MusicMan®* User Manual
Disco Speaker with Microphone BT-X53
The manufacturer Technaxx Deutschland GmbH & Co.KG hereby
declares that this device, to which this user manual belongs, complies
with the essential requirements of the standards referred to the Directive
RED 2014/53/EU. The Declaration of Conformity you find here:
www.technaxx.de/ (in bar at the bottom “Konformitätserklärung”).
Before using the device the first time, read the user manual carefully.
Service phone No. for technical support: 01805 012643 (14 cent/minute
from German fixed-line and 42 cent/minute from mobile networks).
Free Email: [e-mail]
This device has a rechargeable battery. It must be fully charged
before first use. NOTE: Charge the battery of the device every 2–3
month if it is not used!
Keep this user manual for future reference or product sharing carefully.
Do the same with the original accessories for this product. In case of
warranty, please contact the dealer or the store where you bought this
product. Warranty 2 years
Enjoy your product. *Share your experience and opinion on one of
the well-known internet portals.
Features
•LED lighted front panel with sound recognition
•Rotating disco light on the top
•Bluetooth, Micro SD, USB, AUX-IN and FM-Radio functions
•30W loudspeaker
•Inclusive one microphone for singing
•2 microphone plugs for duets
•Built-in 4000mAh battery

Technical specifications
Bluetooth version
V4.2
Bluetooth
Transmitting distance <10m (open space)
Frequency band 2.4GHz
Radiated transmission power max. 2.5mW
Modes
Bluetooth, Micro-SD card, USB, AUX-IN,
FM-radio
FM-Frequency
87.5-108MHz
Micro-SD / USB capacity
Up to 64GB
AUX-connector
3.5mm
Loudspeaker / frequency /
impedance
30W Ø5inch / 90Hz-18kHz / 4Ω
Sound pressure level
>115db 1KHz / THD<1%
Playtime
4-6h
Charging time
4h (5V/1.2A)
Battery
4000mAh lithium polymer battery
7.4V / charging via Micro USB
Power input
DC 5V / 1.2A
Operating temperature
0°C up to +40°C
Material
PC / ABS / Wood
Weight / dimension
3.0Kg / (L)22.9 x (W)21.8 x
(H)34.2cm
Package content
MusicMan® BT-X53, wired
microphone, AUX cable, Micro-
USB charging cable, user manual

Product details
1
Disco light
12
Forward / next
2
Power
13
LED speaker grid
3
Modes LED indicator
14
Line in
4
Echo microphone
15
Microphone plug 1
5
Light button
16
Microphone plug 2
6
Mode button
17
Line out
7
Repeat / back
18
Micro-SD card slot
8
Handle
19
USB port
9
Volume +/-
20
FM-antenna
10
Play / pause
21
DC in 5V/1.2A (Micro USB)
11
Microphone volume
22
Bass port

First use
Connect the speaker with the Micro-USB cable and a USB power
adapter (not included in the delivery).
Press and hold the power button (2) for three seconds until the
activation sound appears. The speaker starts up in Bluetooth
mode. The working indicator LED turns blue. Now the device is
ready for pairing. Open the Bluetooth settings on your Bluetooth
device and select the „MusicMan BT-X53“from the device list.
You can also use the speaker with Aux-In, USB stick, or Micro-
SD card. With the mode button (6) you can change the mode
from Bluetooth to AUX, USB, FM-radio or Micro-SD card.
How to charge the LED Disco Speaker BT-X53
The BT-X53 has an internal, rechargeable battery which must be
fully charged before use for the first time. It takes about 4 hours
to charge the battery full.
Please charge the speaker by using a common USB power
adapter* (DC 5V/1.2A) (*not included). While charging the
charging indicator LED above the Micro USB port will turn RED.
When the speaker is fully charged, the charging indicator LED
will turn off.
The fully charged battery of the speaker has power for up to 4
hours of playing time. The batterie status will be visible on your
phone while connected with Bluetooth.
Modes
Bluetooth Mode
The speaker must be powered on before you begin to initiate the
pairing. Pairing is the process of establishing a link between BT-
X53 and a Bluetooth device.
Note: Activate the Bluetooth feature on the phone, and set the
phone to search for Bluetooth devices. Check the user guide of
your phone for instructions.

Select the speaker „MusicMan BT-X53“from the list of found
devices. When asked the PIN code, please enter “0000” to pair
the speaker to your phone.
If the pairing is successful, you will hear a connection sound and
the speaker enters idle state.
Auto reconnection
When the BT-X53 is in off state, switch it on and it will reconnect
automatically to the last connected device if it is reachable.
Micro-SD card mode
Insert a Micro-SD card in the device in on state. The speaker will
automatically play the songs from the Micro-SD card. You can
also change the mode bypress the mode button (6). The speaker
supports up to 64GB Micro-SD cards.
AUX-Mode
Connect the AUX-cable to any sound-source you will operate
with. Like MP3 player, CD-player, or any other device which
supports AUX (Headphone jack)
You can also change the mode by press the mode button (6) after
the device is in on state. In AUX-Mode just the play/pause button
is useable. For changing tracks please use the source device.
FM-radio
To enter the FM-radio mode press the mode button until the AUX
indicator LED is activated. Without an AUX cable attached, the
speaker enters the FM-radio mode automatically.
To search for broadcasting stations, press the play button (10).
Now the speaker searches for stations. Switch the channels with
next (12) and back (7) buttons.
Hint: Plug in one of the following devices and the mode will be
switched automatically to the plugged-in device mode. Micro-SD,
USB or AUX.

LED light show
Turn on the LED light show of the BT-X53 by press and hold the
“Light” button (5). Both LED modes now in on state.
To change between the modes, single press the light button.
The modes are following: both in on state / disco dome / LED
grid. By press and hold the light button again, the Lightshow will
turn off.
Note: Only the LED grid has sound recognition. It will change the
lights depending on the sound.
Microphone
To sing with the included wired microphone, plug it into the
microphone plug (15) on the back. Turn on the microphone. The
usage of the microphone is in every mode possible.
Both knobs "Echo" (4) and "Mic" (11) are used for the sound of
the microphone. Echo sound option for a more or less short
repetition of your own voice and the volume control for the
general output sound of the microphone.
Troubleshooting
If the BT-X53 fails to link to your mobile device or if it fails to play
music after being connected, the user shall check if your mobile
device supports A2DP. If you cannot connect the BT-X53 to your
phone, do as follows:
Ensure that the speaker is charged or has a power connection
and is in on state. Ensure that the Bluetooth feature is activated
on your phone. Check that the speaker is within 10m of your
phone and that there are no obstructions between the speaker
and the phone, such as walls or other electronic devices.
The BT-X53 powers off or does not turn on again could be either
a low battery or a problem with the power supply. Charge the BT-
X53. (We suggest charging the BT-X53 all 2–3 month if it is not
used for a long time.) If the speaker has problems to play from
USB or Micro-SD sound files, please check the correct formatting
of the sources. They should be formatted in exFAT / NTFS.
The maximum supported data storage is 64GB. The USB port
doesn’t support any external hard disk drive (HDD).

Notes
●Noises are heard from the BT-X53 could be a poor Bluetooth
signal. To avoid noise, stay within the Bluetooth range of ~10m.
●Avoid prolonged exposure to excessive volume that maycause
noise-induced hearing impairment. ●Turn the volume down
before star play with any sound source, then adjust it to the right
volume.
Warnings
● Do not disassemble the BT-X53, it may result in short-circuit or
damage. ●Battery warning: Improper use of the battery may
cause fire or chemical burns. The battery may explode in case of
damage. ●Do not modify, repair or remove without professional
guidance. ● Do not use corrosive or volatile liquid for cleaning.
● Do not drop or shake the BT-X53, it may break internal circuit
boards or mechanics. ● Keep the BT-X53 in dry and ventilated
environment. Avoid high humidity and high temperature. Also,
batteries should not be exposed to excessive heat or direct
sunlight. ● This BT-X53 is not water-resistant; keep it away from
moisture. ● Keep the BT-X53 away from little children.
Hints for Environment Protection: Packages materials are
raw materials and can be recycled. Do not disposal old
devices or batteries into the domestic waste. Cleaning:
Protect the device from contamination and pollution. Avoid
using rough, coarse-grained materials or solvents/aggressive
cleaner. Wipe the cleaned device accurately. Distributor:
Technaxx Deutschland GmbH & Co.KG, Kruppstr. 105, 60388
Frankfurt a.M., Germany
