multicomp pro MP740890 User manual

Page <1> V1.027/06/22
Newark.com/multicomp-pro
Farnell.com/multicomp-pro
sg.element14.com/b/multicomp-pro
Smoke Absorber
User Manual
Part Number: MP740890/MP740891

Page <2> V1.027/06/22
Newark.com/multicomp-pro
Farnell.com/multicomp-pro
sg.element14.com/b/multicomp-pro
Copyright
The design of this product (including internal software) and the accessories are protected by relevent laws of China. Any
violation of relevant rights of our company will be subject to legal sanction.
Please abide by relevant national laws when you use this product.
Essentials
User should have basic knowledge of life and basic electrical operation before using the product. Underage user can only use
this product under the guidance of professional or guardian.
[Note] In order to avoid damage to the machine and keep the operating environment safe: Please read this Manual carefully
before using this product, and keep it properly for future reference.
Disclaimer
We will take no responsibility for any personal injury or property damage caused by reasons other than the product quality
problem, which may include force majeure (natural disasters, etc.) or personal behavior during the operation of the product
This manual is organized, conpiled and released bye Shenzhen atten technology co., ltd. according to the latest product
features dot we will not responsible for further notice of the subsequent improvement of the product and this Manual.
Product overview
This product is a Desktop-type Soldier Smoke Absorber can be operated vertically or horizontally, can remove soldering
smoke and fumes quickly, safely and quickly. Activated carbon lter is made of highly activated carbon , strong obsorb, and
has LED lighting function.
Specications
Item Name Solder Smoke Absorber
Item Model MP740890/ MP740891
Power consumption 220-240V - 16W/50Hz
Maximum suction capacity 1.03m³/min
Dimensions 103.3mm × 161.8mm × 217.2mm
Fitter size 142mm × 142mm × 10mm
Packaging List
User Manual X1, Activated Carbon Filter X1, Solder Smoke Absorber X1

Page <3> V1.027/06/22
Newark.com/multicomp-pro
Farnell.com/multicomp-pro
sg.element14.com/b/multicomp-pro
Instructions
1. Remove widely range of solder smoke
Please adjust two gear keys if removing widely range o󰀨 solder smoke, Gear 1 is suitable to be used under brighter
environment, the LED light is o󰀨 when pressing Gear 1, Gear 2 is suitable to be used under dark environment, the LED light
is on when pressing Gear 2.
2. Remove close-up solder smoke
Please place this device on the desk as below picture if removing close-up solder smoke, and turn on Gear 1.
Comparing with vertical position, horizontal position can provide airow and e󰀩ciency much more than vertical, and is not
much suitable for removing widely range of smoke.
Care and maintenance
1. Replace activated carbon lter
The lter observes soldier fumes and becomes white with clogging. Replace the lter when the suction power is drastically
reduced to clogging, or when the ux smell gets noticeably stronger. (note: Be careful that moisture water etc does not get on
the lter, or it can’t be used.)

Page <4> V1.027/06/22
Newark.com/multicomp-pro
Farnell.com/multicomp-pro
sg.element14.com/b/multicomp-pro
2. Install
Please pick the activated carbon lter on the 4pcs of buckle position as picture on the right. Please don’t operate this device
before put into the activated carbon lter.
Safety precaution
In order to reduce the risk of re alarm or electric shock, please never use this device with solid state speed control
device at the same time please cut o󰀨 power before repairing or it will lead to electric shock.
1. Do not use this produce absorb igniting or explosive gas
2. Keep this product away from wet places.
3. Do not make this product wet or use it with red wet hands
4. Make sure to turn o󰀨 the power when this device stopped using or out of use
5. Please turn o󰀨 the power when replacing parts or not used.
6. Keep this product out of children’s reach.
7. Please replace the power cord by contacting original factory or equivalent person to get rid of danger.
8. Please use the accessories from the original factory when replacing the product parts.
