Moxa Technologies EtherDevice EDS-4008 Series User manual

P/N: 1802040080010
*1802040080010*
EDS-4008 Series
Quick Installation Guide
Moxa EtherDevice™ Switch
Version 1.0, March 2022
Technical Support Contact Information
www.moxa.com/support

2022 Moxa Inc. All rights reserved.

- 2 -
Package Checklist
The EDS-4008 Series industrial DIN-rail EtherDevice Switch (EDS) is
shipped with the following items. If any of these items are missing or
damaged, please contact your customer service representative for
assistance.
•1 EDS-4008 Ethernet switch
•Quick installation guide (printed)
•Warranty card
•Substance disclosure table
•Product certificate of quality inspection (Simplified Chinese)
•Product notices (Simplified Chinese)
NOTE
You can find information and software downloads on the
relevant product pages lo
cated on Moxa’s website:
www.moxa.com
Default Settings
•IP address: 192.168.127.253
•Subnet Mask: 255.255.255.0
•Username: admin
•Password: moxa
Panel Views of EDS-4008 Series
1. 100BaseT(X) LED indicator
2. 10BaseT(X) LED indicator
3. 10/100BaseT(X) ports, Ports
1
to 8
4. Grounding connector screw
5. Terminal blocks for power
input, digital input, and relay
output
6. LED indicators: STATE (S),
FAULT (F), PWR1 (P1), PWR2
(P2), MSTR/HEAD (M/H),
CPLR/TAIL (C/T), SYNC
7. Console port (RJ45, RS-232)
8. USB storage port (type A,
currently disabled)
9. Model name

- 3 -
1. 100BaseT(X) LED indicator
2. 10BaseT(X) LED indicator
3. 10/100BaseT(X) ports,
ports 3 to 8
4. 100BaseFX port (SC/ST
type), port 1 and 2
5. 100BaseFX LED indicator
6. Grounding connector
screw
7. Terminal blocks for power input,
digital input, and relay output
8. LED indicators: STATE (S),
FAULT (F), PWR1 (P1), PWR2
(P2), MSTR/HEAD (M/H),
CPLR/TAIL (C/T), SYNC
9. Console port (RJ45, RS-232)
10.
USB storage port (type A,
currently disabled)
11. Model name
1. 100BaseT(X) LED indicator
2. 10BaseT(X) LED indicator
3. 10/100BaseT(X) ports,
port 1 to 4
4. 10/100/1000BaseT(X)
ports, port G3 to G4
8. 100/1000BaseSFP LED indicator
9. Grounding connector screw
10.
Terminal blocks for power input,
digital input, and relay output
11.
LED indicators: STATE (S),
FAULT (F), PWR1 (P1), PWR2

- 4 -
5. 1000BaseT(X) LED
indicator
6. 10/100BaseT(X) LED
indicator
7. 100/1000BaseSFP ports,
port G1 to G2
(P2), MSTR/HEAD (M/H),
CPLR/TAIL (C/T), SYNC
12.
Console port (RJ45, RS-232)
13.
USB storage port (type A,
currently disabled)
14.
Model name
15.
SmartPoE LED indicator of PoE
ports
Bottom Panel View
1. microSD card slot
(currently disabled)
2. Reset button
3.
DIP switches for Turbo
Ring, Ring Master, and
Ring Coupler
Mounting Dimensions
EDS-4008(-T)/EDS-4008-2MSC(-T)/EDS-4008-2SSC(-T) Models

- 5 -
EDS-4008-2MST(-T) Models

- 6 -
EDS-4008-2GT-2GS(-T)/EDS-4008-4P-2GT-2GS(-T) Models
DIN-rail Mounting
The DIN-rail mounting kit is fixed to the back panel of the EDS device
when you take it out of the box. Mount the EDS device on corrosion-
free mounting rails that meet the EN 60715 standard.
Installation
STEP 1—Insert the upper lip of
the DIN r
ail into the DIN-rail
mounting kit.
STEP 2
—Press the EDS device
towards the
DIN rail
until it snaps
into place.

- 7 -
Removal
STEP 1
—Pull down the latch on
the mounting kit with a
screwdriver.
STEP 2
& 3—Slightly pull the
EDS device forward and lift up to
remove it from the DIN rail.
NOTE
Our DIN rai
l kit now
utilizes a quick release mechanism to make
it easier for users to remove the DIN rail from the EDS device.
Wall Mounting (Optional)
For some applications, you will find it convenient to mount the Moxa
EDS device on a wall, as shown in the following illustrations:
STEP 1—
Remove the DIN-rail
attachment pl
ate from the rear
panel of the EDS device,
as
illustrated
in the diagram on the
right
.
STEP 2—
Mounting the EDS device on a wall
requires
six screws. Use the EDS device, with wall
mount plates attached, as a guide to mark the
correct locations of the
six screws. T
he heads of the
screws should be less than 6.0 mm in diameter,
and the shafts should be less than 3.5
mm in
diameter, as shown in the figure on at right.
NOTE
Before tightening the screws into the wall, make sure the screw
head and shank size are suitable by inserting the screw through
one of the keyhole
-shaped apertures of the Wall Mounting
Plates.
NOTE
Do not screw the screws in all the way
—leave about 2 mm to
allow room for sliding the wall mount panel between the wall
and the screws.

- 8 -
STEP 3—Once the screws are
fixed
to the wall, insert the
four screw heads through the
wide parts of the keyhole
-
shaped apertures, and then
slide
the EDS device
downwards, as indicated
in
the figure
at the right.
Tighten the four screws for
more
stability.
Wiring Requirements
ATTENTION
Safety First!
External metal parts are hot. Take
the necessary precautions if
you are required to handle the device.
ATTENTION
In order to ensure reliable operations, please make sure the
operating temperature of the environment does not exceed the
specifications. When mounting an EDS device with other
operating units in a cabinet without forced ventilation, a
minimum of
4 cm spac
e on both the left and right of the switch
is recommended.
ATTENTION
Safety First!
Be sure to disconnect the power cord before installing and/or
wiring your EDS device. Calculate the maximum possible
current in each
power wire and common wire. Observe all
electrical codes dictating the maximum current allowable for
each wire size. If the current goes above the maximum ratings,
the wiring could overheat, causing serious damage to your
equipment.
Be sure to read and follow these important points below:
•Use separate paths to route wiring for power and devices. If power
wiring and device wiring paths must cross, make sure the wires are
perpendicular at the intersection point.

- 9 -
NOTE
Do not run signal or communications wiring and power wiring
through the same wire conduit. To avoid interference, wires
with different signal characteristics should be routed separately.
•You can use the type of signal transmitted through a wire to
determine which wires should be kept separate. The rule of thumb
is that wiring that shares similar electrical characteristics can be
bundled together.
•You should separate input wiring from output wiring.
•We advise that you label the wiring to all devices in your system.
Grounding the Moxa EDS Series
Grounding and wire routing help limit the effects of noise due to
electromagnetic interference (EMI). Run the ground connection from
the ground screw to the grounding surface prior to connecting devices.
ATTENTION
This product is intended to be mounted to a well
-grounded
mounting surface such as a metal panel.
Suggested Wire Type for Wiring Relay Contact
(RELAY), Digital Input (DI), and Power Inputs
(P1/P2)
The EDS device includes two 4-pins 3.5 mm pin-pitch terminal blocks.
When wiring the relay contact (RELAY), digital input (DI), and power
inputs (P1/P2), we suggest using the cable type – AWG 18-24 and the
corresponding pin type cable terminals.
NOTE
The wire must be able to withstand at least 105°C and the
torque value should be 4.5 lb-in (0.51 N-m).

- 10 -
NOTE
We suggest the length of the pin type cable terminal is 8 mm.
I
n order to tighten the wire properly, ①use a small flathead
screwdriver to press the push
-
in button beside each terminal of
the terminal block connector before and during
②
inserting the
wire.
③Release the screwdriver after the wire has been fully
insert
ed. Please refer to the diagram below.
Wiring the Relay Contact
The EDS device has one set of relay output. This relay contact uses two
contacts of the terminal block on the EDS’s power module. Refer to the
section for detailed instructions on how to connect the wires to the
terminal block connector, and how to attach the terminal block
connector to the terminal block receptor.
Relay:
The two contacts of
the 4-pin terminal
block connector are used to detect
user
-configured events. The two wires
attached to the
fault contacts form an
open circui
t when a user-configured
event is triggered or
there is no power
supply to the switch
. If a user-
configured event does not oc
cur, the
fault circuit remains closed.

- 11 -
Wiring the Redundant Power Inputs
The EDS device includes both high-voltage and low-voltage products.
For the low-voltage (LV models) products, there are two power inputs
for redundancy; for the high-voltage (HV models) products, there is
only one power input. Refer to the instructions and diagram below on
how to connect the wires to the terminal block connector on the
receptor.
STEP 1: Insert the Positive/Negative
DC or Line/Neutral AC wires
into the
V+/V
- or L/N terminals, respectively.
STEP 2:
To keep the DC or AC wires
from pulling loose, use a small flat
-
blade screwdriver to tighten the wire
-
clamp screws on the front of the
terminal block connector.
STEP 3:
Insert the plastic terminal
block connector prongs into the
terminal block receptor, which is
located on the EDS devices’ right side.
Wiring the Digital Inputs
The EDS device has one set of digital input (DI). The DI consists of two
contacts of the 4-pin terminal block connector on the EDS's right-side
panel. Refer to the instructions and diagram below on how to connect
the wires to the terminal block connector on the receptor.

- 12 -
STEP 1: Insert the negative
(ground)/positive DI wires into the
┴
/I terminals, respectively.
STEP 2:
To keep the DI wires from
pulling loose, use a small flat
-blade
screwdriver to tighten the wi
re-clamp
button
on the front of the terminal
block connector.
STEP 3:
Insert the plastic terminal
block connector prongs into the
terminal block receptor, which is
located on the EDS devices’ right side.
Rotating the Power Module
The power module for the EDS device can be rotated to make it easier
to fit your field site application.
Step 1:
Remove
the two screws that fasten the power module to the
EDS device
.
Step 2:
Remove the power module.
Step 3:
Turn the power module clockwise so that the power, digital
input, and relay output connectors can be moved upwards.
Step 4:
P
lace the module back on to the EDS device and then fasten
the
two screws on to the module.
Communication Connections
Each EDS-4008 Series switch has various types of communication
ports:
•RJ45 console port (RS-232 interface)
•USB storage port (type A connector, currently disabled)
•microSD card slot (currently disabled)
•10/100BaseTX Ethernet ports
•100BaseFX (SC/ST-type connector) fiber ports
•10/100/1000BaseT(X) Ethernet ports
•100/1000BaseSFP ports
Console Port Connection
The EDS device has one RJ45 console port (RS-232), located on the
front panel. Use either an RJ45-to-DB9 (see the cable following wiring
diagrams) to connect the EDS’s console port to your PC’s COM port.
You may then use a console terminal program, such as Moxa PComm
Terminal Emulator, to access the EDS that has a baud rate of 115200.

- 13 -
RJ45 Console Port Pinouts
Pin
Description
1
DSR
2
RTS
3
–
4
TxD
5
RxD
6
GND
7
CTS
8
DTR
USB Connection
NOTE
The USB function is currently reserved and may be required in
the
future. It should be noted that this port cannot be used for
charging any devices.
10/100BaseT(X) Ethernet Port Connection
The 10/100BaseT(X) ports located on the front panel of the switch are
used to connect to Ethernet-enabled devices. Most users will choose to
configure these ports for Auto MDI/MDI-X mode, in which case the
port’s pinouts are adjusted automatically depending on the type of
Ethernet cable used (straight-through or cross-over), and the type of
device (NIC-type or HUB/Switch-type) connected to the port.
In what follows, we give pinouts for both MDI (NIC-type) ports and
MDI-X (HUB/Switch-type) ports. We also give cable wiring diagrams for
straight-through and cross-over Ethernet cables.
10/100Base T(x) RJ45 Pinouts
MDI Port Pinouts
MDI-X Port Pinouts
8-pin RJ45
Pin
Signal
1
Tx+
2
Tx-
3
Rx+
6
Rx-
Pin
Signal
1
Rx+
2
Rx-
3
Tx+
6
Tx-
RJ45 (8-pin) to RJ45 (8-pin) Straight-Through Cable Wiring

- 14 -
RJ45 (8-pin) to RJ45 (8-pin) Cross-Over Cable Wiring
100BaseFx Ethernet Port Connection
The concept behind the SC/ST port and cable is quite straightforward.
Suppose you are connecting devices I and II. As opposed to electrical
signals, optical signals do not require a circuit in order to transmit data.
Consequently, one of the optical lines is used to transmit data from
device I to device II, and the other optical line is used transmit data
from device II to device I, for full-duplex transmission.
All you need to remember is to connect the Tx (transmit) port of device
I to the Rx (receive) port of device II, and the Rx (receive) port of
device I to the Tx (transmit) port of device II. If you are making your
own cable, we suggest labeling the two sides of the same line with the
same letter (A-to-A and B-to-B, as shown by the following illustration,
or A1-to-A2 and B1-to-B2).
SC-Port Pinouts
SC-Port to SC-Port Cable Wiring
ST-Port Pinouts
ST-Port to ST-Port Cable Wiring
ATTENTION
This is a Class 1 Laser/LED product. To prevent damage to your
eyes, do not stare directly into the laser beam.

- 15 -
1000BaseT(X) Ethernet Port Connection
1000BaseT(X) data is transmitted on differential TRD+/- signal pairs
over copper wires.
MDI/MDI-X Port Pinouts
Pin
Signal
1
TRD(0)+
2
TRD(0)-
3
TRD(1)+
4
TRD(2)+
5
TRD(2)-
6
TRD(1)-
7
TRD(3)+
8
TRD(3)-
100/1000BaseSFP (mini-GBIC) Fiber Port
The Gigabit Ethernet fiber ports on the switch are 100/1000BaseSFP
fiber ports, which require using 100M or 1G mini-GBIC fiber
transceivers to work properly. Moxa provides a complete selection of
transceiver models for different distance requirements.
The concept behind the LC port and cable is straightforward. Suppose
you are connecting devices I and II; contrary to electrical signals,
optical signals do not require a circuit in order to transmit data.
Consequently, one of the optical lines is used to transmit data from
device I to device II, and the other optical line is used transmit data
from device II to device I, for full-duplex transmission.
Remember to connect the Tx (transmit) port of device I to the Rx
(receive) port of device II, and the Rx (receive) port of device I to the
Tx (transmit) port of device II. If you make your own cable, we suggest
labeling the two sides of the same line with the same letter (A-to-A and
B-to-B, as shown below, or A1-to-A2 and B1-to-B2).
LC-Port Pinouts
LC-Port to LC-Port Cable Wiring
ATTENTION
This is a Class 1 Laser/LED product. To avoid causing serious
damage to your eyes, do not stare directly into the Laser Beam.

- 16 -
Reset Button
There are two functions available on the Reset Button. One is to reset
the Ethernet switch to factory default settings by pressing and holding
the Reset button for 5 seconds. Use a pointed object, such as a
straightened paper clip or toothpick, to depress the Reset button. This
will cause the STATE LED to blink once a second. After depressing the
button for 5 continuous seconds, the STATE LED will start to blink
rapidly. This indicates that factory default settings have been loaded
and you can release the reset button. The other function is to reboot
the device by depressing reset button for less than five seconds.
Turbo Ring DIP Switch Settings
The EDS devices are plug-and-play managed redundant Ethernet
switches. The proprietary Turbo Ring protocol was developed by Moxa
to provide better network reliability and faster recovery time. Moxa
Turbo Ring’s recovery time is less than 50 ms (Turbo Ring V2) —
compared to a 3- to 5-minute recovery time for commercial switches—
decreasing the possible loss caused by network failures in an industrial
setting.
There are five Hardware DIP Switches for Turbo Ring on the bottom
panel of the EDS device that can help setup the Turbo Ring easily
within seconds. If you do not want to use a hardware DIP switch to
setup the Turbo Ring, you can use a web browser, telnet, or console to
disable this function.
NOTE
Please refer to the Turbo Ring section in User's Manual for
more detail inform
ation about the setting and usage of Turbo
Ring V2.
Turbo Ring DIP Switch Settings
The default setting for each DIP Switch is OFF. The
following table explains the effect of setting the DIP
Switch to the ON position
.
Remove the rubber cover on the
bottom panel of
the device
to expose the DIP switches.
DIP Switch Settings
DIP 1
DIP 2
DIP 3
DIP 4
DIP 5
Reserved
for future
use
ON: Enables the
default “Ring
Coupling
(backup)” port
when DIP switch 4
is already enabled.
ON:Enables
this EDS as
the Ring
Master.
ON:
Enables the
default
“Ring
Coupling”
port.
ON:Activates
DIP switch 2,
3, and 4 to
configure
Turbo Ring V2
settings.
OFF:
Enables the
default Ring
Coupling (primary)
port when DIP
switch 4 is already
enabled.
OFF:
This
EDS will not
be the Ring
Master.
OFF:
This
EDS will not
be the Ring
Coupler.
OFF:
DIP
switch 2, 3,
and 4 will be
disabled.

- 17 -
NOTE
You must enable the Turbo Ring (DIP switch 5) first before
using the DIP switch to activate the Master and Coupler
functions.
NOTE
If you do not enable any of t
he EDS switches to be the Ring
Master, the Turbo Ring protocol will
automatically choose the
EDS switch
with the smallest MAC address range to b
e the Ring
Master. If you accidentally enable more
than one switch to be
the Ring Master, these switches will auto
-negotiate to
determine which one will be the Ring Master.
LED Indicators
The front panel of the Moxa EDS-4008 Series contains several LED
indicators. The function of each LED is described in the following table:
Device LED Indicators
LED
Color
State
Description
STATE
Green
On
When system has passed power-
on self-test (POST) and is ready
to run.
Blinking
(1 time/sec)
Press the reset button for five
seconds to reset to factory default
settings
Blinking
(4 times/sec)
When pressing the reset button
depress for 5 seconds to reset to
factory default.
Off
N/A
Red On
The system has initially failed the
boot-up process
•System Info. Read Fail or
EEPROM information error
FAULT Red
On
1. The relay contact has been
triggered
2. The ingress rate limit has
been exceeded and the port
has entered shut down mode
3. Invalid Ring port connection
Off
When the system boots up and
runs correctly or a user-
configured event is not triggered.
P1 Amber
On
Power is being supplied to power
input PWR.
Off
Power is not being supplied to
power input PWR.
P2 Amber
On Power is being supplied to power
input PWR.
Off
Power is not being supplied to
power input PWR.

- 18 -
LED
Color
State
Description
MSTR/
HEAD
(M/H)
Green
On
When the switch is
Master/Head/Root of Turbo
Ring/Turbo Chain/Fast RSTP.
Blinking
(4 times/sec)
1. The switch has become the
Master of Turbo Ring after
Turbo Ring has gone down
2. The switch is set as Head of
Turbo Chain and Turbo Chain
has gone down
3. The switch is set as the Turbo
Ring’s Member and the
corresponding Ring port is
down
4. The switch is set as the Turbo
Chain’s Member/Tail and the
corresponding Head-end
Chain port is down.
Off
When the switch is not the
Master/Head/Root of this Turbo
Ring/ Turbo Chain/Fast RSTP.
CPLR/
TAIL Green
On
1. The switch’s ring coupling or
dual homing function is
enabled.
2. The
switch is set as the Tail of
Turbo Chain.
Blinking
(4 times/sec)
1.
The switch is set as the Tail of
Turbo Chain and the Chain
has gone down.
2. The switch is set as the Turbo
Chain’s Member/Head and the
corresponding Tail-end Chain
port is down.
Off
When the switch disables the
coupling or tail role of Turbo
Chain.
System
LED
(Except
PWR)
Green +
Amber +
Red
Blinking
(2 times/sec)
The switch is being
discovered/located by the locator
function.
System
LED
(Except
PWR)
Green +
Amber +
Red
Rotate
On -> Off
Sequentially
The switch is importing/exporting
a file via ABC-02-USB or SD card.
(currently disabled)

- 19 -
Smart PoE LED Indicators
LED
Color
State
Description
Smart
PoE+ LED
Indicators
Green
On
When the port is connected to
IEEE 802.3bt powered device
and powered at:
•Single signature (PD) Class
5 to 8
•Dual signature (PD) Class 1
to 5
Off
1. When the power is not being
supplied to a powered
device (PD)
2. The port is not connected to
an IEEE 802.3bt powered
device
Amber
On
When the port is connected to
IEEE 802.3af/at powered device
and powered at:
•Single signature (PD) 0 to 4
Blinking
(4 times/sec)
The PoE power supply has been
shut off because of low power
budget.
Off
1. Power is not being supplied
to the powered device (PD)
2. The port is not connected to
an IEEE 802.3af/at standard
PD
Red
On
Powered device (PD) detection
failure
Blinking
(4 times/sec)
Overcurrent or short circuit has
occurred on the powered Device
(PD)
Off
PoE is operating normally
Ports LED Indicators
LED
Color
State
Description
10M/
100M
Copper
top LED
Green
On
When the port is active and links
at 100Mbps.
Blinking
(4 times/sec)
When the port’s data is being
transmitted at 100Mbps.
Off
When the port is inactive or link
down.
10M/
100M
Copper
bottom
LED
Amber
On
When the port is active and links
at 10Mbps.
Blinking
(4 times/sec)
When the port’s data is being
transmitted at 10Mbps.
Off
When the port is inactive or link
down.
10M/
100M/
1000M
Copper
Green
On
When the port is active and links
at 1000Mbps.
Blinking
(4 times/sec)
When the port’s data is being
transmitted at 1000Mbps.

- 20 -
LED
Color
State
Description
top LED
Off When the port is inactive or link
down.
10M/
100M/
1000M
Copper
bottom
LED
Amber
On
When the port is active and links
at 10/100Mbps.
Blinking
(4 times/sec)
When the port’s data is being
transmitted at 10/100Mbps.
Off When the port is inactive or link
down.
100M
Fiber LED
Green
On
When the port’s data is being
transmitted at 100Mbps.
Blinking
(4 times/sec)
When the port’s data is being
transmitted at 100Mbps.
Off When the port is inactive or link
down.
100M/
1000M
(SFP
port)
Green
On
When the port is active and links
at 1,000Mbps.
Blinking
(4 times/sec)
When the port’s data is being
transmitted at 1,000Mbps.
Off When the port is inactive or link
down.
Amber
On
When the port is active and links
at 100Mbps.
Blinking
(4 times/sec)
When the port’s data is being
transmitted at 100Mbps.
Off
When the port is inactive or link
down.
Specifications
Interface
RJ45 Ports
10/100BaseT(X) or 10/100/1000BaseT(X)
Fiber Ports
100BaseFx
100/1000BaseSFP
Console Port
RS-232 (RJ45)
Button
Reset button
LED Indicators
STATE (S), FAULT (F), PWR1 (P1), PWR2 (P2),
MSTR/HEAD (M/H), CPLR/TAIL (C/T), SYNC
Alarm Contact 1 normally open electromagnetic relay output with
current carrying capacity of 1 A @ 24 VDC
Digital Input
1 isolated digital input:
+13 to +30V for state “1”
-30 to +3V for state “0”
Max. input current: 8 mA
PoE
CAUTION: When it is necessary to connect the PoE ports of a Power
Bypass (-LVA) model to a Power Boost (-LVB) model within the same
system, do not use the same power supply to power both models.
Total Power Budget Power Bypass (-LVA model): 240 W @ 48 VDC
power input
Power Boost (-LVB model): 62 W @ 12 VDC, 150
W @ 24 VDC (120 W for -T model), 180 W @ 48
VDC
PoE Output Voltage
55 VDC
