Napoleon BGD38NT User manual

1
W415-0244/A/05.15.03
INSTALLER: THESE INSTRUCTIONS MUST BE CONVEYED TO AND REMAIN WITH THE HOMEOWNER.
Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON L4M 4Y8 Canada • [phone] • fax[phone]
www.napoleonfireplaces.com • [email protected]
CERTIFIED UNDER CANADIAN AND AMERICAN NATIONAL STANDARDS, CSA 2.22, AND ANSI Z21.50 RESPECTIVELY FOR VENTED GAS FIREPLACES.
DIRECT VENT MILLIVOLT SYSTEM
INSTALLATION AND OPERATION INSTRUCTIONS FOR
DIRECT VENT DECORATIVE GAS FIREPLACE
NATURAL GAS MODEL
BGD38NT
PROPANE GAS MODEL BGD38PT
CERTIFIED FOR CANADA AND UNITED STATES USING ANSI / CSA METHODS
Installation and service must be performed by a qualified installer, service agency
or the gas supplier.
WARNING: If the information in these instructions is not followed exactly, a fire or
explosion may result causing property damage, personal injury or death.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapours and liquids in the vicinity of
this or any other appliance.
WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use any phone in your building.
• Immediately call your gas supplier from
a neighbour's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier,
call the fire department.

2
W415-0244/A/05.15.03
WARNING
••
••
• Do not burn wood or other materials in this fireplace.
• Adults and especially children should be alerted to the hazards of high surface temperatures and
should stay away to avoid burns or clothing ignition. Supervise young children when they are in
the same room as the fireplace.
• Due to high temperatures, the fireplace should be located out of traffic and away from furniture
and draperies.
• Clothing or other flammable material should not be placed on or near the fireplace.
• Any safety screen or guard removed for servicing must be replaced prior to operating the fire-
place.
• It is imperative that the control compartments, burners and circulating blower and its passage-
way in the fireplace and venting system are kept clean. The fireplace and its venting system
should be inspected before use and at least annually by a qualified service person. More frequent
cleaning may be required due to excessive lint from carpeting, bedding material, etc. The fire-
place area must be kept clear and free from combustible materials, gasoline and other flammable
vapours and liquids.
• Under no circumstances should this fireplace be modified.
• This fireplace must not be connected to a chimney flue pipe serving a separate solid fuel burning
appliance.
• Do not use this fireplace if any part has been under water. Immediately call a qualified service
technician to inspect the fireplace and to replace any part of the control system and any gas
control which has been under water.
• Do not operate the fireplace with the glass door removed, cracked or broken. Replacement of the
glass should be done by a licensed or qualified service person. Use only with a glass door certified
with the fireplace.
• Do not strike or slam shut the fireplace glass door.
• This fireplace uses and requires a fast acting thermocouple. Replace only with a fast acting
thermocouple supplied by Wolf Steel Ltd.
Louvre Installation
Log Placement
Charcoal Embers
Glowing Embers
PG 20 OPTIONAL BLOWER INSTALLATION
21 OPTIONAL FAN INSTALLATION /
GD36 THERMOSTATIC SENSOR CON-
TROL
22 OPERATION / MAINTENANCE
Operating Instructions
Maintenance
23 ADJUSTMENTS
Pilot Burner Adjustment
Venturi Adjustment
24-25 REPLACEMENTS
Ordering Replacement Parts
Replacement Parts
Vent Kits
Terminal Kits
Accessories
26-27 TROUBLE SHOOTING GUIDE
28 SERVICE HISTORY
PG 2-4 INTRODUCTION
Warranty
General Instructions
General Information
Care of Glass & Plated Parts
5 - 12 VENTING
Venting Lengths
Air Terminal Locations
Typical Vent Installations
Special Vent Installations
Venting Specifications
13 - 17 INSTALLATION
Wall and Ceiling Protection
Using Flexible Vent Components
Fireplace Vent Connection
Using Rigid Vent Components
Gas Installation
Mobile Home Installation
Framing
Nailing Tabs
Mantle Installation
18-19 FINISHING
Door Removal & Installation
NOTE: changes, other than editorial, are denoted by a vertical line in the margin.
TABLE of CONTENTS
PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE

3
W415-0244/A/05.15.03
ALL SPECIFICATIONSAND DESIGNSARE SUBJECTTO CHANGE WITHOUTPRIOR NOTICE DUE TO ON-GOING PRODUCTIMPROVEMENTS. NAPOLEON® ISAREGISTERED
TRADEMARKOFWOLF STEELLTD. PATENTS U.S.5.303.693.801 - CAN.2.073.411, 2.082.915.© WOLF STEELLTD.
NAPOLEON gas fireplaces are manufactured under the strict Standard of the world recognized
ISO 9001 : 2000 Quality Assurance Certificate.
NAPOLEON products are designed with superior components and materials, assembled by trained craftsmen who
take great pride in their work. The burner and valve assembly are leak and test-fired at a quality test station. Once
assembled the complete fireplace is thoroughly inspected by a qualified technician before packaging to ensure that
you, the customer, receives the quality product that you expect from NAPOLEON.
NAPOLEON GAS FIREPLACE PRESIDENT'S LIFETIME LIMITED WARRANTY
The following materials and workmanship in your newThe following materials and workmanship in your new
The following materials and workmanship in your newThe following materials and workmanship in your new
The following materials and workmanship in your new NAPOLEONNAPOLEON
NAPOLEONNAPOLEON
NAPOLEON gas fireplace are war-gas fireplace are war-
gas fireplace are war-gas fireplace are war-
gas fireplace are war-
ranted against defects for as long as you own the fireplace. This covers: combustion chamber,ranted against defects for as long as you own the fireplace. This covers: combustion chamber,
ranted against defects for as long as you own the fireplace. This covers: combustion chamber,ranted against defects for as long as you own the fireplace. This covers: combustion chamber,
ranted against defects for as long as you own the fireplace. This covers: combustion chamber,
heat exchanger, stainless steel burner, phazer™ logs and embers, ceramic glass (thermal break-heat exchanger, stainless steel burner, phazer™ logs and embers, ceramic glass (thermal break-
heat exchanger, stainless steel burner, phazer™ logs and embers, ceramic glass (thermal break-heat exchanger, stainless steel burner, phazer™ logs and embers, ceramic glass (thermal break-
heat exchanger, stainless steel burner, phazer™ logs and embers, ceramic glass (thermal break-
age only), gold plated parts against tarnishing, porcelainized enamelled components and alumi-age only), gold plated parts against tarnishing, porcelainized enamelled components and alumi-
age only), gold plated parts against tarnishing, porcelainized enamelled components and alumi-age only), gold plated parts against tarnishing, porcelainized enamelled components and alumi-
age only), gold plated parts against tarnishing, porcelainized enamelled components and alumi-
num extrusion trims.num extrusion trims.
num extrusion trims.num extrusion trims.
num extrusion trims.
Electrical (110V and millivolt) components and wearable parts such as blowers, gas valves,Electrical (110V and millivolt) components and wearable parts such as blowers, gas valves,
Electrical (110V and millivolt) components and wearable parts such as blowers, gas valves,Electrical (110V and millivolt) components and wearable parts such as blowers, gas valves,
Electrical (110V and millivolt) components and wearable parts such as blowers, gas valves,
thermal switch, switches, wiring, remote controls, ignitor, gasketing, and pilot assembly arethermal switch, switches, wiring, remote controls, ignitor, gasketing, and pilot assembly are
thermal switch, switches, wiring, remote controls, ignitor, gasketing, and pilot assembly arethermal switch, switches, wiring, remote controls, ignitor, gasketing, and pilot assembly are
thermal switch, switches, wiring, remote controls, ignitor, gasketing, and pilot assembly are
covered andcovered and
covered andcovered and
covered and NAPOLEONNAPOLEON
NAPOLEONNAPOLEON
NAPOLEON will provide replacement parts free of charge during the first year ofwill provide replacement parts free of charge during the first year of
will provide replacement parts free of charge during the first year ofwill provide replacement parts free of charge during the first year of
will provide replacement parts free of charge during the first year of
the limited warranty.the limited warranty.
the limited warranty.the limited warranty.
the limited warranty.
Labour related to warranty repair is covered free of charge during the first year. RepairLabour related to warranty repair is covered free of charge during the first year. Repair
Labour related to warranty repair is covered free of charge during the first year. RepairLabour related to warranty repair is covered free of charge during the first year. Repair
Labour related to warranty repair is covered free of charge during the first year. Repair
work, however, requires the prior approval of an authorized company official. Labour costs towork, however, requires the prior approval of an authorized company official. Labour costs to
work, however, requires the prior approval of an authorized company official. Labour costs towork, however, requires the prior approval of an authorized company official. Labour costs to
work, however, requires the prior approval of an authorized company official. Labour costs to
the account ofthe account of
the account ofthe account of
the account of NAPOLEONNAPOLEON
NAPOLEONNAPOLEON
NAPOLEON are based on a predetermined rate schedule and any repair workare based on a predetermined rate schedule and any repair work
are based on a predetermined rate schedule and any repair workare based on a predetermined rate schedule and any repair work
are based on a predetermined rate schedule and any repair work
must be done through an authorizedmust be done through an authorized
must be done through an authorizedmust be done through an authorized
must be done through an authorized NAPOLEONNAPOLEON
NAPOLEONNAPOLEON
NAPOLEON dealer.dealer.
dealer.dealer.
dealer.
CONDITIONS AND LIMITATIONS
NAPOLEONwarrants its productsagainst manufacturing defects to theoriginal purchaser only-- i.e., the individual orlegal entity (registered customer) whose name appears onthe
warrantyregistrationcard filedwith NAPOLEON-- provided thatthe purchase wasmade through anauthorized NAPOLEON dealerand is subjectto the followingconditions andlimitations:
Thisfactory warranty isnontransferable and maynot be extendedwhatsoever by anyof our representatives.
Thegas fireplace mustbe installed by a licenced, authorized service technician or contractor. Installation must be done in accordancewith the installationinstructions included with
theproduct and all local andnational building and fire codes.
Thislimited warranty does not coverdamages causedby misuse, lackof maintenance,accident, alterations, abuse or neglectand parts installed from othermanufacturers will nullify
this warranty.
Thislimited warranty furtherdoes notcover anyscratches, dents, corrosionor discolouringcaused byexcessiveheat, abrasiveand chemicalcleaners norchipping on porcelainenamel
parts,mechanical breakage ofPHAZER™ logs andembers, nor anyventing components usedin the installation of the fireplace.
NAPOLEON warrants its stainless steel burners against defects in workmanship and material for life, subject to the following conditions: During the first 10 years NAPOLEON will
replace or repair the defective parts at our option free of charge. From 10 years to life, NAPOLEON will provide replacement burners at 50% of the current retail price.
Inthe firstyear only,this warranty extends to the repairor replacement of warrantedpartswhichare defective in material orworkmanship providedthat the product has beenoperated
inaccordance with theoperation instructions andunder normal conditions.
Afterthefirst year,withrespect to this President'sLimited LifetimeWarranty,NAPOLEON may,at itsdiscretion, fullydischarge allobligations withrespect to this warranty by refunding
tothe original warranted purchaser the wholesale price of any warrantedbut defective part(s).
After thefirst year, NAPOLEON willnot be responsiblefor installation,labour or anyother costsor expenses relatedto thereinstallation of a warranted part, and such expenses are
notcovered by thiswarranty.
Notwithstandinganyprovisions containedin thisPresident's LimitedLifetime Warranty,NAPOLEON’S responsibilityunder this warrantyis definedas aboveand it shallnot inany event
extendto anyincidental, consequential or indirect damages.
Thiswarranty defines theobligations andliabilityof NAPOLEON withrespect to the NAPOLEONgas fireplace andany otherwarrantiesexpressed orimplied with respectto thisproduct,
itscomponents or accessories are excluded.
NAPOLEONneither assumes, norauthorizes any thirdparty to assume, on its behalf, any other liabilities with respect to the saleof this product.NAPOLEON will notbe responsible
for:over-firing, downdrafts, spillagecaused by environmental conditions such as rooftops, buildings, nearby trees, hills, mountains, inadequatevents or ventilation, excessive venting
configurations,insufficient makeup air, ornegative air pressures which may or may not be caused by mechanical systems such as exhaustfans, furnaces, clothes dryers,etc.
Anydamages tofireplace, combustion chamber, heat exchanger,brass trimor other component due to water,weather damage,long periods ofdampness, condensation,damaging
chemicals or cleaners will not be the responsibility of NAPOLEON.
The bill of sale or copy will be required together with a serial number and a model number when making any warranty claims from your authorized dealer. The warranty registration
cardmust be returned within fourteen days toregister the warranty.
NAPOLEONreserves the right to have its representative inspect any product orpart thereof prior to honouring any warrantyclaim.

4
W415-0244/A/05.15.03
THIS GAS FIREPLACE SHOULD BE INSTALLED AND SERV-
ICEDBYAQUALIFIEDINSTALLER toconformwithlocalcodes.
Installation practices vary from region to region and it is
important to know the specifics that apply to your area,
for example: in Massachusetts State:
• The fireplace damper must be removed or welded in the open
position prior to installation of a fireplace insert or gas log.
• The appliance off valve must be a “T” handle gas cock.
• The flexible connector must not be longer than 36 inches.
• The appliance is not approved for installation in a bedroom or
bathroom unless the unit is a direct vent sealed combustion
product.
• WARNING: This product must be installed by a licensed plumber
or gas fitter when installed within the commonwealth of
Massachusetts.
In absence of local codes, install the BGD38 to the current
National Fuel Gas Code, ANSI Z223.1, or the current CAN/
CGA B149, Installation Codes. Mobile home installation
must conform with local codes. In the absence of local
codes, install to the current standard for gas equipped
mobile housing CAN/CSA Z240 MH Series in Canada or
the manufactured home construction and safety standard,
Title 24 CFR, part 3280, or the Fire Safety Criteria for manu-
factured home installations, Sites and Community Stand-
ardANSI/NFPA501Ain the United States.
The fireplace and its individual shutoff valve must be dis-
connected from the gas supply piping system during any
pressure testing of that system at test pressures in excess
of 1/2 psig (3.5 kPa). The fireplace must be isolated from
the gas supply piping system by closing its individual
manual shutoff valve during any pressure testing of the
gas supply piping system at test pressures equal to or
less than 1/2 psig (3.5 kPa).
When the fireplace is installed directly on carpeting, vinyl
tile or other combustible material other than wood flooring,
the fireplace shall be installed on a metal or wood panel
extending the full width and depth.
If the optional fan or blower is installed, the junction box
must be electrically connected and grounded in accord-
ance with local codes. In the absence of local codes, use
the current CSA C22.1 CANADIAN ELECTRICAL CODE in
Canada or the ANSI/NFPA 70-1996 NATIONAL ELECTRI-
CAL CODE in the United States.
FORYOUR SATISFACTION, THIS FIREPLACE HAS BEEN
TEST-FIRED TO ASSURE ITS OPERATION AND QUAL-
ITY! Maximum input is 26,000 BTU/hr for natural gas and
propane. When the fireplace is installed at elevations above
4,500ft, and in the absence of specific recommendations
from the local authority having jurisdiction, the certified high
altitude input rating shall be reduced at the rate of 4% for
each additional 1,000ft.
Maximum output for natural gas is 16,735 BTU/hr at an
efficiency of 64.4% with the fan on, and 17,212 BTU/hr for
propane at an efficiency of 66.2% with the fan on. The maxi-
mum A.F.U.E. (annual fuel utilization efficiency) rating is
56.3% for natural gas and 57.8% for propane.
Minimum inlet gas supply pressure is 4.5 inches water
column for natural gas and 11 inches water column for
propane. Maximum inlet gas pressure is 7 inches water
column for natural gas and 13 inches water column for
propane. Manifold pressure under flow conditions is 3.5
inches water column for natural gas and 10 inches water
column for propane.
This fireplace is approved for bathroom, bedroom and bed-
sitting room installations and is suitable for mobile home
installation. The natural gas model can only be installed in a
mobile home that is permanently positioned on its site and
fueled with natural gas.
No external electricity (110 volts or 24 volts) is re-No external electricity (110 volts or 24 volts) is re-
No external electricity (110 volts or 24 volts) is re-No external electricity (110 volts or 24 volts) is re-
No external electricity (110 volts or 24 volts) is re-
quired for the gas system operationquired for the gas system operation
quired for the gas system operationquired for the gas system operation
quired for the gas system operation.
Expansion / contraction noises during heating up
and cooling down cycles are normal and are to be
expected.
Do not use abrasive cleaners to clean plated parts. Buff lightly
with a clean dry cloth. The BGD38 is factory equipped with
tempered glass. The glass thickness is 3/16". Use only re-
placement glass available from your Napoleon dealer. DO
NOTSUBSTITUTEMATERIALS.Cleantheglassafterthe first
10 hours of operation with a recommended gas fireplace
glass cleaner. Thereafter clean as required. DO NOT CLEAN
GLASS WHEN HOT! If the glass is not kept clean permanent
discolouration and / or blemishes may result.
Use only accessories designed for and listed with
your specific fireplace.
Provide adequate ventilation air. Provide adequate
accessibility clearance for servicing and operating
the fireplace. Never obstruct the front opening of
the fireplace.
For safe and proper operation of the fireplace follow
the venting instruction exactly.
Deviation from the minimum vertical vent length can
create difficulty in burner start-up and/or carboning.
Provide a means for visually checking the vent con-
nection to the fireplace after the fireplace is installed.
The fireplace must be installed against finished
walls. Do not install against a vapour barrier or ex-
posed insulation.
Vent lengths that pass through unheated spaces (at-
tics, garages, crawl spaces) should be insulated
with the insulation wrapped in a protective sleeve
to minimize condensation.
Objects placed in front of the fireplace must be kept
a minimum of 48" away from the front face of the
unit.
GENERAL INSTRUCTIONS
GENERAL INFORMATION
CARE OF GLASS, AND PLATED PARTS

5
W415-0244/A/05.15.03
Use only Wolf Steel or Simpson Dura-Vent Model DV-GS
venting components. Minimum and maximum vent lengths,
for both horizontal and vertical installations, and air termi-
nal locations for either system are set out in this manual
and must be adhered to. For Simpson Dura-Vent, follow
the installation procedure provided with the venting com-
ponents.
When using Wolf Steel venting components, use only ap-
proved Wolf Steel rigid / flexible components with the fol-
lowing termination kits: WALL TERMINAL KIT GD422, or
1/12TO 7/12 PITCH ROOF TERMINALKITGD410,8/12TO
12/12 ROOF TERMINAL KIT GD411, FLAT ROOF TERMI-
NAL KIT GD412 or PERISCOPE KIT GD401 (for wall pen-
etration below grade). With flexible venting, in conjunction
with the various terminations, use either the 5 foot vent kit
GD420 or the 10 foot vent kit GD430.
Wolf Steel rigid and flexible venting systems must not
be combined.
Wolf Steel and Simpson Dura-Vent venting systems
must not be combined.
These vent kits allow for either horizontal or vertical venting
of the fireplace. FIGURES 3a, & 5a. The maximum allow-
able horizontal run is 20 feet. The maximum allowable ver-
tical vent length is 40 feet. The maximum number of 5" vent
connections is two horizontally or three vertically (exclud-
ing the fireplace and the air terminal connections) when
using aluminum flexible venting.
For optimum flame appearance and fireplace perform-
ance, keep the vent length and number of elbows to a
minimum.
The air terminal must remain unobstructed at all times.
Examine the air terminal at least once a year to verify
that it is unobstructed and undamaged.
Purge all gas lines with the glass door of the fireplace
open. Assure that a continuous gas flow is at the burner
before closing the door.
Under extreme vent configurations, allow several minutes
(5-15) for the flame to stabilize after ignition.
Eight (8") inches is the minimum bend radius allowed
for the 8" diameter flexible liner.
For optimum performance it is recommended that all
horizontal runs have a 1 inch rise per foot when using
Napoleon flexible vent components.
A terminal shall not terminate directly above a sidewalk
or paved driveway which is located between two sin-
gle family dwellings and serves both dwellings. Local
codes or regulations may require different clearances.
Do not allow the inside liner to bunch up on horizontal or
vertical runs and elbows. Keep it pulled tight. A 1¼" air
gap all around between the inner liner and outer liner is
required for safe operation. Use a firestop when pen-
etrating interior walls, floor or ceiling.
Minimum clearance to combustible con-
struction from fireplace and vent sur-
faces:
sides, back, bottom and top of the unit 0 inch
recessed depth 18 inches
top, sides and bottom of the vent pipe 1 inch
Horizontal runs may have a 0 inch rise per foot in all
cases using SIMPSON DURA-VENT or NAPOLEON
RIGID OR FLEXIBLE venting components when vent-
ing as illustrated in Figures 3, and 4.
Only a clearance to combustibles of 1" all around the
vent pipe is required.
FIGURE1
VENTING
VENTING LENGTHS

6
W415-0244/A/05.15.03
AIR TERMINAL INSTALLATIONS
*
*
* Recommended to prevent condensation on windows and thermal breakage
****
****
** It is recommended to use a heat shield and to maximize the distance to vinyl clad soffits.
******
******
*** The periscope GD-201 requires a minimum 18 inches clearance from an inside corner.
********
********
**** This is a recommended distance. For additional requirements check local codes.
†
†
† Three feet above if within 10 feet horizontally.
‡
‡
‡ A vent shall not terminate directly above a sidewalk or paved driveway that is located between two single fam
i
dwellings and serves both dwellings.
† †† †
† †† †
† † Permitted only if the veranda, porch, or deck is fully open on a minimum of two sides beneath the floor.
† *† *
† *† *
† * Recommenced to prevent recirculation of exhaust products. For additional requirements check local codes.
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
12 INCHES
9 INCHES
12 INCHES*
18 INCHES**
12 INCHES**
0 INCHES
0 INCHES***
2 INCHES***
3 FEET****
3 FEET****
9 INCHES
3 FEET†
7 FEET****
12 INCHES****
16 INCHES
2 FEET†*
Clearance above grade, veranda porch, deck or balcony.
Clearance to windows or doors that open.
Clearance to permanently closed windows.
Vertical clearance to ventilated soffit located above the terminal within
a horizontal distance of 2 feet from the centerline of the terminal.
Clearance to unventilated soffit.
Clearance to an outside corner wall.
Clearance to an inside non-combustible corner wall or protruding
non-combustible obstructions (chimney, etc.).
Clearance to an inside combustible corner wall or protruding com-
bustible obstructions ( vent chase, etc.).
Clearance to each side of the centerline extended above the meter
/ regulator assembly to a maximum vertical distance of 15ft.
Clearance to a service regulator vent outlet.
Clearance to a non-mechanical air supply inlet to the building or a
combustion air inlet to any other appliance.
Clearance to a mechanical air supply inlet.
Clearance above a paved sidewalk or paved driveway located on
public property unless fitted with a heat shield kit GD-301.
Clearance under a veranda, porch, deck or balcony.
Clearance above the roof.
Clearance from an adjacent wall including neighbouring buildings.
CANADIAN U.S.A.
12 INCHES
12 INCHES
12 INCHES*
18 INCHES**
12 INCHES**
0 INCHES
0 INCHES***
2 INCHES***
3 FEET
3 FEET
12 INCHES
6 FEET
7 FEET‡
12 INCHES††
16 INCHES
2 FEET†*
INSTALLATIONS

7
W415-0244/A/05.15.03
Use the GD401 periscope kit to locate the air termination
above grade. The periscope must be installed so that when
final grading is completed, the bottom air slot is located a
minimum of 12 inches above grade. The maximum allow-
able vent length depends on the fireplace, as illustrated.
FIGURES3
For optimum performance, it is recommended
that all horizontal runs have a 1 inch rise per foot.
When terminaWhen termina
When terminaWhen termina
When terminating vting v
ting vting v
ting verer
erer
erticallytically
ticallytically
tically, the v, the v
, the v, the v
, the verer
erer
ertical rise is atical rise is a
tical rise is atical rise is a
tical rise is a
minimum 36 inches and a maximum 40 feet fromminimum 36 inches and a maximum 40 feet from
minimum 36 inches and a maximum 40 feet fromminimum 36 inches and a maximum 40 feet from
minimum 36 inches and a maximum 40 feet from
the centre of the fireplace flue outlet.the centre of the fireplace flue outlet.
the centre of the fireplace flue outlet.the centre of the fireplace flue outlet.
the centre of the fireplace flue outlet.
FIGURE4
TYPICAL VENT INSTALLATIONS
SPECIAL VENT INSTALLATIONS
PERISCOPE TERMINATION

8
W415-0244/A/05.15.03
VERVER
VERVER
VERTICALTICAL
TICALTICAL
TICAL
TERMINTERMIN
TERMINTERMIN
TERMINAA
AA
ATIONTION
TIONTION
TION
HORIZONTHORIZONT
HORIZONTHORIZONT
HORIZONTALAL
ALAL
AL
TERMINTERMIN
TERMINTERMIN
TERMINAA
AA
ATIONTION
TIONTION
TION
vertical risevertical rise
vertical risevertical rise
vertical rise
is equal tois equal to
is equal tois equal to
is equal to
or greateror greater
or greateror greater
or greater
than thethan the
than thethan the
than the
horizontalhorizontal
horizontalhorizontal
horizontal
runrun
runrun
run
horizontalhorizontal
horizontalhorizontal
horizontal
run + verti-run + verti-
run + verti-run + verti-
run + verti-
cal rise tocal rise to
cal rise tocal rise to
cal rise to
maximummaximum
maximummaximum
maximum
of 40 feetof 40 feet
of 40 feetof 40 feet
of 40 feet
vertical risevertical rise
vertical risevertical rise
vertical rise
is equal tois equal to
is equal tois equal to
is equal to
or greateror greater
or greateror greater
or greater
than thethan the
than thethan the
than the
horizontalhorizontal
horizontalhorizontal
horizontal
runrun
runrun
run
horizontalhorizontal
horizontalhorizontal
horizontal
run + verti-run + verti-
run + verti-run + verti-
run + verti-
cal rise tocal rise to
cal rise tocal rise to
cal rise to
maximummaximum
maximummaximum
maximum
of 40 feetof 40 feet
of 40 feetof 40 feet
of 40 feet
vertical risevertical rise
vertical risevertical rise
vertical rise
is less thanis less than
is less thanis less than
is less than
horizontalhorizontal
horizontalhorizontal
horizontal
runrun
runrun
run
horizontalhorizontal
horizontalhorizontal
horizontal
run + verti-run + verti-
run + verti-run + verti-
run + verti-
cal rise tocal rise to
cal rise tocal rise to
cal rise to
maximum ofmaximum of
maximum ofmaximum of
maximum of
24.75 feet24.75 feet
24.75 feet24.75 feet
24.75 feet
4.2 times4.2 times
4.2 times4.2 times
4.2 times
the verticalthe vertical
the verticalthe vertical
the vertical
rise equal torise equal to
rise equal torise equal to
rise equal to
or greateror greater
or greateror greater
or greater
than thethan the
than thethan the
than the
horizontalhorizontal
horizontalhorizontal
horizontal
runrun
runrun
run
verticalvertical
verticalvertical
vertical
rise is lessrise is less
rise is lessrise is less
rise is less
than hori-than hori-
than hori-than hori-
than hori-
zontal runzontal run
zontal runzontal run
zontal run
horizontalhorizontal
horizontalhorizontal
horizontal
run + verti-run + verti-
run + verti-run + verti-
run + verti-
cal rise tocal rise to
cal rise tocal rise to
cal rise to
maximummaximum
maximummaximum
maximum
of 40 feetof 40 feet
of 40 feetof 40 feet
of 40 feet
3 times the3 times the
3 times the3 times the
3 times the
vertical risevertical rise
vertical risevertical rise
vertical rise
equal to orequal to or
equal to orequal to or
equal to or
greatergreater
greatergreater
greater
than thethan the
than thethan the
than the
horizontalhorizontal
horizontalhorizontal
horizontal
runrun
runrun
run
VENTING APPLICATION FLOW CHART

9
W415-0244/A/05.15.03
for the following symbols used in the venting calcula-
tions and examples are:
>- greater than
>- equal to or greater than
<- less than
<- equal to or less than
HT- total of both horizontal vent lengths (HR) and offsets
(HO) in feet
HR- combined horizontal vent lengths in feet
HO- offset factor: .03(total degrees of offset - 90°*) in
feet
VT- combined vertical vent lengths in feet
feet inches
1° 0.03 0.5
15° 0.45 6.0
30° 0.9 11.0
45° 1.35 16.0
90°*2.7 32.0
* the first 90° offset has a zero value and is shown in
the formula as -90°
when (HT) < (VT)
Simple venting configuration (only one 90° elbow)
FIGURE5
See graph to determine the required vertical rise VTfor the
required horizontal run HT.
For vent configurations requiring more than one 90° el-
bow, the following formulas apply:
Formula 1: H
T
< V
T
Formula 2: H
T
+ V
T
< 40 feet
Example 1:
90°
90°
V
1
=3ft
V
2
=8ft
VT= V
1
+ V
2
= 3 + 8 = 11 ft
H
1
= 2.5ft
H
2
=2ft
H
R
=H
1
+H
2
=2.5+2=4.5ft
H
O
=. 03(three 90° elbows - 90°) = .03(270° - 90°) = 5.4 ft
H
T
=H
R
+H
O
=4.5+5.4=9.9ft
H
T
+ V
T
= 9.9 + 11=20.9ft
Formula1: H
T
< V
T
9.9<11
Formula2: H
T
+ V
T
< 40 feet
20.9<40
Sincebothformulasare met,thisventconfigurationisac-
ceptable.
FIGURE6
90°
H1
V2
H2
V1
ELBOW VENT LENGTH VALUES
DEFINITIONS
VERTICAL
RISE IN
FEET
V
T
HORIZONTAL VENT RUN PLUS OFFSET IN FEET HT
The shaded area within the lines represents acceptable
values for HTand VT .
TOP EXIT / HORIZONTAL TERMINATION

10
W415-0244/A/05.15.03
H2
H1
V190°
when (Ht)> (Vt)
Simple venting configuration (only one
90° elbow)
See graph to determine the required ver-
tical rise VTfor the required horizontal
run HT.
V1=VT= 6 ft
H1=3ft
H2=5ft
HR=H1+ H2 = 3 + 5 = 8 ft
HO= .03(two 90° elbows - 90°) = .03(180° - 90°) = 2.7 ft
HT=HR+ HO = 8 + 2.7 = 10.7 ft
H
T
+ V
T
= 10.7 + 6 =16.7
Formula1: HT < 4.2 VT
4.2 VT = 4.2 x 6 = 25.2 ft
10.7 < 25.2
Formula2: HT + VT< 24.75 feet
16.7< 24.75
Since both formulas are met, this vent configuration is ac-
ceptable.
For vent configurations requiring more than one 90° elbow
the following formulas apply:
Formula 1: HT< 4.2 VT
Formula 2: HT+ VT< 24.75 feet
Example 2:
Example 3:
V
1
=4ft
V
2
= 1.5ft
VT=V1 + V2 = 4 + 1.5 = 5.5 ft
H
1
=2ft
H
2
=1ft
H
3
=1ft
H
4
= 1.5ft
HR=H1+ H2 + H3+ H4 = 2 + 1 + 1 + 1. 5 = 5.5 ft
HO= .03(four 90° elbows - 90°) = .03(360° - 90°) = 8.1 ft
H
T
=H
R
+H
O
=5.5+8.1=13.6ft
H
T
+ V
T
=13.6+ 5.5=19.1ft
Formula 1:H
T
< 4.2 V
T
4.2 VT = 4.2 x 5.5 = 23.1 ft
13.6<23.1
Formula 2:H
T
+ V
T
< 24.75 feet
19.1<24.75
Sincebothformulasaremet, thisventconfigurationisac-
ceptable.
FIGURE7
FIGURE8
FIGURE9
H2
H4
V2
90°
H3
H1
V1
90°
TOP EXIT / HORIZONTAL TERMINATION
REQUIRED
VERTICAL
RISE IN
INCHES
VT
HORIZONTAL VENT RUN PLUS OFFSET IN FEET HT
The shaded area within the lines represents acceptable
values for HTand VT .

11
W415-0244/A/05.15.03
Example 4:
V
1
=5ft
V
2
=10ft
VT= V
1
+ V
2
= 5 + 10 = 15 ft
H
1
=1ft
H
2
=3ft
H
3
=2.5ft
HR=H1+ H2+ H3= 1 + 3 + 2.5 = 6.5 ft
HO=.03(four 90° elbows - 90°)
=.03(90 + 90 + 90 + 90 - 90) = 8.1 ft
H
T
=H
R
+H
O
=6.5+8.1=14.6ft
H
T
+ V
T
=14.6+15=29.6ft
Formula1: H
T
< V
T
14.6<15
Formula2: H
T
+ V
T
< 40 feet
29.6<40
Sincebothformulasaremet, thisventconfigurationisac-
ceptable.
when (Ht) < (Vt)
Simple venting configurations
FIGURE10 FIGURE11
For vent configurations requiring elbows, the following for-
mulas apply:
Formula 1: H
T
< V
T
Formula 2: H
T
+ V
T
< 40 feet
See graph to determine the required vertical rise VTfor the
required horizontal run HT.
90°
90°
90°
V2
90°
H1
V1
H3
H2
REQUIRED
VERTICAL RISE
IN FEET
V
T
HORIZONTAL VENT RUN PLUS OFFSET IN FEET H
T
The shaded area within the lines represents acceptable
values for HTand VT .
TOP EXIT VERTICAL TERMINATION

12
W415-0244/A/05.15.03
Formula 1: H
T
< 3V
T
Formula 2: H
T
+ V
T
< 40 feet
Example 5:
V
1
=2ft
V
2
=1ft
V
3
=1.5ft
See graph to determine the required vertical rise VTfor the
required horizontal run HT.
For vent configurations requiring elbows, the following for-
mulas apply:
FIGURE13
VT=
V
1
+ V
2
+ V
3
= 2 + 1 + 1.5 = 4.5 ft
H
1
=6ft
H
2
=2ft
HR=H1+ H2= 6 + 2 = 8 ft
HO=.03(four 90° elbows - 90°)
=.03(90 + 90 + 90 + 90 - 90) = 8.1 ft
H
T
=H
R
+H
O
=8+8.1=16.1ft
H
T
+ V
T
=16.1 + 4.5 = 20.6 ft
Formula1: H
T
< 3V
T
3VT= 3 x 4.5 = 13.5 ft
16.1>13.5
Since this formula is not met, this vent configuration is
unacceptable.
Formula2: H
T
+ V
T
< 40 feet
20.6<40
Sinceonlyformula2ismet,thisventconfigurationisunac-
ceptableandanewfireplacelocationorventconfiguration
willneedtobeestablishedtosatisfyboth formulas.
Example 6:
V
1
=1.5ft
V
2
=5ft
VT= V
1
+ V
2
= 1.5 + 5 = 6.5 ft
H
1
=1ft
H
2
=1ft
H
3
=1ft
H
4
=10.75ft
HR=H1+ H2+ H3+ H4= 1 + 1 + 1 + 10.75 = 13.75 ft
HO=.03(four 90° elbows + one 45° elbow - 90°)
=.03(90 + 90 + 90 + 90 + 45 - 90) = 9.45 ft
H
T
=H
R
+H
O
=13.75+9.45=23.2ft
H
T
+ V
T
=23.2+ 6.5=29.7ft
Formula1: H
T
< 3V
T
3VT = 3x 6.5 = 19.5 ft
19.5=19.5
Formula2: H
T
+ V
T
< 40 feet
29.7<40
Sincebothformulasaremet,this vent configurationisac-
ceptable.
when (Ht) > (Vt)
Simple venting configurations
FIGURE14
FIGURE12
H1
H2
V3
V1
90° 90°
90°
V2
90°
H4
V1
V2
90° 45°
90°
H1
90° H3
H2
TOP EXIT VERTICAL TERMINATION
MAXIMUM
VERTICAL
RISE IN
FEET
V
T
HORIZONTAL VENT RUN PLUS OFFSET IN FEET H
T
The shaded area within the lines represents acceptable
values for HTand VT .

13
W415-0244/A/05.15.03
This application occurs
when venting through a
roof. Installation kits for
various roof pitches are
available from your Na-
poleon dealer. See Ac-
cessories to order the
specific kit required.
1. Determine the air
terminal location, cut
and frame 10 inch open-
ings in the ceiling and the roof to provide the minimum 1
inch clearance between the fireplace pipe / liner and any
combustible material. Try to center the exhaust pipe loca-
tion midway between two joist to prevent having to cut them.
Use a plumb bob to line up the center of the openings. DO
NOT FILLTHIS SPACE WITHANYTYPE OF MATERIAL. A
vent pipe shield will prevent any materials such as insula-
tion, from filling up the 1" air space around the pipe. Nail
headers between
the joist for extra
support.
2. Apply a bead of
caulking (not sup-
plied) to the frame-
work or to the Wolf
Steel vent pipe
shield plate or equivalent (in the case of a finished ceiling),
and secure over the opening in the ceiling. FIGURE 18. A
firestop must be placed on the bottom of each framed open-
ing in a roof or ceiling that the venting system passes
through. Apply a bead of caulking all around and place a
firestop spacer over the vent shield to restrict cold air from
being drawn into the room or around the fireplace. Ensure
that both spacer and shield maintain the required clear-
ance to combustibles. Once the vent pipe / liner is installed
in its final position, apply sealant between the pipe / liner
and the firestop spacer.
FIGURE18
FORSAFEANDPROPEROPERATIONOFTHEFIREPLACE,
FOLLOWTHEVENTING INSTRUCTIONSEXACTLY.
AHEATSHIELDMUSTBEUSED IFTHEWALLTERMINALIS
INSTALLEDON COMBUSTIBLE,EXTERIORSURFACES.
NOTE: Only a clearance to combustibles of 1" all
around the vent pipe is required.
This application occurs when
venting through an exterior
wall. Having determined the air
terminal location, cut and frame
a hole in an exterior wall with a
minimum opening as required.
See Note above. (As an alterna-
tive to framing, a vent pipe shield
may be installed, ensuring a 1"
clearance to combustibles.
See Figure 16.)
1. Mark and cut the vent pipe
shield to the determined depth of the combustible wall.
Apply a bead of caulking (not supplied) to the framework or
to the shield plate (in the case of a finished wall) and se-
cure the shield through the opening to the interior wall. The
final location of the vent pipe shield should maintain the
required clearance to the 8" vent pipe / liner. (See note
above). Do not fill this cavity with any type of material. Ap-
ply a bead of caulking all around and place a firestop spacer
over the vent shield to restrict cold air from being drawn
into the room or around the fireplace. Ensure that both
spacer and shield maintain the required clearance to
combustibles. Once the vent pipe / liner is installed in its
final position, apply sealant between the pipe / liner and
the firestop spacer.
FIGURE16
OR
HORIZONTAL INSTALLATION
VERTICAL INSTALLATION
INSTALLATION
WALL AND CEILING PROTECTION
FIGURE15
FIGURE17

14
W415-0244/A/05.15.03
Use only approved aluminum flexi-
ble liner kits marked:
"Wolf Steel Approved Venting" as identified by the
stamp only on the 8” outer liner.
1. Cut or frame a hole in an exterior wall with a minimum
round or square opening listed on page 5. Secure the
firestop spacer over the opening to the interior wall.
2. Stretch the 5" diameter aluminum flexible liner to the
required length taking into account the additional length
needed for the finished wall surface. Slip the liner a mini-
mum of 2" over the inner sleeve of the air terminal and
secure with 3 #8 screws. Apply a heavy bead of the high
temperature sealant.
3. Using the 8" diameter flexible aluminum liner, slide
over the outer combustion air sleeve of the air terminal and
secure with 3 #8 screws. Seal as before.
4. Insert the liners through the firestop maintaining the
required clearance to combustibles. Holding the air termi-
nal (lettering in an upright, readable position), secure to
the exterior wall and make weather tight by sealing with
caulking (not supplied).
5. Apply a heavy bead of the high temperature sealant,
supplied with the unit, to the inside of the 5" liner approxi-
mately 1" from the end. Slip the liner a minimum of 2" over
the fireplace vent collar and secure with 3 #8 screws.
6. Using the 8" diameter flexible aluminium liner, apply
sealant, slide a minimum of 2" over the fireplace combus-
tion air collar and secure with 3 #8 screws.
FIGURE19
Use the GD420 vent kit and couplers for this application.
If more than one length of liner needs to be used to reach
the fireplace, couple them together as illustrated in
FIGURE 20. Seal the joints using the same procedure as
described in points 2 and 3. The vent system must be sup-
ported approximately every 3 feet for both vertical and hori-
zontal runs. Use Wolf Steel support ring assemblies, or
equivalent noncombustible strapping to maintain the mini-
mum 1" clearance to combustibles as well as to prevent
sagging.
Spacers are attached to the 5" inner flex liner at prede-
termined intervals to maintain a 1-1/4" air gap to the 8"
outer liner. These spacers must not be removed.
1. Fasten the roof support to
the roof using the screws pro-
vided. FIGURE 21. The roof sup-
port is optional. In this case the
venting is to be adequately sup-
ported using either an alternate
method suitable to the authority
having jurisdiction or the op-
tional roof support.
2. Stretch the 5" diameter alu-
minium flexible liner to the re-
quired length. Slip the liner a
minimum of 2" over the inner
sleeve of the air terminal and se-
cure with 3 #8 screws. Seal us-
ing a heavy bead of the high
temperature sealant.
3. Repeat using the 8" diam-
eter flexible aluminium liner.
4. Thread the air terminal pipe assembly down through
the roof. The air terminal must be located vertically and
plumb. Attach the air terminal assembly to the roof support,
ensuring that a minimum 16" of air terminal will penetrate
the roof when fastened.
DONOTCLAMP THEFLEXIBLEALUMINIUMLINER.
5. Remove nails from the shingles, above and to the
sides of the chimney. Place the flashing over the air termi-
nal and slide it underneath the sides and upper edge of
the shingles. Ensure that the air terminal is properly
centered within the flashing, giving a 3/4" margin all around.
Fasten to the roof.
FIGURE20
FIGURE22
FIGURE21
USING FLEXIBLE VENT COMPONENTS
HORIZONTAL AIR TERMINAL INSTALLATION
EXTENDED HORIZONTAL
AIR TERMINAL INSTALLATION
VERTICAL AIR TERMINAL INSTALLATION

15
W415-0244/A/05.15.03
FIGURE25
The vent system must be supported approximately every 3
feet for both vertical and horizontal runs. Use Wolf Steel
vent spacers every 3 feet and either side of each elbow to
maintain the minimum 1¼" clearance between the outer
and inner vent pipes. Use Wolf Steel support ring assem-
bly or equivalent noncombustible strapping to maintain the
minimum clearance to combustibles for both vertical and
horizontal runs.
1.Movethefireplaceintoposition.Meas-
ure the vent length required between ter-
minal and fireplace taking into account
the additional length needed for the finished wall surface and
any 1¼" overlaps between venting components.
2. Apply high temperature sealant to the outer edge of the 5"
inner collar of the fireplace. Attach the first vent component and
secure using 3 self tapping screws. Repeat using 8" piping.
3. Holding the air terminal (with the air deflectors to the
top), insert into both vent pipes with a twisting motion to ensure
that both the terminal sleeves engage into the vent pipes and
sealant. Secure the terminal to the exterior wall and make
weather tight by sealing with caulking (not supplied).
The air terminal mounting plate may be recessed into the
exterior wall or siding by 1½", the depth of the return flange.
1. Follow the instructions for "Horizontal Air Terminal In-
stallations", items 1 to 3.
2. Continue adding components alternating inner and
outer venting. Ensure that all 5" venting and elbows have
sufficient vent spacers attached and each component is
securely fastened to the one prior. Attach the 5" telescopic
sleeve to the vent run.
Repeat using a 8" tel-
escopic sleeve. Secure
and seal as before. To
facilitate completion, at-
tach 5" and 8" couplers
to the air terminal.
3. Install the air terminal. See item 3 of
the Horizontal Air Terminal Installation.
Extend the 5" telescopic sleeve; connect
to the air terminal assembly. Fasten with
self tapping screws and seal. Repeat
using the 8" telescopic sleeve.
TELESCOPIC SLEEV
VENTING
20"
COUPLER
AIR TERMINAL
FIGURE26
Do not nail through
the lower portion of the
flashing. Make
weather-tight by seal-
ing with caulking.
Where possible, cover
the sides and top
edges of the flashing
with roofing material.
6. Apply a heavy
bead of weatherproof caulking 2 inches above the flash-
ing. Slide the storm collar around the air terminal and down
to the caulking. Tighten to ensure that a weather-tight seal
between the air terminal and the collar is achieved. Attach
the other storm collar centered between the air intake and
the air exhaust slots onto the air terminal. Tighten securely.
FIGURE 23. Attach the vertical rain cap.
Spacers are attached to the 5" inner flex liner at prede-
termined intervals to maintain a 1-1/4" air gap to the 8"
outer liner. These spacers must not be removed.
7. If more liner needs to be used to reach the fireplace,
follow the same procedure as found in EXTENDED HORI-
ZONTALAIR TERMINAL INSTALLATION.Theventsystem
must be supported approximately every 3 feet for both ver-
tical and horizontal runs. Use Wolf Steel support ring as-
sembly or equivalent noncombustible strapping to main-
tain a clearance to combustibles.
1. Install the 5 inch diameter aluminium flexible liner to
the fireplace. Secure with 3 screws and flat washers. Seal
the joint and screw holes using the high temperature seal-
antprovided. FIGURE 24.
2. Install the 8 inch diameter aluminium flexible liner to
the fireplace. Attach and seal the joints.
FIGURE24
FIGURE23 FIREPLACE VENT CONNECTION
USING RIGID VENT COMPONENTS
HORIZONTAL AIR TERMINAL INSTALLATION EXTENDED HORIZONTAL AND CORNER
AIR TERMINAL INSTALLATION

16
W415-0244/A/05.15.03
Proceed once the vent installation is complete.
1. Move the fireplace into position and secure using the
nailing tabs and/or secure to the floor through the ¼"diam-
eter holes located at either end of the base.
2. Route a 3/8" N.P.T. black iron gas line, 1/2" type-Lcop-
per tubing or equivalent to the fireplace.
3. For ease of accessibility, an optional remote wall switch
or millivolt thermostat may be installed in a convenient lo-
cation. Route 2-strand (solid core) millivolt wire through
the electrical hole located at the bottom left side of the unit.
The recommended maximum lead length depends on wire
size: WIRESIZE MAX.LENGTH
14 gauge 100 feet
16 gauge 60 feet
18 gauge 40 feet
Attach the two leads to terminals 1 and 3 located on the
gas valve.
4. Install rigid black pipe, 1/2" type-L copper tubing or, if
local codes permit, a 3/8" flex connector and shutoff valve
to the gas line and the fireplace gas valve.
Thegas lineandthe shutoffvalve (ifso equipped)must
not interfere with the opening and closing of the door
latch.
Seal and tighten securely. An adapter fitting is required
between the gas valve and the copper tubing or flex con-
nector.
DD
DD
Do not kink flex connector.
5. Check for gas leaks by brushing on a soap and water
solution.
Do not use open flame.
Do not connect either the wall switch, thermostat or gas
valve to electricity (110 volts).
Purge all gas lines with the glass door of the fireplace
open. Assure that a continuous gas flow is at the burner
before closing the door.
1. Move the fireplace into position.
2. Fasten the roof support to the roof using the screws
provided. FIGURE 22. The roof support is optional. In this
case the venting is to be adequately supported using ei-
ther an alternate method suitable to the authority having
jurisdiction or the optional roof support.
3. Apply high temperature sealant to the outer edge of the
inner sleeve of the air terminal. Slip a 5" diameter coupler a
minimum of 2" over the sleeve and secure using 3 screws.
4.Apply high temperature seal-
ant to the outer edge of the of the
outside sleeve of the air terminal.
Slip a 8" diameter coupler over the
sleeve and secure as before. FIG-
URE 27. Trim the 8" coupler even
with the 5" coupler end.
5.Thread the air terminal pipe
assembly down through the roof
support and attach, ensuring that
a minimum 16" of air terminal will
penetrate the roof when fas-
tened. FIGURE 22. If the attic
space is tight, we recommend
threadingtheWolfSteelventpipe
collarorequivalent loosely onto
the air terminal assembly as it is
passed through the attic.
FIGURE 28. The air terminal must
be located vertically and plumb.
6. Remove nails from the shingles, above and to the
sides of the chimney. Place the flashing over the air termi-
nal and slide it underneath the sides and upper edge of
the shingles. Ensure that the air terminal is properly
centered within the flashing, giving a 3/4" margin all around.
Fasten to the roof. Do NOT nail through the lower portion of
the flashing. Make weather-tight by sealing with caulking.
Where possible, cover the sides and top edges of the flash-
ing with roofing material. FIGURE 23.
7. Apply a heavy bead of waterproof caulking 2 inches
above the flashing. Slide the storm collar around the air
terminal and down to the caulking. Tighten to ensure that a
weather-tight seal between the air terminal and the collar
is achieved. Attach the other storm collar centered between
the air intake and air exhaust slots onto the air terminal.
Tighten securely. Attach the rain cap.
8. Continue adding rigid venting sections, sealing and
securing as above. Attach a 5" collapsed telescopic pipe
to the last section of rigid piping. Secure with screws and
seal. Repeat using a 8" telescopic pipe.
9. Run a bead of high temperature sealant around the
outside of the 5" collar on the fireplace. Pull the adjustable
pipe a minimum of 2" onto the collar. Secure with 3 screws.
Repeat with the 8" telescopic pipe.
10. In the attic, slide the vent pipe collar down to cover up
the open end of the shield and tighten. This will prevent
any materials, such as insulation, from filling up the 1" air
space around the pipe.
VENT PIPE
SHIELD
VEN
T
PIP
E
COLLA
R
FIGURE28
FIGURE27
FIGURE30
FIGURE29
P
I
P
I
L
O T
3
12
N
O
L
O
T
H
I
L
O
F
F
O
VERTICAL VENTING INSTALLATION GAS INSTALLATION

17
W415-0244/A/05.15.03
It is not necessary to install a hearth extension with this
fireplace system.
Note: In order to avoid the possibility of exposed insulation
or vapour barrier coming in contact with the
fireplace body, it is recommended that the walls of the
fireplace enclosure be “finished” (ie: drywall/sheetrock), as
you would finish any other outside wall of a home. This will
ensure that clearance to combustibles is maintained within
thecavity.
When roughing in the fireplace, raise the fireplace to ac-
commodate for the thickness of the finished floor materi-
als, i.e. tile, carpeting, hard wood, which if not planned for
will interfere with the opening of the lower access door and
the installation of many decorative flashing accessories.
Objects placed in front of the fireplace should be kept a
minimum of 48" away from the front face.
Combustible materials may be installed flush with the front
of the fireplace but must not cover or protrude past any of
the black face-areas of the fireplace. Non-combustible ma-
terial (brick, stone or ceramic tile) may protrude in these
areas.
To install the fireplace face flush with the finished wall,
position the framework to accommodate the thickness of
the finished wall. Bend out the four nailing tabs, attached on
either side of the fireplace and secure to the 2x4 framing. The
tabs will facilitate the installation of either a 3/4" or a 1" finished
wall thickness.
The nailing tabs must not be removed.
Combustible mantle clearance can vary according to the
mantle depth. Use the graph to help evaluate the clear-
ance needed. Curtains, above the fireplace, must not be
positioned lower than the 3" distance required for the 3"
combustible mantle. These same requirements apply to
any combustibles protruding on either side of the fire-
place.
FIGURES34
FIGURES33
FIGURE32
FIGURE31
In Canada, mobile home installation may be vented hori-
zontally or vertically. In the United States, it may only be
installed vertically. See "Vertical Venting" or "Horizontal Air
Terminal Installation" for installation.
The fireplace is equipped with two 1/4" diameter holes
located in the front left and right corners of the base. For
mobile home installations, the fireplace must be fastened
in place. Use #10 hex head screws, inserted through the
holes in the base to secure. It is recommended that the
fireplace be secured in all installations.
Always turn off the pilot and the fuel supply at the
source, prior to moving the mobile home.
After moving the mobile home and prior to lighting the
fireplace, ensure that the logs are positioned correctly.
It is best to frame your fireplace after it is positioned and
the vent system is installed. Use 2x4's and frame to local
building codes. FIGURES 31-33.
MOBILE HOME INSTALLATION
FRAMING
MANTLE INSTALLATION
NAILING TABS

18
W415-0244/A/05.15.03
Lift up and remove the upper
louvres. Open the valve control
door. Release the top and bot-
tomdoor latches, locatedatthe
right side of the door.
To close the door, repeat in re-
verse order.
The door latch holes are elongated for door levelling. To
level the door may need to be lifted up at the right side
before latching to ensure the door is level.
Remove the pro-
tective plastic wrap
from the louvres
and install as illus-
trated.
Clip each upper
louvre into a slot on
the louvre bracket.
Ensure that the
louvres are
centered within the
opening.
Secure the lower louvre assembly to the lip of the fireplace
base as shown.
Position the hinge screen into place and with the control
door open, secure to the firebox using three screws.
FIGURE35
LOUVRE
BRACKET
FIGURE36a
UPPERLOUVREINSTALLATION
A
C
B
L38 LOUVRE INSTALLATION
FIGURE37 a-c
HOOD
Attach the hood by pressing the
top flange into the clips along
the top of the louvre opening.
Secure using a screw through
the centre slot.
LOWERLOUVRES
Insert the hinge clips into the
slots located at the bottom left
and right corners of the unit.
To remove the louvres, pull the
back tabs of the clips forward,
while pushing the louvre assem-
bly back. Lift the clip.
UPPERLOUVRES
Insert the louvre tabs into the
slots located at the top left and
right corners of the unit.
ACLIPS
CENTRE
SLOT
FLANGE
SLOT
TAB
B
CHINGE
CLIP SLOT
FINISHING
GVFL LOUVRE INSTALLATION
DOOR REMOVAL & INSTALLATION
FIGURES37a-d
FIGURE36b:LOWERLOUVREASSEMBLY
HINGE
SCREEN

19
W415-0244/A/05.15.03
Remove the backing of the
logo supplied and place on the
glass viewing door, as
indicated.
½"
½"
LOGO
FIGURE39
PHAZERTM logsandglowingembersexclusiveto Napoleon Fire-
places, provide a unique and realistic glowing effect that is
different in every installation. Take the time to carefully po-
sition the glowing embers for a maximum glowing effect.
Log colours may vary. During the initial use of the fireplace,
the colours will become more uniform as colour pigments
burn in during the heat activated curing process.
1. Place the back log (#1) onto the log
support tray and in front of the tabs. The
tabs maintain an air space between the
log and firebox back to facilitate combus-
tion air flow. Ensure that the back of the log
rests against the brackets on the back wall
of the firebox.
2. Move the two small logs (#2 & #3) into position, lining
up the studs located on the burner with the holes on the
bottom of the logs. Ensure that the small logs sit flat on the
burner.
3. Place the bottom of the left crossover log (#4) against
the left firebox side and pulled forward to the grate.
The top of the log should rest in the pocket on the back log.
LOG PLACEMENT
#4
#1
4. Position the notch located on the end of the center log
(#5) against the middle grate post with the other end of the
log resting in the pocket of the left crossover log.
5. Place the bottom of the right crossover log (#6) against
the right firebox side and pulled forward to the grate. The
top of the log should rest in the pocket provided on the
center log (#5).
Randomly place the charcoal embers along the front and
sides of the log support tray in a realistic manner. Fine
dust found in the bottom of the bag should not be used.
Tear the embers into pieces and place along the front row
of ports covering all of the burner area in front of the small
logs (#2 & #3). Care should be taken to shred the embers
into thin, small irregular pieces as only the exposed edges
of the fibre hairs will glow. The ember material will only
glow when exposed to direct flame; however, care
should be taken to not block the burner ports.
Blocked burner ports can cause an incorrect flame pattern,
carbon deposits and delayed ignition. PHAZERTM logs glow
when exposed to direct flame. Use only certified "glowing
embers" and PHAZERTM logs available from your Napo-
leon dealer.
#5
#6
FIGURE38a-f
#2 #3
TAB
SIDEVIEW
CHARCOAL EMBERS
GLOWING EMBERS
LOGO PLACEMENT

20
W415-0244/A/05.15.03
INSTALLATION TO BE DONE BY A QUALIFIED IN-
STALLER and must be electrically connected and grounded
in accordance with local codes. In the absence of local
codes, use the current CSA C22.1 CANADIAN ELECTRICAL CODE
in Canadaor the ANSI/NFPA 70 NATIONAL ELECTRICAL CODE inthe
United States
If the fireplace was not previously equipped with a
blower: route a grounded 2-wire, 60hz power cable to the
receptacle / junction box. At this point, it must be strain
relieved and insulated.
The three slots on the
blower mounting
bracket allow ease of
adjustment when
attaching the blower.
For a quiet running
blower, do not allow the
assembly to sit on the
firebox base.
Slide the vibration reducing pad (A) into the clip (C) and up
against the threaded stud (B) at the other end. The blower
must be able to be positioned entirely onto the pad.
Tilt the blower onto its side. Slide it past the controls and
into the clip (C). Secure to the threaded stud using the lock
washer and wing nut provided. Ensure that the blower
does not touch the fireplace base or the firebox.
SLOTS
ELONGATED
Attachtheconnectorsfrom
the black and white wires
to the thermodisc and se-
cure the thermodisc
bracket to the securing
stud at the bottom left of
the unit using a lock
washer and wing nut. En-
sure that the thermodisc
touches the firebox wall.
Attachtheconnectorsfrom
the black and red wires to
the blower.
Attachandsecure the vari-
able speed switch using
the nut provided. Plug the
harness cord into the re-
ceptacle.
The wire harness provided in this kit is a universal
harness. When installed, ensure that any excess
wire is contained, preventing it from making con-
tact with moving or hot objects.
Because the blower is thermally activated, when
turned on, it will automatically start approximately
10 minutes after lighting the fireplace and will run
for approximately 30-45 minutes after the fireplace
has been turned off. Use of the fan increases the
output of heat.
Drywall dust will penetrate into the blower bear-
ings, causing irreparable damage. Care must be
taken to prevent drywall dust from coming into
contact with the blower or its compartment. Any
damage resulting from this condition is not cov-
ered by the warranty policy.
red
white
black
FIGURE40
RECEPTACLE
/
THERMODISC
GROUND
SCREW
JUNCTIONBOX
FIGURE44
FIGURE45
FIGURE41
FIGURE43
C
FIGURE42
A
B
OPTIONAL BLOWER INSTALLATION
