Mycle The Classic User manual

The Classic
User Manual

2
Meet Mycle.
Your New Best Mate.
Equipped with motor-powered assistance, the
Mycle Classic brings a boost to every journey.
To get the most out of your bike – and ensure
you’re using it safely and correctly – make sure you
read this manual before you get out on the road.
Technical Info
Net bike weight: 22kg
Maximum load: 100kg
Dimensions: L 167cm x H 105cm x W 42cm
Frame & Fork: Steel
Wheels: 24 inch
Crank: Prowheel 48T
Rear cassette: Shimano MF-TZ500-7
Shifters: Microshift 7S/P
Motor: 250w high speed motor
Maximum speed: 25km/h
Power assist levels: 5
Capacity: 36V 9.6Ah
Charging time: 4 hours
Imported and distributed by Mycle Ltd.
Your Mycle Classic has been designed
in accordance with the requirements of
European standards: EN 14764 and EN 15194,
which comply with safety requirements.

3
Contents
General Safety
Meet Your Mycle
Quick Set-Up
Power Assist
On Board Display
Charging The Battery
Charger Safety Precautions
Additional Comments
Maintenance
Warranty
Our Misson
4-5
6-7
8-9
10-11
12-13
14-15
16-17
18-19
20
21
22-23

Mycle General Safety
Watch the
weather
Always wear
a helmet
4

Mycle General Safety
General
Safety
Your Mycle Classic has been built and tested in the UK
by our trained Cytech bike technicians. However, before
trying out your Classic, make sure you carry out the routine
checks listed in the MAINTENANCE section of this manual.
When you first try the bike,
make sure the handlebars are
pointing forward and the road
ahead is clear. The assistance
will be triggered when you move
the pedals. Ensure your riding
complies with the Highway
Code and all trac rules.
Electric bikes are not suitable
for children under the age of 14,
and it is illegal for them to ride
on public highways. Riders
under the age of 18 should be
supervised by a grown-up.
We recommend starting your
first ride at level 1 (minimal
assist), then increasing assistance
levels as you grow in confidence.
When pushing the bike, always
set pedal assist to level 0 to
stop the bike accelerating if you
accidentally knock the pedals.
Be extra careful when riding
in dicult weather conditions,
such as rain, cold, ice and
snow, as well as at night.
Reduce your speed and allow
for longer stopping distances
on slippery surfaces.
When transporting your bike
on an external rack, we
recommend you remove the
battery and store it in a cool
place. We recommend you wear
protective clothing when cycling,
such as a helmet and gloves.
Failure to follow these warnings
could result in an accident,
injury or damage to your Classic.
Mycle cannot take responsibility
for any faults or damage
that occurs from improper
maintenance or lack
of safety checks.
5

Mycle Meet Your Mycle
Meet Your
Mycle
6

LCD Display
Shift Lever
Brake
Charging Port
LCD Display Charger
1
11
2
2
2
1
3
2
2
3
Saddle
Seat/Battery
Seat Clamp
Rear Brake
Hub Motor
Rear Derailleur
Handlebar
Frame
Fork
Front Brake
Crankset
1
2
3
4
5
6
7
8
9
10
11
Vehicle
Handlebars
Battery/Seat
2
3
5
4
4
6
8
7
9
10
10
11
1
Mycle Meet Your Mycle
Get started by understanding all the parts and
components of Your Mycle Classic.
7

Quick
Set-up
Before you get out on the road,
make sure your bike is correctly set
up and aligned to your height.
Mycle Quick Set Up
8

2
13
4
5
6
Release the lever
Set the brakes and gears
to a position that suits you
Re-fix the lever
1
2
3
Handlebar
Open the lever to
release the seatpost
Set the height of
your saddle
Re-fix the lever
4
5
6
Seatpost
Mycle Quick Set Up
9

High Power Tackle Hills On Board
Display
Power
Assist
Power Assist is initiated by the pedals and operated
through the On Board Display. Simply pedalling the
bike will create an additional level of power to increase
your riding speed or help you tackle hills. Switch
between the different levels, in combination with the
gears, to maintain a steady pace over varying terrain.
The Power Assist feature is what makes Mycle
special. You can switch from fully manual to high
speed assistance at the push of a button.
Mycle Power Assist
10

Be aware that using the higher power assist levels for
prolonged periods will use up the battery more quickly.
Mycle Power Assist
Level 0 fully manual
Level 1
Level 2
Level 3
Level 4
Level 5
for low speeds
& f lat riding
for low speeds
& gentle slopes
for faster speeds
& slopes
for faster speeds
& uphills
for high speeds
& uphills
11

Mycle On Board Display
On Board
Display
Everything you need to know about your
bike appears on the On Board Display.
It’s also equipped with a USB interface so
you can charge your phone as you ride.
Battery Front Light On
Trip
Distance
Speed
Total DistancePower On/O
Level
Down
Level
Up
12
USB Port

Mycle On Board Display
On Board
Display
Get Started
Hold the Power button for two
seconds to switch on and o.
Use The Light
Hold down the Level Up button for two
seconds to switch on the front light.
Operate Power
Assist
Use Level Up and Level Down to switch
between Power Assist modes.
Walking Mode
Hold down the Level Down button for two seconds to
walk with the bike – it will advance at 6km an hour.
Be aware that the bike will lurch forward in this mode.
13

Mycle Charging The Battery
High Power Uniformly
Balanced
14

Your Mycle Classic’s innovative design means
that the battery is hidden in the seat post. The
battery can be charged both with the seat post
connected to the bike, or by itself.
The battery is delivered with a minimum charge. Before riding
for the first time, you must fully charge it for at least 5 hours.
After charging, we recommend the battery sits for 20-30
minutes before use.
Make sure you charge the battery for at least 2 hours, at least
once a month, maintaining a charge level of around 50%. When
not in use, store the battery in a dry environment, ideally between
12-22°C. Always charge the battery before storing, or before
periods of non-use.
Charging while
connected
Simply remove the waterproof
cover and plug the charger
into the charging port located
under the saddle. Remember
to replace the cover when
charging is complete.
Charging while
removed
Remove the seat post by
unscrewing the connection
port and loosening the seat
clamp. Repeat these steps to
reconnect. If disconnected,
always bring the battery
inside to charge.
Mycle Charging The Battery
15

Power
to you
The range can vary depending on;
• The level of assistance
• The weight of the user
• The gradient of the road
• Tyre inflation
• Wind resistance
• Pedalling eort
• Starting and frequency of stops
• The outside temperature
Battery performance will
decline after prolonged
use. Depending on usage
patterns, the energy
capacity can reduce by
20% to 30% (charge and
discharge) for lithium
batteries. When discarding
batteries, please make
sure you do so responsibly
through an authorised
recycling centre.
• Only use the battery with this bike.
• Only use the specific charger supplied.
• Do not expose the battery to heat or charge
it in direct sunlight.
• Do not disassemble or modify the battery.
• Always charge the battery in a well ventilated area.
• Do not connect the (+) and (-) battery
connections with a metallic object.
• Do not expose the battery to liquids.
• Do not use a damaged battery.
• Do not continue to charge the battery beyond the
recommended charge time.
• Do not use the battery if it emits an unusual smell,
becomes unusually hot, or if something seems abnormal.
• Keep the battery out of the reach of children.
Mycle Charging The Battery
Battery Safety
Precaution
Battery
Range
Battery
Life
16

Charger Safety
Precautions
Mycle Charging The Battery
• Only use the charger supplied with this bike.
• Avoid contact with water while charging the battery.
If a plug becomes wet, dry thoroughly before use.
• For indoor use, do not expose the battery charger to rain.
• Do not short circuit the charger pins.
• Do not dismantle or modify the charger.
• Always place the charger in a well ventilated and dry environment.
• Warning: Explosive gases. Avoid flames and sparks.
Provide adequate ventilation during charging.
• Do not use the charger with a damaged power cord or plugs.
• Do not touch the charger with wet hands.
• Make sure that the charger plug is correctly connected to the
mains for charging.
• Disconnect the power supply before connecting or disconnecting
the connections on the battery.
• Do not touch the charger for too long during charging (risk of
superficial burns).
• Do not position the charger in an unstable manner.
• Do not cover the charger to avoid overheating during charging.
• This charger is designed to charge the Lithium battery supplied
with this bike only.
• Keep out of reach of children, this product is not a toy.
• Do not expose the product to a heat source.
• Do not immerse the product.
• The external flexible cable of this product cannot be replaced;
if the cord is damaged, the item should be discarded.
17

The Pedals
The pedals should feel tight
and secure. If they feel loose,
we recommend having them
adjusted by a bike repair
professional.
Mycle Additional Comments
The Bell
Make sure the bell is correctly
installed, aligned on your
handlebars and in easy reach.
The Spokes
Whilst your Mycle bike has been built
and tested to the highest standard
by Cytech certified technicians, it is
important that your bike is serviced
regularly, including the tightness of
your spokes. Spokes are essential to
supporting the manoeuvrability of your
bike and we always recommended
spoke maintenance is carried out by a
specialist to protect the safety of you
and your Mycle.
The Tyres
We recommend you check the tyre
pressure before each ride, as under-
or over-inflated tyres can aect ride
quality, as well as causing premature
wear and damage, and increasing
the risk of an accident.
18

Components on your Classic may become worn and require attention over time. If the
service life of a part has been exceeded, it could break suddenly, risking injury. Cracks,
scratches and discoloration can indicate that a component has exceeded its service life
and should be replaced. If in doubt, seek professional advice or contact Mycle.
Mycle Additional Comments
The Brakes
The right handle operates the front
brake and the left handle operates
the rear brake. We recommend
you split your braking force 60/40
between the front and the rear.
You should be able to achieve the
maximum braking power without the
brake levers touching the handles. If
this is not the case, we recommend
having the brakes adjusted by a
bike repair professional. Remember,
stopping distances can be longer in
slippery conditions.
The Wheels
& Motors
When the motor engages, there will be
a slight noise that may increase as the
motor works harder – this is normal. We
recommend you tighten the spokes on
the wheels after the first month of use.
19

While your Mycle Classic has been built
and tested in the UK by our trained Cytech
bike technicians, it’s important that you make
the following routine checks before you first
ride the bike, then on an ongoing weekly
basis. We also recommend getting your bike
periodically checked by a professional.
Routine Checklist:
√ Check the tightness of the crank, wheel, stem, pedals,
hanger and seat clamp.
√ Check the brakes are correctly adjusted and working.
√ Check the tension of spokes and wheels.
√ Check the bearings of the bottom bracket, wheels,
steering and pedals.
√ Check general levels of wear, particularly to brake pads,
transmission, cables and tyres.
√ Check that lights and all electrical
components are working.
Cleaning
Rinse your bike with fresh water after each use, particularly
if it has been exposed to sea air, in order to avoid corrosion.
Clean with a sponge and warm water, or using a non-
pressurised water jet.
Lubrication
Regular lubrication of moving parts is essential to avoid
corrosion. Pay particular attention to the ball bearings
located in the axis of the wheels, chain, derailleur and cables
of control. We recommend you use a specialist oil for the
chain and the derailleur, and grease for other components.
Maintenance
Mycle Maintenance
20
