multicomp pro MP780051 User manual

1
AC Current Leakage Tester
Model No. MP780051

2 3
Read all instructions before using the appliance and retain for future reference.
• Please follow all safety operation instructions.
• Check the jaws and case insulation before using. If you nd any breakage
or abnormality, or you consider the device is broken, stop using the device
immediately.
• Never operate the meter with the battery cover open.
• Set the function switch to the correct setting before connecting the meter to the
current source to be tested.
• Never apply voltage greater than the specied maximum allowed.
• Use caution with voltages above 25VAC rms as a shock hazard may exist.
• Always disconnect and remove the test leads before making AC current
measurements.
• Always remove power from circuits being tested and discharge all capacitors before
making resistance or continuity measurements.
• Do not use the product for any purpose other than that for which it is designed.
• Turn the tester off when not in use to save the battery.
• Remove the battery if the meter is not to be used for long periods.
• Replace the battery as soon as the low battery warning appears to avoid possible
electric shock or personal injury caused by incorrect readings.
PRODUCT OVERVIEW
WHAT’S INCLUDED
• AC Leakage Tester
• Batteries
• Test Leads
• Instruction manual.
IMPORTANT SAFETY INFORMATION
OPERATION
1
2
3
4 8 12 15
16
17
5
6
7
9
10
11
13
14
18
AC Leakage Current Measurement
• Set the Function switch to the desired current range.
• Press the jaw trigger to open the clamp jaws and clamp around the conductor
ensuring it is centred within the clamp jaws.
• The measured value is displayed on the LCD screen.
1. Current sense jaws
2. Clamp trigger
3. Function selector control
4. Frequency switch
5. Data HOLD button
6. MAX/MIN button
7. ZER/REL button
8. LCD display
9. Low Battery symbol
10. ZERO/REL symbol
11. Data HOLD symbol
12. Bar Graph display
13. MAX/MIN Hold symbol
14. Continuity symbol
15. Units symbol
16. Test lead input terminal
17. Test lead COM terminal
18. Wrist strap
• 10μA high resolution on 40mA range.
• Shield transformer jaws to minimise the effect of external stray magnetic eld.
• Five Ranges (40mA, 400mA,4A,40A,100A) for all applications.
• A lter circuit is designed to eliminate the effect of high frequency noise and
harmonics by setting the frequency selector switch at the 50/60 Hz position for AC
current measurement.
• Fast bar graph display (20 times/sec.) for transient observation.
• Continuity and frequency measurements.
• Max/Min and Data Hold functions.
• Relative Measurement.
• 600V overload protection for ohm measurement.
AC Leakage Current Measurement
AC Leakage Current Flowing
to Ground Measurement

4 5
Out of Balance Leakage Current Measurement
• Set the Function switch to the desired current range.
• Press the jaw trigger to open the clamp jaws and clamp around all conductor wires.
Two wires (single phase, two wires), three wires (three phases, three wires), or four
wires (three phases, four wires) ensuring they are centred within the clamp jaws.
• The measured value is displayed on the LCD screen.
50/60 position
• This clamp meter has very good frequency response due to the electric property
of the transformer jaws used. Therefore, the measurement result contains not only
the fundamental frequency of 50/60Hz but also the high frequencies and harmonics
superimposed on the fundamental frequency.
• To eliminate the effect of high frequency noise, a low pass lter is designed to lter
out high frequency signal. To enable the lter, set the switch at the 50/60 position.
• The lter’s cut-off frequency is set at 100Hz with an attenuation characteristic of
approx. 24dB/octave.
Wide position
• If the circuit under test is originated from a high frequency generating device such
as inverter, switching regulators etc., then the switch should be set at wide position
to measure the signal which contains the frequency from 40Hz-1kHz.
• To check for the presence of a high frequency signal, set the switch at 50/60 and
then change to the wide position setting to see the difference.
• If the reading is very different, it is certain that the high frequency signals or
harmonics are present.
AC Load Current Measurement
• Set the Function switch to the desired current range.
• Press the jaw trigger to open the clamp jaws and clamp around only one wire.
• Ensure the jaws are fully closed.
• The measured value is displayed on the LCD screen.
AC Voltage Measurements
• Set the rotary switch at 400V.
• Insert the test leads into the input jacks, black lead into the COM socket.
• Connect the probes of the test leads in PARALLEL to the circuit to be measured.
• The measured value is displayed on the LCD screen.
WARNING: Maximum input for DC and for AC are both 600V. Do not attempt to take
any voltage measurement that exceeds the limits. Exceeding the limits could cause
electrical shock and damage to the clamp meter.
Resistance and Continuity Measurement
• Set the rotary switch to Ω.
• Insert the test leads into the input jacks, black lead into the COM socket.
• Connect the probes of the test leads to the two ends of the resistor or circuit to be
measured.
• Read the measured value from the LCD display.
• If the resistance is lower than 40Ω, the internal sounder beeps.

6 7
WARNING: Before taking any in-circuit resistance measurement, remove power from
the circuit being tested and discharge all the capacitors.
Relative Reading Measurements
• The zero button also can be used to make a relative measurement. Pressing the
button sets the current reading as zero and a zero symbol displays on the LCD.
• All the subsequent measurement shall be displayed as a relative value with respect
to the value that has been zeroed.
• Press the zero button again for 2 seconds to return to normal mode.
Holding the LCD Reading
• Press the HOLD button and the reading will be held and kept displayed on the LCD.
Finding the MAX/MIN Value
• Press the MAX/MIN button to enable the maximum and minimum values to be
recorded and updated during measurement.
• Push the button once, the maximum value shall be displayed and updated.
• Push the button again and the minimum value shall be displayed.
• Push the button a third time to disable MAX/MIN and return to the normal
measurement mode.
Auto-Power-Off
• The meter will turn itself off 30 minutes after power-on.
• To power it on again, either press the HOLD button or turn the power off and back
on.
• To disable the Auto-power-off function, hold the HOLD button while turning on the
power.
CLEANING
• Clean the tester with a clean, soft cloth.
• Do not use any chemicals, abrasives or solvents that could damage the tester.
MAINTENANCE
• When the low battery symbol appears on the LCD the battery must be replaced.
• Power the tester down and remove the rear battery compartment screw.
• Slide off the battery compartment cover and replace the 9V NEDA 1604 or G6F22
battery taking note of the polarity.
• Replace the compartment cover and secure the screw.
SPECIFICATIONS
AC Current Accuracy
Range Resolution 50/60 Hz Wide(400-1KHz)
40mA 10μA ±1.0%±0. 5mA ±4.5%±0. 5mA
400mA 100μA ±3.0%±5.0mA ±3.0%±5.0mA
4A 1mA ±4.0%±0.1A ±4.0%±0.1A
40A 10mA ±4.0%±1.0A ±4.0%±1.0A
80A 100mA ±2.5%±1.0A ±3.0%±1.5A
80-100A1100mA ±5.0%±1.0A ±5.0%±1.5A
AC Voltage Overload
protection
Range Resolution 50/60Hz 40Hz-1KHz
400V 0.1V ±1.5%±2dgts ±2.0%±4dgts AC 600V
Resistance & Continuity Overload
protection
Range Resolution Accuracy Beep Sounds
40-400Ω0.1Ω±1.0%±2dgts <38.0ΩAC 600V
Display 33/4 Digit LCD display with 40 segment bar graph
Batteries One 9V NEDA 1604 or G6F22 battery
Jaw Opening 30mm (1.2”)
Auto Power Off 30 minutes approx
Operating Conditions -10ºC to 50ºC (32ºF to 86ºF) <85% Relative Humidity
Storage Conditions -20ºC to 60ºC (-14ºF to 140ºF) <75% Relative Humidity
Sampling Time 2 times/sec. (display)
20 times/sec. (bar graph)
Altitude <3000 meters
Weight 200g inc battery
Dimensions (H x W x D) 210 x 62 x 36mm
Safety Compliance CAT II 600V
NOTE1: Though the meter can display up to 400A, it is not calibrated beyond 100A.
Specications at 23ºC ± 5ºC.

8
