MULTISPAN MI-632-24 User manual

TERMINAL CONNECTION
Front view (mm)
MECHANICAL INSTALLATION
MI-632-24
SIGNAL ISOLATOR
Linearized O/P
1.5KV isolation between supply, input &
output
FEATURES
TECHNICAL SPECIFICATION
Zero & span correction facility through
trim port
Fast Response time <150ms
Din Rail Mounting
Input
INPUT SPECIFICATION:
<100Ω
4- 20 mA DC
CMRR >120dp (Typical)
Temperature
Co-efficient <100 PPM
Output 1 & 2
OUTPUT SPECIFICATION:
Output Inpedance <500Ω
4 to 20mA DC
Response Type <150ms
Isolation between
supply, input & Output At least 1.5KV AC for 1 min
Auxiliary Voltage
POWER SUPPLY:
24 V DC
Isolation Type Optical - 3 way
ISOLATION:
DIMENSION:
Size (HxWxD) mm 76 X 27 X 85
76 76
27
85
Side view (mm)
Input Inpedance
Power Consumption
( VA Rating ) 3VA
Input
4 To 20mA DC
Supply
24V DC, 3VA
Output 2
4 To 20mA DC
MI 632-24-A-AA
Output 1
4 To 20mA DC
O/P-2 O/P-1
S1
S2
Z1
Z2
MI 632-24
I/P
SUPPLY
24V DC
www.multispanindia.com Made in India
!
O/P-2 O/P-1
S1
S2
Z1
Z2
MI 632-24
I/P
SUPPLY
24V DC

Read complete instructions prior to installation
and operation of the unit.
WARNING : Risk of electric shock.
SAFETY PRECAUTION
!
All safety related codifications, symbols and instructions
tha appear in this operating manual or on the equipment must
be strictly followed to ensure the safety of the operating
personnel as well as the instrument.
If all the equipment is not handled in a manner specified by
the manufacturer, it might impair the protection provided by
the equipment.
WARNING GUIDELINES
WARNING : Risk of electric shock.
1. To prevent the risk of electric shock, power supply to the
equipment must be kept OFF while doing the wiring
arrangement. Do not touch the terminals while power is
being supplied.
2. To reduce electro magnetic interference, use wire with
adequate rating and twists of the same of equal size shall
be made with shortest connection.
3. Cable used for connection to power source, must have a
cross section of 1mm or greater. These wires should have
insulations capacity made of at least 1.5kV.
4. A better anti-noise effect can be expected by using
standard power supply cable for the instrument.
INSTALLATION GUIDELINES
MECHANICAL INSTALLATION GUIDELINES
MAINTENANCE
1. The equipment should be cleaned regularly to avoid
blockage of ventilating parts.
2. Clean the equipment with a clean soft cloth. Do not use
isopropyl alcohol or any other cleaning agent.
3. Fusible resistor must not be replaced by operator.
Page 2
1) To install the instrument on a DIN rail, raise the clamp at
the back of the instrument and place it on the rail. Now
release the clamp, so the instrument fits on the DIN rail.
2) Ensure proper fitting of the instrument by pulling it
outwards.
3) To remove the instrument raise the clamp to release it
from the DIN rail.
4) The equipment in its installed state must not come in
close proximity to any heating source, caustic vapors, oil
steam, or other unwanted process byproducts.
5) Do not connect anything to unused terminals.
1) Do not allow pieces of metal, wire clippings, or fine
metallic fillings from installation to enter the product or
else it may lead to a safety hazard that may in turn
endanger life or cause electrical shock to the operator.
2) Circuit breaker or mains switch must be installed
between power source and supply terminal to facilitate
power ‘ON’ or ‘OFF’ function. However this mains switch
or circuit breaker must be installed at convenient place
normally accessible to the operator.
3) Use and store the instrument within the specified ambient
temperature and humidity ranges as mentioned in this
manual.
