MusicMan ® * User Manual
SoundBlaster BT-X55
The manufacturer Technaxx Deutschland GmbH & Co.KG hereby
declares that this device, to which this user manual belongs, complies
with the essential requirements of the standards referred to the Directive
RED 2014/53/EU. The Declaration of Conformity you find here:
www.technaxx.de/ (in bar at the bottom “Konformitätserklärung”).
Before using the device the first time, read the user manual carefully.
Service phone No. for technical support: 01805 012643 (14 cent/minute
from German fixed-line and 42 cent/minute from mobile networks).
Free Email: suppo[email protected]
The support hotline is available Mon-Fri from 9am to 1pm & 2pm to 5pm!
This device has a rechargeable battery. It must be fully charged
before first use. NOTE: Charge the battery of the device every 2–3
month if it is not used!
Keep this user manual for future reference or product sharing carefully.
Do the same with the original accessories for this product. In case of
warranty, please contact the dealer or the store where you bought this
product. Warranty 2 years
Enjoy your product. *Share your experience and opinion on one of
the well-known internet portals.
Features
•Bluetooth V4.2 loudspeaker with 2x 35W
•TWS function – can be used as a stereo system
(two SoundBlaster required)
•Splash-proof SoundBlaster according to IPX5
•Passive bass radiator on the sides
•Integrated FM-radio
•Built-in battery
•Practical carrying handle
•Optimized Google Assistant and Siri voice control
•Hands-free Mic for easy picking up the call
•Line-in function
•USB support

Technical specifications
Bluetooth version
V4.2
Bluetooth
Transmitting distance ~10m (open space)
Frequency band 2.4GHz
Radiated transmission power max. 2.5mW
Functions
Bluetooth, AUX–IN, USB, FM
USB support
Max. 32GB
Loudspeaker
2x 35W stereo / 3 Inch / SNR ≦65dB /
Impedance 4Ω / Frequency 80Hz–12kHz
Audio input
3,5mm
Battery
Rechargeable 7.4V 3600mAh lithium ion
built-in battery
Charging time
4.5 hours (with 5V/2A charger)
Playing time
4.5 hours (with 50% volume)
2 hours (with 100% volume)
Operating temperature
0°C - 40°C
Protection class
IP X5 (splash water proofed)
Material
ABS plastic & fabric
Weight / Dimensions
2.53kg / (L) 36.6 x (W) 14.3 x (H) 18.8cm
Package Contents
MusicMan SoundBlaster BT-X55, Micro
USB charging cable, AUX–IN cable, user
manual
Hints for Environment Protection: Packages materials are raw
materials and can be recycled. Do not disposal old devices or
batteries into the domestic waste. Cleaning: Protect the device
from contamination and pollution. Avoid using rough, coarse-
grained materials or solvents/aggressive cleaner. Wipe the
cleaned device accurately. Distributor: Technaxx Deutschland
GmbH & Co.KG, Kruppstr. 105, 60388 Frankfurt a.M., Germany

Product overview
1
Battery indicator
5
Mode button
2
Backward/Volume down
6
TWS pairing button
3
Forward/Volume Up
7
Power On/Off
4
Play/Pause
8
USB port, charging jack,
AUX-In port
1 2 3 4 5 6 7
8

Charging
Please charge the BT-X55 SoundBlaster fully with the included
Micro-USB charging cable before first use. Plug the charging
cable into the Micro USB slot of the speaker, and the other end
into a USB slot of a charger* (5V/2A, *not included).
The LED indicator will dynamically light up. It turns into static light
when it is fully charged. (We recommend to turn off the speaker
while charging, otherwise, it will take longer time). It is fully
charged after 4 to 6 hours.
Warning: The device does not have power bank function. It is
forbidden to charge other devices via this unit or to connect other
devices via a USB cable then USB flash drive. It can occur
unrepairable damage.
First use
Power on the device by press and hold the power on/off button
(7). A welcome tone sounds. To shut down the SoundBlaster
press again the power button. A good-bye tone sounds.
Modes
Bluetooth
After power on the SoundBlaster it is automatically in the paring
state (blinking power button). To pair the SoundBlaster with your
smartphone, tablet or PC, start the Bluetooth search on your
device and connect it with “MusicMan BT-X55”. The power
button stops blinking and the SoundBlaster makes a tone once
connected.
The SoundBlaster will automatically reconnect the last paired
device if it is reachable. It will shut down automatically after 5
minutes if no connection occurs.

•Long press forward button (3) or backward button (2) to
adjust volume up and down. Short press for switch title.
•Press play/pause (4) on the device to play/pause the music.
•Long press play/pause (4) to activate the voice assistant of
your connected smartphone.
•Press play/pause (4) while an incoming call to accept. Long
press to deny the call.
Play music from USB-disk
After turn on the speaker, insert USB flash drive into the USB slot
under the water-resistant cover (8). The speaker will play the
stored music automatically.
Under playing mode, short press backward (2) or forward (3)
button to select songs. Long press to adjust the volume.
Press play/pause (4) to play or pause music.
Note: Under Bluetooth playing mode, insert USB disk will
disconnect the Bluetooth and switch to play the USB disk. You
can press the mode button (5) to switch to Bluetooth mode again.
FM-radio
In the FM radio mode, the audio cable provided works as an
antenna. Before using please insert the audio cable into the
audio-plug to get the best radio signal.
Under playing mode, short press play/pause” button to auto
search the FM channels. They will be stored automatically in the
order of occur. The order of the saved channels cannot be
changed.
Short press Forward or Backward button to change the stored
FM channel.

TWS Function
Turn on two BT-X55 SoundBlaster speakers you want to pair.
Both speakers have to be in Bluetooth mode without any device
connected.
Short press the TWS pairing button (6) on a speaker. A tone will
be audible and TWS button will keep lighting after paired
successfully.
Make Bluetooth connection with your mobile phone to play music
by the two paired Speakers to create more powerful surround
sound effect.
To exit the TWS mode, press the TWS pairing button (6) again.
Note: Once two units paired with TWS they both will be
connected next time automatically if they are within the effective
range.
Make the TWS connection first, then connect your Bluetooth
device with the speaker.
Under TWS mode and Bluetooth connected, when user long
press the TWS button, both the TWS connection and Bluetooth
connection will be disconnected.
AUX-IN
For other compatible music devices or your MP3/MP4 player, use
the supplied audio line cable to connect from the device’s line-
out to the Aux-In port (8) of this device, then enjoy…
When using an external device, all functions can be controlled by
the external device.

Phone call
The BT-X55 SoundBlaster will ring with your set ringtone in
Bluetooth-mode.
To answer the call, press the play/pause button (4). Talk into the
direction of the speaker for best voice transmission.
Long press play/pause button to reject the call.
To end a call, short press play/pause button or operate on mobile
phone to end the call. During the call, long-press play/pause
button to switch to talk on the phone.
Battery indicator
There are two ways to see the battery level of the BT-X55
SoundBlaster:
•The battery indicator LED (1) display the remaining
battery power on the device. Each LED means 25% of
battery power.
•While connected with your smartphone, the battery
indicator will be displayed in the drop-down menu of the
status bar of your smartphone.
Troubleshooting
If the BT-X55 fails to link to your mobile device or if it fails to play
music after being connected, the user shall check if your mobile
device supports A2DP. If you cannot connect the BT-X55 to your
phone, do as follows:
Ensure that the speaker is charged or has a power connection
and is in on state. Ensure that the Bluetooth feature is activated
on your phone. Check that the speaker is within 10m of your
phone and that there are no obstructions between the speaker
and the phone, such as walls or other electronic devices.

The BT-X55 powers off or does not turn on again could be either
a low battery or a problem with the power supply. Charge the BT-
X55. (We suggest charging the BT-X55 all 2–3 month if it is not
used for a long time.) If the speaker has problems to play from
USB sound files, please check the correct formatting of the
sources. They should be formatted in NTFS. The maximum
supported data storage is 32GB. The USB port doesn’t support
any external hard disk drive (HDD).
Notes
● Noises are heard from the BT-X55 could be a poor Bluetooth
signal. To avoid noise, stay within the Bluetooth range of ~10m.
● Avoid prolonged exposure to excessive volume that may cause
noise-induced hearing impairment. ● Turn the volume down
before star play with any sound source, then adjust it to the right
volume.
Warnings
● Do not disassemble the BT-X55, it may result in short-circuit or
damage. ● Battery warning: Improper use of the battery may
cause fire or chemical burns. The battery may explode in case of
damage. ● Do not modify, repair or remove without professional
guidance. ● Do not use corrosive or volatile liquid for cleaning.
● Do not drop or shake the BT-X55, it may break internal circuit
boards or mechanics. ● Keep the BT-X53 in dry and ventilated
environment. Avoid high humidity and high temperature. Also,
batteries should not be exposed to excessive heat or direct
sunlight. ● Keep the BT-X55 away from little children.
