INSTALLER: THESE INSTRUCTIONS MUST BE CONVEYED TO AND REMAIN WITH THE HOMEOWNER.
Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON L4M 4Y8 Canada • [phone] • fax[phone]
www.napoleonfireplaces.com • [email protected]
GAS - DIRECT VENT MILLIVOLT SYSTEM
INSTALLATION AND OPERATION INSTRUCTIONS FOR
LISTED DIRECT VENTED GAS-FIRED WALL FURNACE
NATURAL GAS MODEL
GD45-N
PROPANE GAS MODEL GD45-P
CERTIFIED FOR CANADA AND UNITED STATES USING ANSI / CSA METHODS
CERTIFIED UNDER CANADIAN AND AMERICAN NATIONAL STANDARDS, CSA 2.33, ANSI Z21.88 FOR VENTED GAS FIREPLACE HEATERS
Installation and service must be performed by a qualified installer, service
agency or the gas supplier.
WARNING: If the information in these instructions is not followed exactly, a fire or
explosion may result causing property damage, personal injury or death.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapours and liquids in the vicin-
ity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use any phone in your build
ing.
• Immediately call your gas supplier
from a neighbour's phone. Follow
the gas supplier's instructions.
• If you cannot reach your gas supplier,
call the fire department.

2
W415-0100/ D /01.13.04
WARNING
• Do not burn wood or other materials in this fireplace.
• Adults and especially children should be alerted to the hazards of high surface temperatures and should stay
away to avoid burns or clothing ignition. Supervise young children when they are in the same room as the
fireplace.
• Due to high temperatures, the fireplace should be located out of traffic and away from furniture and draperies.
• Clothing or other flammable material should not be placed on or near the fireplace.
• Any safety screen or guard removed for servicing must be replaced prior to operating the fireplace.
• It is imperative that the control compartments, burners and circulating blower and its passageway in the fire-
place and venting system are kept clean. The fireplace and its venting system should be inspected before use
and at least annually by a qualified service person. More frequent cleaning may be required due to excessive lint
from carpeting, bedding material, etc. The fireplace area must be kept clear and free from combustible materi-
als, gasoline and other flammable vapours and liquids.
• Under no circumstances should this fireplace be modified.
• This fireplace must not be connected to a chimney flue pipe serving a separate solid fuel burning appliance.
• Do not use this fireplace if any part has been under water. Immediately call a qualified service technician to
inspect the fireplace and to replace any part of the control system and any gas control which has been under
water.
• Do not operate the fireplace with the glass door removed, cracked or broken. Replacement of the glass should
be done by a licensed or qualified service person.
• Do not strike or slam shut the fireplace glass door.
• This fireplace uses and requires a fast acting thermocouple. Replace only with a fast acting thermocouple
supplied by Wolf Steel Ltd.
PG2-5 INTRODUCTION
Warranty
General Instructions
General Information
Care of Glass & Plated Parts
5-8 VENTING
Vent Lengths
Venting Options
Air Terminal Locations
9-13 INSTALLATION / FRAMING
Horizontal Venting Installation
Vertical Venting Installation
Restricting Vertical Vents
Fireplace Vent Connection
Installation
Framing
Mantle Clearances and Enclosures
Mobile Home Installation
14 GAS INSTALLATION
14-16 FINISHING
Brick Panel Installation
Log Placement
Door Opening, Trim & Louvres
17 OPTIONAL BLOWER INSTALLATION
18 OPTIONAL FAN INSTALLATION
OPTIONAL THERMOSTATIC SENSOR
19-20 OPERATION / MAINTENANCE
Operating Instructions
Maintenance
20 ADJUSTMENTS
Pilot Burner Adjustment
Venturi Adjustments
21-22 REPLACEMENTS
Ordering Replacement Parts
Replacement Parts
Terminal Kits
Vent Kits
Accessories
23-24 TROUBLE SHOOTING GUIDE
NOTE: CHANGES, OTHER THAN EDITORIAL, ARE DENOTED BY A VERTICAL LINE IN THE MARGIN.
TABLE of CONTENTS
PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE

3
W415-0100/ D /01.13.04
NAPOLEON gas fireplaces are manufactured under the strict Standard of the world recognized
ISO 9001 : 2000 Quality Assurance Certificate.
NAPOLEON products are designed with superior components and materials, assembled by trained craftsmen
who take great pride in their work. The burner and valve assembly are leak and test-fired at a quality test
station. The complete fireplace is thoroughly inspected by a qualified technician before packaging to ensure that
you, the customer, receives the quality product that you expect from NAPOLEON.
NAPOLEON GAS FIREPLACE PRESIDENT'S LIFETIME LIMITED WARRANTY
The following materials and workmanship in your new napoleon gas fireplace are warrantedThe following materials and workmanship in your new napoleon gas fireplace are warranted
The following materials and workmanship in your new napoleon gas fireplace are warrantedThe following materials and workmanship in your new napoleon gas fireplace are warranted
The following materials and workmanship in your new napoleon gas fireplace are warranted
against defects for as long as you own the fireplace. This covers: combustion chamber, heatagainst defects for as long as you own the fireplace. This covers: combustion chamber, heat
against defects for as long as you own the fireplace. This covers: combustion chamber, heatagainst defects for as long as you own the fireplace. This covers: combustion chamber, heat
against defects for as long as you own the fireplace. This covers: combustion chamber, heat
exchanger, stainless steel burner, phazer™ logs and embers, ceramic glass (thermal breakageexchanger, stainless steel burner, phazer™ logs and embers, ceramic glass (thermal breakage
exchanger, stainless steel burner, phazer™ logs and embers, ceramic glass (thermal breakageexchanger, stainless steel burner, phazer™ logs and embers, ceramic glass (thermal breakage
exchanger, stainless steel burner, phazer™ logs and embers, ceramic glass (thermal breakage
only), gold plated parts against tarnishing, porcelainized enamelled components and aluminumonly), gold plated parts against tarnishing, porcelainized enamelled components and aluminum
only), gold plated parts against tarnishing, porcelainized enamelled components and aluminumonly), gold plated parts against tarnishing, porcelainized enamelled components and aluminum
only), gold plated parts against tarnishing, porcelainized enamelled components and aluminum
extrusion trims.extrusion trims.
extrusion trims.extrusion trims.
extrusion trims.
Electrical (110V and millivolt) components and wearable parts such as blowers, gas valves,Electrical (110V and millivolt) components and wearable parts such as blowers, gas valves,
Electrical (110V and millivolt) components and wearable parts such as blowers, gas valves,Electrical (110V and millivolt) components and wearable parts such as blowers, gas valves,
Electrical (110V and millivolt) components and wearable parts such as blowers, gas valves,
thermal switch, switches, wiring, remote controls, ignitor, gasketing, and pilot assembly arethermal switch, switches, wiring, remote controls, ignitor, gasketing, and pilot assembly are
thermal switch, switches, wiring, remote controls, ignitor, gasketing, and pilot assembly arethermal switch, switches, wiring, remote controls, ignitor, gasketing, and pilot assembly are
thermal switch, switches, wiring, remote controls, ignitor, gasketing, and pilot assembly are
covered andcovered and
covered andcovered and
covered and NAPOLEONNAPOLEON
NAPOLEONNAPOLEON
NAPOLEON will provide replacement parts free of charge during the first year ofwill provide replacement parts free of charge during the first year of
will provide replacement parts free of charge during the first year ofwill provide replacement parts free of charge during the first year of
will provide replacement parts free of charge during the first year of
the limited warranty.the limited warranty.
the limited warranty.the limited warranty.
the limited warranty.
Labour related to warranty repair is covered free of charge during the first year. Repair work,Labour related to warranty repair is covered free of charge during the first year. Repair work,
Labour related to warranty repair is covered free of charge during the first year. Repair work,Labour related to warranty repair is covered free of charge during the first year. Repair work,
Labour related to warranty repair is covered free of charge during the first year. Repair work,
however, requires the prior approval of an authorized company official. Labour costs to thehowever, requires the prior approval of an authorized company official. Labour costs to the
however, requires the prior approval of an authorized company official. Labour costs to thehowever, requires the prior approval of an authorized company official. Labour costs to the
however, requires the prior approval of an authorized company official. Labour costs to the
account ofaccount of
account ofaccount of
account of NAPOLEONNAPOLEON
NAPOLEONNAPOLEON
NAPOLEON are based on a predetermined rate schedule and any repair work mustare based on a predetermined rate schedule and any repair work must
are based on a predetermined rate schedule and any repair work mustare based on a predetermined rate schedule and any repair work must
are based on a predetermined rate schedule and any repair work must
be done through an authorizedbe done through an authorized
be done through an authorizedbe done through an authorized
be done through an authorized NAPOLEONNAPOLEON
NAPOLEONNAPOLEON
NAPOLEON dealer.dealer.
dealer.dealer.
dealer.
CONDITIONS AND LIMITATIONS
NAPOLEONwarrantsitsproductsagainstmanufacturingdefectstotheoriginalpurchaseronly--i.e.,theindividualorlegalentity (registered customer) whose nameappearsonthe
warrantyregistration card filedwithNAPOLEON-- providedthatthe purchase wasmadethrough an authorized NAPOLEONdealerand is subjecttothe following conditionsandlimitations:
Thisfactorywarrantyisnontransferableandmaynotbeextendedwhatsoeverbyanyofourrepresentatives.
Thegasfireplace must be installed by alicenced,authorizedservice technician or contractor. Installation mustbedonein accordancewith the installation instructionsincludedwiththe
productandalllocalandnational building and fire codes.
Thislimitedwarrantydoesnotcover damages caused by misuse, lack of maintenance, accident, alterations, abuse or neglect and parts installed from other manufacturers will nullify
this warranty.
Thislimited warranty further doesnotcover any scratches, dents,corrosionordiscolouring caused by excessiveheat,abrasive and chemical cleanersnorchipping on porcelain enamel
parts,mechanicalbreakageofPHAZER™logsandembers,noranyventingcomponentsusedintheinstallationofthefireplace.
NAPOLEONwarrantsits stainless steel burnersagainstdefects in workmanshipandmaterial for life,subjectto the followingconditions:Duringthe first 10yearsNAPOLEON will replace
or repair the defective parts at our option free of charge. From 10 years to life, NAPOLEON will provide replacement burners at 50% of the current retail price.
Inthefirstyear only,thiswarrantyextendstothe repair or replacement of warranted partswhicharedefective in material or workmanship provided that the product has been operated
inaccordancewiththeoperationinstructionsandundernormal conditions.
Afterthe first year,with respect to this President'sLimitedLifetimeWarranty, NAPOLEON may, at itsdiscretion, fully discharge all obligations with respect tothiswarrantybyrefunding
totheoriginalwarranted purchaser the wholesale price of any warranted but defective part(s).
Afterthefirst year, NAPOLEON will not be responsible for installation,labourorany other costs or expenses relatedtothereinstallationof a warranted part,andsuchexpenses are not
coveredbythis warranty.
Notwithstandingany provisionscontainedin this President's LimitedLifetimeWarranty, NAPOLEON’S responsibility under thiswarrantyisdefined as above anditshallnot in any event
extendtoany incidental, consequential or indirect damages.
Thiswarranty defines the obligationsandliability of NAPOLEONwith respect to theNAPOLEON gas fireplace and anyotherwarranties expressed or impliedwithrespect to thisproduct,
itscomponentsoraccessories are excluded.
NAPOLEONneitherassumes,nor authorizes any third party to assume, on its behalf, any other liabilities with respect to the sale of this product. NAPOLEON will not be responsible
for:over-firing, downdrafts, spillage caused by environmental conditions such as rooftops, buildings, nearby trees, hills, mountains, inadequatevents or ventilation, excessive venting
configurations,insufficient makeup air, or negative air pressures which may or may notbe caused by mechanical systems such as exhaust fans, furnaces, clothes dryers, etc.
Anydamagestofireplace, combustion chamber, heat exchanger, brass trim or other component due to water, weather damage, longperiodsofdampness,condensation,damaging
chemicals or cleaners will not be the responsibility of NAPOLEON.
The bill of sale or copy will be required together with a serial number and a model number when making any warranty claims from your authorized dealer. The warranty registration
cardmustbe returned within fourteen days to register the warranty.
NAPOLEONreserves the right to have its representative inspect any product or part thereof prior to honouring any warranty claim.
ALL SPECIFICATIONS AND DESIGNSARE SUBJECTTO CHANGE WITHOUT PRIOR NOTICE DUE TO ON-GOING PRODUCT IMPROVEMENTS. NAPOLEON® ISA REGISTERED
TRADEMARK OF WOLF STEEL LTD. PATENTS U.S. 5.303.693.801 - CAN. 2.073.411, 2.082.915. © WOLF STEEL LTD.

4
W415-0100/ D /01.13.04
FORYOUR SATISFACTION, THISFIREPLACEHASBEEN
TEST-FIRED TO ASSURE ITS OPERATION AND QUAL-
ITY! Maximum input is 45,000 BTU/hr for natural gas and
40,000BTU/hr for propane. When the fireplace is installed
at elevations above 4,500ft, and in the absence of specific
recommendations from the local authority having jurisdic-
tion, the certified high altitude input rating shall be reduced
at the rate of 4% for each additional 1,000ft. Maximum out-
put for natural gas is 36,900 BTU/hr at an efficiency of 82%
with the fan on, 78.4% with the fan off; and 33,200 BTU/hr
for propane at an efficiency of 83% with the fan on, 80%
with the fan off. Minimum A.F.U.E. (Annual Fuel Utilization
Efficiency) rating is 64%.
Minimum inlet gas supply pressure is 4.5 inches water
column for natural gas and 11 inches water column for
propane. Maximum inlet gas pressure is 7 inches water
column for natural gas and 13 inches water column for
propane. Manifold pressure under flow conditions is 3.5
inches water column for natural gas and 10 inches water
column for propane.
This fireplace is approved for bathroom, bedroom and bed-
sitting room installations and is suitable for mobile home
installation.
No external electricity (110 volts or 24 volts) is required
for the gas system operation.
Expansion / contraction noises during heating up and cool-
ing down cycles are normal and are to be expected. Change
in flame appearance from "HI" to "LO" is more evident in
natural gas than in propane.
Do not use abrasive cleaners to clean plated parts. Buff lightly
with a clean dry cloth. The glass is 3/16" ceramic glass avail-
able from your Napoleon / Wolf Steel Ltd. dealer. DO NOT
SUBSTITUTE MATERIALS. Clean the glass after the first 10
hours of operation with a recommended gas fireplace glass
cleaner.Thereafterclean asrequired.DONOTCLEANGLASS
WHEN HOT! If the glass is not kept clean permanent discol-
ouration and / or blemishes may result.
Provide adequate ventilation and combustion air. Pro-
vide adequate accessibility clearance for servicing and
operating the fireplace.
Never obstruct the front opening of the fireplace.
Objects placed in front of the fireplace must be kept a
minimum of 48" away from the front face of the unit.
FIGURE1
This gas fireplace should be installed and serviced by a
qualified installer to conform with local codes. Installation
practices vary from region to region and it is important to
know the specifics that apply to your area,
for example: in Massachusetts State:
• The fireplace damper must be removed or welded in the open
position prior to installation of a fireplace insert or gas log.
• The appliance off valve must be a “T” handle gas cock.
• The flexible connector must not be longer than 36 inches.
• The appliance is not approved for installation in a bedroom or
bathroom unless the unit is a direct vent sealed combustion
product.
• WARNING: This product must be installed by a licensed plumber
or gas fitter when installed within the commonwealth of
Massachusetts.
In absence of local codes, install to the current CAN/CGA -
B149 Installation Code in Canada or to the National Fuel
Gas Code,ANSI Z223.1, and NFPA 54 in the United States.
Suitable for mobile home installation if installed in
accordance with the current standard CAN/CSA Z240MH
Series, for gas equipped mobile homes, in Canada or ANSI
Z223.1 and NFPA 54 in the United States.
The fireplace and its individual shutoff valve must be discon-
nected from the gas supply piping system during any pres-
sure testing of that system at test pressures in excess of 1/2
psig (3.5 kPa). The fireplace must be isolated from the gas
supply piping system by closing its individual manual shutoff
valve during any pressure testing of the gas supply piping
system at test pressures equal to or less than
1/2 psig (3.5 kPa).
When the fireplace is installed directly on carpeting, vinyl tile
or other combustible material other than wood flooring, the
fireplace shall be installed on a metal or wood panel extend-
ing the full width and depth.
The optional heat circulating blower is supplied with a cord. If
installed, the junction box must be electrically connected and
grounded in accordance with local codes. In the absence of
local codes, use the current CSA C22.1 CANADIAN ELEC-
TRICAL CODE in Canada or the ANSI/NFPA 70 NATIONAL
ELECTRICAL CODE in the United States.
Mobile home installation must conform with local codes. In
the absence of local codes, install to the current standard
for gas equipped mobile housing CAN/CSA Z240 MH Se-
ries in Canada or the manufactured home construction
and safety standard, Title 24 CFR, part 3280, or the Fire
Safety Criteria for manufactured home installations, Sites
and Community Standard ANSI/NFPA 5OIA in the United
States.
GENERAL INSTRUCTIONS GENERAL INFORMATION
CARE OF GLASS, AND PLATED PARTS

5
W415-0100/ D /01.13.04
FIGURE3
• Under extreme vent configurations, allow several min-
utes (5-15) for the flame to stabilize after ignition.
• Eight (8") inches is the minimum bend radius allowed for
the 7" diameter flexible air liner.
Whenterminatingvertically,the
vertical rise is a minimum 36
inches and a maximum 40 feet
above the fireplace.
Do not radius vertical vent
rises.
When venting, the immediate horizontal run must be kept
to a minimum of 10 inches or a maximum of 3 feet.
Minimum clearance to combustible construc-
tion from fireplace and vent surfaces:
sides, back, bottom, and top 0 inches
vent pipe 1 inch
recessed depth 22 inches
Use only Napoleon or Simpson Dura-Vent Model DV-GS
venting components. Minimum and maximum vent lengths,
for both horizontal and vertical installations, and air termi-
nal locations for either system are set out in this manual
and must be adhered to.
When using Napoleon venting components, use only the
following vent kits: WALL TERMINAL KIT GD-222R, or 1/12
TO 7/12 PITCH ROOFTERMINAL KITGD-110, 8/12 TO 12/
12 ROOF TERMINALKIT GD-111, FLAT ROOF TERMINAL
KIT GD-112 or PERISCOPE KIT GD-201 (for wall penetra-
tion below grade) in conjunction with the various termina-
tions, use either the 5 foot vent kit GD-220 or the 10 foot
vent kit GD-330 For Simpson Dura-Vent, follow the installa-
tion procedure provided with the venting components.
These vent kits allow for either horizontal or vertical venting
of the fireplace. The maximum number of 4" flexible con-
nections is four (excluding the fireplace and the air termi-
nal connections).
For optimum flame appearance and fireplace performance,
keep the vent length and number of elbows to a minimum.
The air terminal must remain unobstructed at all times.
Examine the air terminal at least once a year to verify that it
is unobstructed and undamaged.
• All horizontal runs must have a 1 inch rise per foot in all
cases using Napoleon flexible venting components.
• Horizontal runs can have a 0 inch rise per foot using
Simpson Dura-Vent or Napoleon rigid venting components.
For optimum performance, it is recommended that all hori-
zontal runs have a minimum ¼ inch rise per foot using
rigid venting.
• Provide a means for visually checking the vent connec-
tion to the fireplace after the fireplace is installed.
• Do not allow the inside liner to bunch up on horizontal or
vertical runs and elbows. Keep it pulled tight. A 1¼" air
gap between the inner and outer liner all around is re-
quired for safe operation.
• Use a firestop when penetrating interior walls, floor or
ceiling.
• For safe and proper operation of the fireplace follow the
venting instruction exactly.
• Deviation from the minimum vertical vent length can cre-
ate difficulty in burner start-up and/or carboning.
• Vent lengths that pass through unheated spaces (attics,
garages, crawl space) should be insulated with the insu-
lation wrapped in a protective sleeve to minimize conden-
sation.
• Purge all gas lines with the glass door of the fireplace
open. Assure that a continuous gas flow is at the burner
before closing the door.
FIGURE2
FIGURES4a
FIGURES4b
VENTING
VENTING LENGTHS

6
W415-0100/ D /01.13.04
FIGURES5 40FTMAX
1FTMIN
8FT MAX
(1FTMAX)
HORIZONTALVENTRUN
in feet
VERTICAL
RISE in feet
HORIZONTAL VENT RUN
in feet
VERTICAL
RISE in feet
Use the venting option charts to calculate vertical rises for horizontal runs between 3 and 20 feet.
When calculating maximum run lengths, include 10 feet for each 90° elbow or 5 feet for each 45° elbow. (DO NOT
INCLUDE THE FIRST ELBOW DIRECTLY OFF THE UNIT.)
Use this chart to calculate vertical rise for horizontal run between 1 foot (maximum
length when the vertical rise is at its minimum of 1 foot) and 8 feet.
Use this chart to calculate vertical rise for horizontal run between 3 feet (maximum length when the vertical rise is at its
minimum of 1 foot) and 20 feet.
VENTING OPTION #1
VENTING OPTION #2
FIGURES6 20FTMAX
1FTMIN
20FTMAX
(3FTMAX)
When venting, the horizontal run must be kept to a
minimum of 10 inches or a maximum of 20 feet.

7
W415-0100/ D /01.13.04
FIGURES8
HORIZONTAL VENT RUN
in feet
COMBINED
VERTICAL
RISE in feet
COMBINED HORIZON-
TAL VENT RUN in feet
VERTICAL
RISE in feet
FIGURES7
20FTMAX
1FTMIN
10FTMAX
(1FTMAX)
8FT MAX
(2FTMAX)
34FTMAX
(1FTMAX)
18FTMAX
(3FTMAX)
6FTMAX
1FTMIN
Use this chart to calculate the vertical rise when using a total of 2 horizontal runs. When the vertical rise is at its minimum
of 1 foot, the first horizontal run can be a maximum of 2 feet and 1 foot maximum for the second run. When the vertical rise
is at its maximum of 20 feet, the first horizontal run can be a maximum of 8 feet and 10 feet maximum for the second run.
Use this chart to calculate the total vertical rise required when the horizontal run is between 18 feet maximum or
3 feet maximum length when the initial vertical rise is at its minimum of 1 foot.
VENTING OPTION #3
VENTING OPTION #4

8
W415-0100/ D /01.13.04
AIR TERMINAL INSTALLATIONS
**
**
* Recommended to prevent condensation on windows and thermal breakage
****
****
** It is recommended to use a heat shield and to maximize the distance to vinyl clad soffits.
******
******
*** The periscope GD-201 requires a minimum 18 inches clearance from an inside corner.
********
********
**** This is a recommended distance. For additional requirements check local codes.
††
††
† Three feet above if within 10 feet horizontally.
‡‡
‡‡
‡ A vent shall not terminate directly above a sidewalk or paved driveway that is located between two single fam
i
dwellings and serves both dwellings.
††††
††††
†† Permitted only if the veranda, porch, or deck is fully open on a minimum of two sides beneath the floor.
†*†*
†*†*
†* Recommenced to prevent recirculation of exhaust products. For additional requirements check local codes.
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
12 INCHES
9 INCHES
12 INCHES*
18 INCHES**
12 INCHES**
0 INCHES
0 INCHES***
2 INCHES***
3 FEET****
3 FEET****
9 INCHES
3 FEET†
7 FEET****
12INCHES****
16 INCHES
2 FEET†*
Clearance above grade, veranda porch, deck or balcony.
Clearance to windows or doors that open.
Clearance to permanently closed windows.
Vertical clearance to ventilated soffit located above the terminal within
a horizontal distance of 2 feet from the centerline of the terminal.
Clearance to unventilated soffit.
Clearance to an outside corner wall.
Clearance to an inside non-combustible corner wall or protruding
non-combustible obstructions (chimney, etc.).
Clearance to an inside combustible corner wall or protruding com-
bustible obstructions ( vent chase, etc.).
Clearance to each side of the centerline extended above the meter
/ regulator assembly to a maximum vertical distance of 15ft.
Clearance to a service regulator vent outlet.
Clearance to a non-mechanical air supply inlet to the building or a
combustion air inlet to any other appliance.
Clearance to a mechanical air supply inlet.
Clearance above a paved sidewalk or paved driveway located on
public property unless fitted with a heat shield kit GD-301.
Clearance under a veranda, porch, deck or balcony.
Clearance above the roof.
Clearance from an adjacent wall including neighbouring buildings.
CANADIAN U.S.A.
12 INCHES
12 INCHES
12 INCHES*
18 INCHES**
12 INCHES**
0 INCHES
0 INCHES***
2 INCHES***
3 FEET
3 FEET
12 INCHES
6 FEET
7 FEET‡
12 INCHES††
16 INCHES
2 FEET†*
INSTALLATIONS
FIGURE9

9
W415-0100/ D /01.13.04
FIGURE12
This application occurs when vent-
ing through an exterior wall.
Having determined the air termi-
nal location, cut and frame a hole
in an exterior wall with a minimum
square or round opening of 9".
(Asanalternativetoframing,avent
pipe shield may be installed, en-
suring a 1" clearance to
combustibles.)
1. Mark and cut the vent pipe
shield to the determined depth of the
combustible wall. Apply a bead of caulk-
ing (not supplied) to the framework or to the
shield plate (in the case of a finished wall) and secure the
shield through the opening to the interior wall. The final
location of the vent pipe shield should maintain the re-
quired clearance to the 7" vent pipe. Do not fill this cavity
withanytypeofmaterial. Applyabeadofcaulkingallaround
and place a firestop spacer over the vent shield to restrict
cold air from being drawn into the room or around the stove.
Ensure that both spacer and shield maintain the required
clearance to combustibles. Once the vent pipe is installed
in its final position, apply sealant between the pipe and the
firestop spacer.
This application occurs when venting through a roof. In-
stallation kits for various roof pitches are available from
your Napoleon dealer. See Accessories to order the spe-
cific kit required.
1. Determine the air ter-
minal location and
move the stove into po-
sition. Cut and frame 9
inch openings in the
ceiling and the roof to
provide the minimum 1
inch clearance between
the stove pipe and any
combustible material. Try to centre the ex-
haust pipe location
midway between two
joist to prevent hav-
ing to cut them. Use
a plumb bob to line
up the centre of the
openings.
DONOTFILLTHIS SPACEWITHANYTYPEOFMATERIAL.
A vent pipe shield will prevent any materials such as insu-
lation, from filling up the 1" air space around the pipe. Nail
headers between the joist for extra support.
2. Apply a bead of caulking (not supplied) to the frame-
work or to the Wolf Steel vent pipe shield plate or equiva-
lent (in the case of a finished ceiling), and secure over the
opening in the ceiling. A firestop must be placed on the
bottom of each framed opening in a roof or ceiling that the
venting system passes through. Apply a bead of caulking
all around and place a firestop spacer over the vent shield
to restrict cold air from being drawn into the room or around
the stove. Ensure that both spacer and shield maintain the
required clearance to combustibles. Once the vent pipe is
installed in its final position, apply sealant between the
pipe and the firestop spacer.
3. In the attic, after the pipe
has been installed, slide the
vent pipe collar down to cover
up the open end of the shield
and tighten. This will prevent
any materials, such as insu-
lation, from filling up the 1" air
space around the pipe.
OR
FIGURE11
FIGURE10
For optimum performance, it is recommended that all horizontal runs have a minimum ¼ inch rise per foot using
rigid venting.
For safe and proper operation of the stove, follow the venting instructions exactly.
INSTALLATION
WALL AND CEILING PROTECTION
HORIZONTAL INSTALLATION VERTICAL INSTALLATION
FIGURE13
FIGURE14

10
W415-0100/ D /01.13.04
6. If more than one length of liner needs to be used to
reach the fireplace, couple them together as illustrated.
Seal the joints using the same procedure as described in
points 2 and 3. The vent system must be supported every 3
feet, for both vertical and horizontal runs. Use Napoleon
support W010-0370 or equivalent noncombustible strap-
ping to maintain the 1" clearance from combustibles as
well as to prevent sagging.
1. Fasten the roof support
to the roof using the screws
provided. The roof support is
optional. The venting is to be
adequately supported using
either an alternate method
suitable to the authority hav-
ing jurisdiction or the optional
roof support.
2. Stretch the 4" diameter aluminium flexible liner to the
required length. Slip the liner a minimum of 2" over the
inner sleeve of the air terminal and secure with 3 #8 screws.
Seal using a heavy bead of the high temperature sealant.
3. Repeat using the 7" diam-
eter aluminium flexible liner.
4. Thread the air terminal pipe
assembly down through the roof.
The air terminal must be located
vertically and plumb. Attach the
air terminal assembly to the roof
support, ensuring that a
minimum 16" of air terminal will
penetrate the roof when
fastened.
DONOT CLAMPTHE FLEXIBLEALUMINIUMLINER.
5. Remove nails from the shingles, above and to the
sides of the chimney. Place the flashing over the air termi-
nal and slide it underneath the sides and upper edge of
the shingles. Ensure that the air terminal is properly cen-
tred within the flashing, giving a 3/4" margin all around.
Fasten to the roof. Do not nail through the lower portion of
the flashing. Make weather-tight by sealing with caulking.
Use only approved aluminum flexible liner kits marked:
"Wolf Steel Approved Venting" as
identified by the stamp only on the 7”
outer liner.
For safe and proper operation of the fireplace, follow
the venting instructions exactly.
* The vent system must be supported every 3 feet, for
both vertical and horizontal runs. Use Wolf Steel support
W010-0370 or equivalent non-combustible strapping to
maintain the 1" clearance from combustibles as well as to
prevent sagging.
1. Stretch the 4" diameter aluminium flexible liner to the
required length taking into account the additional length
needed for the finished wall surface. Apply a heavy bead of
the high temperature sealant, supplied with the unit, to the
inside of the 4" liner approximately 1" from the end. Slip the
liner a minimum of 2" over the fireplace vent collar and
secure with 3 #8 screws.
2. Using the 7" diameter flexible aluminium liner, apply
sealant, slide a minimum of 2 " over the fireplace combus-
tion air collar and secure with 3 #8 screws.
3. Insert the liners through the firestop. Position and
secure the fireplace using the nailing tabs (2 per side)
and/or secure to the floor using #10 hex head screws (not
supplied). The liners should be flush with the exterior wall.
The air terminal may be recessed into the exterior wall
or siding by ½", the depth of the return flange.
4. From outside, apply a bead of the high temperature
sealant to the inside of both liners, approximately 1" from
the end of each liner.
5. Holding the air terminal (lettering in an upright, read-
able position), insert into both liners with a twisting motion
to ensure that both the terminal sleeves engage into the
liners / sealant. Secure the terminal to the exterior wall and
make weather tight by sealing with caulking (not supplied).
FIGURE15
FIGURE17
FIGURE16
USING FLEXIBLE VENT COMPONENTS
HORIZONTAL AIR TERMINAL INSTALLATION
VERTICAL AIR TERMINAL INSTALLATION
FIGURE18
* All horizontal runs must have a 1 inch rise per foot.

11
W415-0100/ D /01.13.04
Where possible, cover the sides and top edges of the flash-
ing with roofing material.
6. Apply a heavy bead of
weatherproof caulking
2 inches above the flashing.
Slide the storm collar around
the air terminal and down to
the caulking. Tighten to en-
sure that a weather-tight seal
between the air terminal and
the collar is achieved.
Attach the other storm collar centred between the air intake
and the air exhaust slots onto the air terminal. Tighten
securely. Attach the vertical rain cap.
Spacers are attached to the 4" inner flex liner at prede-
termined intervals to maintain a 1-1/4" air gap to the 7"
outer liner. These spacers must not be removed.
7. If more liner needs to be used to reach the fireplace,
follow the same procedure as found in HORIZONTAL AIR
TERMINAL INSTALLATION. The vent system must be sup-
ported approximately every 3 feet for both vertical and hori-
zontal runs. Use Wolf Steel support ring assembly
W010-0370 or equivalent noncombustible strapping to
maintain the minimum 1" clearance to combustibles as
well as to prevent sagging.
Vertical installations running longer than 10 feet may dis-
play a very active flame. If this appearance is not desirable,
remove the brick baffle from the firebox, exposing the flue
gas outlet openings. Bend the restrictor plates up (from
their normal opening of 45°) into the flue openings. Re-
place the brick baffle. This reduces the velocity of the ex-
haust gases, slowing down the flame pattern and creating
a more traditional gentle appearance. Specific instructions
are shown in "Trouble Shooting".
1. Install the 4 inch diameter aluminium flexible liner to
the fireplace. Secure with 3 screws and flat washers. Seal
the joint and screw holes using the high temperature seal-
ant provided.
2. Install the 7 inch diameter aluminium flexible liner to
the fireplace. Attach and seal the joints.
FIGURE19
FIGURE20
FIGURE21
RESTRICTING VERTICAL VENTS
FIREPLACE VENT CONNECTION

12
W415-0100/ D /01.13.04
FIGURE22
The vent system must be supported approximately every 3
feet for both vertical and horizontal runs. Use Wolf Steel
vent spacers W615-0033 every 3 feet and either side of
each elbow to maintain the minimum 1¼" clearance be-
tween the outer and inner vent pipes. Use Wolf Steel sup-
port ring assembly W010-0370 or equivalent noncombus-
tible strapping to maintain the minimum 1" clearance to
combustibles for both vertical and horizontal runs.
1. Movethefireplaceinto position. Measure the vent length
required between terminal and fireplace taking into account
the additional length needed for the finished wall surface
and any 1¼" overlaps between venting components.
2. Apply high temperature sealant to the outer edge of
the 4" inner collar of the fireplace. Attach the first vent
component and secure using 3 self tapping screws. Re-
peat using 7" piping.
3. Holding the air terminal (lettering in an upright, read-
able position), insert into both vent pipes with a twisting
motion to ensure that both the terminal sleeves engage into
the vent pipes and sealant. Secure the terminal to the exte-
rior wall and make weather tight by sealing with caulking
(not supplied).
The air terminal may be recessed into the exterior
wall or siding by 1½", the depth of the return flange.
1. Attach 4" and 7" elbows to the stove. Apply high tem-
perature sealant and secure the joints with 3 screws.
2. Move the fireplace into position.
3. Fasten the roof support to the roof using the screws
provided. The roof support is optional. The venting is to be
adequately supported using either an alternate method
suitable to the authority having jurisdiction or the optional
roof support.
4. Apply high temperature sealant to the outer edge of
the inner sleeve of the air terminal. Slip a 4" diameter cou-
pler over the sleeve and secure using 3 screws.
5.Apply high temperature sealant to the outer edge of
the outside sleeve of the air terminal. Slip a 7" diameter
coupler over the sleeve and secure as before. Trim the 7"
coupler even with the 4" coupler end.
6. Thread the air terminal pipe
assembly down through the roof
support and attach, ensuring that
a minimum 16" of air terminal will
penetrate the roof when fas-
tened. If the attic space is tight,
we recommend threading the
Wolf Steel vent pipe collar or
equivalent loosely onto the air
terminal assembly as it is
passed through the attic. Theair
terminal must be located
vertically and plumb.
7. Remove nails from the shingles, above and to the
sides of the chimney. Place the flashing over the air termi-
nal and slide it underneath the sides and upper edge of
the shingles. Ensure that the air terminal is properly cen-
tred within the flashing, giving a 3/4" margin all around.
Fasten to the roof. Do NOT nail through the lower portion of
the flashing. Make weather-tight by sealing with caulking.
Where possible, cover the sides and top edges of the flash-
ing with roofing material.
8. Apply a heavy bead of waterproof caulking 2 inches
above the flashing. Slide the storm collar around the air
terminal and down to the caulking. Tighten to ensure that a
weather-tight seal between the air terminal and the collar
is achieved. Attach the other storm collar centred between
the air intake and air exhaust slots onto the air terminal.
Tighten securely. Attach the rain cap.
9. Continue adding rigid venting sections, sealing and
securing as above. Attach a 4" collapsed telescopic pipe to
the last section of rigid piping. Secure with screws and
seal. Repeat using a 7" telescopic pipe.
10. Run a bead of high temperature sealant around the
outside of the 4" elbow. Pull the adjustable pipe a mini-
mum 2" onto the elbow. Secure with 3 screws. Repeat with
the 7" telescopic pipe.
11. In the attic, slide the vent pipe collar down to cover up
the open end of the shield and tighten. This will prevent
any materials, such as insulation, from filling up the 1" air
space around the pipe.
FIGURE23
USING RIGID VENT COMPONENTS
For safe and proper operation of the fireplace, follow the venting instructions exactly.
For optimum performance, it is recommended that all horizontal runs have a minimum ¼ inch rise per foot
using rigid venting.
HORIZONTAL AIR TERMINAL INSTALLATION
VERTICAL VENTING INSTALLATION

13
W415-0100/ D /01.13.04
Combustible materials may be installed flush with the front
of the fireplace but must not cover any of the black face-
areas of the fireplace. Noncombustible material (brick,
stone or ceramic tile) may protrude in these areas.
It is not necessary to install a hearth extension with this
fireplace system.
When roughing in the fireplace, raise the fireplace to ac-
commodate for the thickness of the finished floor materi-
als, i.e. tile, carpeting, hard wood, which if not planned for
will interfere with the opening of the lower access door
and the installation of many decorative flashing accesso-
ries.
Objects placed in front of the fireplace should be kept a
minimum of 48" away from the front face.
Combustible mantle clearance
can vary according to the man-
tle depth. Use the graph to help
evaluate the clearance needed.
The U-channel may be removed if framing is faced with a
noncombustible material (cement board) (not supplied).
These same mantle clearance requirements apply to
any combustibles protruding on either side of the
fireplace.
The fireplace is equipped with two 1/4" diameter holes
located in the front left and right corners of the base. For
mobile home installations, the fireplace must be fastened
in place. Use #10 screws, inserted through the holes in
the base to secure. It is recommended that the fireplace
be secured in all installations.
In Canada, mobile home installation may be vented hori-
zontally or vertically. In the United States, it may only be
installed vertically. See "Vertical Venting" or "Horizontal Air
Terminal Installation" for installation.
Proceed once the vent installation is complete.
Move the fireplace into position and secure using the nail-
ing tabs (2 per side) and/or secure to the floor using #10
screws (not supplied).
It is best to frame your fireplace after it is positioned and the
vent system is installed. Use 2x4's and frame to local build-
ing codes. To install the fireplace face flush with the fin-
ished wall, position the framework to accommodate the
thickness of the finished wall. Pull out the four nailing tabs,
attached on either side of the fireplace and secure to the 2x4
framing to facilitate drywall installation. FIGURE24
FIGURE25
FIGURE26
INSTALLATION / FRAMING
INSTALLATION
FRAMING
Note: In order to avoid the possibility of exposed insulation
or vapour barrier coming in contact with the fireplace body, it
is recommended that the walls of the fireplace enclosure be
“finished” (ie: drywall/sheetrock), as you would finish any
other outside wall of a home. This will ensure that clearance
to combustibles is maintained within the cavity.
MOBILE HOME INSTALLATION
MANTLE CLEARANCES & ENCLOSURES
FIGURES28
FIGURE27
1" clearance to combustibles from the vent pipe
must be maintained .
=22" IFVENTING ISHORIZONTAL
=27½" IFVENTING ISVERTICAL
A

14
W415-0100/ D /01.13.04
4. Install rigid black pipe, 1/2" type-L copper tubing or, if
local codes permit, a 3/8" flex connector and shutoff valve
to the gas line and the fireplace gas valve. Seal and tighten
securely. An adapter fitting is required between the gas
valve and the copper tubing or flex connector.
Do not kDo not k
Do not kDo not k
Do not kink fink f
ink fink f
ink flele
lele
lex connectorx connector
x connectorx connector
x connector
..
..
.
Purge all gas lines with the glass door of the fireplace
open. Assure that a continuous gas flow is at the burner
before closing the door.
5. Check for gas leaks by brushing on a soap and water
solution.
Do not use open flame.
1. Route a 3/8" N.P.T. black iron gas line, 1/2" type-L
copper tubing or equivalent to the fireplace.
2. For ease of accessibility, an optional remote wall
switch or millivolt thermostat may be installed in a conven-
ient location. Route double strand solid core millivolt wire
through the electrical hole located at the bottom left side of
the unit. The recommended maximum lead length de-
pends on wire size:
WIRESIZE MAX.LENGTH
14 gauge 100 feet
16 gauge 60 feet
18 gauge 40 feet
3. Attach the two leads to terminals 1 and 3 located on
the gas valve.
Do not connect either the wall switch, thermostat or gas
valve to electricity (110 volts).
FIGURE31
FIGURE30
FIGURE29
1. Remove the two brick retainers located on either of the
firebox sides as illustrated.
2. Remove the protective plastic wrap from all four pan-
els. Centre the rear brick panel against the back of the
firebox.
3. Tilt and insert the left brick panel against the left side
of the firebox, ensuring that it butts up to the rear panel.
Excess material may be trimmed with a utility knife. Secure
in place using a retainer bracket and 2 of the screws. Re-
peat for the right side.
4. Slide the upper brick baffle into place over the side
brick panels.
When shipped, the brick panels range in colour from
white to varying shades of brown. During initial use,
the panels will darken temporarily and emit a slight
odour for a few hours. This is a normal condition that
will not occur again. Simply open a window to suffi-
ciently ventilate the room. The appearance of the pan-
els will permanently lighten in colour with use.
GAS INSTALLATION
FINISHING
BRICK PANEL INSTALLATION

15
W415-0100/ D /01.13.04
PHAZERTM logs, exclusive to Napoleon Fireplaces, pro-
vide a unique and realistic glowing effect that is different in
every installation. Use only certified PHAZERTM logs avail-
able from your Napoleon / Wolf Steel Ltd. dealer.
POSITIONING THE LOGS IMPROP-
ERLY WILL CAUSE FLAME IMPINGE-
MENT AND CARBONING.
Position the logs as shown. All logs are numbered.
The rear log should be centred on the log support.
Logs (#2) and (#3) have one leg on each underside that fits
into the rectangular cutouts on the burner securing plate.
Log (#6) has a leg that fits into an indentation on the top of
log (#3).
Logs (#5) and (#7) fit onto the indentations of the lower
logs.
FIGURE32c
FIGURE32b
FIGURE32d
LOG PLACEMENT
FIGURE32a

16
W415-0100/ D /01.13.04
(To open the door, the trim must be removed.) When
opening the fire viewing door, a simple procedure must be
followed in order to not damage the door. First open the
valvecontroldoor. Next remove the louvres
located above the door. The door is se-
cured by two latches at the top and an-
other two at the bottom. Pull the latch han-
dles towards you and release each catch. The door may
now be safely opened.
To close the door, repeat in reverse order.
To remove the door, fully open to 90°, lift up and off.
The 2 vertical trim pieces are each held on with two mag-
nets. Attach the trim to the magnets.
The louvre assemblies are installed as illustrated in figure
33. In addition, the louvre hood, located above the upper
louvres, is held in place with 4 clips. Slide the short leg of
the louvre hood into the clips, as shown.
A
C
B
L45 LOUVRE INSTALLATION
HOOD
Attach the hood by pressing
the top flange into the clips
along the top of the louvre
opening. Secure using two
screws located through the
slots.
LOWERLOUVRES
Insert the hinge clips into the
slots located at the bottom left
and right corners of the unit.
To remove the louvres, pull
the back tabs of the clips
forward, while pushing the
louvre assembly back. Lift the
clip.
UPPERLOUVRES
Insert the louvre tabs into the
slots located at the top left
and right corners of the unit.
ACLIPS
SLOT
FLANGE
SLOT
TAB
B
CHINGE
CLIP SLOT
FIGURE34a-c
GDL45 LOUVRE INSTALLATION
FIGURE33
DOOR OPENING
DOOR REMOVAL
TRIM INSTALLATION

17
W415-0100/ D /01.13.04
INSTALLATION TO BE DONE BY A QUALIFIED IN-
STALLER and must be electrically connected and grounded
in accordance with local codes. In the absence of local
codes, use the current CSA C22.1 CANADIAN ELECTRICAL CODE
inCanadaor the ANSI/NFPA70NATIONAL ELECTRICAL CODE inthe
United States.
The three slots on the
blower mounting
bracket allow ease of
adjustment when
attaching the blower.
For a quiet running
blower, do not allow the
assembly to sit on the
firebox base.
Slide the vibration reducing pad
(A) into theclip (C) and up against
the threaded stud (B) at the other
end. The blower must be able to
be positioned entirely onto the
pad.
Tilt the blower onto its
side. Slide it past the
controls and into the
clip (C). Secure to the
threaded stud using
the lock washer and
wing nut provided. En-
sure that the blower
does not touch the fire-
place base or the fire-
box.
Attach the connectors from the black and white wires to the
thermodisc and secure the thermodisc bracket to the se-
curing stud at the bottom left of the unit using a lock washer
and wing nut. Ensure that the thermodisc touches the fire-
box wall.
Attach the connectors from the black and red wires to the
blower.
Attach and secure the variable speed switch using the nut
provided. Plug the harness cord into the receptacle.
The wire harness provided in this kit is a universal
harness. When installed, ensure that any excess
wire is contained, preventing it from making con-
tact with moving or hot objects.
Because the blower is thermally activated, when
turned on, it will automatically start approximately
10 minutes after lighting the fireplace and will run
for approximately 30-45 minutes after the fireplace
has been turned off. Use of the fan increases the
output of heat.
Drywall dust will penetrate into the blower bear-
ings causing irreparable damage and must be pre-
vented from coming into contact with the blower
or its compartment. Any damage resulting from
this condition is not covered by the warranty
policy.
FIGURE40
C
B
A
FIGURE35
FIGURE36
FIGURE39
FIGURE38
FIGURE37
OPTIONAL BLOWER INSTALLATION

18
W415-0100/ D /01.13.04
ELECTRICAL INSTALLATION TO BE DONE BYA QUALI-
FIED INSTALLER and must be connected and grounded
in accordance with local codes. In the absence of local
codes, use the current CSA C22.1 CANADIAN ELECTRICAL CODE
in Canada or the ANSI/NFPA 70 NATIONAL ELECTRICAL CODE in
the United States.
To safely install the fan, turn off the electricity first.
Use of the fan increases the output of heat.
Unplug the power cord from the receptacle. Connect all
wires as shown.
Attach and secure the sensor assembly bracket to the se-
curing stud located next to the receptacle/junction box at
the bottom left of the unit using the lock washer and wing
nut. Ensure that the thermodisc touches the firebox wall.
Plug the power cord back into the receptacle.
When installed, ensure that any excess wire is contained,
preventing it from making contact with moving or hot ob-
jects.
This optional kit is meant to be used only in conjunction
with the GD65 Fan Kit, shown above, which may be or-
dered from your Wolf Steel / Napoleon dealer.
With the thermostatic sensor option, the fan, when turned
on, becomes thermally activated, and will automatically
run approximately 15-30 minutes after the fireplace has
been lit and for approximately 30-45 minutes after the fire-
place has been turned off.
If the fireplace was not previously equipped with a fan:
route a grounded 2-wire, 60hz power cable to the junction
box. At this point, it must be strain relieved and insulated.
The wire harness provided in this kit is a universal har-
ness. When installed, ensure that any excess wire is con-
tained, preventing it from making contact with moving or
hot objects.
To ease installation of the fan, remove the hinge screen
and valve control door (lower louvres) from the base of the
fireplace.
Position the vibration reducing pad into the clip and onto
the threaded stud at the other end, piercing a hole into the
pad. The fan assembly must be able to be positioned en-
tirely onto the pad.
Slide the fan assembly past the controls and into the clip.
Secure using the lock washer and nut provided.
Plug the harness cord into the receptacle.
FIGURE41
FIGURE42 FIGURE43
OPTIONAL FAN INSTALLATION
GD36 THERMOSTATIC SENSOR CONTROL

19
W415-0100/ D /01.13.04
• Turn off all gas to the fireplace.
• Open windows.
• Do not try to light any appliance.
• Do not touch any electric switch; do
not use any phone in your building.
• Immediately call your gas supplier from a neighbour's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire de-
partment.
GAS KNOB
A. This fireplace is equipped with a pilot which must be lit by
hand while following these instructions exactly.
B. Before operating smell all around the fireplace area for
gas and next to the floor because some gas is heavier
than air and will settle on the floor.
C. Use only your hand to turn the gas control knob. Never
use tools. If the knob will not turn by hand, do not try to
repair it. Call a qualified service technician. Force or at-
tempted repair may result in a fire or explosion.
D. Do not use this fireplace if any part has been under water.
Immediately call a qualified service technician to inspect
the fireplace and replace any part of the control system
and any gas control which has been under water.
WARNING: The gas valve has an interlock device which
will not allow the pilot burner to be lit until the thermocou-
ple has cooled. Allow approximately 60 seconds for the
thermocouple to cool.
Whenlightingandrelighting,the gas knob cannot be turned
from pilot to off unless the knob is depressed slightly.
1. Stop! Read the above safety information on this label.
2. Turn off all electric power to the fireplace.
3. Turn the gas knob clockwise to off.
4. Wait five (5) minutes to clear out any gas. If you smell
gas including near the floor. Stop! Follow "B" in the above
safety information on this label. If you don't smell gas go
the next step.
5. Turn gas knob counter-clockwise to pilot.
6. Depress slightly and hold gas knob while lighting the
pilot with the push button igniter. Keep knob depressed
for one minute, then release. If pilot does not continue to
burn, repeat steps 3 through 5.
7. With pilot lit, depress and turn gas knob counter-clock-
wise to on.
8. If equipped with remote on-off switch/thermostat, main
burner may not come on when you turn valve to on.
Remote switch must be in the on position to ignite burner.
9. Turn on all electric power to the fireplace.
1. Turn off all electric power to the fireplace if service is to
be performed.
2. For a complete shutdown procedure: push in gas con-
trol knob slightly and turn clockwise to off. Do not force.
3. For a temporary showdown procedure: set thermostat
to lowest setting or remote switch to off. Press and turn
the gas knob clockwise to pilot.
When lit for the first time, the fireplace will emit a slight
odour for a few hours. This is a normal temporary condi-
tion caused by the curing of the logs and the "burn-in" of
internal paints and lubricants used in the manufacturing
process and will not occur again. Simply open a window to
sufficiently ventilate the room.
After extended periods of non-operation such as following
a vacation or a warm weather season, the fireplace may
emit a slight odour for a few hours. This is caused by dust
particles in the heat exchanger burning off. Open a window
to sufficiently ventilate the room.
Purge the gas line with the glass door open. assure that
a continuous gas flow is at the burner before closing
the door. Allow several minutes (5-15) for the flame to
stabilize after ignition.
OPERATION / MAINTENANCE
OPERATING INSTRUCTIONS
FOR YOUR SAFETY READ BEFORE LIGHTING: WHAT TO DO IF YOU SMELL GAS
LIGHTING INSTRUCTIONS
TO TURN OFF GAS

20
W415-0100/ D /01.13.04
Natural gas models have air shutters set at ¼ (.250") inch
open. Propane gas models have air shutters set at 3/8
(.375) inch open. Closing the air shutter will cause a more
yellow flame, but can lead to carboning. Opening the air
shutter will cause a more blue flame, but can cause flame
lifting from the burner ports. The flame may not appear
yellow immediately; allow 15 to 30 minutes for the final
flame colour to be established.
AIRSHUTTERADJUSTMENT MUSTONLYBE DONEBYA
QUALIFIEDGASINSTALLER!
FIGURE45
FIGURE44
FIGURE46
Turn off the gas and electrical power before servicing
the fireplace.
CAUTION: Label all wires prior to disconnection when serv-
icing controls. Wiring errors can cause improper and dan-
gerous operation. Verify proper operation after servicing.
This fireplace and its venting system should be inspected
before use and at least annually by a qualified service per-
son. The fireplace area must be kept clear and free of
combustible materials, gasoline or other flammable va-
pours and liquids. The flow of combustion and ventilation
air must not be obstructed.
1. In order to properly clean the burner and pilot as-
sembly, remove the logs to expose both assemblies.
2. Keepthe control compartment,logs, burner, airshut-
teropening and the area surrounding thelogs clean by
vacuuming orbrushing, at leastonce a year.
3. Checkto see that all burner ports are burning. Clean
outany ofthe ports which may notbe burningor are not
burningproperly.
4. Check to see that the pilot flame is large enough to
engulf the thermocouple and thermopile and reaches
toward the burner with the third jet.
5. Replace the cleaned logs.
6. Checkto seethat themain burner ignites completely
on all openings when the gas knob for the burner is
turned on.A5 to 10 second total light-up period is sat-
isfactory. If ignitiontakeslonger, consult your Napoleon
dealer/ distributor.
7. Checkthat the gasketing on thedoor is notbroken or
missing. Replace if necessary.
Adjust the pilot screw to provide properly sized flame. Turn
in a clockwise direction to reduce the gas flow.
MAINTENANCE
ADJUSTMENTS
PILOT BURNER ADJUSTMENT VENTURI ADJUSTMENT
