Murdock A151.8-VR-BF4 Series Installation and operating instructions

A151.8-VR-BF4 Series
Barrier-Free, Vandal Resistant, Wall Mounted Chilled
Drinking Fountain w/ Sensor Activated Bottle Filler
A151408F-VR-BF4 / A151408S-VR-BF4
TECHNICAL ASSISTANCE TOLL FREE TELEPHONE NUMBER:
1.800.591.9360
Technical Assistance Fax: [phone]
NOTES TO INSTALLER:
1. Please leave this documentation with the owner of the fixture when finished.
2. Please read this entire booklet before beginning the installation.
3. Check your installation for compliance with plumbing, electrical and other applicable codes.
LIMITED WARRANTY - UNITED STATES & CANADA
Murdock warrants the compressor and hermetically sealed refrigeration system, including cooling coil assembly
when part of the hermetically sealed refrigeration system, to be free from defects in material and workmanship
under normal use for an additional four (4) years from the end of the one (1) year period described above.
Murdock warrants that every cooler, bottle filling station, packaged water chiller, fountain and accessory to be free
from defects in material and workmanship under normal use for one (1) year from date of install or eighteen (18)
months after the date of shipment from the factory, whichever comes first.
This warranty does not cover installation or labor charges and does not apply to materials, which have been
damaged by other causes such as mishandling or improper care or abnormal use. The repair or replacement of the
defective materials shall constitute the sole remedy of the Buyer and the sole remedy of Murdock under this
warranty. Murdock shall not be liable under any circumstances for incidental, consequential or direct charges
caused by defects in the materials, or any delay in the repair or replacement thereof. This warranty is in lieu of all
other warranties expressed or implied. Product maintenance instructions are issued with each unit and disregard
or non-compliance with these instructions will constitute an abnormal use condition and void the warranty.
Stainless steel must be protected on job site during construction and must be properly maintained after the water
has been introduced into the water cooler or drinking fountain, or Murdock’s limited warranty is void.
LIMITED EXPORT WARRANTY - One year on parts only.
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
COMPLIES WITH
7021-025-001 Date: 11/10/2020
Federal
Public Law
111-380
(No Lead)
Murdock assumes no responsibility for use of void or
suspended data. © Copyright Murdock, City of
Industry, CA Member of Morris Group International.
Please visit www.murdockmfg.com for most
current specifications.
Member of 15125 Proctor Ave, City of Industry,
CA, 91746 U.S.A.
Phone [phone]
626-336-4561
Fax [phone]
www.murdockmfg.com

IMPORTANT
A dielectric coupling must be used to connect the drinking fountain to the water supply . A nonmetallic coupler is
furnished with this water cooler to meet this requirement.
Prior to roughing consult with local, state, and federal codes for proper mounting height.
NOTICE
A131408S-VR-BF4 Refrigerated Wall Mounted Drinking Fountain
ROUGHING-IN AND DIMENSIONAL DRAWING
This fixture is intended to dispense water that has been lowered in temperature, but otherwise remains
unchanged by the materials in the drinking fountain. It is common for electrical equipment to be grounded to
water lines either within a structure or away from it. Every attempt should be made to prevent this kind of
grounding from generating electrical feedback into the drinking fountain creating electrolysis. Electrolysis will
cause a metallic taste or cause water metal content to increase.
NOTES: Dimensions shown for Adult ADA compliant installation. For Child ADA compliant parallel
approach installation, decrease height of installation by 3 inches. Provide clear floor space as required.
Adjust vertical dimensions as required to comply with federal, state, and local codes.
A151.8-VR-BF4
Page 2 of 20
Date: 11/10/2020
7021-025-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
GENERAL NOTES:
1. ALL DIMENSIONS ARE IN INCHES [MM].
*2. DIMENSIONS SHOWN ARE FOR RECOMMENDED ADULT HEIGHT. ADJUST VERTICAL
DIMENSIONS AS NECESSARY TO COMPLY WITH FEDERAL, STATE & LOCAL CODES.
3. WATER LINE FROM CHILLER TO FOUNTAIN SHOULD BE COVERED WITH SPONGE
FOAM RUBBER OR ICE WATER TYPE INSULATION OF ADEQUATE THICKNESS
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
*33"
6" 13
8"
21"
143
4"
511
2"
23"
111
4"
*511
4"
501
2"
45
8"
101
2"
Finished
Floor
Supplied Mounting
Frame

A151408S-VR-BF4 Refrigerated Wall Mounted Drinking Fountain Inlet & Outlet Rough-Ins
A151.8-VR-BF4
Page 3 of 20
Date: 11/10/2020
7021-025-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
NOTE:
DIMENSION INDICTED WITH **
IS FOR 33" DRINKING FOUNTAIN
DISCHARGE HEIGHT. IF DISCHARGE
HEIGHT DIFFERS ADJUST
ACCORDINGLY.
1-1/4" O.D. DRINKING FOUNTAIN WASTE OUTLET
3/8" NCT DRINKING FOUNTAIN SUPPLY INLET
ALTERNATE 3/8" NCT BOTTLE FILLER SUPPLY INLETS
ALTERNATE 1-1/4" O.D. BOTTLE FILLER WASTE OUTLET
ELECTRICAL SERVICE ROUGH
1
2
3
4
5
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS

Prior to roughing consult with local, state, and federal codes for proper mounting height.
DIMENSIONAL DRAWING
A151.8-VR-BF4
Page 4 of 20
Date: 11/10/2020
7021-025-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
CHILLER MOUNTING FRAME 2 , PANEL, ANCHORING CLIPS 3
C-
INSTALLATION INSTRUCTIONS:
B-
A-
D-
4
3
PROVIDE 19-1/4" WIDE x 50-1/2" TALL WALL OPENING AT
APPROPRIATE HEIGHT. PROVIDE STRUCTURAL SUPPORT
AROUND INSIDE OF THE OPENING FOR FRAME ANCHORING.
CAREFULLY REMOVE BI-LEVEL MOUNTING FRAME 1 ,
CENTER BOTH FRAMES WITHIN WALL OPENING WITH SIDE,
UP AGAINST FINISHED WALL FACE. SET CHILLER SHELVE IN
BOTTOM. SECURE TO WALL THROUGH THE SIDES, TOP AND
BOTTOM USING HARDWARE 5 BY OTHERS ENSURING
16" CENTERLINE DIMENSION LEFT-TO-RIGHT.
SIDES OF CHILLER MOUNTING FRAME 2 ALIGN HOLES IN
SCREWS 4 PROVIDED. SEE ANCHORING CLIP DETAIL.
CLIPS WITH HOLES 6 FRAME AND USE SHEET METAL
AND SCREWS 4 FROM PACKAGING PREVENTING DAMAGE.
191
8"
1
561
4"
5
501
2"
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS

1. Read all installation instructions carefully, before proceeding.
9. WARNING: Warranty is voided if installation is not made following current Acorn Engineering installation
instructions and if components are assembled to the fixture that are not approved by Acorn Engineering.
5. Do NOT solder tubes inserted into the chiller, bottle filler or the fountain strainer as damage to the o-rings on
the push-in fittings may result.
3. Waste is 1-1/4” Outer Diameter. Chiller water inlet is 3/8” Outer Diameter copper tube. Chiller water outlet is
3/8” Outer Diameter copper tube. Drinking Fountain water inlet is 3/8” Outer Diameter copper tube. Bottle
Filler water inlet is 3/8” Outer Diameter copper tube. Water line by others from in-wall chiller to drinking
fountain must have adequate insulation.
IMPORTANT:
5. It is common for electrical equipment to be grounded to water lines either within a structure or away otherwise
remains unchanged by the materials in the water cooler. Every attempt should be made to prevent this kind of
grounding from generating feedback into the water cooler creating electrolysis. Electrolysis will cause a
metallic taste or cause water content to increase.
7. Power supply must be identical in voltage, cycle and phase to that specified on the chiller data plate. Refer to
submittal.
2. Provide 4” minimum clear space in front of bottom trim panel and above in-wall chiller to allow for proper
ventilation.
4. Completely flush supply lines of all foreign debris before connecting to fixture. Water cooler designed to not
cause problems with taste, odor, color, or sediment. Optional water filter (Wf1), is available should any of
these problems arise from the water supply.
8. This unit must be grounded per the requirements of applicable electrical codes.
10. Fixture operates within water pressure range of 174 kPa (25 psig) to 724 kPa (105 psig). Acorn Engineering
will not warranty chiller damaged when connected to supply lines with flow pressure lower than 174 kPa (25
psig) or higher than 724 kPa (105 psig). A pressure regulator must be furnished by others on supply line if
inlet pressure is greater than 724 kPa (105 psig).
11. Due to cold waste water, Acorn Engineering recommends that waste piping supplied by installer be insulated
appropriately to prevent excessive condensation.
12. Per UPC 609.10-All building water supply systems in which quick acting valves are installed shall be
provided with devices to absorb the hammer caused by high pressure resulting from the quick closing of the
valve. These pressure-absorbing devices shall be approved mechanical devices. Water pressure-absorbing
devices shall be installed as close as possible to the quick closing valve.
6. All burrs must be removed from outside of cut tubes before inserting into strainer or other components.
1. Water Supply Service Stop Valve, Water Connections and Electrical Connections to be supplied by others in
accordance with local codes.
PRIOR TO INSTALLATION:
2. Carefully remove all fixture components from packaging, preventing scratching or damage. Inspect fixture and
all parts from damages and all parts are bolted on.
3. Provide mounting surface, sufficient to support the fixture and loads on the fixture.
4. Provide rough-ins as shown on the roughing-in and dimensional drawing, including water supply, drain pipe
and gravel drain well. (See rough-in details)
6. Receptacle(s) must be wired to a GFCI protected circuit. Fixture must be earth grounded per NEC (National
Electrical Code).
7. Completely flush water supply lines of all foreign debris, before connecting to the fixture.
A151.8-VR-BF4
Page 5 of 20
Date: 11/10/2020
7021-025-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS

4. Install the four threaded studs into the Wall Mounting Frame
DRINKING FOUNTAIN INSTALLATION:
1. Insert mounting frame into the rough-in block out and secure using 1/4”-20 UNC mounting hardware (Provided
by Others).
2. Place the Chiller Unit onto the basepan of the frame assembly.
3. Hang upper trim panel on mounting frame. Note: The included 1” brackets do not get used with this installation
and the plastic spacers are typically not required and can be discarded.
5. Remove the drinking fountain top by taking out the drain screw and lifting at the front while pulling forward.
Disconnect bubbler tube. Set top aside in a safe place where it will not be damaged. Place the screw in a
secure location where it will not be lost.
7. Assemble P-trap to drain adapter and then assemble to unit with Phillips screws.
8. Make-up 1-1/4” outer diameter waste connection.
9. After thoroughly flushing the 3/8” outer diameter supply line, connect water supply to in-wall chiller and provide
connection from chiller to the multi-line “Y” strainer assembly. From multi-line “Y” strainer assembly, connect to
drinking fountain bubbler.
10. Place drain gasket on drain adapter. Reconnect bubbler tube. Reassemble top to unit by engaging back clip
and securing with screw.
BOTTLE FILLER INSTALLATION:
1. With drinking fountain installed, connect water supply line from multi-line “Y” strainer assembly to bottle filler.
6. Slide Fixture over studs and secure with nuts and washers.
2. Loosen slip nuts to orientate P-trap to desired direction then tighten slip nuts and make up 1-1/4” O.D. waste
connection.
NOTE: BEFORE PERFORMING STEP 4 REFER TO ELECTRICAL INSTALLATION.
4. Test for leaks and proper operation, and then install the bottle filler panel using the water filler bracket and
secure the bottle filler by tightening the screws under the bottle fille
3. FOR -BF4 ONLY Make up power connections to the ground, neutral & hot within the electrical box.
DRINKING FOUNTAIN START UP:
1. Before connecting power supply, but after thoroughly flushing the supply line and connecting it to the cooler,
turn on building water supply and check all connections for leaks.
1. Air within the bottle filler system or the structure supply piping will cause an irregular spout outlet stream until
purged out by incoming water. Press and hold pushbutton until steady water stream is achieved.
4. If water flow requires adjustment, insert a slotted narrow blade screwdriver in the hole centered on the
underside of the fixture in the knee clearance area up to the flow regulator. Turning clockwise will increase
flow and turning counterclockwise will decrease flow.
7. Provide power to water chiller and make sure unit begins to function.
ŸSENSOR OPERATED: Hold container to be filled just below the sensor in the center of the filler spout
and then move the container upward and water flow will start automatically. When the container is
almost filled, lower the container below the sensor until the water stops flowing. (See label on the bottle
filler.
3. Depress front push pad until steady water stream is achieved.
BOTTLE FILLER START UP:
6. With power still NOT connected, carefully manually rotate cooling fan to ensure proper clearance and free
fan action
2. Air within the drinking fountain system or the structure supply piping will cause an irregular bubbler outlet
stream until purged out by incoming water. Covering the bubbler with a clean cup (or similar object) is
recommended when first activating drinking fountain to prevent excessive splashing.
8. Assemble louvered bottom trim panel with screws provided to brackets on either side of wall mounting frame.
5. Recheck all water connections with water flowing through system.
A151.8-VR-BF4
Page 6 of 20
Date: 11/10/2020
7021-025-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS

A151.8-VR-BF4
Page 7 of 20
Date: 11/10/2020
7021-025-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
WATER TUBING CONNECTIONS:
NOTE: Insulation on all water tubes not shown (all PE water tubes are insulated).
3/8" O.D. Copper Inlet
Removable
Access Panel
3/8" O.D. Copper Inlet
3/8" O.D. Copper Outlet
"Y" Strainer Assembly,
2-Way 3
8" x 1
4"
9-12VDC Solenoid
Valve
Solenoid Valve
Inlet Fitting Fill Spout
Thermostat
Adjustment
Electrical
Knockout
Solenoid Valve
Outlet Elbow
w/ Flow Control
Sensor
PE Tubing
PE Tubing
Chiller Assembly Detail

A151.8-VR-BF4
Page 8 of 20
Date: 11/10/2020
7021-025-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
OPTIONAL -WF1 WATER FILTER
Page for models with -WF1 Water Filter (A131.8-BF4-WF1)
FILTER MOUNTING
DETAIL
(BACKVIEW)
Out In
Mount Filter Bracket to
Corner of Mounting
Frame
4
3
5
2
1
WATER TUBING
DIAGRAM
In
Out
7
6
Connect 1
4" Tubings
to Drinking Fountains
and Bottle Filler Valve
In
Out
ITEM PART NUMBER DESCRIPTION
1 0250-006-000 #10 x 5/8" Phillips Truss Head Screw
2 7014-035-199 Water Filter Bracket
3 0124-031-000 #8 x 3/8" Hex Washer Head Screw
4 1895-709-000 Elbow , 1/4" Push-In x 1/4" Stem
5 7012-311-000 WF1 Filter 1500 Gallon
6 2169-000-000 Tubing, 1/4" O.D. LLDPE, (Blue)
7 7012-055-000 Foam Pipe Insulation

A151.8-VR-BF4
Page 9 of 20
Date: 11/10/2020
7021-025-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
FILTER CARTRIDGE REPLACEMENT:
1. Remove panel assembly, this allows access to the
filter and the inlet valve (provided by others). Turn
valve knob 1/4 turn clockwise to close.
2. With the filter assembly secured on the unit, hold the
cap firmly, turn the replaceable cartridge filter
counterclockwise to remove.
3. Remove and replace the cartridge turning clockwise
to secure.
4. Turn inlet 1/4 turn knob 1/4 turn counterclockwise to
OPTIONAL -WF1 WATER FILTER INSTALLATION
open and test for leaks and proper operation before
remounting panel assembly to fixture.
PANEL ASSEMBLY
WATER INLET
VALVE OPEN
WATER INLET
VALVE CLOSED
REPLACEMENT
CARTRIDGE

A151.8-VR-BF4
Page 10 of 20
Date: 11/10/2020
7021-025-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
ELECTRICAL INSTALLATION:
NOTE: Plug in power is a standard feature.
1A. Plug-In Operation: Plug transformer provided into GFCI protected electrical service, used by the
semi-recessed bottle filler. Plug in transformer to power supply and connect to red sensor wire.
9-12VDC Solenoid
Valve
Plug-In Transformer
Sensor
Red Wire
Blue Wire
Junction Box
Provided

A151.8-VR-BF4
Page 11 of 20
Date: 11/10/2020
7021-025-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
Description
Illuminated LCD display, counts bottles, and has a filter replacement alert function
BOTTLE COUNTER ADJUSTING & RESETTING INSTRUCTIONS:
OPTIONAL -BCD BOTTLE COUNTER DISPLAY
NOTE: Bottle Counter Has Multiple Functions
Reset/ Mode Button
• Counts refilled bottles, otherwise purchased
• Adjustable for Units with and without filters
• “REPLACEMENT FILTER” alert function
• Alert reset, when filter is replaced
Bottle Counting Function
The software applies a flow volume of approximately 16.9 fl oz (volume in standard size plastic water
bottle) to each bottle counted. If the flow volume is less than 16.9 fl oz there will be no count but the
volume will accumulate, so that part way through the next cycle the total bottle count will change.
ILLUMINATED LCD DISPLAY

A151.8-VR-BF4
Page 12 of 20
Date: 11/10/2020
7021-025-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
OPTIONAL -BCD BOTTLE COUNTER DISPLAY
Counter Modes
Located on the back of the display you will find the reset button for the mode settings. The Reset/Mode
selection button is accessible by removing the bottle filler panel assembly, then locate the large hole in the
back of the display mounting bracket. Use your finger or nonconductive implement to depress the
Reset/Mode Selection Button.
!!!DO NOT USE SHARP OR METAL IMPLEMENTS!!!
With this reset button, you are able to indicate whether or not the unit has a filter or does not have a filter.
The reset button will also take away the “REPLACE FILTER” alert once the filter has been replaced.
CLEARING “REPLACE FILTER” ALERT:
NOTE: This Function only applies if the system as a filter
• Replace old filter with new filter.
• Depress the Reset/Mode selection button for 2 SECONDS
• The “REPLACE FILTER” will no longer appear on the display
• Test by actuating the bottle filler, alert will not appear.
FILTER REPLACEMENT FUNCTIONS:
NOTE: When the volume accumulates to 1500 gallons (recommended maximum filter flow volume) the
“REPLACE FILTER” alert will appear on the display every time the bottle filler is activated.
Systems With or Without Filter
• Depress the Reset/Mode selection button for 6
Seconds, the number of seconds will count up on the
display.
• At the end of the 6 seconds, “FLTR YES” or “FLTR NO”
WILL APPEAR on the display.
• “FLTR YES” means that there is a filter in the system
and a “REPLACE FILTER” alert WILL APPEAR on the
display when the maximum filter flow volume is reached.
• “FLTR NO” means that there is no filter in the system
and a “REPLACE FILTER” alert WILL NOT APPEAR
on the display.
• Release button when the option required is on the
display (Filter Yes or No)
RESET/MODE BUTTON

A151.8-VR-BF4
Page 13 of 20
Date: 11/10/2020
7021-025-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
SOLENOID
CONNECTION
POWER SUPPLY CONNECTION
(BLACK CABLES)
SENSOR CONNECTION
(BLACK & RED CABLES)
SENSOR CONNECTION TRANSFORMER
SOLENOID VALVE
BOTTLE COUNT DISPLAY
SENSOR
OPTIONAL -BCD BOTTLE COUNTER DISPLAY
BOTTLE FILLER & BOTTLE COUNTER CONNECTIONS:

A151.8-VR-BF4
Page 14 of 20
Date: 11/10/2020
7021-025-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
NOTE: FITTINGS AND TUBE SHOULD BE KEPT
CLEAN, BAGGED AND UNDAMAGED PRIOR
TO INSTALLATION.
PUSH-IN FITTING INSTALLATION
2. Pull on the fitted tubing to ensure it is secure.
Tube should not come free from the fitting. Water
test the connection assembly prior to leaving the
site to ensure there are no leaks.
DISCONNECTING THE TUBE:
To disconnect the tube from the fitting ensure that
the water line is depressurized. Push collet square
towards the push-in fitting body and hold. While
holding the collet in, pull on the PE tubing to remove
from the push-in fitting.
TO CUT TUBE:
Cut to fit length of 1/4” PE tubing and remove any
burrs or sharp edges. Ensure that the outside
diameter is free from score marks. Tube ends
should be square.
1. Firmly and fully insert the tubing end into the
push-in fitting up to the tube stop located
approximately ½” deep.
INSERTING THE TUBE:
COLLET
COLLET
O-RING
O-RING
TUBE STOP
COLLET
COLLET
COLLET

A151.8-VR-BF4
Page 15 of 20
Date: 11/10/2020
7021-025-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
TROUBLE SHOOTING:
IMPORTANT: BEFORE MAKING ANY OF THE REPAIRS LISTED, MAKE SURE THE
WATER CHILLER IS DISCONNECTED FROM THE ELECTRICAL SUPPLY AND THE
WATER SUPPLY VALVE IS SHUT OFF.
1. ADJUSTMENTS:
d. Check the water inlet “Y” strainer. Sediment from the main supply can get trapped in the screen along
with installation materials such as pipe dope and flux. The screen should be cleaned and checked on a
regular basis and replace if needed.
f. Check flow adjustment. See start up note #3.
a. Check the electrical supply for power and correct voltage. The incoming voltage must be within 10% of
the rated voltage on the serial nameplate.
d. If all components check positive for continuity then test the wiring harness plug for continuity to see if
there is a broken wire within the wiring harness insulation.
c. Check for loose wires within the compressor box. The incoming power leads must be connected to the
overload and relay.
c. An incorrect refrigerant charge, restriction or defective compressor (not pumping) will also cause the
compressor to run without producing cold water. All these signs indicate a problem within the refrigeration
system and the water chiller must be checked by an authorized service company.
b. Cold Water Thermostat – The water temperature can be adjusted using a slotted screwdriver and turning
clockwise to make colder and counterclockwise to make warmer.
b. If the cold thermostat capillary bulb loses its charge or becomes kinked it will fail in the open position
causing a disruption of power to the compressor. Disconnect electrical supply to the water chiller and
using an ohm meter check for continuity across the two electrical terminals on the thermostat. Install a
new thermostat if there is no continuity.
b. Make sure the condenser fan motor is operative. The fan blade must turn freely to help remove the heat
of compression.
b. Check the incoming voltage to make sure it is within 10% of the serial nameplate rating.
a. Check to make sure the fan blade is rotating freely.
2. COMPRESSOR DOES NOT RUN:
c. Check for twists or kinks in outlet tubing.
a. Cartridge – The water flow can be adjusted using a slotted narrow blade screwdriver and turning
clockwise to increase flow and counterclockwise to decrease flow.
b. Check the compressor mounting to make sure the pins and clips are not rattling. If the compressor
appears to be noisy internally, it must be replaced.
c. Bubbler Stream - Bubbler can be rotated slightly to direct the stream backwards or forwards. Adjust the
stream to minimize splashing. Splashing may occur from bubbler stream if the unit is not level. Shim lower
mounting point, if necessary, to level chiller.
4. COMPRESSOR CYCLING ON OVERLOAD PROTECTOR:
b. Verify minimum 20 psig supply line flow pressure.
a. Ensure water supply service stop valve is fully open.
a. A dirty condenser or a blocked fan will cause a high head pressure and frequent cycling of the overload
protector.
3. COMPRESSOR RUNS - WATER IS WARM:
a. The most common cause for a water chiller to run without producing cold water is a loss of refrigerant.
The water chiller must be taken to a certified refrigerant technician for repairs.
d. Change the overload or relay if defective.
6. RESTRICTED OR NO WATER FLOW:
c. A restriction or moisture in the system will also cause intermittent cycling. A certified refrigeration
mechanic should be contacted in this situation.
5. NOISY OPERATION:
e. The cartridge valve located in the water control assembly or bubbler can also become clogged with
foreign material. The cartridge valve can only be replaced and not repaired.
g. Flow control in solenoid valve outlet elbow clogged remove & clean.

A151.8-VR-BF4
Page 16 of 20
Date: 11/10/2020
7021-025-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
1. ADJUSTMENTS:
b. Cold Water Thermostat – The water temperature can be adjusted using a slotted screwdriver and turning
clockwise to make colder and counterclockwise to make warmer.
IMPORTANT: BEFORE MAKING ANY OF THE REPAIRS LISTED, MAKE SURE THE
WATER CHILLER IS DISCONNECTED FROM THE ELECTRICAL SUPPLY AND THE
TROUBLE SHOOTING:
WATER SUPPLY VALVE IS SHUT OFF.
a. Cartridge – The water flow can be adjusted using a slotted narrow blade screwdriver and turning
clockwise to increase flow and counterclockwise to decrease flow.
2. COMPRESSOR DOES NOT RUN:
b. If the cold thermostat capillary bulb loses its charge or becomes kinked it will fail in the open position
causing a disruption of power to the compressor. Disconnect electrical supply to the water chiller and
using an ohm meter check for continuity across the two electrical terminals on the thermostat. Install a
new thermostat if there is no continuity.
c. Check for loose wires within the compressor box. The incoming power leads must be connected to the
overload and relay.
d. If all components check positive for continuity then test the wiring harness plug for continuity to see if
there is a broken wire within the wiring harness insulation.
3. COMPRESSOR RUNS - WATER IS WARM:
a. The most common cause for a water chiller to run without producing cold water is a loss of refrigerant.
The water chiller must be taken to a certified refrigerant technician for repairs.
b. Make sure the condenser fan motor is operative. The fan blade must turn freely to help remove the heat
of compression.
c. An incorrect refrigerant charge, restriction or defective compressor (not pumping) will also cause the
compressor to run without producing cold water. All these signs indicate a problem within the refrigeration
system and the water chiller must be checked by an authorized service company.
a. A dirty condenser or a blocked fan will cause a high head pressure and frequent cycling of the overload
protector.
b. Check the incoming voltage to make sure it is within 10% of the serial nameplate rating.
d. Change the overload or relay if defective.
a. Check the electrical supply for power and correct voltage. The incoming voltage must be within 10% of
the rated voltage on the serial nameplate.
5. NOISY OPERATION:
a. Check to make sure the fan blade is rotating freely.
4. COMPRESSOR CYCLING ON OVERLOAD PROTECTOR:
c. A restriction or moisture in the system will also cause intermittent cycling. A certified refrigeration
mechanic should be contacted in this situation.
c. Bubbler Stream - Bubbler can be rotated slightly to direct the stream backwards or forwards. Adjust the
stream to minimize splashing. Splashing may occur from bubbler stream if the unit is not level. Shim
lower mounting point, if necessary, to level chiller.
6. RESTRICTED OR NO WATER FLOW:
f. Check flow adjustment. See start up note #3.
a. Ensure water supply service stop valve is fully open.
g. Flow control in solenoid valve outlet elbow clogged remove & clean.
c. Check for twists or kinks in outlet tubing.
e. The cartridge valve located in the water control assembly or bubbler can also become clogged with
foreign material. The cartridge valve can only be replaced and not repaired.
b. Check the compressor mounting to make sure the pins and clips are not rattling. If the compressor
appears to be noisy internally, it must be replaced.
b. Verify minimum 20 psig supply line flow pressure.
d. Check the water inlet “Y” strainer. Sediment from the main supply can get trapped in the screen along
with installation materials such as pipe dope and flux. The screen should be cleaned and checked on a
regular basis and replace if needed.

A151.8-VR-BF4
Page 17 of 20
Date: 11/10/2020
7021-025-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
1. Motors have lifetime lubrication and do not require scheduled maintenance.
CLEANING & MAINTENANCE GUIDE:
2. Excess dirt or poor ventilation will cause the compressor overload protector to turn the compressor off and it
will cycle on and off with no cold water coming out of bubbler. Periodically clean with vacuum cleaner, air
hose or brush the condenser fins and cabinet ventilation louvers. In environments where dirt and dust is
more prevalent, clean more frequently.
1. To Remove water spots or rust spots, stainless steel cleaner/polish on a cloth is recommended.
For Powder coated units: Units should be cleaned using a mild soap solution with a sponge or cotton cloth.
Wipe down surfaces then rinse with clean water.
3. Stainless steel should be kept clean at all times. If a coating of stainless steel cleaner/polish is maintained,
stainless steel surfaces will retain their new, clean, polished appearance indefinitely.
For Stainless steel units:
2. If there are stubborn spots or if you wish to treat a scratch, synthetic abrasive general purpose pads such as
scotch brite are recommended.
4. Periodically remove access panel of cooler and clean out inline “Y’’ strainer
3. Periodically remove fountain top and clean out in-line strainer.
CARTRIDGE VALVE PARTS BREAKDOWN
3
2
1
5
4
CARTRIDGE REPLACEMENT/ STRAINER MAINTENANCE
Note: Use the Universal Maintenance Tool to perform the following:
1. Strainer Plug must be removed before Cartridge replacement and Strainer maintenance (no need to turn the
water off at the Angle Stop). Some residual water will drainduring Plug removal.
2. Clean Strainer as needed using clean water.
3. Cartridge Replacement - insert diamond end of the Universal Tool into Pushbutton, rotate 90 degrees and pull
firmly to remove the Button. Remove Cartridge Retaining Nut . Remove and replace Cartridge. When replacing
Cartridge, be sure to align the inlet and outlet Ports on the Cartridge with the Ports in the Valve Body.
— NOTE: STRAINER SCREEN MUST BE IN PLACE FOR WATER TO FLOW.
-Button Removal
-Cartridge Retaining Nut
-Strainer Plug
Push-in Fittings
-Removal of P.E. Tubing from
Universal Maintenance Tool
6
ITEM # PART NUMBER DESCRIPTION
1 7003-095-000 Valve Body Sub Assembly
2 7000-060-000 Valve Cartridge
3 7000-052-000 Retaining Nut
4 7003-864-000 Strainer, Auto Stop
5 7003-097-001 Strainer Cap
6 7003-194-199 Maintenance Tool

A151.8-VR-BF4
Page 18 of 20
Date: 11/10/2020
7021-025-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
Repairs must be made with Murdock Manufacturing parts only. Please order through your local representative or
distributor. The phone number to locate your local representative is 1.800.591.9360.
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
NOTE:
** Flow Restrictor Only Available
With Low Flow Bubbler.
ITEM # PART NUMBER DESCRIPTION ITEM # PART NUMBER DESCRIPTION
1 7000-005-199 Drain Adapter 9 7003-193-000 Spring, Pushbutton Return
2 0116-016-000 #10-32 x 3/8" Phillips Truss Head Screw 10 7003-196-199 Pushbutton, Chrome
3 7000-006-000 Flat Drain Adapter Gasket 11 7003-197-199 Escutcheon, Chrome
4 7000-015-000 1-1/4" OD P-Trap 12 0161-062-000 #6-32 x 1/2" Phillips, Flat Head Screw
5 0152-010-000 #10-32 x 1" Hex Flat Head Screw 13 0124-055-000 #8 x 3/4" Phillips, Round Head Screw
6A 7000-012-001 Stainless Steel Bubbler Assembly 14 7003-198-199 Mounting Sleeve
6B 7000-099-002 Flexible Gray Bubbler Assembly 15 7003-095-001 Valve Body Sub Assembly
7 1895-123-000 1/4" x 3/8" OD Tube Union Push-In 16 7003-093-001 Flow Restrictor - Low-Flow Bubbler Only
8 7003-195-000 Spring, Overtravel
1
2
3
4
5
6A
6B
9
10
11
8
16
15
14
13
12
7
VANDAL RESISTANT DRINKING FOUNTAIN PARTS BREAKDOWN DRAWING

A151.8-VR-BF4 SERIES BREAKDOWN
Repairs must be made with Murdock Manufacturing parts only. Please order through your local
representative or distributor. The phone number to locate your local representative is 1.800.591.9360.
A151.8-VR-BF4
Page 19 of 20
Date: 11/10/2020
7021-025-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
11
13
12
6
3
5
1
4
2
7
10
9
8
39
38
37
36
34
35
33
41
42
35
32A
27
28
29
31
32B
40
30
23
21
26
22
24
25
20
19
43
16
18
17
15
14

A151.8-VR-BF4 SERIES BREAKDOWN
Repairs must be made with Murdock Manufacturing parts only. Please order through your local
representative or distributor. The phone number to locate your local representative is 1.800.591.9360.
A151.8-VR-BF4
Page 20 of 20
Date: 11/10/2020
7021-025-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
ITEM #
PART NUMBER DESCRIPTION
1 0110-004-000 #8 x 3/4" Phillip Pan Head Screw
2 7014-034-199 Drain Tray, -BF4
3 7000-006-000 Drain Adapter Gasket
4 7003-186-199 1-1/4" x 2-3/4": Plastic Drain Tube
5 4970-265-000 1-1/4" P-Trap
6 0124-031-000 #8-3/8" Hex Head Screw
7 0302-004-000 #10-32 S/S Hex Nut
8 0321-011-000 #10 S/S External Tooth Lockwasher
9 0710-730-001 9V Plug-In Transformer
10 7014-160-001 Mounting Frame Assembly, BF4
11 6502-070-000 #10-32 x 1/2" Pan Head Screw
12 7014-036-199 Solenoid Mounting Bracket
13 7013-133-001 Valve Assembly
14 0116-010-000 #10-32 x 1/2" S/S Phillips Truss Head Screw
15 7013-232-199 "Y' 2-Way Divider Bracket Clamp
16 7013-220-001 "Y" 2-Way Divider Assembly, BF4
17 0112-021-000 #10-32 x 1/2" S/S Hex Screw
18 7013-221-199 Bracket "Y" Strainer Mount
19 7014-140-001 Frame, Chiller Mount, BF4
20 7000-245-000 Back Panel Spacer
21 7014-167-199 Upper Trim Panel, #4 Finish, BF4
22 1895-123-000 1/4" x 3/8" O.D. Tube Union Push-In
23 Drinking Fountain See Drinking Fountain Repair Parts for components
24 7008-010-001 8GPH Chiller Assembly
25 0124-051-000 #8 x 3/8" Allen Pan Head
26 7000-238-199 Vented Panel, #4 Finish
27 0116-013-000 #10-32 x 3/4" Phillips Round Head Screw
28 7013-103-199 Mesh Screen
29 7013-114-199 Screen Plate -BF4
30 0302-005-000 1/4-20 UNC S/S Hex Nut
31 7013-032-000 Graphics Plate, #4 Finish
32A 7014-019-003 Bottle Filler Panel Assembly, Less BCD, #4 Finish
*32B 7014-020-003 Bottle Filler Panel Assembly, BF4-BCD, #4 Finish
33 0331-023-000 #8 S/S Flat Washer
34 6527-108-000 #8 Internal Tooth Lockwasher
35 0302-003-000 #8-32 S/S Hex Nut
36 7013-014-199 Nano Sensor Bracket
37 7013-019-199 Foam Tape
38 2563-380-001 Nano Sensor Assembly
39 7013-009-001 Nano Sensor Spacer Assembly
*40 7013-034-000 Nameplate, Outdoor Bottle Filler (Green)
*41 7014-022-001 BCD, Bottle Filler Counter Bracket Assembly
*42 0331-003-000 #8 Helical Spring Lock Washer
43 7000-021-001 "Y"-Strainer Assembly, 1/4"
NOTE:
Items with (*) are for units
with -BCD option only.
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
DRINKING FOUNTAINS
