MSI Modern AM242 12M User manual

Modern Series
All-in-One PC
Modern AM242 12M (MS-AE07)
Modern AM242T 12M (MS-AE07)
Modern AM242P 12M (MS-AE07)
Modern AM242TP 12M (MS-AE07)
Modern AM272 12M (MS-AF82)
Modern AM272P 12M (MS-AF82)
User Guide

2Contents
Contents
Getting Started.............................................................................................................. 3
Package Contents................................................................................................... 3
Safety & Comfort Tips ............................................................................................ 3
System Overview..................................................................................................... 4
OSD Setup............................................................................................................. 18
Component Replacement & Upgrade .................................................................. 23
Windows 11 System Operations................................................................................ 25
Power Management ............................................................................................. 25
Network Connections........................................................................................... 29
System Recovery .................................................................................................. 37
F3 Hotkey Recovery (Optional) .................................................................................. 39
Troubleshooting.......................................................................................................... 40
Safety Instructions...................................................................................................... 42
TÜV Rheinland Certification....................................................................................... 44
Regulatory Notices..................................................................................................... 45
Revision
V1.0, 2021/12

3
Getting Started
Getting Started
This chapter provides you with the information on hardware setup procedures. While
connecting devices, be careful in holding the devices and use a grounded wrist strap
to avoid static electricity.
Package Contents
All-in-One PC
Modern AM242 12M, Modern AM242T 12M
Modern AM242P 12M, Modern AM242TP 12M
Modern AM272 12M, Modern AM272P 12M
Documentation
Quick Start Guide (Optional)
User Guide (Optional)
Warranty Book (Optional)
Warranty Card (Optional)
Accessories
Power Cord
Power Adapter
Mouse (Optional)
Keyboard (Optional)
⚠
Important
∙ Contact your place of purchase or local distributor if any of the items is damaged or
missing.
∙ Package contents may vary by country.
∙ The included power cord is exclusively for this personal computer and should not be
used with other products.
Safety & Comfort Tips
∙Choosing a good workspace is important if you have to work with your PC for a long
period of time.
∙Your work area should have enough illumination.
∙Choose the proper desk and chair and adjust their height to fit your posture when
operating.
∙When sitting on the chair, sit straight and keep a good posture. Adjust the chair’s
back (if available) to support your back comfortably.
∙Place you feet flat and naturally on the floor, so that your knees and elbows have the
proper position (about 90-degree) when operating.
∙Put your hands on the desk naturally to support your wrists.
∙Avoid using your PC in a place where discomfort may occur (such as on the bed).
∙The PC is an electrical device. Please treat it with great care to avoid personal
injury.

4Getting Started
System Overview
Front View
Modern AM242 12M
Modern AM242T 12M
Modern AM272 12M
1
2

5
Getting Started
Modern AM242P 12M
Modern AM242TP 12M
Modern AM272P 12M
1
2
1Webcam
2Touch Screen (for Modern AM242T 12M/ Modern AM242TP 12M)

6Getting Started
Rear View
Modern AM242 12M
Modern AM242T 12M
Modern AM272 12M
1 2 3 4 5 6 7

7
Getting Started
Modern AM242P 12M
Modern AM242TP 12M
Modern AM272P 12M
1 2 3 4 5 6 7
1Navi Key
The AIO PC comes with a Navi Key, a multi-directional control that helps
navigate the On-Screen Display (OSD) menu.
2Power Jack
Power supplied through this jack supplies power to your system.
3Kensington Lock

8Getting Started
4HDMI-In Port (with MSI Instant Display Technology)
The High-Definition Multimedia Interface (HDMI) is an all-digital audio/video
interface capable of transmitting uncompressed streams. HDMI supports
all TV format, including standard, enhanced, or high-definition video, plus
multi-channel digital audio on a single cable.
With MSI Instant Display Technology, when you connect power to the AIO PC
successfully, the monitor will automatically enter “standby” mode without
pressing the power button. When devices are connected to the HDMI-in
port, the monitor will be turned on immediately. You can also switch the
modes through the Monitor Power/ Mode Button on the side panel if you
have already turned on your AIO PC. This technology helps to save more
energy for your system.
5HDMI 2.0b Port
Supports a maximum resolution of 4K 60Hz.
⚠
Important
∙ Available for the processor with integrated graphics.
∙ Graphics specifications may vary depending on the installed CPU.
6USB 2.0 Port
This connector is provided for USB peripheral devices. (Speed up to 480
Mbps)
⚠
Important
High-speed devices are recommended for USB 3.2 ports whereas low-
speed devices, such as mouse or keyboard, are suggested to be plugged
into the USB 2.0 ports.
7LAN Jack
The standard RJ-45 LAN jack is provided for connection to the Local Area
Network (LAN). You can connect a network cable to it.
LINK/ACT
LED
SPEED
LED
LED Status Description
Link/ Activity
LED
Off No link
Yellow Linked
Blinking Data activity
Speed LED
Off 10 Mbps
Green 100 Mbps
Orange 1 Gbps

9
Getting Started
Side View
Modern AM242 12M
Modern AM242T 12M
Modern AM272 12M
7
1
2
3
4
5
6

10 Getting Started
Modern AM242P 12M
Modern AM242TP 12M
Modern AM272P 12M
7
1
2
3
4
5
6
1USB 3.2 Gen 2 Port (Type-C)
This connector is provided for USB peripheral devices. This connector can
provide up to 5V 3A of power. (Speed up to 10 Gbps)
2USB 3.2 Gen 2 Port
This connector is provided for USB peripheral devices. (Speed up to 10
Gbps)
3Combo Audio Jack
This connector is provided for headphones or speakers or microphones.
