIN-Rail attachment unit will
snap into place as shown.
metal
spring
DIN-Rail
metal
spring
DIN-Rail
To remove EDS-505A/508A from the DIN-Rail, simply reverse Steps 1 and 2.

—6 —
Wall Mounting (optional)
For some applications, you will find it convenient to mount the
EDS-505A/508A on the wall, as shown in the following figures.
STEP 1: Remove the
aluminum DIN-Rail
attachment plate from the
EDS-505A/508A’s rear
panel, and then attach the
wall mount plates with M3
screws, as shown in the
figures at the right.
⇒
STEP 2:
Mounting the EDS-505A/508A on the wall requires 4 screws.
Use the EDS, with wall mount plates attached, as a guide to
mark the correct locations of the 4 screws. The heads of the
screws should be less than 6.0 mm in diameter, and the shafts
should be less than 3.5 mm in diameter, as shown in the
figure at the right.
6.0 mm
3.5 mm
NOTE Before tightening the screws into the wall, make sure the screw head
and shank size are suitable by inserting the screw into one of the
keyhole-shaped apertures of the Wall Mounting Plates.
Do not screw the screws in completely—leave about 2 mm to allow room for
sliding the wall mount panel between the wall and the screws.
STEP 3: Once the screws are fixed in the wall, insert the four screw heads
through the large parts of the keyhole-shaped apertures, and then slide the
EDS-505A/508A downwards, as indicated. Tighten the four screws for added
stability.
II 3G
ATEX Information
1. Certificate number DEMKO 08 ATEX
0712961X
2. Ambient range (-40°C ≤Tamb ≤75°C)
3. Certification string (Ex nC nL IIC T4)
4. Standards covered ( EN60079-0:2006, EN60079-15:2005)
5. The conditions of safe usage:
yThese products must be mounted in an IP54 enclosure.
yInstall in an area of pollution degree 2 or less.
yUse a conductor wire of size 0.2 mm² or greater.
yPROVISIONS SHALL BE MADE, EITHER IN EXTERNAL TO
THE APPARATUS, TO PREVENT THE RATED VOLTAGE BEING
EXCEEDED BY THE TRANSIENTS DISTURBANCES OF MORE
THAN 40 %

—7 —
Wiring Requirements
WARNING
The power for this product is intended to be supplied by a Listed
Power Unit, with output marked LPS, and rated to deliver 12 to
45 VDC at a maximum of 600 mA.
WARNING
Safety First!
Be sure to disconnect the power cord before installing and/or
wiring your Moxa EtherDevice Switch. Calculate the maximum
possible current in each power wire and common wire. Observe
all electrical codes dictating the maximum current allowable for
each wire size. If the current goes above the maximum ratings,
the wiring could overheat, causing serious damage to your
equipment.
Please read and follow these important guidelines:
yUse separate paths to route wiring for power and devices. If power wiring
and device wiring paths must cross, make sure the wires are perpendicular
at the intersection point.
yNOTE: Do not run signal or communications wiring, and power wiring
through the same wire conduit. To avoid interference, wires with different
signal characteristics should be routed separately.
yUse the type of signal transmitted through a wire to determine which wires
should be kept separate. The rule of thumb is that wiring that shares similar
electrical characteristics can be bundled together.
yKeep input wiring and output wiring separate.
yIt is strongly advised that you label wiring to all devices in the system,
when necessary.
Grounding the EtherDevice Switch
Grounding and wire routing help limit the effects of noise due to
electromagnetic interference (EMI). Run the ground connection from the
ground screw to the grounding surface prior to connecting devices.
ATTENTION
This product is intended to be mounted to a well-grounded
mounting surface, such as a metal panel.
Wiring the Relay Contact
The EDS-505A/508A has two sets of relay output—relay 1 and relay 2. Each
relay contact consists of two contacts of the terminal block on the
EDS-505A/508A’s top panel. Refer to the next section for detailed instructions
on how to connect the wires to the terminal block connector, and how to attach
the terminal block connector to the terminal block receptor.

—8 —
Relay1 Relay2
Relay1 Relay2
The fault circuit will open if::
1. A relay warning event is triggered, OR
2. The EDS-505A/508A is the Master of this Turbo Ring, and the Turbo Ring
is broken, OR
3. Start-up failure.
If none of these three conditions is met, the fault circuit will remain closed.
Wiring the Redundant Power Inputs
The EDS-505A/508A unit has two sets of power inputs—power input 1 and
power input 2. Top and front views of one of the terminal block connectors are
shown below.
V1- V1+
PWR1
V2- V2+
PWR2
PWR1
PWR2
V1- V1+V2- V2+
Take the following steps to wire the redundant power inputs:
STEP 1: Insert the negative/positive DC wires into the V-/V+ terminals.
STEP 2: To keep the DC wires from pulling loose, use a small flat-blade
screwdriver to tighten the wire-clamp screws on the front of the terminal block
connector.
STEP 3: Insert the plastic terminal block connector prongs into the terminal
block receptor, which is located on the EDS’s top panel.
ATTENTION
Before connecting the EDS to the DC power inputs, make sure
the DC power source voltage is stable.
Wiring the Digital Inputs
The EDS-505A/508A unit has two sets of digital inputs, DI 1 and DI 2. Each
DI consists of two contacts of the 6-pin terminal block connector on the EDS’s
top panel. The remaining contacts are used for the EDS’s two DC inputs. Top
and front views of one of the terminal block connectors are shown below.
I1
D2I
I2
D1I
I1I2
D2ID1I

—9 —
Take the following steps to wire the digital inputs:
STEP 1: Insert the negative (ground)/positive DI wires into the ┴/I1
terminals.
STEP 2: To keep the DI wires from pulling loose, use a small flat-blade
screwdriver to tighten the wire-clamp screws on the front of the terminal block
connector.
STEP 3: Insert the plastic terminal block connector prongs into the terminal
block receptor, which is located on the EDS-505A/508A’s top panel.
Communication Connections
EDS-508A models have 8 or 6 10/100BaseT(X) Ethernet ports, and 0 (zero) or
2 100BaseFX (SC/ST-type connector) fiber ports. EDS-505A models have 5 or
3 10/100BaseT(X) Ethernet ports, and 0 (zero) or 2 100 BaseFX (SC/ST-type
connector) fiber ports
10/100BaseT(X) Ethernet Port Connection
The 10/100BaseT(X) ports located on EDS’s front panel are used to connect to
Ethernet-enabled devices.
Next, we show pinouts for both MDI (NIC-type) ports and MDI-X
(HUB/Switch-type) ports, and also show cable wiring diagrams for
straight-through and cross-over Ethernet cables.
MDI Port Pinouts MDI-X Port Pinouts 8-pin RJ45
Pin Signal Pin Signal
1 Tx+ 1 Rx+
2 Tx- 2 Rx-
3 Rx+ 3 Tx+
6 Rx- 6 Tx-
RJ45 (8-pin) to RJ45 (8-pin) Straight-Through Cable Wiring
Straight-Through Cable
RJ45 Plug Pin 1
Switch Port
RJ45
Connector
RJ45
Connecto
r
Tx+
Tx-
Rx+
Rx-
NIC Port
Cable Wiring
3 3
6 6
1 1
2 2
Rx+
Rx-
Tx+
Tx-
RJ45 (8-pin) to RJ45 (8-pin) Cross-Over Cable Wiring
Cross-Over Cable
RJ45 Plug Pin 1
Switch Port
(NIC Port)
RJ45
Connector
RJ45
Connector
Tx+
Tx-
Rx+
Rx-
(Rx+)
(Rx-)
(Tx+)
(Tx-)
(Tx+)
(Tx-)
(Rx+)
(Rx-)
Switch Port
(NIC Port)
Cable Wiring
3 1
6 2
1 3
2 6
Rx+
Rx-
Tx+
Tx-
1 8

—10 —
100BaseFX Ethernet Port Connection
Remember to connect the Tx (transmit) port of device I to the Rx (receive) port
of device II, and the Rx (receive) port of device I to the Tx (transmit) port of
device II. If you make your own cable, we suggest labeling the two sides of the
same line with the same letter (A-to-A and B-to-B, as shown below, or
A1-to-A2 and B1-to-B2).
SC-Port Pinouts SC-Port to SC-Port Cable Wiring
Tx
Rx
AA
BB
Cable Wiring
A A
B B
ST-Port Pinouts ST-Port to ST-Port Cable Wiring
Tx
Rx
AA
B
Cable Wiring
A A
B B
B
ATTENTION
This is a Class 1 Laser/LED product. To avoid causing serious
damage to your eyes, do not stare directly into the Laser Beam.
Turbo Ring DIP Switch Settings
EDS-505A/508A series are plug-and-play managed redundant Ethernet
switches. The proprietary Turbo Ring protocol was developed by Moxa to
provide better network reliability and faster recovery time. Moxa Turbo Ring’s
recovery time is less than 300 ms (Turbo Ring) or 20 ms (Turbo Ring
V2) —compared to a 3- to 5-minute recovery time for commercial
switches—decreasing the possible loss caused by network failures in an
industrial setting.
There are 4 Hardware DIP Switches for Turbo Ring on the top panel of
EDS-505A/508A that can help setup the Turbo Ring easily within seconds. If
you do not want to use a hardware DIP switch to setup the Turbo Ring, you can
use a web browser, telnet, or console to disable this function.
NOTE Please refer to the Turbo Ring DIP Switch section and Using
Communication Redundancy section in User’s Manual for more
detail information about the settings and usage of Turbo Ring and
Turbo Ring V2.

—11 —
EDS-505A/508A Series DIP Switches
21
------
MASTER
COUPLER
TURBO
RING
43
The default setting for each DIP Switch is OFF. The
following table explains the effect of setting the DIP
Switch to the ON position.
“Turbo Ring” DIP Switch Settings
DIP 1 DIP 2 DIP 3 DIP 4
ON: Enables this
EDS as the Ring
Master.
ON: Enables the
default “Ring
Coupling” ports.
ON: Activates
DIP switches 1,
2, 3 to configure
“Turbo Ring”
settings.
Reserved for
future use. OFF: This EDS
will not be the
Ring Master.
OFF: Do not use
this EDS as the
ring coupler.
OFF: DIP
switches 1, 2, 3
will be disabled.
“Turbo Ring V2” DIP Switch Settings
DIP 1 DIP 2 DIP 3 DIP 4
ON: Enables the
default “Ring
Coupling
(backup)” port.
ON: Enables this
EDS as the Ring
Master.
ON: Enables the
default “Ring
Coupling” port.
ON: Activates
DIP switches 1,
2, 3 to configure
“Turbo Ring V2”
settings.
OFF: Enables the
default “Ring
Coupling
(primary)” port.
OFF: This EDS
will not be the
Ring Master.
OFF: Do not use
this EDS as a
ring coupler.
OFF: DIP
switches 1, 2, 3
will be disabled.
NOTE You must enable the Turbo Ring function first before using the DIP
switch to active the Master and Coupler functions.
NOTE If you do not enable any of the EDS-505A/508A switches to be the
Ring Master, the Turbo Ring protocol will automatically choose the
EDS-505A/508A with the smallest MAC address range to be the
Ring Master. If you accidentally enable more than one
EDS-505A/508A to be the Ring Master, these EDS-505A/508A
switches will auto-negotiate to determine which one will be the
Ring Master.
LED Indicators
There are several LEDs on the EDS’s front panel. The function of each LED is
described in the following table.
LED Color State Description
PWR1 AMBER On Power is being supplied to power
input PWR1.

—12 —
Off Power is not being supplied to power
input PWR1.
On Power is being supplied to power
input PWR2.
PWR2 AMBER
Off Power is not being supplied to power
input PWR2.
On
When (1) a relay warning event is
triggered, (2) EDS-505A/508A is the
Master of this Turbo Ring, and the
Turbo Ring is broken, or (3) start-up
failure.
FAULT RED
Off When a relay warning event is not
triggered.
On
When the EDS-505A/508A is set as
the Master of the Turbo Ring, or as
the Head of the Turbo Chain.
Blinking
The EDS-505A/508A has become
the Ring Master of the Turbo Ring, or
the Head of the Turbo Chain, after
the Turbo Ring or the Turbo Chain is
down.
MSTR/HEAD GREEN
Off
When theEDS-505A/508A is not the
Master of this Turbo Ring or is set as
the Member of the Turbo Chain.
On
When the EDS-505A/508A coupling
function is enabled to form a back-up
path, or when it's set as the Tail of
the Turbo Chain.
Blinking When the Turbo Chain is down.
CPLR/TAIL GREEN
Off
When the EDS-505A/508A disables
the coupling function, or is set as the
Member of the Turbo Chain.
On TP port’s 10 Mbps link is active.
Blinking Data is being transmitted at 10 Mbps.
10M
(TP) GREEN
Off TP Port’s 10 Mbps link is inactive.
On TP port’s 100 Mbps link is active.
Blinking Data is being transmitted at 100
Mbps.
100M
(TP) GREEN
Off TP Port’s 100 Mbps link is inactive.
On FX port’s 100 Mbps is active.
Blinking Data is being transmitted at 100
Mbps.
100M
(FX) GREEN
Off FX port’s 100 Mbps is inactive.

—13 —
Auto MDI/MDI-X Connection
The Auto MDI/MDI-X function allows users to connect the EDS-505A/508A’s
10/100BaseTX ports to any kind of Ethernet device, without needing to pay
attention to the type of Ethernet cable being used for the connection. This
means that you can use either a straight-through cable or cross-over cable to
connect the EDS-505A/508A to Ethernet devices.
Fiber Ports
The fiber ports are factory-built as either multi-mode or single-mode SC/ST
connectors. Therefore, you should use fiber cables that have SC/ST connectors
at both ends. When plugging the connector into the port, make sure the slider
guide is positioned to the right side such that it fits snuggly into the port.
slider
slider guide
slider ridges
slider
slider guide slider ridges
Specifications
Technology
Standards IEEE802.3, 802.3u, 802.3x, 802.1D, 802.1w, 802.1Q,
802.1p, 802.1X, 802.3ad
Protocols IGMPv1/v2, GVRP, SNMPv1/v2c/v3, DHCP
Server/Client, BootP, TFTP, SNTP, SMTP, RARP,
GMRP, LACP, RMON, HTTP, HTTPS, Telnet,
Syslog, DHCP Option 66/67/82, SSH, SNMP Inform,
Modbus/TCP, LLDP, IEEE 1588 PTP, IPv6
MIB MIB-II, Ethernet-Like MIB, P-BRIDGE MIB,
Q-BRIDGE MIB, Bridge MIB, RSTP MIB, RMON
MIB Group 1,2,3,9
Forwarding and Filtering
Rate
148810 pps
Processing Type Store and Forward
Flow Control IEEE802.3x flow control, back pressure flow control
Interface
RJ45 Ports 10/100BaseT(X) auto negotiation speed, F/H duplex
mode, and auto MDI/MDI-X connection
Fiber Ports 100BaseFX ports (SC/ST connector)
Console RS-232 (RJ45)
LED Indicators PWR1, PWR2, FAULT, 10/100M (TP port), 100M
(Fiber Port), MSTR/HEAD and CPLR/TAIL
SC Connector
ST Connector

—14 —
Relay Contact Two relay outputs with current carrying capacity of
1A @ 24 VDC
DIP Switches Master, Coupler, Turbo Ring, Reserve
Digital Input Two inputs with the same ground, but electrically
isolated from the electronics
• For state “1”: +13 to +30V
• For state “0”: -30 to +3V
• Max. input current: 8 mA
Optical Fiber
Multi-mode Single-mode Single-mode,
80 km
Wavelength 1300 nm 1310 nm 1550 nm
Max. Tx -10 dBm 0 dBm 0 dBm
Min. Tx -20 dBm -5 dBm -5 dBm
Rx Sensitivity -32 dBm -34 dBm -34 dBm
Link Budget 12 dB 29 dB 29 dB
Typical Distance 5 km (a)
4 km (b)
40 km (c) 80 km (d)
Saturation -6 dBm -3 dBm -3 dBm
a. using [50/125 μm, 800 MHz*km] cable
b. using [62.5/125 μm, 500 MHz*km] cable
c. using [9/125 μm, 3.5 PS/(nm*km)] cable
d. using [9/125 μm, 19 PS/(nm*km)] cable
Power
Input Voltage 12 to 45 VDC, redundant inputs
Input Current (@24V) Max. 0.24A: (EDS-505A)
Max. 0.26A: (EDS-508A)
Max. 0.35A: (EDS-505A-MM, EDS-505A-SS)
Max. 0.36A: (EDS-508A-MM, EDS-508A-SS)
Connection Two removable 6-pin terminal blocks
Overload Current
Protection
Present
Reverse Polarity
Protection
Present
Mechanical
Casing IP30 protection, metal case
Dimensions 80.5 ×135 ×105 mm (W ×H ×D)
Weight 1.04 kg
Installation DIN-Rail, Wall Mounting (optional kit)
Environment
Operating Temperature 0 to 60°C (32 to 140°F),
-40 to 75°C (-40 to 167°F ) for -T models
Storage Temperature -40 to 85°C (-40 to 185°F)
Ambient Relative
Humidity
5 to 95% (non-condensing)
Regulatory Approvals
Safety UL60950-1, UL 508, CSA C22.2 No. 60950-1,
EN60950-1

—15 —
Hazardous Location UL/cUL Class I, Division 2, Groups A, B, C, and D.
ATEX Class I, Zone 2, Ex nC nL IIC T4
EMI FCC Part 15, CISPR (EN55022) class A
EMS EN61000-4-2 (ESD), Level 2
EN61000-4-3 (RS), Level 3
EN61000-4-4 (EFT), Level 3
EN61000-4-5 (Surge), Level 3
EN61000-4-6 (CS), Level 3
EN61000-4-8
EN61000-4-11
EN61000-4-12
Shock IEC60068-2-27
Freefall IEC60068-2-32
Vibration IEC60068-2-6
WARRANTY 5 years
Technical Support Contact Information
www.moxa.com/support
Moxa Americas:
Toll-free: 1-888-669-2872
Tel: [phone]
Fax: [phone]
Moxa China (Shanghai office):
Toll-free: 800-820-5036
Tel: [phone]
Fax: [phone]
Moxa Europe:
Tel: [phone]
Fax: [phone]
Moxa Asia-Pacific:
Tel: [phone]
Fax: [phone]
