MSI MEGA651 PC User manual

i

ii
FCC-B Radio Frequency Interference Statement
This equipment has been tested and found to comply with the limits for a class B
digital device, pursuant to part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment
is operated in a commercial environment. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to
cause harmful interference, in which case the user will be required to correct the
interference at his own expense.
Notice 1
The changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
Notice 2
Shielded interface cables and AC. power cord, if any, must be used in order to
comply with the emission limits.
VOIR LA NOTICE D’INSTALLATION AVANT DE RACCORDER AU RESEAU.
Micro-Star International MS-6251
Tested to comply
with FCC Standard
For Home or Office Use

iii
Copyright Notice
The material in this document is the intellectual property of MICRO-STAR
INTERNATIONAL. We take every care in the preparation of this document, but
no guarantee is given as to the correctness of its contents. Our products are
under continual improvement and we reserve the right to make changes with-
out notice.
Trademarks
All trademarks are the properties of their respective owners.
Intel®and Pentium®are registered trademarks of Intel Corporation.
PS/2 and OS®/2 are registered trademarks of International Business Machines
Corporation.
Windows®95/98/2000/NT/XPareregisteredtrademarksofMicrosoftCorporation.
Netware®is a registered trademark of Novell, Inc.
Award®is a registered trademark of Phoenix Technologies Ltd.
AMI®is a registered trademark of American Megatrends Inc.
Revision History
Revision Revision History Date
V1.0 First release April 2003

iv
Safety Instructions
1. Always read the safety instructions carefully.
2. Keep this User’s Manual for future reference.
3. Keep this equipment away from humidity.
4. Lay this equipment on a reliable flat surface before setting it up.
5. The openings on the enclosure are for air convection hence protects the
equipment from overheating. DO NOT COVER THE OPENINGS.
6. Make sure the voltage of the power source and adjust properly 110/220V
before connecting the equipment to the power inlet.
7. Place the power cord such a way that people can not step on it. Do not
place anything over the power cord.
8. Always Unplug the Power Cord before inserting any add-on card or module.
9. All cautions and warnings on the equipment should be noted.
10. Never pour any liquid into the opening that could damage or cause elec
trical shock.
11. If any of the following situations arises, get the equipment checked by a
service personnel:
- The power cord or plug is damaged.
- Liquid has penetrated into the equipment.
- The equipment has been exposed to moisture.
- The equipment has not work well or you can not get it work according to
User’s Manual.
- The equipment has dropped and damaged.
- The equipment has obvious sign of breakage.
12. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT
UNCONDITIONED, STORAGE TEMPERATURE ABOVE 600 C (1400F), IT MAY
DAMAGE THE EQUIPMENT.
CAUTION: Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type recommended by
the manufacturer.

v
CONTENTS
Introduction
Chapter 1. Getting Started............................................................................1-1
All-in-One Feature Set.........................................................................1-2
Front Panel......................................................................................1-3
Back Panel......................................................................................1-3
System Specification.............................................................................1-4
Performance PC...................................................................................1-6
Hi-Fi Audio..........................................................................................1-8
Home Theater......................................................................................1-10
Chapter 2. Using PC Function.......................................................................2-1
Mainboard Layout................................................................................2-2
CPU/Memory...................................................................................... 2-3
Introduction to DDR SDRAM..........................................................2-3
Power Supply.......................................................................................2-4
Front Panel...........................................................................................2-5
IEEE 1394 Port: J1394-2..................................................................2-5
IEEE 1394 Port: J1394-1..................................................................2-6
USB Ports........................................................................................2-6
Mic-in/Head-Phone.........................................................................2-7
OPTICAL SPDIF-in...........................................................................2-7
Back Panel...........................................................................................2-8
Serial Port........................................................................................2-8
VGA Port........................................................................................2-9
Mouse/Keyboard Connectors...........................................................2-9
RJ45 LAN Jack................................................................................2-10
USB Ports......................................................................................2-10
OPTICAL SPDIF-out......................................................................2-10
Parallel Port...................................................................................2-11
Audio Port.....................................................................................2-12

vi
Connectors..........................................................................................2-13
IDE Connectors: CN22&CN23.......................................................2-13
FDD Connector: CN10................................................................. 2-13
CD-in Connector: CN16.................................................................2-14
TV-Tuner Card Connector: CN13...................................................2-14
CPU Fan Connector: CN15..........................................................2-14
Front Panel Power Connector: CN4...............................................2-15
USB Card Reader Connector: CN6.................................................2-15
LCM Connector: CN8..................................................................2-16
Modem Module Connector: CN21.................................................2-16
Jumper................................................................................................2-17
Clear CMOS Jumper: J2................................................................2-17
Slots...................................................................................................2-18
PCI Slot.........................................................................................2-18
AGP Slot.........................................................................................2-18
Chapter 3. Using Audio Function................................................................. 3-1
Control Panel........................................................................................3-2
Remote Controller................................................................................3-3
AC Power on........................................................................................3-4
Playing CD/MP3...................................................................................3-5
Playing FM/AM.....................................................................................3-9
Chapter 4. Setting BIOS Function.................................................................4-1
Entering Setup.......................................................................................4-2
Control Keys....................................................................................4-2
Getting Help...................................................................................4-3
Main Menu.....................................................................................4-3
Sub-Menu.......................................................................................4-3
General Help<F1>...........................................................................4-3
The Main Menu...................................................................................4-4
Standard CMOS Features.....................................................................4-6
Advanced BIOS Features......................................................................4-8
Advanced Chipset Features.................................................................4-11

vii
Integrated Peripherals.........................................................................4-13
Power Management Setup....................................................................4-19
PNP/PCI Configurations.....................................................................4-23
PC Health Status................................................................................4-25
Frequency/Voltage Control.................................................................4-26

Introduction
Introducing Your
“Digital Media Platform”

Thank you for purchasing MEGA651 PC, the Best of Computing & Home
Entertainment. Based on the design idea of consumer product, the MEGA651 is
not just a PC anymore. The equipped “All-in-One” features position MEGA651
as a “Digital Media Platform”.
From the recent years, the ownership and usage of desktop and notebook
PCs across W.W households has turned computers into a commodity item. While
Microsoft strongly promotes the “Media Center” platform concept “Windows XP
Media Center Edition” on HP “Free Style”, Intel is also exploring their “Digital-
Home” concept for the “Home-use” PC.
To meet the new concept of Home PC, the MEGA651 has been positioned
as a digital media platform to perform TV-recording (optional), home theater
(DVD+5.1 channels), digital audio playback (MP3, Audio CD), photo and video
stream data browsing/authoring/burning (optional with Media Center and bundled
applications). Meanwhile, it could also support high game performance (AGP
4X slot). The remote controller also allows you to use it like a Hi-Fi Stereo.
An innovative feature to implement all the Hi-Fi Stereo
into home-PC with a fancy equalizer LCM and control
panel in the front bezel.

Introduction
Maximize YOUr connection to the digital planet
- Hi-Fi Stereo: Audio CD+ MP3 Player+ AM/FM Tuner
- Home Theater: DVD+ 5.1 Channel+ TV Tuner (option)
- Media Center: Card Reader+ 1394+ SPDIF I/O+ PVR
- Complete PC: Office+ Game Machine
For Home, For WFor Home, For W
For Home, For WFor Home, For W
For Home, For Work & For Funork & For Fun
ork & For Funork & For Fun
ork & For Fun
A new Digital Media Form Factor from MSI that allows you to
- Control Live Television
- Enjoy Home Heater (DVD + 5.1 Channel)
- Listen to Digital Music (MP3, Audio CD)
- Burn Music, Photos and Videos (option)
- View Your Favorite Photos (option)
- Edit Digital Videos (option)
- Incredible Gaming Performance
- And more.....

○○○○○○○○○○○○○○○○○○○○○○○○○
1-1
Getting Started
Getting StartedGetting Started
Getting StartedGetting Started
Getting Started
1.1 All-in-1.1 All-in-
1.1 All-in-1.1 All-in-
1.1 All-in-One Feature SetOne Feature Set
One Feature SetOne Feature Set
One Feature Set
1.2 System Specification1.2 System Specification
1.2 System Specification1.2 System Specification
1.2 System Specification
1.3 P1.3 P
1.3 P1.3 P
1.3 Performance PCerformance PC
erformance PCerformance PC
erformance PC
1.4 Hi-Fi Audio1.4 Hi-Fi Audio
1.4 Hi-Fi Audio1.4 Hi-Fi Audio
1.4 Hi-Fi Audio
1.5 Home Theater1.5 Home Theater
1.5 Home Theater1.5 Home Theater
1.5 Home Theater
1
1

○○○○○○○○○○○○○○○○○○○○○○○○○
1-2
Chapter 1
1.1 All-in-one Feature Set
The MEGA651 implements all the Hi-Fi Stereo into Home-PC with a fancy
equalizer LCM and control panel in the front bezel. When PC is power-off, you
can use it just like a Hi-Fi Stereo with a remote controller. When PC is power-
on, you can use it for Home Theater and Media Center PC. The all-in-one feature
provides you with multiple functions in a small form factor. It can be set any-
where you want, such as bedroom or living room, while it’s easily be moved to
anywhere whenever you need.
See the following for the feature:
- Hi-Fi Stereo: Audio CD+ MP3 Player+ AM/FM Tuner (power off)
- Home Theater: DVD+ 5.1 Channel
- Media Center: A/V Browsing/Authoring/Burning (Card Reader+
1394+ SPDIF I/O+CD-RW) + PVR (TV Tuner)
- Completed PC: Office+ Game Machine
TV-out(option) TV-Tuner (Option)
Optical Drive (Option)
Equalizer LCM
Card Reader/FDD/2nd HDD
(Option)
MDC Modem
5.1 Channel
Hi-Fi Power Switch
PC Power Switch
Remote Controller

○○○○○○○○○○○○○○○○○○○○○○○○○
1-3
Getting Started
Front Panel
Back Panel
Power Jack
Serial Port
VGA Port
Keyboard
USB x 2
Optical SPDIF-out
Speak-out
Lin-in
Mic-in
AGP Slot
PCI Slot
Modem
Mouse
LAN Port Parallel Port
Radio Antenna
Jack
Optical SPDIF-in
Mic-in
Head-Phone
USB x 2
J1394-1
J1394-2
IR Receiver
Mode
Eject/Stop
Forward
Play/Pause
Backward
Shuttle Controller
PC Reset
Hi-Fi Power Switch
HDD LED
PC Power Switch

○○○○○○○○○○○○○○○○○○○○○○○○○
1-4
Chapter 1
1.2 System Specification
M/B
- MS-6760 (Proprietary F/F), 185 x 290 mm (4 layer)
CPU:
- Support Socket 478 for Pentium® 4, 2.8 GHz
Chipset:
- SiS 651 + SiS 962
Memory:
- DDR 333 x 2, support memory up to 2.0GB
On-Board Audio:
- AC’97 Codec integrated in ALC 650, support 5.1 channel , SPDIF In/Out.
On-Board VGA:
- Integrated (AGP 4X)
** On-Board VGA memory: None
On-Board Communication
- LAN: integrated in Realtek (10/100Mb)
- Modem: 56K MDC module
On-Board USB
- Front x 2; Rear x 2; On-Board x 2 for Card Reader & RF K/B, M/S (MFG Option)
On-Board IEEE 1394:
- RTL8801B PHY (2 ports), Front x 2 (4 pin, 6 pin)
Expansion Slots:
- PCI 2.2 x 1, AGP (4X) x1
Power Off Function:
- Playback Audio CD, MP3, AM/FM Radio Tuner (with Remote Controller)
TV Tuner Function
- MS-8606 (Option PCI with remote controller)
Power Supply:
- 200W (PFC 5V/12V SB) Full Range
Chassis:
- 202(W) x 320(D) x 151(H) mm (9.76 Liters)

○○○○○○○○○○○○○○○○○○○○○○○○○
1-5
Getting Started
On-Board Headers & Connectors
- Rear Panel: Parallel Port x 1, Serial Port x 1, VGA x 1, PS/2 x 2, Mic in/Line in/
Line out x 1, USB x 2, LAN (RJ45) x 1, SPDIF/O x 1, Modem (RJ11) x 1
- Front Panel: Mic in/Headphone x 1, USB x 2, SPDIF/I x 1, 1394 x 1 (4-pin), 1394
x 1(6-pin)
BIOS
- 2MB Flash
Others
- Microsoft® PC 2001
- LAN Wake Up Function
- Suspend to RAM/DISk function
- Top Tech III (Thermal Overheat Protection Technology)
- PC Alert System Hardware Monitor
- On-Board BlueBird Module for Power-Off features
- On-Board Equalizer (LCM)

○○○○○○○○○○○○○○○○○○○○○○○○○
1-6
Chapter 1
1.3 Performance PC
When PC is power on, the MEGA651 is your performance PC. Power on
means “If the power button of PC is pressed, the Hi-Fi stereo has no function even
you press the “Hi-Fi” button.”
Press the Power button to start
the PC function
CPU support: Intel P4
PCI/AGP Expansion
Front I/O
- Mic-in/Head-Phone
- USB x 2
- 1394 x 2 (6-pin & 4-pin)
- Optical SPDIF-in
- 6-in-1 Card Reader
See Chapter 2 for more information of mainboard, Front and Rear I/O.
Features
Rear I/O
- COM/VGA/Parallel/PS2 x 2
- LAN (RJ45)
- USB x 2
- Optical SPDIF-out
- Speaker-out/Line-in/Mic-in (5.
1channel)
- Modem
- Radio Antenna

○○○○○○○○○○○○○○○○○○○○○○○○○
1-7
Getting Started
Target Operating System
-- Microsoft Windows XP Home Edition
Security
-- The security features protect the data of machine from unveiled publicity and
unauthorized access through BIOS control.
Password
-- The MEGA651 uses three levels of BIOS access (User Password, Supervisor
Password, HDD Password) to protect the computer system.
Storage Subsystem
1) Floppy (Standard Floppy & USB Floppy)
2) Hard Disk
3) CD-ROM (OPTIONAL)
4) DVD-RW (OPTIONAL)
5) CD-RW (OPTIONAL)
6) DVD +/- RW (OPTIONAL)

○○○○○○○○○○○○○○○○○○○○○○○○○
1-8
Chapter 1
1.4 Hi-Fi Audio
When PC is power off, the MEGA651 can be used as a Hi-Fi audio. You
can press the Hi-Fi button or use the remote controller to start the audio function.
Power-off means “When used as a Hi-Fi audio, the PC should be in power-off
status. If you press the PC power button on, the Hi-Fi audio will be disabled .”
Press the Power button to use the
audio function
Option 1
Press the Hi-Fi button to use the
audio function
Features
LCM Display, Clock, AM/FM Radio Tuner, Audio CD Play,
MP3 CD Play, SRS
See Chapter 3 for more information of using audio function.
Option 2

○○○○○○○○○○○○○○○○○○○○○○○○○
1-9
Getting Started
SRS
MEGA651 is equipped with SRS audio enforce-
ment technology. SRS (Sound Retrieval System) was
the first generation of 3D sound, dramatically improv-
ing the quality of standard stereo. SRS is based on the
human hearing system and was designed to retrieve
the natural spatial cues and ambient information that
is present in audio but masked by traditional record-
ing and playback methods.
Whether the signal is mono or stereo, SRS ex-
pands the audio material to create a realistic three-
dimensional sound image. SRS has no sweet-spot and
fills the room with a sound experience much closer to
that of a live performance.
SRS is a trademark of SRS Labs, Inc. SRS tech-
nology is incorporated under license from SRS Labs,
Inc.

○○○○○○○○○○○○○○○○○○○○○○○○○
1-10
Chapter 1
1.5 Home Theater
Except the general PC function, the MEGA651 has the extra Home The-
ater function when PC button is pressed on.
When PC button is pressed on, you can use the equipped optical drive to
play DVD. The equipped 5.1 channel audio effect gives you a wonderful feeling
of home theater while playing DVD.
Plus, the OPTIONAL MS8606 TV-Tuner card allows you to watch TV.
The top part of remote controller is designed specially for the TV-Tuner function.
To enforce the multimedia effect, the “Media Center”, which is developed
by MSI, will be bundled in the next generation of MEGA651. You will find the
simplified PC control of multimedia resources, such as watching TV, listening to
music, viewing pictures and playing DVD..., etc.
