Music Man BT-X51 User manual

MusicMan® * User Manual
DAB+ Socket Soundstation BT-X51
Portable Bluetooth Kitchen Radio with DAB+, FM Radio and BT
with 27 x 15mm display
The manufacturer Technaxx Deutschland GmbH & Co.KG hereby declares that this device,
to which this user manual belongs, complies with the essential requirements of the
standards referred to the Directive RED 2014/53/EU. The Declaration of Conformity you
find here: www.technaxx.de/ (in bar at the bottom “Konformitätserklärung”). Before using
the device the first time, read the user manual carefully.
Service phone No. for technical support: 01805 012643 (14 C/min. from German fixed-line
& 42 C/min. from mobile networks).
Free Email: [email protected]
The support hotline is available Mon-Fri from 9 am to 1 pm & 2 pm to 5 pm
This device has a rechargeable battery. It must be fully charged before
first use. Turn OFF nearby Bluetooth devices to avoid signal
interference!
Keep this user manual for future reference or product sharing carefully. Do the
same with the original accessories for this product. In case of warranty, please
contact the dealer or the store where you bought this product.
Warranty 2 years
Enjoy your product. Share your experience and opinion on one of the
well-known internet portals.
Security and Disposal Hints for Batteries: Hold children off batteries.
When a child swallowed a battery go to a doctors place or bring the child
into a hospital promptly! Look for the right polarity (+) and (--) of batteries!
Always change all batteries. Never use old and new batteries or batteries of
different types together. Never short, open, deform or load up batteries!
Risk of injury! Never throw batteries into fire! Risk of explosion!
Hints for Environment Protection: Packages materials are raw materials
and can be recycled. Do not disposal old devices or batteries into the
domestic waste. Cleaning: Protect the device from contamination and
pollution (use clean drapery). Avoid using rough, coarse-grained materials
or solvents/aggressive cleaner. Wipe the cleaned device accurately.
Important Notice: Should battery fluid leak from a battery, wipe the battery
case with a soft cloth dry. Distributor: Technaxx Deutschland GmbH &
Co.KG, Kruppstr. 105, 60388 Frankfurt a.M., Germany

Features
Soundstation with DAB+/DAB & FM radio, Bluetooth V4.2 & AUX-IN
Pairing with Bluetooth-enabled audio devices, Smartphones, Tablets, etc.
Rechargeable everywhere via sockets Exchangeable 800mAh battery for
portable use MicroSD card slot & USB port up to 32GB AUX input for
connection of other audio devices Illuminated LCD display (2,7x1,5cm)
Clock & Alarm function Power options: replaceable battery, MicroUSB or
AC adapter* (*included) Ideal to use at home or for traveling (wide radio
variety, easiest installation, brilliant sound quality
Technical specifications
Bluetooth
Bluetooth V4.2 / ~10m distance / transmitting band 2.4GHz /
radiated transmission power max. 2.5mW
Functions
DAB/FM, Bluetooth, MicroSD carte, USB flash drive,
AUX–IN
Output
RMS 3W (mono, Ø 5.2cm) speaker, Impedance 4Ω, Ø 5.2cm
/ THD = 10%
Frequency speaker
100Hz–20kHz
DAB+ frequency band
170Hz–240MHz
FM frequency band
87.5Hz–108.0MHz
AUX-IN
3.5mm stereo plug (analog audio input)
Music format
MP3 / WAV
SNR / DAB+ sensitivity
≥ 80dB / –101dB
Power supply
Replaceable rechargeable Lithium 800mAh battery
3.7V
Charging time
~2–3 hours (USB charging cable or socket power
plug*, *included)
Playing time
~3 hours / ~4 hours (max. VOL, BT/SD card or USB)
~10 hours with 50% volume
Standby time
~20 hours (BT connection without playing music)
Standby time
~6 month (in Power OFF mode)
Power input
DC 5V/1A or AC 220–240V 50Hz
External FM antenna (for DAB+ & FM Radio), Length: 8.5–33.5cm
Material
PC & ABS
Weight / Dimensions
260g / (L) 9.5 x (W) 10.5 x (H) 4.5cm
Package
contents
MusicMan® DAB Socket Soundstation BT-X51, BL-5C 800mAh
Battery, Micro USB charging cable, AUX–IN cable, Socket
adapter, User Manual

Charging
Before first use open the battery cover, put battery into the compartment and
close it. There are two ways of charging the BT-X51: Either connect the AC
adapter to the BT-X51 and plug it into an AC 220-240V 50Hz socket, or use
the MicroUSB port (12) by connecting a MicroUSB cable to the BT-X51.
Connect the charging cable to a DC 5V/1A USB adaptor* (*not included) or
computer USB port.
The RED LED on the top shines bright while charging in the OFF status. When
the BT-X51 is fully charged, the RED LED turns off and battery signal on the
display will be full. (We suggest to turn off the BT-X51 while charging. It takes
a longer time to get fully charged if it is in usage when being charged.)
Product overview: Front / Back / Top / Side

1
LCD Display (illuminated)
2
MENU (only for DAB+ & FM mode)
Under DAB+ & FM mode:
Press short to check signal strength, frequency, genre, Bitrate, Radio
text Press long to enter Menu to set: Time/Date, Alarm1, Alarm2,
Sleep time, Factory reset, System version, Backlight, Contrast (to enter
the setting use Play/Pause (7), Previous (5)/Next (9) to select)
3
Power On / Off / change mode
Power On press the button once.
Power Off keep pressing the button for 2 seconds
Short press to change the mode (DAB+, FM, BT, USB, SD, AUX-IN)
after power on
4
Search
Under DAB+ & FM mode: short press to search and save radio stations
automatically
5
Previous track
Short press go back to last track / switch between the radio stations
6
Volume –
Short press decrease VOL / Long press decrease VOL rapidly
7
Play / Pause
Short press Play/Pause / select DAB+ radio station.
Long press change device into standby mode.
8
Next track
Short press move to next track / switch between the radio stations
9
Volume +
Short press increase VOL / Long press increase VOL rapidly
10
Speaker
14
MicroSD card slot
11
USB port (data only)
15
AC power plug
12
MicroUSB port
16
Battery compartment
13
AUX–IN port
17
Antenna (DAB+ & FM)
18
LED (indicator light)
Under DAB+ or FM mode: BLUE LED is off
Under BT/AUX/USB/MicroSD card the BLUE LED
blinks fast when BT/USB or MicroSD is not connected.
blinks slowly when BT is connected or MicroSD/USB unit is playing
music.
remains steady when music is paused.
Under AUX mode the BLUE LED always flashes slowly.
Under charging mode the RED LED remains steady and turns off when
it is fully charged

Radio mode (DAB+ / FM)
Note: Radio stations are saved and stored in the found order. It is not possible
to change the order of the found radio stations or set favorites.
To switch on the BT-X51 press the power button (3).
Briefly press the power button (3) to switch to Radio mode. You can choose
between digital radio (DAB+) and FM radio (FM). The LED is off. The
automatic station search and the storage of the found stations can be started
by pressing the search button (4). Press the next track or previous track button
to switch between the stored stations. Press the Play/Pause button to confirm
a station. Adjust the volume by pressing the Volume Down and Volume Up
buttons.
Music Mode (MicroSD or USB)
Note: The inserted device (MicroSD or USB flash drive) must be formatted to
FAT32 and the music files have to be MP3, WAV.
To switch on the BT-X51 press the power button (3).
To play MP3 files from a MicroSD card or USB stick, press the power button (3)
repeatedly to enter USB or SD mode. The LED flashes BLUE. Playback starts
automatically. If necessary, remove an inserted AUX cable. Press the
Play/Pause button to start and pause music playback. Press the next track or
previous track button to select a song. Adjust the volume by pressing the
Volume Down and Volume Up buttons.
Bluetooth Mode
To switch on the BT-X51 press the power button (3). Press the power button
briefly several times to switch to Bluetooth mode. The LED flashes BLUE.
After entering the Bluetooth mode automatically Bluetooth is enabled. Turn on
Bluetooth of cell phone or other Bluetooth enabled devices to pair and search
for the pairing name “MusicMan DAB BT-X51”.
Press the Play/Pause button to start and pause music playback. Press the
next track or previous track button to select a song. Adjust the volume by
pressing the Volume Down and Volume Up buttons.

AUX–IN Mode
You can play music directly from a device connected via an AUX-IN cable.
Plug one end of 3.5mm AUX–IN cable into AUX–IN connector and the other
end into AUX-OUT connector of MP§ Player, Smartphone, PC or CD player to
listen to music.
To switch on the BT-X51 press the power button (3).
Press the power button briefly several times to switch to AUX-IN mode. The
function flashes BLUE. To adjust the volume, press the Volume Down and
Volume Up buttons on the external device and on the BT-X51.
Note: Under AUX–IN mode, only VOL–/VOL+ work. By pressing play/pause
you can mute the device but the song plays along, because it is coming from
an external device.
System settings
To enter the System settings go to DAB+ or FM mode and press the menu
button long. Press previous track/next track to choose a setting. Enter the
setting by pressing play/pause button.
Time/Date
To adjust the date and the time press previous track/next track and confirm
with play/pause button
Alarm Clock
You can set up two alarms on the BT-X51. To adjust the alarm use previous
track / next track to choose Alarm: on, set the hour, set the minute, set the
volume and set the mode (alarm, DAB+ or FM). Use Play/Pause button to
confirm the input.
When the alarm starts, press Play/Pause button to activate the snooze
function. BT-X51 starts alarming again after 9 minutes. To exit, press power.
Note: If you want to be woken up and the BT-X51 should not play music all
night. Press the play/pause button long to enter standby mode.

Sleep time
To adjust the sleep time press previous track / next track to set the counter
between 5 and 120 minutes (5, 15, 30, 60, 90, 120min). Use Play/Pause
button to confirm the input. After the set time BT-X51 turns into standby mode.
Factory reset
To set the device back to factory settings choose Yes. Choose No nothing will
happen. Use play/pause button to confirm the input.
System version
Look up the firmware version here.
Backlight
Set the time how long it should take the backlight to go off. Set it by pressing
previous track / next track. Use play/pause button to confirm the input.
Contrast
Set the contrast (0-31) by pressing previous track / next track. Use play/pause
button to confirm the input.
FAQ
Something does not work correctly with the BT-X51 Power device OFF,
unplug from power source and remove the rechargeable battery or Use the
factory reset.
It is not possible to press any buttoncharge the device via MicroUSB or
AC socket

Warnings
If the device does not turn on after switching it on, or it turns off after turning
it on, check whether the battery is fully charged. If it is OFF power, get it fully
charged and try again later. (We suggest charging the device 1x week if it is
not used for a long time.)
When the device works under AUX–IN mode, do not (!) increase the volume
of your mobile phone, PC, MP3/MP4 Player, CD, DVD etc. to a large extend; a
sonic boom or sound distortion may occur. In that case, decrease volume
either of mobile phone, PC, MP3/MP4 Player, CD, DVD or device. The sound
gets normal soon.
If the device fails to link to your mobile device or if it fails to play music after
being connected, the user shall check if the correct PIN code (0000) is entered
or if your mobile device supports A2DP.
Only charge the device with the DC 5V/1A USB adaptor* (*not included) or
in USB slot of your PC with the provided original USB charging cable. It would
make the device fail to work or even damage the headphone if it is not
charged with recommended voltage.
Do not attempt to disassemble the device, it may result in short-circuit or
even damage.
Do not drop or shake the device, it may break internal circuit boards or
mechanics.
Keep the device in dry and ventilated environment. Avoid high humidity and
high temperature. Also batteries should not be exposed to excessive heat or
direct sunlight.
This device is not water resistant, therefore keep it away from moisture.
Keep the device away from little children.
