Moxa Technologies AirWorks AWK-3131A User manual

P/N: 1802031311017
*1802031311017*
AWK-3131A
Quick Installation Guide
Moxa AirWorks
Edition 7.1, October 2018
Technical Support Contact Information
www.moxa.com/support
Moxa Americas:
Toll
-free: 1-888-669-2872
Tel:
1-714-528-6777
Fax:
1-714-528-6778
Moxa China (Shanghai office):
Toll
-free: 800-820-5036
Tel:
[phone]
Fax:
[phone]
Moxa Europe:
Tel:
[phone]
Fax:
[phone]
Moxa Asia-Pacific:
Tel:
[phone]
Fax:
[phone]
Moxa India:
Tel:
[phone]
Fax:
[phone]

2018 Moxa Inc. All rights reserved.

- 2 -
Table of Contents
Overview............................................................................... - 3 -
Hardware Setup .................................................................... - 3 -
Package Checklist ............................................................... - 3 -
Panel Layout of the AWK-3131A ........................................... - 4 -
Mounting Dimensions .......................................................... - 5 -
DIN-Rail Mounting .............................................................. - 5 -
Wall Mounting (Optional) ..................................................... - 6 -
Wiring Requirements........................................................... - 7 -
Read and Follow These Guidelines: ....................................... - 7 -
Grounding the AWK-3131A .................................................. - 8 -
Installations with Cable Extended Antennas for Outdoor
Applications ................................................................. - 8 -
Wiring the Redundant Power Inputs ...................................... - 9 -
Wiring the Relay Contact ..................................................... - 9 -
Wiring the Digital Inputs.....................................................- 10 -
Cable Holder Installation ....................................................- 10 -
Communication Connections ...............................................- 10 -
10/100BaseT(X) Ethernet Port Connection ......................- 10 -
1000BaseT Ethernet Port Connection..............................- 11 -
RS-232 Connection ......................................................- 11 -
LED Indicators ..................................................................- 12 -
Specifications....................................................................- 13 -
Software Setup ................................................................... - 15 -
How to Access the AWK......................................................- 15 -
First-Time Quick Configuration ............................................- 16 -
Point-to-Multipoint Scenario (AP/Client Mode) .................- 16 -
Point-to-Point Scenario (Master/slave mode) ...................- 18 -

- 3 -
Overview
The AWK-3131A 3-in-1 industrial wireless access point meets the growing
need for faster data transmission speeds and wider coverage by
supporting IEEE 802.11n technology with a net data rate of up to 300
Mbps. The AWK-3131A combines two adjacent 20 MHz channels into a
single 40 MHz channel to deliver a potent combination of greater
reliability and more bandwidth. The two redundant DC power inputs
increase the reliability of the power supply, and the AWK-3131A can be
powered via PoE to make deployment easier. The AWK-3131A can
operate on either the 2.4 or the 5 GHz band and is backwards-compatible
with existing 802.11a/b/g deployments.
Hardware Setup
This section covers the hardware setup for the AWK-3131A.
Package Checklist
Moxa’s AWK-3131A is shipped with the following items. If any of these
items is missing or damaged, please contact your customer service
representative for assistance.
•1 AWK-3131A wireless AP/client
•2 2.4/5 GHz antennas: ANT-WDB-ARM-0202
•DIN-rail kit
•2 plastic RJ45 protective caps
•Cable holder with one screw
•Quick installation guide (printed)
•Warranty card

- 4 -
Panel Layout of the AWK-3131A
1. Grounding screw (M5)
2. Terminal block for PWR1,PWR2,
relay, DI1, and DI2
3. Reset button
4. System LEDs: PWR1, PWR2, PoE,
FAULT, and STATE LEDs
5. LEDs for signal strength
6. WLAN LED
7. Ethernet LED
8. RS-232 console port
9. LAN: 10/100/1000 BaseT(X) RJ45
Port
10.
Antenna A
11.
Antenna B
12.
Model name
13.
Screw holes for wall-mounting kit
14.
DIN-rail mounting kit

- 5 -
Mounting Dimensions
Unit = mm
DIN-Rail Mounting
The aluminum DIN-rail attachment plate should be fixed to the back panel
of the AWK-3131A when you take it out of the box. If you need to reattach
the DIN-rail attachment plate to the AWK-3131A, make sure the stiff
metal spring is situated towards the top, as shown in the figures below.
STEP 1:
Insert the top of the DIN rail into
the
slot just below the stiff metal spring.
STEP 2:
The DIN
-rail attachment unit will
snap into place as shown below.
To remove the AWK-3131A from the DIN rail, reverse Steps 1 and 2.

- 6 -
Wall Mounting (Optional)
For some applications, it may be more convenient to mount the
AWK-3131A to a wall, as illustrated below.
STEP 1:
Remove the aluminum
DIN
-rail attachment plate
from the AWK
-3131A, and
then attach the
wall
-mounting plates with
M3 screws, as shown in the
adjacent diagrams.
STEP 2:
Mounting the AWK
-3131A to a wall requires 3 screws.
Use
the AWK-3131A device, with wall-mounting plates
attached, as a guide to mark the correct locations of the
3 screws. The heads of the screws should be less than 6.0
mm in diameter, and the
shafts should be less than 3.5
mm in diameter, as shown in the figure on the right.
Do not drive the screws in all the way—leave a space of about 2 mm to
allow room for sliding the wall-mounting panel between the wall and the
screws.
NOTE
Test the screw head and shank size by inserting the screws
into
one of the keyhole shaped apertures of the wall
-
mounting plates
before they are fixed to the wall.
STEP 3:
Once the screws are fixed into the wall,
insert the four screw heads through
the large opening of the
keyhole
-shaped apertures, and then
slide the AWK
-3131A downwards, as
indicated to the right. Tighten the
three screws for added stability.

- 7 -
WARNING
•
This equipment is intended to be used in a
Restricted Access
Location, such as a dedicated computer room where only
authorized service personnel or users can gain access.
Such
personnel must be instructed about the fact that the metal
chassis of the equipment is extremely hot and may cause
burns.
•
Service personnel
or users have to pay special attention and
take special precautions before handling this equipment.
•
Only authorized, well-
trained professionals should be allowed
to access the restricted access location. Access should be
controlled by the authority responsible for the location with
lock and key or a security identity system.
•
External metal parts are hot!! Pay special attention or
use
special protection before handling the equipment.
Wiring Requirements
WARNING
Safety First!
Be sure to disconnect the power cord before installing and/or
wiring your AWK
-3131A.
Calculate the maximum possible current in each power wire and
common wire. Observe all electrical codes
that dictate the
maximum current allowed for each wire size. If the current goes
above the maximum ratings, the wiring could overheat, causing
serious damage to your equipment.
Read and Follow These Guidelines:
•Use separate paths to route wiring for power and devices. If power
wiring and device wiring paths must cross, make sure the wires are
perpendicular at the crossing point.
NOTE
Do not run signal or communications wiring and power wiring in
the same wire conduit. To avoid interference, wires with different
signal characteristics should be routed separately.
•You can use the type of signal transmitted through a wire to
determine which wires should be kept separate. The rule of thumb is
that wiring that shares similar electrical characteristics can be
bundled together.
•Keep input wiring and output wiring separated.
•For future reference, you should label the wiring used for all of your
devices.
ATTENTION
This product is
intended to be supplied by a Listed Power Unit
marked “Class 2” or “LPS” and rated O/P: 7.2 W

- 8 -
ATTENTION
Make sure
the external power adapte
r (includes power cords and
plug assemblies) provided with the unit is certified and suitable
for use in your country.
ATTENTION
DO NOT
use a
PoE Injector. Instead, use an IEEE 802.3af or IEEE
802.3at compliant PSE (Power Sourcing Equipment) for PoE
(Power over Ethernet) devices.
Grounding the AWK-3131A
Grounding and wire routing help limit the effects of noise due to
electromagnetic interference (EMI). Run the ground connection from the
ground screw to the grounding surface prior to connecting devices.
ATTENTION
This product is intended to be mounted to a well
-grounded
mounting surface, such as a metal panel.
The
potential difference
between any two
grounding points
must be zero. If the potential
difference is NOT zero, the product could be permanently
damaged.
Installations with Cable Extended Antennas for Outdoor
Applications
If an AWK device or its antenna is installed in an outdoor location, proper
lightning protection is required to prevent direct lightning strikes to the
AWK device. In order to prevent the effects of coupling currents from
nearby lightning strikes, a lightning arrester should be installed as part of
your antenna system. Ground the device, antenna, as well as the arrester
properly to provide maximum outdoor protection for the device.

- 9 -
Arrester Accessories
•SA-NMNF-01: Surge arrester, N-type (male) to N-type (female)
•SA-NFNF-01: Surge arrester, N-type (female) to N-type (female)
Wiring the Redundant Power Inputs
The top two pairs of contacts of the 10-contact terminal block connector
on the AWK-3131A’s top panel are used for the AWK-3131A’s two DC
inputs. Top and front views of the terminal block connector are shown
below.
STEP 1: Insert the negative/positive DC wires
into the
V-/V+ terminals.
STEP 2:
To keep the DC wires from pulling
loose,
use a small flat
-
blade screwdriver to tighten the
wire
-clamp screws on the front of the terminal
block connector.
STEP 3:
Insert the plastic terminal block
connector prongs into the terminal block
receptor, which is
located on the AWK-3131A’s
t
op panel.
NOTE
Input Terminal Block (CN1) is suitable for wire size range of
12
-28 AWG (3.31-0.0804 mm²) and a torque value of 4.5 lb-in
(0.51 Nm).
ATTENTION
If the AWK
-
3131A is connected to a motor or other similar type of
equipment, be sure to use power isolation protection. Before
connecting the
AWK-3131A to the DC power inputs, make sure
the DC power source voltage is stable.
Wiring the Relay Contact
The AWK-3131A has one relay output, which consists of the two contacts
of the terminal block on the AWK-3131A’s top panel. Refer to the previous
section for detailed instructions on how to connect the wires to the
terminal block connector, and how to attach the terminal block connector
to the terminal block receptor. These relay contacts are used to indicate
user-configured events. The two wires attached to the Relay contacts
form an open circuit when a user-configured event is triggered. If a
user-configured event does not occur, the Relay circuit will be closed.

- 10 -
Wiring the Digital Inputs
The AWK-3131A has two sets of digital inputs—DI1 and DI2. Each DI
comprises two contacts of the 10-pin terminal block connector on the
AWK-3131A’s top panel. Refer to the “Wiring the Redundant Power Inputs”
section for detailed instructions on how to connect the wires to the
terminal block connector, and how to attach the terminal block connector
to the terminal block receptor.
Cable Holder Installation
Attach the cable holder to the bottom of the AWK-3131A to keep cabling
neat and avoid accidents that result from untidy cables.
STEP 1: Screw the cable holder onto the bottom
of the AWK
-3131A.
STEP 2:
After mounting the AWK-
3131A and plugging in the LAN cable,
tighten the cable along the device and wall.
Communication Connections
10/100BaseT(X) Ethernet Port Connection
The 10/100BaseT(X) ports located on the AWK-3131A’s front panel are
used to connect to Ethernet-enabled devices.
Below we show pinouts for both MDI (NIC-type) ports and MDI-X
(HUB/switch-type) ports.
MDI Port Pinouts
MDI-X Port Pinouts
8-pin RJ45
Pin
Signal
1
Tx+
2
Tx-
3
Rx+
6
Rx-
Pin
Signal
1
Rx+
2
Rx-
3
Tx+
6
Tx-

- 11 -
1000BaseT Ethernet Port Connection
1000BaseT data is transmitted on differential TRD+/- signal pairs over
copper wires.
MDI/MDI-X Port Pinouts
Pin
Signal
1
TRD(0)+
2
TRD(0)-
3
TRD(1)+
4
TRD(2)+
5
TRD(2)-
6
TRD(1)-
7
TRD(3)+
8
TRD(3)-
RS-232 Connection
The AWK-3131A has one RS-232 (8-pin RJ45) console port located on the
front panel. Use either an RJ45-to-DB9 or RJ45-to-DB25 cable to connect
the AWK-3131A’s console port to your PC’s COM port. You may then use
a console terminal program to access the AWK-3131A for console
configuration.
Console Pinouts for 10-pin or 8-pin RJ45 Ports
10-Pin
Description
8-Pin
1
–
2
DSR
1
3
RTS
2
4
GND
3
5
TxD
4
6
RxD
5
7
DCD
6
8
CTS
7
9
DTR
8
10
–
NOTE
1. The pin numbers for DB9 and DB25 male connectors, and
hole numbers for DB9 and DB25 female connectors are
labeled on the connector strip. However, the numbers are
typically quite small, so you may need to use a magnifying
glass to see the numbers clearly.
2. The pin numbers for both the 8-pin and 10-pin RJ45
connectors (and ports) are typically not labeled on the
connector (or port). Refer to the pinout diagram above for
details.

- 12 -
LED Indicators
The front panel of the AWK-3131A contains several LED indicators. The
function of each LED is described in the table below:
LED
Color
State
Description
Front Panel LED Indicators (System)
PWR1 Green
On
Power is on (power input 1)
Off
Power is not being supplied.
PWR2 Green
On
Power is on (power input 2)
Off
Power is not being supplied.
PoE Amber
On
Power is being supplied via the PoE.
Off
Power is not being supplied via PoE.
FAULT Red
On
System is booting up, or a system
configuration error or relay event has
occurred.
Blinking
(fast at
0.5-
second
intervals)
Cannot get an IP address from the
DHCP server.
Blinking
(slow at
1-second
intervals)
IP address conflict
Off
Error condition does not exist.
STATE Green
On System startup is complete and the
system is in operation.
Blinking
(fast at
0.5-
second
intervals)
AeroLink Protection is enabled and is
currently in “Backup” state.
Blinking
(slow at
1-second
intervals)
Device has been located by Wireless
Search Utility
Red
On
System is booting up
SIGNAL
(5 LEDs)
Green
On
Wi-Fi Signal Level (for client/slave/
client-router modes only)
Off
WLAN
Green
On
WLAN function is in client/slave/
client-router mode and has established
a link with an AP.
Blinking
WLAN data transmission is in
client/slave/client-router mode.
Off
WLAN is not in client/slave/
client-router mode or has not
established a link with an AP.
Amber
On
WLAN is in AP/master mode.
Blinking
WLAN data transmission is in AP/master
mode.
Off WLAN is not in use or not working
properly

- 13 -
LED
Color
State
Description
LAN
Green
On
LAN port’s 1000 Mbps link is active.
Blinking
Data is being transmitted at 1000 Mbps.
Off
LAN port’s 1000 Mbps link is inactive.
Amber
On
LAN port’s 10/100 Mbps link is active.
Blinking
Data is being transmitted at 10/100
Mbps.
Off
LAN port’s 10/100 Mbps link is inactive.
Specifications
Input Current
0.6 A @ 12 VDC; 0.15 A @ 48 VDC
Input Voltage
12 to 48 VDC, redundant dual DC power inputs
or 48 VDC Power-over-
Ethernet (IEEE 802.3af
compliant)
Power Consumption
7.2 W
Operating Temperature
Standard Models: -25 to 60°C (-13 to 140°F)
Wide Temp. Models: -40 to 75°C (-40 to
167°F)
Storage Temperature
-40 to 85°C (-40 to 185°F)
ATTENTION
The AWK
-3131A is NOT a portable mobile device and
should be
located at least 20 cm away from the human body.
The AWK
-3131A is NOT designed for the general public. To
en
sure that your AWK-3131A wireless network is safe and
configured correctly, consult a well
-trained technician to assist
with the installation process.
ATTENTION
Use the
appropriate antennas for your wireless setup: Use 2.4
GHz antennas when the AWK
-3131A is configured for IEEE
802.11b/g/n.
Use 5 GHz antennas when the AWK-3131A is
configured for
IEEE802.11a/
n. Make sure that the antennas are
located in an area with a lightning and surge protection system
installed.
ATTENTION
This device complies with part 15 of the FCC Rules.
Operation i
s
subject to the following
two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received,
including interference that may cause undesired operation.

- 14 -
ATTENTION
Do not locate the antenna near overhead
power lines or other
electric light or power circuits, or where it can come into contact
with such circuits. When installing the antenna, take extreme
care not to come into contact with such circuits, because they
may cause serious injury or death. For pro
per installation and
grounding of the antenna, refer to national and local codes (for
example, U.S.: NFPA 70;
National Electrical Code (NEC) Article
810; Canada: Canadian Electrical Code, Section 54).
NOTE
For installation flexibility, either the A ante
nna (on the front
panel) or the
B antenna (on the top panel) may be selected for
use. Make sure the antenna connection matches the antenna
s
configured in the AWK
-3131A web interface.
To protect the connectors and RF module, all radio ports should
be termin
ated by either an antenna or a terminator.
We strongly
recommend using resistive terminators for terminating the
unused antenna ports.
ATTENTION
For EXPLOSION
-PROOF applications, the AWK-
3131A is designed
and certified to
meet ATEX and C1D2
requirements; it should be
mounted in a suitable enclosure rated to at least IP54
in
accordance with IEC/EN 60079
-
15 and accessible only by the use
of a tool
and Pollution Degree 2 as defined in EN 60529
or IEC/EN
60664
-1 and used within its rated electrical and environmental
ratings.
When the AWK
-
3131A is installed in an enclosure, the antennas
must remain internal to the enclosure and not external. External
antenna deployment is allowed only if the antennas are certified
by C1D2, ATEX
Zone 2 or IECEx.
The AWK
-3131A devices are open-
type devices that are provided
with a tool
-removable cover or door that make these devices
suitable for installation inside an enclosed environment.
This equipment is suitable for use only in Class I, Divisio
n 2,
Groups A, B, C, and D or non-hazardous locations.
WARNING
EXPLOSION HAZARD
Do not disconnect equipment unless power has been removed or
the area is known to be non-hazardous.

- 15 -
WARNING
EXPLOSION HAZARD
Substitution of any component may impair suitability for Class I,
Division 2.
Software Setup
This section covers the software setup for the AWK-3131A.
How to Access the AWK
Before installing the AWK device (AWK), make sure that all items in the
package checklist are provided in the product box. You will also need
access to a notebook computer or PC equipped with an Ethernet port.
•Step 1: Select a suitable power source and plug in the AWK.
The AWK can be powered by DC power ranging from 12 VDC to 48
VDC or by a PoE PSE via an Ethernet connection.
•Step 2: Connect the AWK to the notebook or PC via the AWK’s
LAN port.
The LED indicator on the AWK’s LAN port will light up when a
connection is established.
NOTE
If you are using an Ethernet-to-USB adapter, follow the
instructions in the user’s manual provided with the adapter.
•Step 3: Set up the computer’s IP address
Choose an IP address for the computer that is on the same subnet as
the AWK. Since the AWK’s default IP address is 192.168.127.253,
and the subnet mask is 255.255.255.0, set the IP address to
192.168.127.xxx, where xxx is a value between 1 and 252.
•Step 4: Access the homepage of the AWK.
Open your computer’s web browser and type
http://192.168.127.253 in the address field to access the AWK’s
homepage. Log in using the following default username and
password:
Default Username: admin
Default Password: moxa
Click the Login button to access the homepage of the AWK device.

- 16 -
First-Time Quick Configuration
After successfully accessing the AWK, refer to the appropriate subsection
below to quickly set up a wireless network.
NOTE
Ensure that there are no IP address conflicts when you configure
more than one AWK on the same subnet.
Point-to-Multipoint Scenario (AP/Client Mode)
Configuring the AWK as an AP
•Step 1: Set the operation mode of the AWK to AP mode.
Go to Wireless LAN Setup Operation Mode and select AP.
NOTE
The default operation mode for the AWK is AP.
•Step 2: Set up your own SSID.
Go to Wireless LAN Setup WLAN Basic WLAN Setup and
click Edit to set the SSID.
NOTE
The default SSID is MOXA.

- 17 -
•Step 3: Set the RF type and Channel for the AWK.
Go to Wireless LAN Setup WLAN Basic WLAN Setup.
We recommend that you choose the RF type 5 GHz for a relative clean
medium with minimum interference.
For the Channel setting, we recommend that you choose a channel
other than the default channel to avoid interference.
Click Submit to apply the changes, and restart the AWK in AP mode
to complete the configuration process.
Configuring the AWK as a Client
•Step 1: Set the operation mode of the AWK to Client mode.
Go to Wireless LAN Setup Operation Mode, set the operation
mode to Client, and then click Submit to apply the change.
•Step 2: Link to an existing SSID.
Go to Wireless LAN Setup WLAN Basic WLAN Setup and
click Site Survey to select an existing SSID, or directly enter an
existing SSID in the text field.

- 18 -
•Step 3: Set the RF type and Channel settings for the AWK.
On the Wireless LAN Setup WLAN Basic WLAN Setup page,
edit the RF type and Channel settings.
Click Submit to apply the changes, and restart the AWK in client
mode to complete the configuration process.
Point-to-Point Scenario (Master/slave mode)
Configuring the AWK as a Master
•Step 1: Set the operation mode of the AWK to Master mode.
Go to Wireless LAN Setup Operation Mode, set the operation
mode to Master, and then click Submit to apply the change.
•Step 2: Set up your own SSID.
Go to Wireless LAN Setup WLAN Basic WLAN Setup and
click Edit to set the SSID.
•Step 3: On the Wireless LAN Setup WLAN Basic WLAN
Setup page edit the RF type and Channel settings.
Click Submit to apply the changes, and restart the AWK in master
mode to complete the configuration process.

- 19 -
Configuring the AWK as a Slave
•Step 1: Set the operation mode of the AWK to Slave mode.
Go to Wireless LAN Setup Operation Mode, set the operation
mode to Slave, and then click Submit to apply the change.
•Step 2: Link to an existing SSID.
Go to Wireless LAN Setup WLAN Basic WLAN Setup and
click Site Survey to select an existing SSID, or directly enter an
existing SSID in the text field.
•Step 3: Set the RF type for the AWK.
On the Wireless LAN Setup WLAN Basic WLAN Setup page
edit the RF type setting.
Click Submit to apply the changes, and restart the AWK in slave
mode to complete the configuration process.
