ABC3Pro Trolley line indicator
ABC3Pro-E1-V10
1 / 2
Application
This product is used to indicate the conductor power, specially designed for overhead crane, gantry cranes etc.
Main features and functions
• Aluminum enclosure with powdercoat paint finishes, durable and reliable, corrosion resistant, light weight.
• LED light source, long life time.
• Multple seals with silicon rubber, high ingress protection grade.
• Easy to mount, lamp numbers and colors are flexible combination.
Specification
Rated voltage
DV24V/AC110V/AC220V/AC380
V/AC460V
Frequency 50Hz~60Hz
Rated Power
Consumption
＜8W (signle light) Light Color
Red, Yellow, Green, Blue
(optional)
Visible distance ＞300m LEDs life time 100,000h
Operating mode
steady burning (flash can be
customized)
Wiring Y type connection
Operating
Temperature
-30˚C ~ +70˚C IP Rate IP65
Ambient humidity 10% ~ 95% (non condesation) Material
Aluminum alloy / Plastic
(optinal)
Mount type Horizental mount / Vertical mount
Installation and operation
• Ensure that the input voltage is correct.
• Fix product to mount face by using four nos. M10 screws (not provided), ensure mount face is flat and has
enough mechanical strength.
• Remove 4 nos. screws on enclosure to open the product, refer wiring connection diagram to connect wires to
terminal blocks, close the product and fix the screws after wiring.
• Ensure cable connection is correct before power on.
Model selection table
Model Color (from top to bottom) Lamp diameter Cable gland Weight (KG)
2-light
combination
Red+Green 118mm
Metal 4.0 Red+Yellow 118mm
Green+Yellow 118mm
2-light
combination
Yellow+Green+Red 118mm
Metal
5.7
Green+Red+Yellow 118mm
Red +Yellow+Green 118mm
Green+Red+Blue 118mm
Wiring connection
2-light combination
3-light combination
Mounting dimension (unit: mm)
150
防水接头
295
420
324
384
136 135
2-light combination
136
544
135 150
484
580
防水接头
3-light combination

Shanghai Nanhua Electronics Co., Ltd Tel：[phone] Fax：[phone]ext 808/818 Web：www.nanhua.com E-mail：sa[email protected]
Add: Building 9, No. 1755Wenbei Road, Jiading district Shanghai 201802
All rights reserved by Nanhua, without the written authorization of the Nanhua, any part thereof shall not be reproduced or transmitted in any form.
ABC3Pro Trolley line indicator
ABC3Pro-E1-V10
2 / 2
Wiring
Application
Caution
• Ensure cable connection is correct.
• While product is operating, temperature rise is normal phenomenon.
• While product is operating, do not open proucts, prevent any dangers.
• The product is sealed structure, warranty is terminated if unauthorzied people maintain the
product.
• Read these instructions completely and carefully.
