mxr M108 User manual

92503002230revC
M108 TEN BAND GRAPHIC EQ

M108 10 BAND GRAPHIC EQ
DESCRIPTION
• Upto±12dBofcuttingor
boostingat10dierent
frequencies
•Easytoseeandadjustonstage
withglow-in-the-darkgraphics
andsliders
•18-voltoperationfor
increasedheadroom
•Truebypassswitching
POWER
TheMXRTenBandEQispowered
byan18-voltACadaptersuchas
theDunlopECB004/ECB004E
(included)oraDCBrick™power
supply.
CONTROLS
 VOLUMESLIDERcontrols
overalleectvolume
 PARAGRAPHICSLIDERSboost
orattenuateupto±18dBatsix
dierentfrequencycenters
 GAINSLIDERcontrolsamount
ofgainboost
 FOOTSWITCHtoggleseect
on/bypass(illuminatedred
sliderLEDsindicateon)
DIRECTIONS
• Runacablefromyourguitarto
theTenBandEQ’sINPUTjack
andrunanothercablefromthe
TenBandEQ’sOUTPUTjackto
youramplier.
• Setallsliderstotheir0dB
positionanddepressthe
footswitchtoturnthepedalon.
• MovetheVOLUMESLIDERupto
increaseoveralleectvolumeor
downtodecreaseit.
SPECIFICATIONS
InputImpedance 470kΩ
OutputImpedance 5kΩ
MaxInputLevelALLSlidersat0dB +14dBVat1kHz
MaxOutputLevelALLSlidersat0dB +14dBVat1kHz
NoiseFloor* -100dBv
Filtering ±12dbat:31.25,62.5,125,250,
   500,1k,2k,4k,8kHz
   ±12dBshelfat16kHz
Bypass TrueHardwire
CurrentDraw 26mA
*A-weighted at 5.2Vrms
• MovetheGAINSLIDERup
toincreasegainordownto
decreaseit.
• ExperimentwiththeTenBand
EQ’stone-shapingcapabilitiesby
movingthetenPARAGRAPHIC
SLIDERSupanddowntoboost
andcutvariousfrequenciesto
hearhowthisaectsthesound
ofyoursignal.
DUNLOP MANUFACTURING, INC.
P.O. BOX 846 BENICIA, CA 94510 U.S.A.
TEL: [phone] FAX: [phone]
