myomo MyoPro 2 Motion E User manual

Specific instructions for your unique MyoPro 2
User manual appendix C
PN25623 Rev8
Heruntergeladen von manualslib.de Handbücher-Suchmachiene

PN25623 Rev8 2
Heruntergeladen von manualslib.de Handbücher-Suchmachiene

CONTENTS
›MyoPro 2 Motion G Diagram 5
›Finger Support Diagram Close-Up 6
›Putting Your MyoPro 2 On (“Donning”) 7
›Warnings Review 9
›Steps for Putting Your MyoPro 2 On 10
›Taking Your MyoPro 2 Off (“Doffing”) 17
›Warnings Review 19
›Steps for Taking Your MyoPro 2 Off 19
›Using Your MyoPro 2 21
›Control panel 23
›Modes of Use 24
›Start Mode 24
›Elbow Modes 25
›Grasp Modes 27
›Changing Elbow Modes with the Control Panel 29
›Changing Grasp Modes with the Control Panel 29
Dansk 30
Deutsch 60
PN25623 Rev8 3
Heruntergeladen von manualslib.de Handbücher-Suchmachiene

PN25623 Rev8 4
Heruntergeladen von manualslib.de Handbücher-Suchmachiene

Upper Arm
Shell
Upper-Arm
Sensor Cuff
Forearm
Closure
Forearm
Sensor Cuff
Multi-Articulating Wrist
(MAW), Rotational Ring Upper Cuff
Closure
Hand
Motor
Control Panel
(User
Interface)
Elbow Motor
Battery
Compartment
Multi-Articulating Wrist
(MAW), Flexion Joint
Hand Carrier
Bar
MYOPRO 2 MOTION G DIAGRAM
Component names and references (not every device includes every component).
Hand
Support Shell
PN25623 Rev8
Forearm Bar
Forearm
Shell
Harness
Attachment
Point
5
Heruntergeladen von manualslib.de Handbücher-Suchmachiene

Anvil
Finger
Saddle
Loop
Prehensile
Pinchers
Latch
FINGER SUPPORT DIAGRAM CLOSE-UP
Dorsal Finger
Piece
Thumb
Saddle
Stem
PN25623 Rev8
Hand Strap
6
Heruntergeladen von manualslib.de Handbücher-Suchmachiene

PUTTING YOUR MYOPRO 2
ON
(“DONNING”)
PN25623 Rev8 7
Heruntergeladen von manualslib.de Handbücher-Suchmachiene

PN25623 Rev8 8
Heruntergeladen von manualslib.de Handbücher-Suchmachiene

PUTTING YOUR MYOPRO 2 ON (“DONNING”)
The following pages include step-by-step instructions for putting the MyoPro 2 on (sometimes referred to as
“donning the MyoPro 2”).
WARNINGS REVIEW
BEFORE donning the MyoPro 2, review the warnings below:
WARNING: DO NOT expose the MyoPro 2 to flame or excessive heat; personal injury may
occur.
WARNING: The MyoPro 2 is a prescription device and should only be used as indicated under
clinical supervision of a Provider, or after receiving instruction from a clinical Provider for at-
home use.
WARNING: The MyoPro 2 is only to be used by the person for whom it is prescribed.
WARNING: Each component of the device is supplied for safety and best performance. Use all
provided components for optimal operation.
WARNING: ONLY use the MyoPro 2 upper limb orthosis on the prescribed elbow, wrist and
hand joints. Each MyoPro 2 is built specifically for a left arm or a right arm; never wear the
MyoPro 2 on the other arm.
WARNING: Tight straps may restrict the User’s circulation. Therefore, always check that straps
are not too tight throughout the User’s range of motion.
WARNING: Do not sleep while wearing the device as straps may alter the User’s circulation.
▲CAUTION: If you detect fumes, flames, melting of components around the battery or battery
charger, or the device is hot to touch, TURN THE DEVICE OFF IMMEDIATELY and contact your
Provider.
PN25623 Rev8 9
Heruntergeladen von manualslib.de Handbücher-Suchmachiene

STEPS FOR PUTTING YOUR MYOPRO 2 ON
1. POWER OFF: While donning, the MyoPro 2 should be turned OFF; check that it is OFF before starting to
put the MyoPor on your arm.
NOTE: Pads and straps should be fully air-dried from the previous use.
▲CAUTION: Do not use a hairdryer to dry components of the MyoPro 2.
2. PREPARE: Place the MyoPro 2 in your lap, or on a flat surface that is not slippery.
3. HAND: Start with the hand support shell: check that the strap around the hand support shell is loose.
Feed your fingers through so the under side of the hand support shell sits in your palm, and your thumb
rests in the Thumb Saddle. Be sure the base of your thumb presses against the hard plastic (opposite of
the hand strap). Leave the fingers free while you continue to put the rest of the device on –we will
secure the finger support as the last step.
NOTE: The motor and battery case should rest on the outside of the arm. If the motor and
battery case is aligned along the interior of the arm, you may be donning upside down or on
the wrong arm.
4. WRIST: Lower your wrist into the multi-articulating wrist (MAW), rotation portion.
5. FOREARM: Lower your forearm into the forearm shell.
6. Secure the Forearm Closure.
7. FINISH LOWER ARM: Tighten and secure the Velcro hand strap. This will keep the MyoPro 2 in place
while you continue to don.
PN25623 Rev8 10
Heruntergeladen von manualslib.de Handbücher-Suchmachiene

STEPS FOR PUTTING YOUR MYOPRO 2 ON, CONTINUED
8. UPPER ARM:
Wrap the Upper Sensor Cuff around your upper arm, keeping attention on the Biceps and Triceps sensors;
when the Upper Sensor Cuff is properly fit, the sensors should be centered over the biceps and triceps
muscles. Secure the Upper Cuff Closure and pull to tighten before securing the strap’s Velcro.
NOTE: the sensor with the BLUE Velcro goes on biceps, the sensor with the RED Velcro goes on
triceps.
Upper Sensor Cuff
Upper Cuff Closure
PN25623 Rev8 11
Heruntergeladen von manualslib.de Handbücher-Suchmachiene

STEPS FOR PUTTING YOUR MYOPRO 2 ON, CONTINUED
9. FOREARM SENSOR: Slide the Forearm Sensor Cuff onto the forearm. Tuck the Forearm Sensor Cuff’s
Velcro strap under the forearm bar and secure the Velcro.
NOTE: The sensor with the GREEN Velcro goes on the inner side of the forearm (aligned with
the palm), and the sensor with the YELLOW Velcro goes on the outer side of the forearm
(aligned with the back of the hand).
PN25623 Rev8 12
Heruntergeladen von manualslib.de Handbücher-Suchmachiene

STEPS FOR PUTTING YOUR MYOPRO 2 ON, CONTINUED
10. HARNESS: Secure the harness:
•Rest the shoulder pad on the shoulder of your MyoPro 2 arm.
•Wrap the strap under your non-MyoPro 2 arm.
•Secure the Quick Release tab.
PN25623 Rev8 13
Heruntergeladen von manualslib.de Handbücher-Suchmachiene

Start with the finger
support detached from
the Anvil.
Work the Finger Saddle
under your fingers while
holding the Stem and
Loop.
Lift the Stem upward to
position the Loop over the
Anvil.
You can hang the Loop
from the Anvil to take a
break or to reposition
your other hand for the
next step.
STEPS FOR PUTTING YOUR MYOPRO 2 ON, CONTINUED
11. FINGER SUPPORT:
PN25623 Rev8 14
Heruntergeladen von manualslib.de Handbücher-Suchmachiene

Continue to guide the
loop over the anvil. The
instructions below outline
two different techniques
for this:
Push down on the end of
the Loop to engage the
Latch.
Lift your fingers from
underneath the Finger
Saddle.
Since the Stem is rigid,
this will cause the end of
the loop to rotate over
the Latch. (You may also
push down on the stem
for additional leverage.)
Technique A
Done!
Technique b
STEPS FOR PUTTING YOUR MYOPRO 2 ON, CONTINUED
11. FINGER SUPPORT, continued:
PN25623 Rev8 15
Heruntergeladen von manualslib.de Handbücher-Suchmachiene

PN25623 Rev8 16
Heruntergeladen von manualslib.de Handbücher-Suchmachiene

TAKING YOUR MYOPRO 2 OFF
(“DOFFING”)
PN25623 Rev8 17
Heruntergeladen von manualslib.de Handbücher-Suchmachiene

PN25623 Rev8 18
Heruntergeladen von manualslib.de Handbücher-Suchmachiene

TAKING YOUR MYOPRO 2 OFF (“DOFFING”)
WARNINGS REVIEW
WARNING: If at any time during the use of this device, you notices any of the following,
discontinue use and seek guidance from your Provider.
•Movement does not match the User’s desired motion.
•Persistent redness, swelling, or skin breakdown (bleeding, chafing, etc.)
•Rash on the arm, hand, or fingers.
•Pain associated with wearing the MyoPro 2 orthosis.
•Unusual noises from the orthosis (popping, clicking, etc.)
•Smells from the orthosis (smoking, burning plastic, etc.)
•Odor from the orthosis (sour smells or other indications of bio-contamination.)
STEPS FOR TAKING YOUR MYOPRO 2 OFF
1. Turn the MyoPro 2 OFF.
2. Place the MyoPro 2 in your lap, or on a flat surface that is not slippery.
3. Undo the harness Quick Release tab.
4. Release the Finger Support (see Page 17 for images).
5. Loosen the hand strap.
6. Remove the Forearm Sensor Cuff from your forearm.
7. Undo the Upper Cuff Closure.
8. Undo the Forearm Closure.
9. Gently slide your hand back through the loosened hand strap and Hand Support Shell
10. Rest the MyoPro 2 in a clean, dry location to ensure it will fully air-dry before next use.
11. Place the MyoPro 2 into the carrying bag for travel or storage.
NOTE: The MyoPro 2 should remain OFF any time the MyoPro 2 is not being worn.
PN25623 Rev8 19
Heruntergeladen von manualslib.de Handbücher-Suchmachiene

Push/pull the slider
forward to release the
loop.
The loop will slide over
the Anvil as soon as it is
free.
Remove the “W”, Stem
and Loop from under your
fingers and store in the
MyoPro 2’s carrying bag.
STEPS FOR TAKING YOUR MYOPRO 2 OFF, CONTINUED
