Naomi Home Windsor User manual

Windsor Cuisine Cart
Assembly Instructions
Product Dimensions:
30” W x 18” D x 36” H
Please take a moment to read through the entire instruction booklet before assembly to
familiarize yourself with this product. Once you feel ready to start, follow the instructions
step by step and this should make this process as easy as we could make it for you.
If you need help or have damaged or missing parts, contact customer service at
www.NaomiHome.com.
Page 1 of 10

Tools Required
Phillips Screwdriver
(Medium) Ruler/Tape Measure (to help correctly identify the screws & bolts)
Page 2 of 10
ADULT ASSEMBLY REQUIRED
CHOKING HAZARD
• This product includes small parts, sharp points and sharp edges in its unassembled
state. Keep unassembled parts away from children under 3 years of age, & animals.
•If used improperly, your kitchen cart may be pulled over or fall, creating risk of injury or
damage. Children should not be permitted to climb or pull on the kitchen cart.
USE AND MAINTENANCE
• Use on level surfaces only
•Because this product needs assembly, it is prone to working itself loose from time to
time depending on the use. Please take the time to check that all connections are still
tight and working properly for safety.
•Only clean using a damp cloth and mild detergent, do not use bleach or abrasive
cleaners.
PARENTAL SUPERVISION IS REQUIRED
• This Naomi Home product is intended for adult use
• Parents or Guardians should supervise use under the intended age specifically
regarding children that may have access to it and might climb on the unit.
ASSEMBLY RECOMMENDATIONS
•Check you have all the components and tools listed on page 3, 4 and 5.
•Do not stand or put weight on this product during assembly, this could cause damage.
•Remove all hardware from the plastic bags and separate them into their groups.
•Assemble the item as close to its final position (in the same room) as possible.
•Assemble on a soft level surface to avoid damaging the unit or your floor.
•Make sure you have enough space to layout the parts before starting.
•Parts of the assembly will be easier with 2 people.
•Dispose of all packaging carefully and responsibly.
•Do not use this item if any components are missing or damaged.
•We do not recommend the use of power drill/drivers for inserting screws, as this could
damage the unit. Only use hand screwdrivers.
WARNING CAUTION

A Bottom Panel x 1 B Back Rail x 2 C Back Panel x 2 D Left Side Panel x 1
E Right Side Panel x 1 F Front Upper Rail x 1 G Front Middle Rail x 1 H Top Panel x 1
I Adjustable Shelf x 1 J Left Drawer Side x 1 K Right Drawer Side x 1
M Drawer Bottom x 1
R Towel Rack x 2
N Drawer Front x 1 O Left Door x 1
P Right Door x 1 Q Back Support Bar x 1
L Drawer Back x 1
COMPONENT PARTS
Please check that you have all the parts listed below
1 2 3 4
Page 3 of 10
5 6 7 8
910 11 12
13 14 15
16 18
17

1 Caster x 2 2 Caster w/ lock x 2 ∅4 x15mm
3 Round Head Screw x 16
5 Cam Bolt x 16 6 Cam Lock x 16
9 Spring Washer x 4 11 Allen Key x 1
14 Knob x 3 15 Shelf Pin x 4
16 Barrel Nut x 4 17 Magnet x 1
10 Flat Washer x 8
∅8 x 30mm
4 Wood Dowel x 10
∅1/4” x 1-3/8”
7 Allen Bolt x 4 ∅1/4” x 2-1/4”
8 Allen Bolt x 4
∅3.5 x 25mm
12 Flat Head Screw x 8
∅5/32” x 15mm
13 Round Head Bolt x 3
∅3 x12mm
18 Round Head Screw x 2
Page 4 of 10
ASSEMBLY HARDWARE
A B C D
EFGH
IJK L
MN O
PQ R

Read
This drawing is to give
you an overall idea only
of how this assembly
will go together and
does not replace the
assembly instructions.
COMPONENT PARTS
Page 5 of 10

Attach Casters (A) and
Casters w/ Lock (B) to
Bottom Panel (1) with
Round Head Screws
(C). Use Phillips
Screwdriver to tighten
Screws.
Substitute for Island
Feet (not include) as
shown.
Insert Wood Dowels (D)
into Back Support Bar
(17), attach Back Rails
(2) to Back Support Bar
(17). Slide Back Panels
(3) into grooves of Back
Rails (2) and Back
Support Bar (17) as
shown.
ASSEMBLY INSTRUCTIONS
1
2
Page 6 of 10

As Shown, insert Wood
Dowels (D) and Cam Bolts
(E) into Right Side Panel
(5) and Left Side Panel (4),
insert Cam Locks (F) into
Back rails (2), Front Upper
Rail (6) and Front Middle
Rail (7).
Attach Back rails (2),
Front Upper Rail (6) and
Front Middle Rail (7) to
Right Side Panel (5), use
Phillips screwdriver to
clockwise rotate Cam
Locks (F) with ½-circle to
lock.
Attach Left Side Panel (4)
to Back rails (2), Front
Upper Rail (6) and Front
Middle Rail (7), use
Phillips Screwdriver to
clockwise rotate Cam
Locks (F) with ½-circle to
lock.
Attach Towel Racks (18) to
Assembled frame (finished at step 3)
with Flat Washers (J) andAllen Bolts
(G), use Allen Key (K) to tighten Allen
Bolts (G).
Insert Wood Dowels (D) into Bottom
Panel (1).
Insert Barrel Nuts (P) into Left Side
Panel (4) and Right Side Panel (5).
Attach Assembled Frame to Bottom
Panel (1) with Flat Washers
(J),Spring Washers (I) and Allen Bolts
(H),use Allen Key (K) to tighten Allen
Bolts (H).
ASSEMBLY INSTRUCTIONS
3
4
Page 7 of 10

Attach Left Drawer Side (10) and
Right Drawer Side (11) to Drawer
Front (14) with Flat Head Screws
(L).
Slide Drawer Bottom (13) to
grooves of Drawer Sides (10) &
(11) and Drawer Front (14).
Attach Drawer Back (12) to
Assembled Frame with Flat Head
Screws (L),make sure Drawer
Bottom (13) into groove of Drawer
Back (12).
Attach Knob (N) to Drawer Front
(14) with Round Head Screw (M).
Use Phillips Screwdriver to tighten
Screws.
Insert Cam Bolts (E) into Top
Panel (8).
Insert Cam Locks (F) into Side
Panels (4) & (5).
Attach Top Panel (8) to
Assembled Frame (finished at
step 4). Use Phillips Screwdriver
to clockwise rotate Cam Locks (F)
with ½-circle to lock.
Insert Shelf Pins (O) into Side
Panels (4) & (5).
Place Adjustable Shelf (9) into
Assembled Frame.
ASSEMBLY INSTRUCTIONS
5
6
Page 8 of 10

Attach Magnet (Q) to Front
Middle Rail (7) with Round
Head Screws (R). Attach
Knobs (N) to Doors (15) & (16)
with Round Head Screws (M),
Use Phillips Screwdriver to
tighten screws.
Attach Left Door (15) and
Right Door (16) to Assembled
cart as shown. Identify the
left door (15) with the knob
on the right and the inside
magnetic plate at the top.
Insert left door bottom hinge
into the far left hole on the
base. Press in the top hinge
of the door and insert the
hinge into the hole of Bottom
Panel (1) and Front Middle
Rails (7). Repeat for Right
door (16).
Place Drawer into Assembled
Frame as shown.
ASSEMBLY INSTRUCTIONS
7
8
Page 9 of 10

CONGRATULATIONS, YOUR NAOMI HOME
WINDSOR CUISINE CART IS COMPLETE!
www.NaomiHome.com
MADE IN CHINA
Product Packaging Information
Model #:
Color:
Shipment Ref. #:
Date:
________________________________
__________________________________
_________________________
__________________________________
ASSEMBLY COMPLETE
