Napoleon GI3014-N User manual

WS-415-44/11.06.98
GAS INSERTGAS INSERT
GAS INSERTGAS INSERT
GAS INSERT
INSTINST
INSTINST
INSTALLAALLA
ALLAALLA
ALLATION AND OPERATION AND OPERA
TION AND OPERATION AND OPERA
TION AND OPERATION INSTRUCTIONS FORTION INSTRUCTIONS FOR
TION INSTRUCTIONS FORTION INSTRUCTIONS FOR
TION INSTRUCTIONS FOR
GAS-FIREDGAS-FIRED
GAS-FIREDGAS-FIRED
GAS-FIRED VENTED ROOM HEAVENTED ROOM HEA
VENTED ROOM HEAVENTED ROOM HEA
VENTED ROOM HEATERTER
TERTER
TER
NATURAL GAS MODEL
GI3014-N / GI3014B-NGI3014-N / GI3014B-N
GI3014-N / GI3014B-NGI3014-N / GI3014B-N
GI3014-N / GI3014B-N
PROPANE GAS MODEL
GI3014-P / GI3014B-PGI3014-P / GI3014B-P
GI3014-P / GI3014B-PGI3014-P / GI3014B-P
GI3014-P / GI3014B-P
GAS-ZEROCLEARANCEWHENINSTALLEDWITHGI-700KIT
WITHOUTGI-700KITINSTALLRECESSEDINTOAWOODBURNINGNON-COMBUSTIBLEFIREPLACE
CERTIFICATION LABEL AFFIXED TO UNDERSIDE OF FRESH AIR DAMPER
INSTINST
INSTINST
INSTALLER: THESE INSTRUCTIONS MUST BE CONVEYED TO AND REMAIN WITH THE HOMEOWNER.ALLER: THESE INSTRUCTIONS MUST BE CONVEYED TO AND REMAIN WITH THE HOMEOWNER.
ALLER: THESE INSTRUCTIONS MUST BE CONVEYED TO AND REMAIN WITH THE HOMEOWNER.ALLER: THESE INSTRUCTIONS MUST BE CONVEYED TO AND REMAIN WITH THE HOMEOWNER.
ALLER: THESE INSTRUCTIONS MUST BE CONVEYED TO AND REMAIN WITH THE HOMEOWNER.
CERTIFIED UNDER CANADIAN AND AMERICAN NATIONAL STANDARDS, CSA 2.33 AND ANSI Z21.88 RESPECTIVELY FOR VENTED GAS FIREPLACE HEATERS
Fax: [phone] EMAIL: [email protected]
WEB: www.napoleon.on.ca
Wolf Steel Ltd., RR#1, 9 Napoleon Rd.,
Barrie, On., Canada L4M 4Y8 [phone]
R-2000
WW
WW
WARNING:ARNING:
ARNING:ARNING:
ARNING: If the information in these instructions is not followed exactly, a fire or
explosion may result causing property damage, personal injury or death.
FOR YOUR SAFETYFOR YOUR SAFETY
FOR YOUR SAFETYFOR YOUR SAFETY
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapours and liquids in the vicinity of
this or any other appliance.
WHAWHA
WHAWHA
WHATT
TT
TTT
TT
TO DO IF YOU SMELLO DO IF YOU SMELL
O DO IF YOU SMELLO DO IF YOU SMELL
O DO IF YOU SMELL GAS:GAS:
GAS:GAS:
GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use any phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas suppli-
er's instructions.
• Ifyoucannotreachyourgassupplier,call
thefiredepartment.
Installation and service must be performed by a qualified installer, service agency
or the gas supplier.

2
WS-415-44/11.17.99
NAPOLEON gas fireplaces are manufactured under the strict Standard of the world recognized
ISO9002 Quality Assurance Certificate.
NAPOLEON products are designed with superior components and materials, assembled by trained craftsmen
who take great pride in their work. The burner and valve assembly are leak and test-fired at a quality test
station. Once assembled the complete fireplace is thoroughly inspected by a qualified technician before packaging
to ensure that you, the customer, receives the quality product that you expect from NAPOLEON.
NAPOLEON GAS FIREPLACE PRESIDENT'S LIFETIME LIMITED WARRANTY
The following materials and workmanship in your newThe following materials and workmanship in your new
The following materials and workmanship in your newThe following materials and workmanship in your new
The following materials and workmanship in your new NAPOLEONNAPOLEON
NAPOLEONNAPOLEON
NAPOLEON gas fireplace aregas fireplace are
gas fireplace aregas fireplace are
gas fireplace are
warranted against defects for as long as you own the fireplace. This covers: combustionwarranted against defects for as long as you own the fireplace. This covers: combustion
warranted against defects for as long as you own the fireplace. This covers: combustionwarranted against defects for as long as you own the fireplace. This covers: combustion
warranted against defects for as long as you own the fireplace. This covers: combustion
chamber, heat exchanger, stainless steel burner, phazer™ logs and embers, ceramic glasschamber, heat exchanger, stainless steel burner, phazer™ logs and embers, ceramic glass
chamber, heat exchanger, stainless steel burner, phazer™ logs and embers, ceramic glasschamber, heat exchanger, stainless steel burner, phazer™ logs and embers, ceramic glass
chamber, heat exchanger, stainless steel burner, phazer™ logs and embers, ceramic glass
(thermal breakage only), gold plated parts against tarnishing, porcelainized enamelled com-(thermal breakage only), gold plated parts against tarnishing, porcelainized enamelled com-
(thermal breakage only), gold plated parts against tarnishing, porcelainized enamelled com-(thermal breakage only), gold plated parts against tarnishing, porcelainized enamelled com-
(thermal breakage only), gold plated parts against tarnishing, porcelainized enamelled com-
ponents and aluminum extrusion trims.ponents and aluminum extrusion trims.
ponents and aluminum extrusion trims.ponents and aluminum extrusion trims.
ponents and aluminum extrusion trims.
Electrical (110V and millivolt) components and wearable parts such as blowers, gas valves,Electrical (110V and millivolt) components and wearable parts such as blowers, gas valves,
Electrical (110V and millivolt) components and wearable parts such as blowers, gas valves,Electrical (110V and millivolt) components and wearable parts such as blowers, gas valves,
Electrical (110V and millivolt) components and wearable parts such as blowers, gas valves,
thermal switch, switches, wiring, remote controls, ignitor, gasketing, and pilot assembly arethermal switch, switches, wiring, remote controls, ignitor, gasketing, and pilot assembly are
thermal switch, switches, wiring, remote controls, ignitor, gasketing, and pilot assembly arethermal switch, switches, wiring, remote controls, ignitor, gasketing, and pilot assembly are
thermal switch, switches, wiring, remote controls, ignitor, gasketing, and pilot assembly are
covered andcovered and
covered andcovered and
covered and NAPOLEONNAPOLEON
NAPOLEONNAPOLEON
NAPOLEON will provide replacement parts free of charge during the first yearwill provide replacement parts free of charge during the first year
will provide replacement parts free of charge during the first yearwill provide replacement parts free of charge during the first year
will provide replacement parts free of charge during the first year
of the limited warranty.of the limited warranty.
of the limited warranty.of the limited warranty.
of the limited warranty.
Labour related to warranty repair is covered free of charge during the first year. RepairLabour related to warranty repair is covered free of charge during the first year. Repair
Labour related to warranty repair is covered free of charge during the first year. RepairLabour related to warranty repair is covered free of charge during the first year. Repair
Labour related to warranty repair is covered free of charge during the first year. Repair
work, however, requires the prior approval of an authorized company official. Labour costswork, however, requires the prior approval of an authorized company official. Labour costs
work, however, requires the prior approval of an authorized company official. Labour costswork, however, requires the prior approval of an authorized company official. Labour costs
work, however, requires the prior approval of an authorized company official. Labour costs
to the account ofto the account of
to the account ofto the account of
to the account of NAPOLEONNAPOLEON
NAPOLEONNAPOLEON
NAPOLEON are based on a predetermined rate schedule and any repairare based on a predetermined rate schedule and any repair
are based on a predetermined rate schedule and any repairare based on a predetermined rate schedule and any repair
are based on a predetermined rate schedule and any repair
work must be done through an authorizedwork must be done through an authorized
work must be done through an authorizedwork must be done through an authorized
work must be done through an authorized NAPOLEONNAPOLEON
NAPOLEONNAPOLEON
NAPOLEON dealer.dealer.
dealer.dealer.
dealer.
CONDITIONS AND LIMITATIONS
NAPOLEONwarrantsitsproductsagainstmanufacturingdefectstotheoriginalpurchaseronly--i.e.,theindividualorlegalentity (registered customer) whose nameappearsonthe
warrantyregistrationcard filed with NAPOLEON--providedthat the purchasewasmadethrough an authorizedNAPOLEONdealerandis subject tothefollowingconditions and limitations:
Thisfactorywarrantyisnontransferableandmaynotbeextendedwhatsoeverbyanyofourrepresentatives.
Thegasfireplacemustbe installed by a licenced, authorizedservicetechnicianorcontractor.Installationmust be done in accordance withtheinstallationinstructionsincludedwith the
productandalllocalandnationalbuildingandfirecodes.
Thislimitedwarrantydoesnotcoverdamagescausedbymisuse,lackofmaintenance,accident,alterations, abuse or neglect and parts installed from other manufacturers will nullify
this warranty.
Thislimitedwarrantyfurther does not coveranyscratches,dents, corrosion or discolouringcausedbyexcessiveheat, abrasive and chemicalcleanersnorchippingon porcelain enamel
parts,mechanicalbreakageofPHAZER™logsandembers,noranyventingcomponentsusedintheinstallationofthefireplace.
NAPOLEONwarrantsitsstainlesssteel burners againstdefectsinworkmanship and materialforlife,subjectto the followingconditions:Duringthefirst 10 yearsNAPOLEONwillreplace
or repair the defective parts at our option free of charge. From 10 years to life, NAPOLEON will provide replacement burners at 50% of the current retail price.
Inthefirstyearonly,thiswarrantyextendsto the repair or replacement of warranted parts whicharedefectiveinmaterialorworkmanshipprovidedthattheproduct has been operated
inaccordancewiththeoperationinstructionsandundernormalconditions.
Afterthefirstyear,withrespecttothisPresident'sLimited Lifetime Warranty,NAPOLEONmay,atitsdiscretion,fullydischargeall obligations with respect to this warranty byrefunding
totheoriginalwarranted purchaser the wholesale price of any warranted but defective part(s).
Afterthefirstyear,NAPOLEONwillnotbe responsible for installation, labour oranyothercostsorexpensesrelated to the reinstallation of awarrantedpart,andsuchexpensesare not
coveredbythis warranty.
Notwithstandinganyprovisionscontained in this President's LimitedLifetimeWarranty,NAPOLEON’Sresponsibilityunderthis warranty is defined asaboveanditshall not in any event
extendtoanyincidental,consequentialor indirect damages.
Thiswarrantydefinesthe obligations andliabilityofNAPOLEON with respecttotheNAPOLEON gas fireplace andanyotherwarrantiesexpressed orimpliedwithrespect to this product,
itscomponentsoraccessories are excluded.
NAPOLEONneitherassumes,nor authorizes any third party to assume, on its behalf, any other liabilities with respect to the sale of this product. NAPOLEON will not be responsible
for:over-firing, downdrafts, spillage caused by environmental conditions such as rooftops, buildings, nearby trees, hills, mountains, inadequateventsorventilation,excessiveventing
configurations,insufficient makeup air, or negative air pressures which may or may notbecausedbymechanicalsystemssuch as exhaust fans, furnaces, clothes dryers, etc.
Anydamagestofireplace,combustionchamber,heatexchanger,brasstrim or other component due to water, weather damage, long periods of dampness, condensation, damaging
chemicals or cleaners will not be the responsibility of NAPOLEON.
The bill of sale or copy will be required together with a serial number and a model number when making any warranty claims from your authorized dealer. The warranty registration
cardmustbe returned within fourteen days to register the warranty.
NAPOLEONreserves the right to have its representative inspect any product or part thereof prior to honouring any warranty claim.
ALLSPECIFICATIONSANDDESIGNSARESUBJECTTOCHANGE WITHOUT PRIOR NOTICE DUE TO ON-GOING PRODUCT IMPROVEMENTS. NAPOLEON® IS A REGISTERED
TRADEMARKOFWOLF STEELLTD. PATENTSU.S.5.303.693.801 -CAN.2.073.411,2.082.915.©WOLF STEELLTD.

3
WS-415-44/11.17.99
PG 8-9 OPERATION / MAINTENANCE
Fresh Air Damper System
Operating Instructions
Maintenance
10 BLOWER INSTALLATION
Blower Replacement Instructions
10 ADJUSTMENTS
Pilot Burner Adjustment
Venturi Adjustments
10-12REPLACEMENTS
Ordering Replacement Parts
Replacement Parts
Accessories
13-14TROUBLE SHOOTING GUIDE
PG 2-4 INTRODUCTION
Warranty
General Instructions
Mantle Clearance
General Information
Care of Glass, Enamelled & Plated Parts
5-6 INSTALLATION
Spill Switch
Venting Action Check
Installation
Flashing Installation
Framing
6 BRICK PANEL INSTALLATION
7-8 FINISHING
Log Placement/Charcoal Embers
Door, & Louvre Installation
PLEASE RETPLEASE RET
PLEASE RETPLEASE RET
PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCEAIN THIS MANUAL FOR FUTURE REFERENCE
AIN THIS MANUAL FOR FUTURE REFERENCEAIN THIS MANUAL FOR FUTURE REFERENCE
AIN THIS MANUAL FOR FUTURE REFERENCE
TABLE of CONTENTS
WARNINGWARNING
WARNINGWARNING
WARNING
• Itisimperativethatthecontrolcompartments,
burnersandcirculatingbloweranditspassageway
inthefireplaceandventingsystemarekeptclean.
Thefireplaceanditsventingsystemshouldbein-
spectedbeforeuseandatleastannuallybyaquali-
fiedserviceperson.Morefrequentcleaningmay
berequiredduetoexcessivelintfromcarpeting,
beddingmaterial,etc.Thefireplaceareamustbe
keptclearandfreefromcombustiblematerials,
gasolineandotherflammablevapoursandliquids.
• Donotusethisfireplaceifanyparthasbeenunder
water.Immediatelycallaqualifiedservicetechni-
ciantoinspectthefireplaceandtoreplaceanypart
ofthecontrolsystemandanygascontrolwhich
hasbeenunderwater.
• Undernocircumstancesshouldthisfireplacebe
modified.
• Donotburnwoodorothermaterialsinthisfire-
place.
• Adultsandespeciallychildrenshouldbealertedto
thehazardsofhighsurfacetemperaturesandshould
stayawaytoavoidburnsorclothingignition.Su-
perviseyoungchildrenwhentheyareinthesame
roomasthefireplace.
• Clothingorotherflammablematerialshouldnotbe
placedonornearthefireplace.
• Anysafetyscreenorguardremovedforservicing
mustbereplacedpriortooperatingthefireplace.
• Thisfireplacemustnotbeconnectedtoachimney
fluepipeservingaseparatesolidfuelburningappli-
ance.
• Donotoperatethefireplacewiththeglassdoor
removed,crackedorbroken.Replacementofthe
glassshouldbedonebyalicensedorqualifiedserv-
iceperson.
• Donotstrikeorslamshutthefireplaceglassdoor.
• Duetohightemperatures,thefireplaceshouldbe
locatedoutoftrafficandawayfromfurnitureand
draperies.

4
WS-415-44/11.17.99
Provide adequate ventilation and combustion air. Pro-
videadequateaccessibility clearanceforservicingand
operating the fireplace. Never obstruct the front open-
ing of the fireplace.
MANTLE CLEARANCE
Mantleclearance,while
conforming to the
stated clearance to
combustible materials,
can vary according to
the mantle depth.
These clearances do
notapplyto a GI-700kit
type installation.
GENERAL INFORMATION
FORYOURSATISFACTION, THISFIREPLACE HAS BEEN
TEST-FIRED TO ASSURE ITS OPERATION AND QUAL-
ITY! Maximum input is 30,000 BTU/hr for natural gas and
24,000 BTU/hr for propane. When the fireplace is installed
at elevations above 4,500ft, and in the absense of specific
recommendations from the local authority having jurisdic-
tion, the certified high altitude input rating shall be reduced
at the rate of 4% for each additional 1,000ft. Maximum out-
put for natural gas is 22,800 BTU/hr at an efficiency of 76%
with the fan on, 72% with the fan off; and 18,240 BTU/hr for
propane at an efficiency of 76% with the fan on, 71% with
the fan off. Minimum A.F.U.E.(Annual Fuel Utilization Effi-
ciency) rating is 64% for both natural and propane gas.
Where the fireplace has been factory equipped for hi-alti-
tude, the input has been downrated by 10%. This fireplace
is certified for bedroom and bed-sitting room installation.
Minimum inlet gas supply pressure is 4.5 inches water
column for natural gas and 11 inches water column for
propane. Maximum inlet gas pressure is 7 inches water
column for natural gas and 13 inches water column for
propane. Manifold pressure under flow conditions is 3.5
inches water column for natural gas and 10 inches water
column for propane.
Noexternal electricity (110voltsor 24volts)is required
for the gas system operation.
Change in flame appearance from "HI" to "LO" is more
evident in natural gas than in propane. The self generating
pilot provides current for a remote burner On-Off switch.
CARE OF GLASS, ENAMELLED AND
PLATED PARTS
Do not use abrasive cleaners to clean these parts. Buff
lightly with a clean dry cloth. Porcelain enamelled compo-
nents must be handled with care. The baked-on finish is
glass-like. If struck, it will chip! Touch-up paint is available
through your Napoleon dealer.
The glass is 3/16" ceramic glass available from your Na-
poleon / Wolf Steel Ltd. dealer. DO NOT SUBSTITUTE MA-
TERIALS. Clean the glass after the first 10 hours of opera-
tion with a recommended gas fireplace glass cleaner.
Thereafter clean as required. DO NOT CLEAN GLASS
WHEN HOT! If the glass is not kept clean permanent
discolouration and / or blemishes may result.
GENERAL INSTRUCTIONS
THIS GAS FIREPLACE SHOULD BE INSTALLED AND
SERVICED BY A QUALIFIED INSTALLER to conform with
local codes. In absence of local codes, install to the cur-
rent CAN1-B149 Installation Code in Canada or to the Na-
tional Fuel Gas Code, ANSI Z223.1-1988, and NFPA 54-
1988 in the United States.
Purge all gas lines with the glass door of the fireplace
removed. Assure that a continuous gas flow is at the
burnerbefore installingthe door.
Underextremeventconfigurations,allowseveralminutes
(5-15) for the flame to stabilize after ignition. Altitudes
greaterthan 4,000ftrequire aminimum ventrun of12 ft.
The heater and its individual shutoff valve must be discon-
nected from the gas supply piping system during any pressure
testing of that system at test pressures in excess of ½ psig (3.5
kPa). The fireplace must be isolated from the gas supply pip-
ing system by closing its individual manual shutoff valve during
any pressure testing of the gas supply piping system at test
pressures equal to or less than ½ psig (3.5 kPa).
A 1/8 inch NPT plug, accessible for test gauge connection,
must be installed immediately upstream of the gas supply
connection to the fireplace.
Thisfireplace mustbeconnected toany acceptedlined chim-
ney system listed to ULC-S635M (in Canada) or UL-1777
(in USA). The venting connection must be in compliance
with the chimney manufacturers installation instructions.
The draft hood must be installed so that it is in the same
atmospheric pressure zone as the combustion air inlet to
the fireplace.
This heater can be installed two different ways. If installed
as is, it must be recessed into a vented non-combustible
woodburning fireplace (prefabricated or masonry) only. This
is referred to as an INSERT type of installation.
The minimum fireplace size in which the heater is to be
installed is:
HEIGHT 21 inches
WIDTH 26-1/2 inches
DEPTH 17-1/2 inches
If installed in conjunction with kit #GI-700, it may be framed
into an enclosure made of combustible materials. This is
referred to as a ZERO CLEARANCE type of installation.
The minimum clearance to combustible construction in
this form of installation is:
MANTLEHEIGHT 7 inches*
SIDES,BACK, BOTTOM&TOP 0 inches
B-VENT 1 inch
RECESSEDDEPTH 18-1/2 inches
*MAXIMUM HORIZONTAL EXTENSION IS 6INCHES.
Objects placed in front of the fireplace must be kept a
minimum of 48" away from the front face.
The fireplace, when installed, must be electrically con-
nected and grounded in accordance with local codes. In
the absence of local codes, use the current CSA C22.1
CANADIAN ELECTRICAL CODE in Canada or the ANSI/
NFPA70-1996 NATIONAL ELECTRICALCODE intheUnited
States. The blower power cord must be connected into a
properly grounded receptacle. The grounding prong must
not be removed from the cord plug.

5
WS-415-44/11.17.99
Leveling the insert will eliminate rocking or excessive noise
when the fan is in operation. Replace the securing screw
to the front of the dilution plate.
Install rigid black pipe, a flex connector, if local codes per-
mit, or 1/2" type L, copper tubing with a 3/8" to 1/2" adapter
and a shut off valve to the fireplace. Seal and tighten se-
curely. The adapter will be required between the gas valve
and the copper tubing or flex connector.
Do not damage or kink flex connector!
Check for gas leaks by brushing on a soap and water
solution.
Do not use open flame!
An on/off switch has been included and can be located at
the lower right, behind the louvre access door or at the
right side trim.
For ease of accessibility, this switch may be replaced with
a wall switch or substituted with a millivolt thermostat that
may be installed in a convenient location on any wall. Route
a 2-strand solid core millivolt wire through the electrical
hole located at the bottom right side of the unit. The recom-
mended maximum lead length depends on wire size:
WIRESIZE MAX.LENGTH
14gauge 100 feet
16gauge 60 feet
18gauge 40 feet
Attach the two leads to terminals 1 and 3 located on the
gas valve.
Donot connect eitherthewall switch orthegas valve to
electricity (110 volts or 24 volts).
INSTALLATION
Clean out the ashes from the inside of the woodburning
fireplace. Make sure that the chimney and woodburning
fireplace are in clean and sound condition. Do not remove
bricks or mortar from the masonry fireplace. If necessary
have any repair work done by a qualified person before
installing the insert. Remove the existing fireplace damper
or lock into an open position. Line the chimney with a 4 inch
diameter approved liner. Pack insulation around the liner
in the damper area to prevent air flow from entering the
chimney. Chimney installation must conform to both na-
tional and local code requirements. The liner must be con-
tinuous from the fireplace to the chimney cap.
Remove the securing screw from the front of the dilution
plate.Push the dilution hood out of its securing clip and
attach the liner using 3 screws equally spaced. Move the
insert into the centre of the woodburning fireplace making
sure that the dilution draft hood inserts back into its secur-
ing clip. Level using the four leveling screws located front
and back on either side of the fireplace base.
INSTINST
INSTINST
INSTALLAALLA
ALLAALLA
ALLATIONTION
TIONTION
TION
FIGURE2
FIGURE3
FIGURE4
FIGURE5

6
WS-415-44/11.17.99
FIGURE8
FIGURE6
FIGURE7
SPILL SWITCH
This is a thermally activated switch, attached to the back of
the unit and extending up into the dilution draft hood, which
senses the change in temperature and shuts down the
gas valve in the event of a severe downdraft of air or a
blocked or disconnected vent. It acts as a safety shut-off to
prevent a build up of carbon monoxide or an explosion of
unburnt gases during start up. If the flue is blocked or has
no "draw", the spill switch will automatically shut off the
supply of gas within about 5-10 minutes.
TAMPERING WITH THE SWITCH CAN RESULT IN
CARBON MONOXIDE (CO) POISONING AND POS-
SIBLE DEATH.
FLASHING INSTALLATION
The insert can be equipped with a flashing kit to close off
most fireplace openings. The flashing and trim are avail-
able in many finishes to accent any room decor.
GI3014: Mount the flashing inside the unit's outer shell
using 4 securing screws.
GI3014B: To install the flashing, the short louvre brackets
located at either side of the base must first be removed.
FIGURE9.
VENTING ACTION CHECK:
A check for correct venting
action must be made before the installed insert is left
withthe customer.
Test after installing the unit into either the GI-700 ZERO
CLEARANCE KIT or a vented non-combustible fireplace
in the following manner:
1. Close all doors and windows in the room / start exhaust
fans in the home / turn fireplace blower off.
2. Set controls to "high" and light the unit.
3. Wait 5 minutes. Light a match and hold it to the spill tube
opening.
4. Venting action is satisfactory if smoke is drawn into the
spill tube. Venting action is unsatisfactory if the flame and
smoke are not drawn into the tube.
5. If venting action is unsatisfactory, turn the unit off, wait
10 minutes and try again. If the smoke or flame is still not
drawn into the spill tube, turn the unit off and check for
adequate fresh air supply, vent blockage or restriction. If
necessary, consult with a qualified inspector.
GI-3014B BRICK PGI-3014B BRICK P
GI-3014B BRICK PGI-3014B BRICK P
GI-3014B BRICK PANEL INSTANEL INST
ANEL INSTANEL INST
ANEL INSTALLAALLA
ALLAALLA
ALLATIONTION
TIONTION
TION
Remove the securing screws located on either of the fire-
box sides as illustrated. Remove protective plastic wrap
from all four panels. Center the rear brick panel against
the back of the firebox. Place the left brick panel against the
left side of the firebox, ensuring that it butts up to the rear
panel. Excess material may be trimmed with a utility knife.
Secure in place using a retainer bracket and 2 of the
screws. Repeat for the right side. Place the front brick
panel into the hearth area at the front.
When shipped, the brick panels range in colour from
white to varying shades of brown. During initial use, the
panels will darken temporarily and emit a slight odour
for a few hours. This is a normal condition that will not
occur again. Simply open a window to sufficiently venti-
late the room. The appearance of the panels will perma-
nently lighten in colour with use.

7
WS-415-44/11.17.99
SKEWERING
SCREW
FIGURE9
FIGURE10
FINISHINGFINISHING
FINISHINGFINISHING
FINISHING
POSITIONINGTHE LOGS IMPROPERLYWILL CAUSE
FLAMEIMPINGEMENTANDCARBONING.
LOG PLACEMENT INSTRUCTIONS /
CHARCOAL EMBERS
PHAZERTM logs and charcoal embers, exclusive to Napo-
leon Fireplaces, provide a unique and realistic glowing
effect that is different in every installation. Take the time to
carefully position the charcoal embers for a maximum glow-
ing effect.
CHARCOAL EMBERS: Randomly place the embers be-
neath the front log, covering all of the burner area beneath
the hollowed out section of the log. Place the remaining
embers along the front. Keep ember dust away from burner
ports to avoid plugging them.
Fine dust found in bottom of bag not to be used.
PHAZERTM logs and charcoal embers glow when exposed
to direct flame. Use only certified PHAZERTM logs and char-
coal embers available from your Napoleon / Wolf Steel Ltd.
dealer.
1. Place the front log onto the main burner, pushing it
as close as possible to the burner ports without
blocking/covering them. The left and right spacing between
the log ends and the burner ports should be equal.
YOUMAYFINDITEASIER TOPLACESOME CHARCOAL
EMBERSBENEATHTHEFRONTLOGNOW.
2. Place the back log onto the log support brackets
located on the rear wall of the combustion chamber. The
notch situated at the lower left of the back log should be
centered evenly above the pilot assembly.
3. While supporting the back log, to prevent it from
falling forward, set the three smaller logs into the pockets
and grooves of the front and back logs, respectively.
Log colours may vary. During the initial use of the fire-
place, the colours will become more uniform as colour
pigmentsburn in duringtheheat activatedcuringproc-
ess.

8
WS-415-44/11.17.99
FIGURE13
FIGURES11 FIGURE12
GI-3014B: In order to access the interior of the firebox,
remove the two screws located below the upper louvre
assembly and the two screws located to either side be-
tween the first and second lower side louvre. Lift out the
bay frame assembly. Install the louvres and louvre as-
semblies as illustrated. Attach the decorative (magnetic)
upper glass bracket.
DOOR & LOUVRE INSTALLATION
GI-3014: In order to access the interior of the firebox, re-
move two screws holding the upper glass bracket cover,
and the upper glass bracket in place and the two screws
holding the lower glass bracket. The louvre assemblies
are installed as illustrated. The upper glass bracket cover
is formed with tabs to create a gap for air flow and must not
be adjusted.
UPPER LOUVRES - 3 PC SET
A
B
C
FIGUREA FIGUREB
FIGURESC
OPERAOPERA
OPERAOPERA
OPERATION / MAINTENANCETION / MAINTENANCE
TION / MAINTENANCETION / MAINTENANCE
TION / MAINTENANCE
FRESH AIR DAMPER SYSTEM
If your masonry fireplace is equipped with a fresh air inlet
in the floor of the firebrick chamber, the insert is able to
take outside air directly into the unit through an opening in
its base thereby eliminating the need to use preheated
room air for combustion. The flow of air may be adjusted
through the use of a damper located below the louvre ac-
cess door. The damper should be kept closed (pushed all
the way in) when the unit is not in operation or if no outside
air is available. The damper is fully open when pulled for-
ward (one inch from the closed position).
Never obstruct the flow of combustion or
ventilationair.

9
WS-415-44/11.17.99
Simply open a window to sufficiently ventilate the room.
After extended periods of non-operation such as following
a vacation or a warm weather season, the fireplace may
emit a slight odour for a few hours. This is caused by dust
particles in the heat exchanger burning off. Open a window
to sufficiently ventilate the room.
OPERATING INSTRUCTIONS
When lit for the first time, the stove will emit a slight odour
for a few hours. This is a normal temporary condition
caused by the curing of the logs and the "burn-in" of inter-
nal paints and lubricants used in the manufacturing proc-
ess and will not occur again.
Call a qualified service technician. Force or attempted
repair may result in a fire or explosion.
DDo not use this insert if any part has been under water.
Immediately call a qualified service technician to inspect
the unit and replace any part of the control system and
any gas control touched by water.
FORYOURSAFETYREADBEFOREOPERATING
AThis stove has a pilot which must be lit by hand while
following these instructions exactly.
BBefore lighting, smell all around the firplace area for
gas and next to the floor because some gas is heavier
than air and will settle on the floor.
CUse only your hand to push in or turn the gas control
knob. Never use tools. If the knob will not push in or turn
by hand, do not try to repair it.
• Immediately call your gas supplier from a neighbour's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire de-
partment.
WHATTODO IFYOUSMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone
in your building.
8.Depress and hold the gas knob while lighting the pilot
with the push button ignitor. Keep the knob fully de-
pressed for one (1) minute, then release. If the pilot does
not continue to burn, repeat steps 3 through 7.
9.With the pilot lit, turn the gas knob counter-clock-
wise to "on" position.
10.If your insert is equipped with a flame adjustment
valve, push and turn the knob to "high".
11.If your insert is equipped with a remote "on-off" switch,
the main burner may not come on when you turn the gas
valve to "on" or "high". The remote switch must be in the
"on" position as well to ignite the main burner.
12.Turn on all electrical power to the insert.
LIGHTINGINSTRUCTIONS:
1.Stop! Readallthe safetyinformationabove. Whenlight-
ing and re-lighting, the gas knob cannot be turned from
"pilot" to "off" unless the knob is depressed.
2.Turn off all electrical power to the stove.
3.Turn the gas knob clockwise to off.
4.Wait 5 minutes for any gas in the combustion chamber
to escape. Continue to the next step if you do NOT smell
any gas. If you smell gas, STOP! and follow the instruc-
tions in "What to do if You Smell Gas" listed above.
5.If the unit is equipped with a flame adjustment valve,
turn clockwise to off.
6.Locate the pilot situated in front of the rear log.
7.Turn the gas knob counter-clockwise to "pi-
lot" position.
2.Push in gas control knob slightly and turn clock-
wise to off. Do not force.
INSTRUCTIONSTOTURNOFFGAS:
1.Turn off all electrical power to the unit if service is
to be performed.
3. Check to see that all burner ports are burning. Clean out
any of the ports which may not be burning or are not burn-
ing properly. (right brick panel must be removed in order to
facilitate burner removal)
4. Check to see that the pilot flame is large enough to
engulf the thermopile on one leg and reaches toward the
burner on the other leg.
5. Replace the cleaned logs.
6. Check to see that the main burner ignites completely on
all openings when the gas knob for the burner is turned
on. A 5 to 10 second total light-up period is satisfactory. If
ignition takes longer, consult your Napoleon dealer / dis-
tributor.
7. Check that the gasketing on the door is not broken or
missing. Replace if necessary.
MAINTENANCE SEE FIGURE 18 TURNTURN
TURNTURN
TURN
OFF THE GAS AND ELECTRICAL POWEROFF THE GAS AND ELECTRICAL POWER
OFF THE GAS AND ELECTRICAL POWEROFF THE GAS AND ELECTRICAL POWER
OFF THE GAS AND ELECTRICAL POWER
BEFORE SERVICING THE FIREPLACE.BEFORE SERVICING THE FIREPLACE.
BEFORE SERVICING THE FIREPLACE.BEFORE SERVICING THE FIREPLACE.
BEFORE SERVICING THE FIREPLACE.
CAUTION: Label all wires prior to disconnection when serv-
icing controls. Wiring errors can cause improper and dan-
gerous operation. Verify proper operation after servicing.
This insert and its venting system should be inspected
before use and at least annually by a qualified service per-
son. The fireplace area must be kept clear and free of
combustible materials, gasoline or other flammable va-
pours and liquids. The flow of combustion and ventilation
air must not be obstructed.
1. In order to properly clean the burner and pilot assembly,
remove the logs to expose both assemblies.
2. Keep the control compartment, logs, burner, air shutter
opening and the area surrounding the logs clean by vacu-
uming or brushing, at least once a year.
THERMOPILE
ELECTRODE
PILOT BURNER
GAS VALVE

10
WS-415-44/11.17.99
FIGURE15 FIGURE17
FIGURE16
FIGURE14
BLOWER SYSTEM
The Napoleon gas fireplace insert comes standard with a
blower, a heat sensor, variable on/off speed control and a
power cord. Because the blower is thermally activated,
when turned on, it will automatically start approximately 15
minutes after lighting the fireplace and will run for approxi-
mately 30 minutes after the fireplace has been turned off.
Use of the fan increases the output of heat. Air, drawn in
through the lower louvre access door, is driven up the back
of the firebox, and exhausted as hot air between the upper
louvres.
REPLACEMENT BLOWER INSTREPLACEMENT BLOWER INST
REPLACEMENT BLOWER INSTREPLACEMENT BLOWER INST
REPLACEMENT BLOWER INSTALLAALLA
ALLAALLA
ALLATIONTION
TIONTION
TION
ADJUSTMENTSADJUSTMENTS
ADJUSTMENTSADJUSTMENTS
ADJUSTMENTS
BLOWER REPLACEMENT IN-BLOWER REPLACEMENT IN-
BLOWER REPLACEMENT IN-BLOWER REPLACEMENT IN-
BLOWER REPLACEMENT IN-
STRUCTIONS (STRUCTIONS (
STRUCTIONS (STRUCTIONS (
STRUCTIONS (FIGURE 14 & 18):):
):):
):
• Turn off the gas and electric power to the unit.
• Remove the glass door.
• Remove the lower glass bracket.
• Remove the logs.
• Remove the burner assembly. (right brick panel must
be removed in order to facilitate removal)
• Remove the four screws holding the access door in
place on the control assembly (located to the back of
the burner assembly). FIGURE 18.
• Disconnect the electrical connectors at the blower.
• Remove the blower.
PILOT BURNER ADJUSTMENT
1. Remove the pilot adjustment cap.
2. Adjust the pilot screw to provide properly sized flame.
3. Replace the pilot adjustment cap.
VENTURI ADJUSTMENT
Natural gas models have air shutters set at 1/16 (.063")
inch open. Propane gas models have air shutters set at 5/
16 (.313) inch open. Closing the air shutter will cause a
more yellow flame, but can lead to carboning. Opening the
air shutter will cause a more blue flame, but can cause
flame lifting from the burner ports. The flame may not ap-
pear yellow immediately; allow 15 to 30 minutes for the
final flame colour to be established.
AIRSHUTTERADJUSTMENT MUST ONLY BE DONEBYA
QUALIFIEDGASINSTALLER!
ORDERING REPLACEMENT PARTS
Contact your dealer or the factory for questions concerning
prices and policies on replacement parts. Normally all parts
can be ordered through your Napoleon dealer or distribu-
tor. When ordering replacement parts always give the fol-
lowing information:
REPLACEMENTSREPLACEMENTS
REPLACEMENTSREPLACEMENTS
REPLACEMENTS
1. Model & Serial Number of the unit.
2. Installation date of the unit.
3. Part Number
4. Part Description
5. Finish
FLAMEMUSTENVELOPUPPER
3/16"TO½" OF THERMOPILE
THERMOPILE

11
WS-415-44/11.17.99
REPLACEMENT PARTS LIST
PART NO. DESCRIPTION
COMMON PARTS
GZ-551 REPLACEMENTBLOWER
WS-725-13 NATURAL GAS VALVE
GA-GI-010.168 PROPANE GAS VALVE
WS-010-175 LP HI-LO VALVE
WS-010-87 NG HI-LO VALVE
WS 455-04 #36 DMS NATURAL GAS BURNER ORIFICE
WS 455-03 #54 DMS PROPANE GAS BURNER ORIFICE
WS 455-13 #37 DMS NATURAL GAS BURNER ORIFICE - HIALT
WS 455-02 #55 DMS PROPANE GAS BURNER ORIFICE - HIALT
WS 380-1 FLAME ADJUSTMENT VALVE KNOB
WS 660-7 SPILL SWITCH (NATURAL GAS)
WS 660-6 SPILL SWITCH (PROPANE GAS)
GA-GI-010.337 NATURAL GAS PILOT ASSEMBLY
GA-GI-010.338 PROPANE GAS PILOT ASSEMBLY
WS-357-01 PIEZO IGNITER
WS-680-01 THERMOPILE
WS-690-02 THERMAL SENSING SWITCH
GI 707K UPPER LOUVRE ASS'Y - BLACK
GI 707G UPPER LOUVRE ASS'Y- 24K GOLD PLATE
GI 941B6 "MARQUIS"TRIM - SATINBRASS FOR 6" FLASHINGS
GI 941B9 "MARQUIS"TRIM - SATINBRASS FOR 9" FLASHINGS
WS-660-09 BURNER ON/OFF SWITCH
GA GI 135.07 BACK LOG
GA GI 135.052 FRONT LOG
GA GI 135.10 RIGHT LOG
GA GI 135.09 CENTER LOG
GA GI 135.08 LEFT LOG
GL-610 LOG SET c/w CHARCOAL EMBERS
GA GI 550.01 CHARCOAL EMBERS
GA GI 10.333 BURNER ASSEMBLY
WS 455-5 NATURAL GAS PILOT ORIFICE
WS 455-6 PROPANE GAS PILOT ORIFICE
GI 945AB-6 ANTIQUE BRASS FLASHINGS - 6"
GI 945B-6 POLISHED BRASS FLASHINGS - 6"
GI 945C-6 CHROME FLASHINGS - 6"
GI 945K-6 BLACK FLASHINGS - 6"
GI 950S-6 ALMOND ENAMEL FLASHINGS - 6"
GI 950B-6 BLUE ENAMEL FLASHINGS - 6"
GI 950K-6 BLACK ENAMEL FLASHINGS - 6"
GI 950F-6 GREEN ENAMEL FLASHINGS - 6"
GI 945AB-9 ANTIQUE BRASS FLASHINGS - 9"
GI 945B-9 POLISHED BRASS FLASHINGS - 9"
GI 945C-9 CHROME FLASHINGS - 9"
GI 945K-9 BLACK FLASHINGS - 9"
GI 950S-9 ALMOND ENAMEL FLASHINGS - 9"
GI 950B-9 BLUE ENAMEL FLASHINGS - 9"
GI 950K-9 BLACK ENAMEL FLASHINGS - 9"
GI 950F-9 GREEN ENAMEL FLASHINGS - 9"
WS-385-33 NAPOLEONLOGO
KB35 VARIABLE SPEED SWITCH
GI3014
WS-300-12 DOOR GLASS
GA-GI-562.012 DOOR GASKET (2PC - SIDE)
GA-GI-562.011 DOOR GASKET - TOP
GI 200B UPPER GLASS BRACKET COVER - POL. BRASS
GI 200AB UPPER GLASS BRACKET COVER - ANT. BRASS
GI 200C UPPER GLASS BRACKET COVER - CHROME
GA-GI-080.62 UPPER GLASS BRACKET
GA-GI-080.79 LOWER GLASS BRACKET
GI 708PB LOWER LOUVRE ASS'Y - POLISHED BRASS
GI 708AB LOWER LOUVRE ASS'Y- ANTIQUE BRASS
GI 708C LOWER LOUVRE ASS'Y - CHROME
GI 708G LOWER LOUVRE ASS'Y - 24K GOLD PLATE
GI 941K6 1" TRIM - BLACK FOR 6" FLASHINGS
GI 941K9 1" TRIM - BLACK FOR 9" FLASHINGS
GI3014B
GI 808PB LOWER LOUVRE ASS'Y - POLISHED BRASS
GI 808AB LOWER LOUVRE ASS'Y- ANTIQUE BRASS
GI 808G LOWER LOUVRE ASS'Y - 24K GOLD PLATE
GA GI 010.336 BAY FRAME ASS'Y C/WGASKET
GA GI 010.326 FRONT GLASS C/WGASKET
GA-GI 010.325 SIDE GLASS C/WGASKET
GI 201AB BAY DOOR TRIM - ANTIQUE BRASS
GI201B BAY DOOR TRIM - POLISHED BRASS
GI 778KT BRICK PANEL KIT
GL-610

12
WS-415-44/11.17.99
111KT
WS-690-01
GI 700KT
GD240-K
ACCESSORIES / OPTIONS
PART NO. DESCRIPTION
COMMON PARTS
GI 778KT BRICK VENEER KIT
WS 470-2 ENAMEL TOUCH UP AND BRUSH (SPECIFY COLOUR)
GI 700KT ZERO CLEARANCE SHELL
111-KT OUTSIDE AIR KIT
WS 690-1 MILLIVOLT THERMOSTAT
WS 660-2 HANDHELD REMOTE CONTROL
WS-660-010 REMOTE CONTROL - ADVANTAGE
WS-660-011 REMOTE CONTROL - ADVANTAGE PLUS
GD 660 WALL SWITCH/20FT WIRE
WS 500-33 V.S.S. MOUNTING PLATE FOR WALL SWITCH
GI3014
GI 709G GOLD PLATED LOUVRES
GI 940B-6 6" FLASHING KIT - POLISHED BRASS
GI 940AB-6 6" FLASHING KIT - ANTIQUE BRASS
GI 940K-6 6" FLASHING KIT - BLACK
GI 940C-6 6" FLASHING KIT - CHROME
GI 940B-9 9" FLASHING KIT - POLISHED BRASS
GI 940AB-9 9" FLASHING KIT - ANTIQUE BRASS
GI 940K-9 9" FLASHING KIT - BLACK
GI 940C-9 9" FLASHING KIT - CHROME
GI 960S-6 6" PORCELAIN FLASHING KIT - ALMOND
GI 960B-6 6" PORCELAIN FLASHING KIT - BLUE
GI 960K-6 6" PORCELAIN FLASHING KIT - BLACK
GI 960F-6 6" PORCELAIN FLASHING KIT - GREEN
GI 960S-9 9" PORCELAIN FLASHING KIT - ALMOND
GI 960B-9 9" PORCELAIN FLASHING KIT - BLUE
GI 960K-9 9" PORCELAIN FLASHING KIT - BLACK
GI 960F-9 9" PORCELAIN FLASHING KIT - GREEN
GD240-K WEBBED DOOR FACIA
GI3014B
GI 809-G GOLD PLATED LOUVRES
GI949B-6 6" FLASHING KIT - POLISHED BRASS
GI 949AB-6 6" FLASHING KIT - ANTIQUE BRASS
GI 949K-6 6" FLASHING KIT - BLACK
GI 949B-9 9" FLASHING KIT - POLISHED BRASS
GI 949AB-9 9" FLASHING KIT - ANTIQUE BRASS
GI 949K-9 9" FLASHING KIT - BLACK
GI 969S-6 6" PORCELAIN FLASHING KIT - ALMOND
GI 969B-6 6" PORCELAIN FLASHING KIT - BLUE
GI 969K-6 6" PORCELAIN FLASHING KIT - BLACK
GI 969F-6 6" PORCELAIN FLASHING KIT - GREEN
GI 969S-9 9" PORCELAIN FLASHING KIT - ALMOND
GI 969B-9 9" PORCELAIN FLASHING KIT - BLUE
GI 969K-9 9" PORCELAIN FLASHING KIT - BLACK
GI 969F-9 9" PORCELAIN FLASHING KIT - GREEN
GI-778KT
GA-GI-475.142
GA-GI-475.145
GA-GI-475.144

13
WS-415-44/11.17.99
SYMPTOM PROBLEM TEST SOLUTION
BEFOREATTEMPTINGTOTROUBLESHOOT,PURGEYOURUNITANDINITIALLY LIGHTTHEPILOTANDTHEMAINBURNERWITHTHEGLASSDOORREMOVED.
TROUBLE SHOOTING GUIDETROUBLE SHOOTING GUIDE
TROUBLE SHOOTING GUIDETROUBLE SHOOTING GUIDE
TROUBLE SHOOTING GUIDE
Gas piping is undersized.
Pilot goes out while
standing; Main burner
is in 'OFF' position.
- turn on all gas appliances and see if pilot flame flutters,
diminishes or extinguishes, especially when main burners
ignite. Monitor supply pressure.
- check if supply piping size is to code. Correct all under-
sized piping.
Pilot goes out when the
gas knob is released. A - System is not correctly purged. - purge the gas line with the glass door removed.
- fill the tank and purge the gas line with the glass door
removed.
B - Out of propane gas.
- turn up the pilot flame.
D - Pilot flame is not engulfing
the thermopile. - gently twist the pilot head to improve the flame pattern around the thermopile.
E - Thermopile shorting. - clean thermopile and valve connection.
- check that thermopile insulation is not frayed and ground-
ing out on the housing or the burner support.
- replace thermopile.
- replace valve.
F - Faulty thermopile. - test & replace if necessary.
G- Faultyvalve. - test & replace if necessary.
C - Pilot flame is not
large enough
Pilot burning; no gas to
main burner; gas knob
is on; wall switch is on;
heat/flame adjustment
valve is on (if so
equipped.
A- Wall switch is defective - connect a jumper wire across the wall switch terminals;
if the main burner lights, replace the wall switch.
B - Wall switch wiring is defec-
tive. - disconnect switch wires from valve and connect a jumper wire across terminals 1 and 3; if the main burner lights,
check the wires for defects and/or replace wires.
C- Main burner orifice is
plugged. - remove stoppage in orifice.
D- Remote gas valve operator
is defective. - connect a jumper wire across terminals 1 and 3; if main burner does not light, replace gas valve.
- fill the tank and purge the gas line with the glass door
removed.
Pilot will not light. - check that the wire is connected to the push button ignitor.
- check if the push button ignitor needs tightening.
- replace pilot assembly if the wire insulation is broken or
frayed.
- replace pilot assembly if the ceramic insulator is cracked
or broken.
- replace the push button ignitor.
A - No spark at pilot burner
B - Spark gap is incorrect - spark gap should be 1/16" to 1/8" from the electrode tip
and the pilot burner. Light the pilot with a match and adjust
the electrode tip to the required spark gap and proper loca-
tion.
C - No gas at the pilot burner - check that the manual valve is turned on.
- check the pilot orifice for blockage.
- replace the valve.
- call the gas distributor.
D - Out of propane gas
THERMO-
PILE PILOT BURNER
PIEZO
IGNITER
1/16" TO 1/8"

14
WS-415-44/11.17.99
SYMPTOM TEST SOLUTION
PROBLEM
Main burner goes out;
pilot goes out. A- Refer to "Main burner goes out; pilot stays on"
B- Chimney down-drafting - wait ten minutes. Shut off all exhaust fans in the house
(ie: kitchen and bathrooms), furnace, and clothes dryer.
Open windows and/or doors. Start fireplace and monitor its
operation.
Close doors and windows and start appliances as before;
room is in negative pressure; increase fresh air supply.
C- Chimney is blocked - check for chimney blockage.
D- Liner disconnected from in-
sert. - re-attach liner.
E - Faulty spill switch. - replace.
Carbon is being de-
posited on glass, logs
or combustion cham-
ber surfaces. Flame is impinging on the logs
or combustion chamber. - check that the logs are correctly positioned. - open air shutter to increase the primary air.
- check the input rate: check the manifold pressure and
orifice size as specified by the rating plate values.
- check that the door gasketing is not broken or missing
and that the seal is tight.
- check that the 4" vent liner is free of holes and well sealed
at all joints.
- check that minimum rise per foor has been adhered to for
any horizontal venting.
Air shutter has become blocked - ensure air shutter opening is free of lint or other obstruc-
tions.
Exhaust
fumes
smelled in room, head-
aches.
- check for chimney blockage.
- check that chimney is installed to building code.
- room is in negative pressure; increase fresh air supply.
Fireplace is spilling.
A- Wall switch is mounted up-
side down.
B- Remote wall switch is
grounding.
C- Remote wall switch wire is
grounding.
Remote wall switch is
in off position; main
burner comes on
when gas knob is
turned to "ON" posi-
tion.
- reverse.
- replace.
- check for ground (short); repair ground or replace wire.
D -Faulty valve. - replace.
Main burner flame is a
blue, lazy, transparent
flame.
A- Insufficient secondary air. - increase fresh air supply (open door, window, add make-
up air supply)
B- Downdraft or blockage in
chimney. - remove blockage. - check that chimney is installed to building codes (3ft
above highest roof line or 2ft higher than any portion of a
building within a horizontal radius of 10ft of the chimney.)
B- Thermopile shorting.
A - Pilot flame is not large
enough or not engulfing the ther-
mopile.
Main burner goes out;
pilot stays on. - turn on pilot flame. Gently twist the pilot head to improve the flame pattern aroung the thermopile.
- clean thermopile and thermopile connection to valve.
White /grey film forms. Sulphur from fuel is being de-
posited on glass, logs or com-
bustion chamber surfaces.
- clean the glass with a gas fireplace glass cleaner. DO
NOT CLEAN GLASS WHEN HOT.
If deposits are not cleaned off regularly, the glass may be-
come permanently marked.

15
WS-415-44/11.17.99
NOTES:NOTES:
NOTES:NOTES:
NOTES:
