WM-70 PLASTER/MORTAR MIXER — TABLE OF CONTENTS
NOTE
Specifications and are
subject to change without
notice.
MQ WHITEMAN —
WM-70 SERIES
PLASTER/MORTAR MIXER
Here's How To Get Help .............................................3
Table Of Contents ...................................................... 4
Parts Ordering Procedures ........................................ 5
Specifications .............................................................6
Dimensions ................................................................7
Safety Messages Alert Symbols ............................ 8-9
Rules For Safe Operation .................................. 10-11
Towing Guidelines ....................................................12
Safety Chain Connection .........................................13
Operation and Safey Decals ....................................14
General Information .................................................15
Major Components ..................................................16
Basic Engine Components .......................................17
Electric Motor ..................................................... 18-19
Paddle Blade Adjustment (Steel Drum) ...................20
Paddle Blade Adjustment (Poly Drum) .....................21
Inspection ........................................................... 22-23
Start-Up Procedures .......................................... 24-26
Operation .................................................................26
Shut-Down Procedures ............................................27
Maintenance (Engine) ........................................ 28-29
Maintenance (Mixer) .......................................... 30-34
Troubleshooting (Engine) ................................... 35-36
Troubleshooting (Mixer/Electric Motor) ....................37
Electric Motor Wiring Diagram .................................38
Discount-Equipment.com

PAGE 6 — WM-70 PLASTER/MORTAR MIXER — OPERATION MANUAL — REV. #1 (08/09/04)
WM-70 PLASTER/MORTAR MIXER — SPECIFICATIONS
SNOITACIFICEPSREXIM.1ELBAT
yticapaC)sretil891(tf.uc0.7
yticapaCgaBsgab2/1-2ot2/1-1
thgieW).gk753(.sbl887
eldnaHpmuD/WthgieH).mc581(.ni37
thgieHegrahcsiD).mc35(.ni12
evirDraeG/tleB-V
noitcApmuDlaunaM
NOTE
In accordance with our established
policy of constant improvement, we
reserve the right to amend these
specifications at any time without
notice.
)ROTOMCIRTCELE&ENIGNE(SNOITACIFICEPS.2ELBAT
cirtcelE/enignE
rotoM
ledoM2XH1K061XGADNOH2AH1K042XGADNOH203S922L53RODLAB
epyT latnoziroH,ekorts4delooc-riA
enignEenilosaGtfahS
elgniS,032/511,PH5.1
rotoMcirtcelEesahP
ekortSXeroB .ni56.1X.ni15.2
)mm24xmm8.36(
.ni03.2X.ni09.2
)mm85xmm37( A/N
tnemecalpsiDcc57.8cc18.41A/N
tuptuOxaMM.P.R0063/PH5.5.M.P.R0063/.P.H0.8MPR5271/.P.H5.1
yticapaCknaTleuF snollaG159.
)sretiL6.3(
snollaG.S.U95.1.xorppA
)sretiL6( A/N
leuFenilosaGdedaelnUA/N
yticapaCliOebuLstnip3/1-2A/N
lortnoCdeepS
dohteM epyTthgiew-ylFlagufirtneCA/N
dohteMgnitratStratSlioceRA/N
)HxWxL(snoisnemiD .ni8.31X2.41x2.21
)mm533X263X213(
.ni1.61X9.61x0.41
)mm014X034X553(
.ni60.9X7.8x3.31
)mm032X022X833(
thgieWteNyrD ).gK51(.sbl33).gK52(.sbl1.55).gK01(.sbl22.xorppA
Discount-Equipment.com

WM-70 PLASTER/MORTAR MIXER — OPERATION MANUAL — REV. #1 (08/09/04) — PAGE 7
WM-70 PLASTER/MORTAR MIXER — DIMENSIONS
Figure 1. Dimensions
SNOISNEMID.3ELBAT
noitpircseD)mc(.nisnoisnemiD
htgneL
)raBwoT/w( )mc071(.ni76
htdiW)mc721(.ni05
thgieH)mc241(.ni65
Discount-Equipment.com

PAGE 8 — WM-70 PLASTER/MORTAR MIXER — OPERATION MANUAL — REV. #1 (08/09/04)
This Owner's Manual has been
developed to provide complete
instructions for the safe and efficient
operation of the MQ Whiteman
WM-70 mortar and plaster mixer.
Refer to the engine manufacturers
instructions for data relative to its safe operation.
Before using this mixer,ensure that the operating
individual has read and understands all instructions in
this manual.
Lethal Exhaust Gases
WM-70 PLASTER/MORTAR MIXER — SAFETY MESSAGE ALERT SYMBOLS
NOTE
HAZARD SYMBOLS
SAFETY MESSAGE ALERT SYMBOLS
The three (3) Safety Messages shown below will inform you
about potential hazards that could injure you or others. The
Safety Messages specifically address the level of exposure
to the operator, and are preceded by one of three words:
DANGER, WARNING, or CAUTION.
You WILL be KILLED or SERIOUSLY injured if you DO
NOT follow directions.
You CAN be KILLED or SERIOUSLY injured if you DO
NOT follow directions.
You CAN be INJURED if you DO NOT follow directions.
CAUTION
Potential hazards associated with the operation of an WM-
70 Plaster/Mortar Mixer
will be referenced with Hazard
Symbols which appear throughout this manual, and will be
referenced in conjunction with Safety Message Alert
Symbols.
Engine exhaust gases contain
poisonous carbon monoxide. This gas
is colorless and odorless, and can
cause death if inhaled. NEVER operate
this equipment in a confined area or
enclosed structure that does not provide ample free flow
air.
Gasoline is extremely flammable, and
its vapors can cause an explosion if
ignited. DO NOT start the engine near
spilled fuel or combustible fluids.
DO NOT fill the fuel tank while the engine is running or
hot. DO NOT overfill tank, since spilled fuel could ignite if
it comes into contact with hot engine parts or sparks from
the ignition system. Store fuel in approved containers, in
well-ventilated areas and away from sparks and flames.
Engine components can generate extreme
heat. To prevent burns, DO NOT touch
these areas while the engine is running or
immediately after operations. Never
operate the engine with heat shields or heat
guards removed.
ALWAYS wear approved respiratory
protection when required.
Safety precautions should be followed
at all times when operating this
equipment. Failure to read and
understand the Safety Messages and
Operating Instructions could result in
injury to yourself and others.
FOR YOUR SAFETY AND THE SAFETY OF OTHERS!
DANGERDANGER
DANGERDANGER
DANGER
WARNINGWARNING
WARNINGWARNING
WARNING
CAUTIONCAUTION
CAUTIONCAUTION
CAUTION
Lethan Exhaust Gas Hazards
WARNINGWARNING
WARNINGWARNING
WARNING
Explosive Fuel Hazards
WARNINGWARNING
WARNINGWARNING
WARNING
Burn Hazards
WARNINGWARNING
WARNINGWARNING
WARNING
Respiratory Hazards
WARNINGWARNING
WARNINGWARNING
WARNING
Discount-Equipment.com

WM-70 PLASTER/MORTAR MIXER — OPERATION MANUAL — REV. #1 (08/09/04) — PAGE 9
WM-70 PLASTER/MORTAR MIXER — SAFETY MESSAGE ALERT SYMBOLS
Other important messages are provided throughout this
manual to help prevent damage to your light tower, other
property, or the surrounding environment.
ALWAYS place the power source, circuit
breakers or ON/OFF switch in the OFF
position, when the generator is not in use,
unless connected to transfer switch.
ALWAYS wear approved eye and
hearing protection.
NEVER operate equipment with covers,
or guards removed. Keep fingers, hands,
hair and clothing away from all moving
parts to prevent injury.
Rotating Parts Hazards
CAUTIONCAUTION
CAUTIONCAUTION
CAUTION
Accidental Starting Hazards
CAUTIONCAUTION
CAUTIONCAUTION
CAUTION
Eye and Hearing Hazards
CAUTIONCAUTION
CAUTIONCAUTION
CAUTION
Equipment Damage
Hazards
CAUTIONCAUTION
CAUTIONCAUTION
CAUTION
Discount-Equipment.com

PAGE 10 — WM-70 PLASTER/MORTAR MIXER — OPERATION MANUAL — REV. #1 (08/09/04)
WM-70 PLASTER/MORTAR MIXER — RULES FOR SAFE OPERATION
The following safety guidelines should always be used when
operating the WM-70 plaster and mortar mixer:
GENERAL SAFETY
■ DO NOT operate or service this
equipment before reading this entire
manual.
■ This equipment should not be operated by persons under
18 years of age.
■ NEVER operate this equipment without proper protective
clothing, shatterproof glasses, steel-toed boots and other
protective devices required by the job.
■ High Temperatures – Allow the
engine to cool before adding fuel or
performing service and maintenance
functions. Contact with
hot! components can cause
serious burns.
■ The engine section of this mixer requires an adequate
free flow of cooling air.
NEVER operate the mixer in any
enclosed or narrow area where free flow of the air is
restricted. If the air flow is
restricted it will cause serious
damage to the mixer or engine
and may cause injury to
people. Remember the
mixer's engine gives off
DEADLY carbon monoxide
gas.
■ ALWAYS refuel in a well-ventilated area, away from
sparks and open flames.
DANGERDANGER
DANGERDANGER
DANGER
Failure to follow instructions in this manual may lead to
serious injury or even death! This equipment is to be
operated by trained and qualified personnel only! This
equipment is for industrial use only.
■ NEVER operate this equipment under the influence of
drugs or alcohol .
NEVER! start the engine or engage the paddle arms
when the drum is in the discharge (down) position.
WARNINGWARNING
WARNINGWARNING
WARNING
Read this manual!
Starting the Mixer Engine
■ NEVER touch the hot exhaust
manifold, muffler or cylinder. Allow
these parts to cool before servicing
engine or mixer.
■ ALWAYS wear proper respiratory (mask),
hearing and eye protection equipment when
operating the mixer.
■ NEVER place hands inside the drum while the blades are
rotating.
■ Whenever necessary, replace nameplate, operation and
safety decals when they become difficult read.
■ Manufacture does not assume responsibility for any
accident due to equipment modifications.
■ NEVER use accessories or attachments, which are not
recommended by Multiquip for this equipment. Damage
to the equipment and/or injury to user may result.
■ NEVER operate this equipment when not
feeling well due to fatigue, llness or taking
medicine.
■ NEVER operate the mixer in an explosive
atmosphere or near combustible
materials. An explosion or fire could
result causing severe bodily harm or
even death.
■ Topping-off to filler port is dangerous, as it tends to spill
fuel.
■ Stop the engine when leaving the mixer unattended.
■ Block the unit when leaving or when using on a slope.
■ Maintain this equipment in a safe operating condition at
all times.
■ ALWAYS use extreme caution when
working with flammable liquids. When
refueling, stop the engine and allow it to
cool. DO NOT smoke around or near the
machine. Fire or explosion could result
from fuel vapors, or if fuel is spilled on a
hot engine.
Discount-Equipment.com

WM-70 PLASTER/MORTAR MIXER — OPERATION MANUAL — REV. #1 (08/09/04) — PAGE 11
■ ALWAYS stop the engine before servicing, adding fuel
and oil.
■ NEVER run engine without air filter. Severe engine may
occur.
■ ALWAYS service air cleaner frequently to prevent
carburetor malfunction.
■ ALWAYS be sure the operator is familiar with proper safety
precautions and operations techniques before using mixer.
■ ALWAYS store equipment properly when it is not being
used. Equipment should be stored in a clean, dry location
out of the reach of children.
■ DO NOT operate this equipment unless all guards and
safety devices are attached and in place.
■ CAUTION must be exercised while servicing this
equipment. Rotating and moving parts can cause injury
if contacted.
■ When towing, an adequate safety chain must be fastened
to the frame. See Towing Guidelines section in this manual.
■ Keep all inexperienced and unauthorized people away
from the equipment at all times.
■ Unauthorized equipment modifications will void all
warranties.
■ Check all fasteners periodically for tightness. Also check
towing tongue bolt, lock nut and wheel lug nuts for wear.
■ Stop the engine and disconnect the spark plug before
allowing anybody’s hands in the mixing drum.
■ NEVER pour or spray water over the engine or electric
motor.
TRANSPORTING
■ ALWAYS shutdown engine before transporting.
■ Tighten fuel tank cap securely and close fuel cock to
prevent fuel from spilling.
■ Drain fuel when transporting mixer over long distances
or bad roads.
MAINTENANCE
■ NEVER lubricate components or attempt service on a
running mixer.
■ ALWAYS allow the mixer a proper amount of time to
cool before servicing.
■ Keep the mixer in proper running condition.
■ Fix damage to the mixer immediately and always replace
broken parts.
■ Dispose of hazardous waste properly. Examples of
potentially hazardous waste are used motor oil, fuel and
fuel filters.
■ DO NOT use food or plastic containers to dispose of
hazardous waste.
EMERGENCIES
■ ALWAYS know the location of the nearest fire
extinguisher and first aid kit.
WM-70 PLASTER/MORTAR MIXER — RULES FOR SAFE OPERATION
■ In emergencies always know the location of the
nearest phone or keep a phone on the job site .
Also know the phone numbers of the nearest
ambulance , doctor and fire department . This
information will be invaluable in the case of an
emergency.
WARNINGWARNING
WARNINGWARNING
WARNING
Always stand clear of the dump handle when the mixer
is in operation. Any binding of material between the mixer
blades and the drum will cause the drum handle to quickly
move and could cause bodily harm.
■ Depending on type of mixer, test the ON/OFF switch for
either the gasoline engine or electric motor before operating.
The purpose of these switches is to shut down the engine
or motor of the mixer.
■ Refer to the HONDA Engine Owner's Manual for engine
technical questions or information recommended by
Multiquip for this equipment. Damage to the equipment
and/or injury to user may result.
Stand Clear of the
Mixer when in use
Discount-Equipment.com
