Napoleon GVF40N User manual

1
W415-0319/D/08.03.05
INSTALLER: THESE INSTRUCTIONS MUST BE CONVEYED TO AND REMAIN WITH THE HOMEOWNER.
Wolf Steel Ltd., 24 Na oleon Rd., Barrie, ON L4M 4Y8 Canada • [phone] • fax[phone]
www.na oleonfire laces.com • ask@na oleon.on.ca
CERTIFIED UNDER AMERICAN NATIONAL STANDARDS, ANSI Z21.11.2b, VOLUME II FOR UNVENTED ROOM HEATERS.
UNVENTED MILLIVOLT SYSTEM
INSTALLATION AND OPERATION INSTRUCTIONS FOR
UNVENTED GAS FIREPLACE - GVF40
NATURAL GAS MODEL GVF40N
PROPANE GAS MODEL GVF40P
CERTIFIED FOR CANADA AND UNITED STATES USING ANSI / CSA METHODS
WARNING: If the information in these instructions is not followed exactly, a fire or
explosion may result causing property damage, personal injury or death.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapours and liquids in the vicinity
of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use any phone in your build
ing.
• Immediately call your gas supplier from
a neighbour's phone. ollow the gas
supplier's instructions.
• If you cannot reach your gas supplier,
call the fire department.
Installation and service must be performed by a qualified installer, service agency
or the gas supplier.
This is an unvented gas- ired heater that uses air (oxygen) rom the room in which it is
installed. Provisions or adequate combustion and ventilation air must be provided.

2
W415-0319/D/08.03.05
Hood
Louvre Bracket
Hinge Screen
Louvre Installation & Removal
Heat Shield Stand Off Removal
Logo Placement
16-17 OPTIONS
Patented Catalytic Glass Door
Blower Installation
18-19 OPERATION / MAINTENANCE
Operating Instructions
Maintenance
Catalytic Tile Maintenance
Oxygen Depletion Sensor Pilot Cleaning
Pilot Flame Appearance
Venturi Adjustment
20-21 REPLACEMENTS
Ordering Replacement Parts
Replacement Parts
22-23 TROUBLE SHOOTING GUIDE
PG 3-4 INTRODUCTION
Warranty
General Instructions
General Information
Care of Glass Doors, Catalytic Tiles
& Plated Parts
5-12 INSTALLATION
Combustion and Ventilation Air Provisions
Determining Confined or Unconfined Space
Gas Installation
Framing Dimensions
Peninsula Installation Procedure
Open End Installation Procedure
See-Thru Installation Procedure
Island Installation Procedure
13-15 FINISHING
Log Placement
Glowing Embers
Charcoal Embers
Mantle Installation
Curtain Mesh
ARNING
• Under no circumstances should this heater be modified.
• Provide adequate ventilation and combustion air. Provide adequate accessibility clearance for
servicing and operating the heater. Never obstruct the front opening of the heater.
• If heater shuts off, do not re-light until you provide fresh air. If heater keeps shutting off, have it
serviced. eep burner and control compartment clean.
• Do not burn wood or other materials in this heater.
• Adults and especially children should be alerted to the hazards of high surface temperatures and
should stay away to avoid burns or clothing ignition. eep young children and animals away
when the fireplace is hot.
• Due to high temperatures, the heater should be located out of traffic and away from furniture and
draperies.
• Clothing or other flammable material should not be placed on or near the heater.
• Any safety screen or guard removed for servicing must be replaced prior to operating the heater.
• It is imperative that the control compartments, burners and circulating air passageways in the
heater are kept clean. The heater should be inspected before use and at least annually by a
qualified service person. More frequent cleaning may be required due to excessive lint from
carpeting, bedding material, etc. The heater area must be kept clear and free from combustible
materials, gasoline and other flammable vapours and liquids.
• Furniture or other objects must be kept a minimum of 4 feet away from the front of the fireplace.
• Do not use this heater if any part has been under water. Immediately call a qualified service
technician to inspect the heater and to replace any part of the control system and any gas con-
trol which has been under water.
• Do not allow fans to blow directly into the fireplace. Avoid any drafts that alter burner flame
patterns.
• Do not use a blower insert, heat exchanger insert or other accessory not approved for use with
this heater.
ANY CHANGE TO THIS HEATER OR ITS CONTROLS CAN BE DANGEROUS AND IS PROHIBITED.
NOTE: CHANGES, OTHER THAN EDITORIAL, ARE DENOTED BY A VERTICAL LINE IN THE MARGIN
TABLE of CONTENTS
PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE

3
W415-0319/D/08.03.05
NAPOLEON gas fireplaces are manufactured under the strict Standard of the world recognized
ISO 9001 : 2000 Quality Assurance Certificate.
NAPOLEON products are designed with superior components and materials, assembled by trained craftsmen who take
great pride in their work. The burner and valve assembly are leak and test-fired at a quality test station. The complete
fireplace is test-fired and thoroughly inspected by a qualified technician before packaging to ensure that you, the
customer, receives the quality product that you expect from NAPOLEON.
NAPOLEON GAS FIREPLACE PRESIDENT'S LIFETIME LIMITED WARRANTY
The following materials and workmanship in your newThe following materials and workmanship in your new
The following materials and workmanship in your newThe following materials and workmanship in your new
The following materials and workmanship in your new NAPOLEONNAPOLEON
NAPOLEONNAPOLEON
NAPOLEON gas fireplace are warranted against defects forgas fireplace are warranted against defects for
gas fireplace are warranted against defects forgas fireplace are warranted against defects for
gas fireplace are warranted against defects for
as long as you own the fireplace. This covers: combustion chamber, heat exchanger, stainless steel burner, phazer™as long as you own the fireplace. This covers: combustion chamber, heat exchanger, stainless steel burner, phazer™
as long as you own the fireplace. This covers: combustion chamber, heat exchanger, stainless steel burner, phazer™as long as you own the fireplace. This covers: combustion chamber, heat exchanger, stainless steel burner, phazer™
as long as you own the fireplace. This covers: combustion chamber, heat exchanger, stainless steel burner, phazer™
logs and embers, ceramic glass (thermal breakage only), gold plated parts against tarnishing, porcelainized enamelledlogs and embers, ceramic glass (thermal breakage only), gold plated parts against tarnishing, porcelainized enamelled
logs and embers, ceramic glass (thermal breakage only), gold plated parts against tarnishing, porcelainized enamelledlogs and embers, ceramic glass (thermal breakage only), gold plated parts against tarnishing, porcelainized enamelled
logs and embers, ceramic glass (thermal breakage only), gold plated parts against tarnishing, porcelainized enamelled
components and aluminum extrusion trims.components and aluminum extrusion trims.
components and aluminum extrusion trims.components and aluminum extrusion trims.
components and aluminum extrusion trims.
Electrical (110V and millivolt) components and wearable parts such as catalytic tiles, blowers, gas valves, thermalElectrical (110V and millivolt) components and wearable parts such as catalytic tiles, blowers, gas valves, thermal
Electrical (110V and millivolt) components and wearable parts such as catalytic tiles, blowers, gas valves, thermalElectrical (110V and millivolt) components and wearable parts such as catalytic tiles, blowers, gas valves, thermal
Electrical (110V and millivolt) components and wearable parts such as catalytic tiles, blowers, gas valves, thermal
switch, switches, wiring, remote controls, ignitor, gasketing, and pilot assembly are covered andswitch, switches, wiring, remote controls, ignitor, gasketing, and pilot assembly are covered and
switch, switches, wiring, remote controls, ignitor, gasketing, and pilot assembly are covered andswitch, switches, wiring, remote controls, ignitor, gasketing, and pilot assembly are covered and
switch, switches, wiring, remote controls, ignitor, gasketing, and pilot assembly are covered and NAPOLEONNAPOLEON
NAPOLEONNAPOLEON
NAPOLEON willwill
willwill
will
provide replacement parts free of charge during the first year of the limited warranty.provide replacement parts free of charge during the first year of the limited warranty.
provide replacement parts free of charge during the first year of the limited warranty.provide replacement parts free of charge during the first year of the limited warranty.
provide replacement parts free of charge during the first year of the limited warranty.
Labour related to warranty repair is covered free of charge during the first year. Repair work, however, requiresLabour related to warranty repair is covered free of charge during the first year. Repair work, however, requires
Labour related to warranty repair is covered free of charge during the first year. Repair work, however, requiresLabour related to warranty repair is covered free of charge during the first year. Repair work, however, requires
Labour related to warranty repair is covered free of charge during the first year. Repair work, however, requires
the prior approval of an authorized company official. Labour costs to the account ofthe prior approval of an authorized company official. Labour costs to the account of
the prior approval of an authorized company official. Labour costs to the account ofthe prior approval of an authorized company official. Labour costs to the account of
the prior approval of an authorized company official. Labour costs to the account of NAPOLEONNAPOLEON
NAPOLEONNAPOLEON
NAPOLEON are based on aare based on a
are based on aare based on a
are based on a
predetermined rate schedule and any repair work must be done through an authorizedpredetermined rate schedule and any repair work must be done through an authorized
predetermined rate schedule and any repair work must be done through an authorizedpredetermined rate schedule and any repair work must be done through an authorized
predetermined rate schedule and any repair work must be done through an authorized NAPOLEONNAPOLEON
NAPOLEONNAPOLEON
NAPOLEON dealer.dealer.
dealer.dealer.
dealer.
CONDITIONS AND LIMITATIONS
NAPOLEON warrants its products against manufacturing defects to the original purchaser only -- i.e., the individual or legal entity (registered customer) whose name appears on the
warrantyregistration cardfiled with NAPOLEON -- provided that thepurchase wasmade throughan authorizedNAPOLEON dealerand is subject to thefollowing conditionsand limitations:
Thisfactory warranty is nontransferable and may not beextended whatsoever by any of our representatives.
Thegas fireplace must be installed by a licenced,authorized service technician or contractor.Installation must be done in accordance with the installation instructions includedwith the
productand all local and nationalbuilding and fire codes.
Thislimited warrantydoes notcover damagescaused bymisuse, lackof maintenance,accident, alterations,abuse orneglect and parts installed from other manufacturers will nullify this
warranty.
Thislimited warrantyfurther does not cover any scratches, dents, corrosion ordiscolouring causedby excessive heat, abrasive and chemical cleaners nor chipping on porcelainenamel
parts,mechanical breakage of PHAZER™ logs and embers, norany venting componentsused in the installation of the fireplace.
NAPOLEONwarrants itsstainless steelburners againstdefects inworkmanship andmaterial forlife, subjectto thefollowing conditions:During thefirst 10years NAPOLEONwill replace
or repair the defective parts at our option free of charge. From 10 years to life, NAPOLEON will provide replacement burners at 50% of the current retail price.
Inthe first yearonly, this warranty extends to the repair or replacement of warranted parts which are defective in material or workmanship provided that theproduct has been operated
inaccordance with the operation instructionsand under normal conditions.
Afterthe first year,with respect to this President's Limited Lifetime Warranty, NAPOLEON may,at itsdiscretion, fully dischargeall obligations with respect to this warranty by refunding
tothe original warrantedpurchaser the wholesaleprice of anywarranted but defective part(s).
Afterthe first year, NAPOLEON will not be responsiblefor installation, labour or any other costs orexpenses related tothe reinstallation of a warrantedpart, and suchexpenses are not
coveredby this warranty.
Notwithstandingany provisions containedin this President's Limited LifetimeWarranty, NAPOLEON’Sresponsibility under this warranty is defined as above and itshall not in any event
extendto anyincidental, consequentialor indirectdamages.
Thiswarranty definesthe obligationsand liabilityof NAPOLEON withrespect tothe NAPOLEON gas fireplaceand anyother warrantiesexpressed orimplied withrespect tothis product,
itscomponents or accessoriesare excluded.
NAPOLEONneither assumes, nor authorizes anythird party to assume, on its behalf,any other liabilities with respectto the sale of thisproduct. NAPOLEONwill not be responsiblefor:
over-firing,downdrafts, spillagecaused by environmental conditions such as rooftops,buildings, nearbytrees, hills, mountains, inadequate vents or ventilation,excessive ventingconfigu-
rations, insufficient makeup air, or negative air pressures which may or may not be caused by mechanical systems such as exhaust fans, furnaces, clothes dryers, etc.
Anydamages to fireplace, combustion chamber, heat exchanger,brass trim or other component due to water,weather damage, long periods of dampness, condensation, damaging
chemicals or cleaners will not be the responsibility of NAPOLEON.
Thebill of sale or copywill be required together witha serial number and amodel number when making anywarranty claims from your authorizeddealer. The warranty registration card
mustbe returned within fourteen days to register the warranty.
NAPOLEONreserves the right to have its representative inspect any product or part thereof prior to honouring any warranty claim.
ALL SPECIFICATIONS AND DESIGNSARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE DUETO ON-GOING PRODUCT IMPROVEMENTS. NAPOLEON® ISA REGISTERED
TRADEMARKOFWOLF STEELLTD. PATENTSU.S.5.303.693.801 -CAN.2.073.411,2.082.915. ©WOLF STEELLTD.

4
W415-0319/D/08.03.05
This fireplace may be installed in an aftermarket per-
manently located, manufactured (mobile) home, where
not prohibited by local codes.
This fireplace is only for use with the type of gas indi-
cated on the rating plate. This fireplace is not convert-
ible for use with other gases, unless a certified kit is
used.
Minimum inlet gas supply pressure is 4.5 inches water
column for natural gas and 11 inches water column for
propane. Maximum inlet gas pressure is 7 inches water
column for natural gas and 13 inches water column for
propane. Manifold pressure under flow conditions is 3.5
inches water column for natural gas and 10 inches water
column for propane.
No external electricity ( 0 volts or 24 volts) is required
for the gas system operation.
Expansion / contraction noises during heating up and cool-
ing down cycles are normal and are to be expected.
CARE OF OPTIONAL GLASS DOORS,
CATALYTIC TILES AND PLATED PARTS
Do not use abrasive cleaners to clean plated parts. Buff
lightly with a clean dry cloth. This fireplace may have op-
tional glass doors which are equipped with either 3/16"
thick tempered or ceramic glass. Use only replacement
glass available from your Napoleon dealer. DO NOT SUB-
STITUTE MATERIALS. Clean the glass after the first 10
hours of operation with a recommended gas fireplace
glass cleaner. Thereafter clean as required. DO NOT
CLEAN GLASS WHEN HOT! If the glass is not kept clean
permanent discolouration and / or blemishes may result.
Catalytic tiles normally do not require cleaning. Physical
contact should be avoided. See Maintenance.
This heater is equipped with a pilot light safety
system referred to as an OXYGEN DEPLETION
SENSOR and is designed to turn off the heater if
not enough fresh air is available.
Use only accessories designed for and
listed with your specific fireplace.
THIS GAS FIREPLACE SHOULD BE INSTALLED AND
SERVICED BYA QUALIFIED INSTALLER to conform with
local codes. Installation practices vary from region to re-
gion and it is important to know the specifics that apply to
your area, for example: in Massachusetts State:
• The appliance off valve must be a “T” handle gas cock.
• The flexible connector must not be longer than 36 inches.
• The appliance is not approved for installation in a bedroom or
bathroom unless the unit is a direct vent sealed combustion
product.
• WARNING: This product must be installed by a licensed
plumber or gas fitter when installed within the commonwealth
of Massachusetts.
• Un-vented room heater shall be installed in accordance with
527 CMR 30.00 and 248 CMR 3.00 through 7.00.
• Sellers of un-vented propane or natural gas-fired
space/room heaters shall provide to each purchaser a copy
of 527 CMR 30.00 upon the sale of the unit from
http://www.napoleonfireplaces.com/Webshare/
installation_manuals/mass_requirements.pdf
In absence of local codes, install the GVF40 to the current
National Fuel Gas Code, ANSI Z223.1 Installation Code
which can be obtained from:
American Nation Standards Institute Inc.
1430 Broadway
New York, NY 10018
or
National Fire Protection Association Inc.
Batterymarch Park
Quincy, MA02269
The fireplace and its individual shutoff valve must be dis-
connected from the gas supply piping system during any
pressure testing of that system at test pressures in ex-
cess of 1/2 psig (3.5 kPa). The fireplace must be isolated
from the gas supply piping system by closing its individual
manual shutoff valve during any pressure testing of the
gas supply piping system at test pressures equal to or
less than 1/2 psig (3.5 kPa).
When the fireplace is installed directly on carpeting, vinyl
tile or other combustible material other than wood floor-
ing, the fireplace shall be installed on a metal or wood
panel extending the full width and depth.
If the optional fan or blower is installed, the junction box
must be electrically connected and grounded in accord-
ance with local codes. In the absence of local codes, use
the currentANSI/NFPA 70 NATIONALELECTRICAL CODE
in the United States.
FORYOUR SATISFACTION,THISFIREPLACE HASBEEN
TEST-FIRED TO ASSURE ITS OPERATION AND QUAL-
ITY! Maximum input is 30,000 BTU/hr for natural gas and
28,500 BTU/hr for propane. When the fireplace is installed
at elevations above 2,000ft, and in the absence of specific
recommendations from the local authority having jurisdic-
tion, the certified high altitude input rating shall be reduced
at the rate of 4% for each additional 1,000ft.
This heater must not be installed in a bedroom or
bathroom.
CARBON MONOXIDE POISONING
MAY LEAD TO DEATH
Earlysigns of carbonmonoxide poisoning re-
semblethe flu, with headache, dizzinessand/
ornausea. If you have these signs,the heater
may not be working properly. Get fresh air
at once! Have heater serviced.
Some people---pregnant women, persons
with heart or lung disease, anaemia, those
under the influence of alcohol, those at high
altitudes---are more affected by carbon mon-
oxide than others.
GENERAL INSTRUCTIONS
GENERAL INFORMATION

5
W415-0319/D/08.03.05
This heater shall not be installed in a confined
space or unusually tight construction unless pro-
visions are provided for adequate combustion and
ventilation air.
In order to avoid the possibility of exposed insu-
lation or vapour barrier coming in contact with
the fireplace body, it is recommended that the
walls of the fireplace enclosure be 'finished', (i.e.
drywall/sheetrock as would any other outside
wall of the home. This will ensure that clearance
to combustibles is maintained within the cavity.
The National Fuel Gas Code, ANSI Z223.1 defines a con-
fined space as a space whose volume is less than 50
cubic feet per 1,000 Btu per hour (4.8 m3 per kW) of the
aggregate input rating of all appliances installed in that
space and an unconfined space as a space whose vol-
ume is not less than 50 cubic feet per 1,000 BTU per hour
(4.8 m3 per kW) of the aggregate input rating of all appli-
ances installed in that space. Rooms communicating di-
rectly with the space in which the appliances are installed,
through openings not furnished with doors are consid-
ered a part of the unconfined space.
The GVF40 is rated at 30,000BTUs per hour for
natural gas and 28,500 BTUs for propane and
therefore requires a minimum un onfined spa e
of 1,500 and 1,425 ubi feet respe tively.
To determine the volume of the room where the heater is
to be installed, multiply the width x the length x the ceiling
height of that room measured in feet. If any adjoining rooms
are connected by grills or openings such as kitchen pass-
throughs, etc., the volume of those rooms may be added to
the total.
Multiply the room volume by 1000 and divide this amount
by 50 to determine the maximum Btu/hr that the space can
support with adequate combustion and ventilation air.
Add the BTU/hr of all fuel burning appliances located within
the space such as gas furnace, gas water heater, etc. Do
not include direct vent gas appliances which draw their
input and output air from and to the outdoors.
WARNING: If the area in which the heater may be oper-
ated is smaller than that defined as an unconfined space
or if the building is of unusually tight construction, provide
adequate combustion and ventilation air by one of the
methods described in the National Fuel Gas Code ANSI
Z223.1, Section 5.3 or the applicable local code.
Unusually tight construction is defined as con-
struction where:
a) Walls and ceilings exposed to the outside atmos-
phere have a continuous water vapour retarder with a
rating of 1 perm (6 x 10-11 kg per pa-sec-m2) or less with
openings gasketed or sealed, and
b) Weather stripping has been added on openable
windows and doors, and
c) Caulking or sealants are applied to areas such as
joints around window and door frames, between sole
plates and floors, between wall-ceiling joints, between
wall panels, at penetrations for plumbing, electrical, and
gas lines, and at other openings.
An unvented room heater is recommended for use as a
secondary heat source rather than as a primary source.
Gas combustion produces water vapour which could oc-
cur at the rate of approximately one ounce of water for
every 1,000 BTU/hr of gas input. During the cold weather
season, indoor humidity levels tend to be low. Conse-
quently, this water vapour can enhance the living space.
However if a problem should occur:
a) ensure sufficient combustion and circulation air
b) use a dehumidifier
c) do not use the unvented room heater as a primary
heat source
Without sufficient fresh air for proper operation, poor fuel
combustion can result. Carbon Monoxide is a result of
poor combustion.
If additional fresh air is required, use one of the meth-
ods described in the National Fuel Gas Code, ANSI Z223.1,
Section 5.3 or the applicable local code.
INSTALLATION
COMBUSTION AND VENTILATION
AIR PROVISIONS
DETERMINING CONFINED OR
UNCONFINED SPACE

6
W415-0319/D/08.03.05
50
If in this example a solid door separates Room 1 from
Room 2, the volume of Room 2 could not be used. In this
case the maximum BTU/h would be:
Maximum BTU/h: 800 x 1000 = 16,000 BTU/h
This would be considered a confined space since it can
not support the 30,000BTU/h input of the heater and it
would be necessary to provide adequate combustion and
ventilation air to Room 1.
WIRE SIZE MAX.LENGTH
14gauge 100 feet
16gauge 60 feet
18gauge 40 feet
5. Attach the two leads to terminals 1 and 3 located on
the gas valve.
Do not connect either the wall switch, thermostat or
gas valve to electricity (110 volts).
6. Mark the appropriate boxes on the rating plate label to
indicate the model type.
USINGDOOR OPTION:
Purge all gas lines with the glass door of the fireplace
opened. Assure that a continuous gas flow is at the
burner before closing the door.
1. Move the fireplace into position and secure to the floor
through the ¼"ø holes located at the four outside corners
of the base.
2. Install rigid black pipe, 1/2" type-L copper tubing or, if
local codes permit, a 3/8" flex connector and shutoff valve
to the gas line and the fireplace gas valve. Seal and tighten
securely. An adapter fitting is required between the gas
valve and the copper tubing or flex connector.
DONOTKINK FLEX CONNECTOR.
3. Check for gas leaks by brushing on a soap and water
solution.
DONOTUSE OPEN FLAME.
4. For ease of accessibility, an optional remote wall
switch or millivolt thermostat may be installed in a con-
venient location. Route a 2 strand, solid core millivolt wire
through the electrical hole located at the bottom left side of
the unit. The recommended maximum lead length de-
pends on wire size:
FIGURE2
P
I
P
I
L
O T
3
12
N
O
L
O
T
H
I
L
O
F
F
O
FIGURE3
If for example,
the length of the
rooms is 10 feet,
the width of Room 1
is 10 feet,
the width of Room 2
is 15 feet
the height of the
rooms is 8 feet.
The volume of Room 1: 10 x 10 x 8 =
800 cubic feet.
The volume of Room 2: 10 x 15 x 8 = 1200
cubic feet.
FIGURE1
In this example, because there is no door to the adjoining
room, the volume of the adjoining room may be added to
the volume of the room with the heater to get a total
unconfined space.
The total unconfined space: 800 + 1200 = 2000 cubic feet.
Maximum BTU/h: 2000 x 1000 = 40,000 BTU/h
If there are no more fuel burning appliances within this
space then the 30,000 BTU/h input of the fireplace is suit-
able to be installed. This also assumes that the construc-
tion of this space is not unusually tight.
50
Room Volume = Length x Width x Height
Max BTU/hr = Room Volume x 1000 ÷ 50
EXAMPLE 1 EXAMPLE 2
ROOM 2
ROOM 1
HEIGHT
LENGTH
GAS INSTALLATION

7
W415-0319/D/08.03.05
FIGURES4a-d
PENIN ULA
OPEN-END
EE-THRU
4- IDED

8
W415-0319/D/08.03.05
Note: In order to avoid the possibility of exposed insula-
tion or vapour barrier coming in contact with the
fireplace body, it is recommended that the walls of the
fireplace enclosure be “finished” (ie: drywall/sheetrock),
as you would finish any other outside wall of a home.
This will ensure that clearance to combustibles is
maintained within the cavity.
It is best to frame your fireplace after it is positioned. Use
2x4's and frame to local building codes. FIGURE 5.
To install the fireplace face flush with the finished wall,
position the framework to accommodate the thickness
of the finished wall.
When finishing the fireplace, combustible material may
rest directly on of the top extension.
Note:Note:
Note:Note:
Note: Maximum weight tolerance is 400 lbs, provided
that it is evenly distributed across the top extensions
of the fireplace.
In order to achieve a countertop or bar type appearance
with the minimum height allowed, framing must be non-
combustible and may be done with metal studding at-
tached to the heat shield sides or the upper frame of the
fireplace.FIGURE 7.
A
FIGURE5
TOP OF THE UNIT
TOP EXTENTION
FIGURE8
FIGURE6
A = 22 " minus finishing material thickness each side.
FIGURE7
* The top extension may be removed if non-combustible
framing is faced with a non-combustible material placed
flush with the front face of the unit and extending from the
top of the unit. (Example: cement board) (not supplied).
Combustible counter / bar tops must maintain a minimum
of 38 inches from the base of the fireplace to the underside
of the top. Figure 8.
NOTE: Wolf Steel trim and/or surround kits will not to-
tally cover the top extension of the fireplace. In order to
obtain a smooth transition from the trim / surround to
the wall, it is recommended that the top extension be
removed and the unit be installed following the above
procedure.
PENINSULA INSTALLATION PROCEDURE
FRAMING COUNTERTOP / BAR INSTALLATION

9
W415-0319/D/08.03.05
Combustible materials may be installed flush with the front
of the fireplace but must not cover any of the black face-
areas of the fireplace. Non-combustible material (brick,
stone or ceramic tile) may protrude in these areas.
It is not necessary to install a hearth extension with this
fireplace system.
When roughing in the fireplace, raise the fireplace to ac-
commodate for the thickness of the finished floor materi-
als, i.e. tile, carpeting, hard wood, which if not planned for
will interfere with the opening of the lower access door and
the installation of many decorative flashing accessories.
Objects placed in front of the fireplace should be
kept a minimum of 48" away from the glass front
faces of the fireplace.
Refer to pages 13-15 for complete instructions regarding
mantle requirements and installations, log placement,
glass door and upper and lower louvre attachments.
Install the base panels as illustrated in steps 1-4 . The
side panel sits under the bracket tab.Holding the side
panel in position, bend down the tab to secure. [DETAIL 5.]
FIGURES9a-e
RETAINER
DETAIL5
STEP3
STEP2
STEP1
STEP4
STEP5
FIGURE10
DRYWALL
4"MIN
DRYWALL
BRICK PANEL INSTALLATION FACING
FINISHING

10
W415-0319/D/08.03.05
FIGURE14
Note: In order to avoid the possibility of exposed insula-
tion or vapour barrier coming in contact with the
fireplace body, it is recommended that the walls of the
fireplace enclosure be “finished” (ie: drywall/sheetrock),
as you would finish any other outside wall of a home.
This will ensure that clearance to combustibles is
maintained within the cavity.
It is best to frame your fireplace after it is positioned and
the vent system is installed. Use 2x4's and frame to local
building codes. FIGURE 11.
See PAGE 8 for bar type / countertop installation.
NOTE: LEFT CORNER UNIT ILLUSTRATED
To install the fireplace face flush with the finished wall,
position the framework to accommodate the thickness
of the finished wall.
Install the base panels as illustrated in steps 1-4 on page
9. The side panel sits under the bracket tab.Holding the
side panel in position, bend down the tab to secure. [DE-
TAIL 6].
A
O
L
O
F
F
P
H
I
L O
FIGURE11
A = 25¼" minus finishing material thickness each side.
FIGURES13a-c
FIGURE12 Combustible materials may be installed flush with the front
of the fireplace but must not cover any of the black face-
areas of the fireplace. Non-combustible material (brick,
stone or ceramic tile) may protrude in these areas.
It is not necessary to install a hearth extension with this
fireplace system.
When roughing in the fireplace, raise the fireplace to ac-
commodate for the thickness of the finished floor materi-
als, i.e. tile, carpeting, hard wood, which if not planned for
will interfere with the opening of the lower access door
and the installation of many decorative flashing accesso-
ries.
Objects placed in front of the fireplace should be
kept a minimum of 48" away from the glass front
faces of the fireplace.
Refer to pages 13-15 for complete instructions regarding
mantle requirements and installations, log placement,
glass door and upper and lower louvre attachments.
STEP6
RETAINER
DETAIL6
STEP 5
OPEN-END INSTALLATION PROCEDURE
BRICK PANEL INSTALLATION
FRAMING
FACING
FINISHING
DRYWALL
DRYWALL
4"MIN

11
W415-0319/D/08.03.05
Install the base panels as illustrated in steps 1-4 on page
9. Both side panels sit under the bracket tab.Holding the
side panel in position, bend down the tab to secure. [DE-
TAIL 6].
DRYWALL
DRYWALL
4"MIN
FIGURE17
Note: In order to avoid the possibility of exposed insula-
tion or vapour barrier coming in contact with the
fireplace body, it is recommended that the walls of the
fireplace enclosure be “finished” (ie: drywall/sheetrock),
as you would finish any other outside wall of a home.
This will ensure that clearance to combustibles is
maintained within the cavity.
It is best to frame your fireplace after it is positioned and
the vent system is installed. Use 2x4's and frame to local
building codes. FIGURE 15.
See PAGE 8 for bar type / countertop installation.
A
A = 22" minus finishing material thickness, each side.
FIGURE15
FIGURES16a-c
RETAINER
RETAINER
STEP 5
STEP 6
DETAIL5 & 6
Combustible materials may be installed flush with the front
of the fireplace but must not cover any of the black face-
areas of the fireplace. Non-combustible material (brick,
stone or ceramic tile) may protrude in these areas.
It is not necessary to install a hearth extension with this
fireplace system.
When roughing in the fireplace, raise the fireplace to ac-
commodate for the thickness of the finished floor materi-
als, i.e. tile, carpeting, hard wood, which if not planned for
will interfere with the opening of the lower access door
and the installation of many decorative flashing accesso-
ries.
Objects placed in front of the fireplace should be
kept a minimum of 48" away from the glass front
faces of the fireplace.
Refer to pages 13-15 for complete instructions regarding
mantle requirements and installations, log placement,
glass door and upper and lower louvre attachments.
SEE-THROUGH INSTALLATION PROCEDURE
FACING
FINISHING
FRAMING
BRICK PANEL INSTALLATION

12
W415-0319/D/08.03.05
Combustible materials may be installed flush with the front
of the fireplace but must not cover any of the black face-
areas of the fireplace. Non-combustible material (brick,
stone or ceramic tile) may protrude in these areas.
It is not necessary to install a hearth extension with this
fireplace system.
When roughing in the fireplace, raise the fireplace to ac-
commodate for the thickness of the finished floor materi-
als, i.e. tile, carpeting, hard wood, which if not planned for
will interfere with the opening of the lower access door
and the installation of many decorative flashing accesso-
ries.
Objects placed in front of the fireplace should be
kept a minimum of 48" away from the glass front
faces of the fireplace.
Refer to pages 13-15 for complete instructions regarding
mantle requirements and installations, log placement,
glass door and upper and lower louvre attachments.
FIGURE20
DRYWALL DRYWALL
Note: In order to avoid the possibility of exposed insula-
tion or vapour barrier coming in contact with the
fireplace body, it is recommended that the walls of the
fireplace enclosure be “finished” (ie: drywall/sheetrock),
as you would finish any other outside wall of a home.
This will ensure that clearance to combustibles is
maintained within the cavity.
It is best to frame your fireplace after it is positioned. Use
2x4's and frame to local building codes. FIGURE 18.
To install the fireplace face flush with the finished wall,
position the framework to accommodate the thickness
of the finished wall.
FIGURE19
A
FIGURE18
A = 22 " minus finishing material thickness each side.
Install the base panels as illustrated in steps 1-4 on page
9.
ISLAND INSTALLATION PROCEDURE
FACING
FRAMING BRICK PANEL INSTALLATION
FINISHING

13
W415-0319/D/08.03.05
PHAZERTM logs, glowing and charcoal embers, exclusive
to Napoleon fireplaces, provide a unique and realistic glow-
ing effect that is different in every installation. Take the time
to carefully position the embers for a maximum glowing
effect.Figures 21 A - H.
1. Place log #1 diagonally across the textured burner cover
onto the pins. The texture is designed to cradle the under-
side of the log.
2. Depending on the type of installation, the view of the log
positioning will reverse. Here the lower end of log #2 rests
near the back left corner of the firebox on the locating pin.
The upper end sits on top of log #1, inside the groove on
log #2.
3. Log # 3 is made up of
two pieces, a and b. Piece
#3a is the base of log #3.
The base sits diagonally in
the designated area lo-
cated between logs #1 and
fits tight up against #2.
4. The slot in the under-
side of piece #3b fits over
#3a. Place the end of
piece #3b onto the pin.
5. When pieces #3a and #3b are attached to create log
#3, the upper end of log #3 should rest in the groove, on
top of log # 2.
6.As with log # 1, log #4 is also cradled by the texture of the
burner cover and the pin in the base. Position log #4 so that
the lower end fits onto the pin. The upper end rests against
the moulded locater on the top of log # 1.
7. Like log #3, log #5
also comes in two
pieces. The base
(#5a) slopes
outwards between
logs #2 and #4.
As with pieces #3a &
b, piece #5b fits over
piece #5a. Place the
end of piece #5b
onto the pin.
8. The upper end of log #5 rests in the groove, on top of
log #4 and creates the final appearance of the log set.
a
Db
#3
#3
E
#1
#2
#3 #4
#5
H
#5
a
b
G
ALOCATINGPINS #1 LOCATINGPINS
#2
B
C#3a
F
#4
FINISHING
LOG PLACEMENT

14
W415-0319/D/08.03.05
The curtain mesh must be kept fully closed during opera-
tion to help prevent accidental burns from occurring.
The heater must
not be used when
the hood is re-
moved. Hook the
hood over the lip of
the curtain support
plate.
Combustible mantle clearance can vary according to the
mantle depth. Use the graph to help evaluate the clear-
ance needed. The four-sided top extension piece may be
removed if non-combustible framing is faced with a non-
combustible material.
Dashed lines are suitable
mantle sizes and clear-
ances when a non-combus-
tible facing is used.
Attach the hood with louvre brackets by pressing the top
flange of the bracket into the clips along the top of the
louvre opening with louvre securing tabs facing out.
FIGURE 24
FIGURE 25
MANTLE INSTALLATION
HOOD
UPPER LOUVRE BRACKETS & HOOD
Tear the embers into small pieces and place on the ported
area of the burner. Care should be taken to shred the
embers into thin, small irregular pieces as only the ex-
posed edges of the fibre hairs will glow. The ember mate-
rial will only glow when exposed to direct flame; however,
care should be taken to not block the burner ports. Blocked
burner ports can cause an incorrect flame pattern, carbon
deposits and delayed ignition. PHAZERTM logs glow when
exposed to direct flame.
Randomly place the embers around the bottom brick pan-
els in a realistic manner but not in contact with the flames.
Keep ember dust away from burner ports to avoid plugging
them.
Finedustfoundin bottom of bag not tobeused. PHAZERTM
logs, and embers glow when exposed to direct flame. Use
only certified PHAZERTM logs, glowing embers and char-
coal embers available from your Napoleon / Wolf Steel Ltd.
dealer.
22
GLOWING EMBERS
GLO ING EMBERS
CHARCOAL EMBERS
Ensure that glowing embers sufficiently cover the carry over
ports, highlighted below, to achieve maximum glow.
CARRY OVER PORTS
FIGURE23
HOOD
CURTAINSUPPORT
PLATE
FIGURE27
HOOD
CURTAIN
MESH
FIGURE26
FIGURE 28

15
W415-0319/D/08.03.05
L36 LOUVRE INSTALLATION
FIGURE32 a-c
HOOD
Attach the hood by pressing the
top flange into the clips along
the top of the louvre opening.
Secure using a screw through
the centre slot.
LOWERLOUVRES
Insert the hinge clips into the
slots located at the bottom left
and right corners of the unit.
To remove the louvres, pull the
back tabs of the clips forward,
while pushing the louvre assem-
bly back. Lift the clip.
UPPERLOUVRES
Insert the louvre tabs into the
slots located at the top left and
right corners of the unit.
SLOT
TAB
B
CHINGE
CLIP SLOT
A
B
C
Remove the backing of
the logo supplied and
place on the screen
cover, as indicated.
LOGO PLACEMENT
Using 6 screws, attach the lower louvre brackets and hinge
screen as illustrated. Be sure to install the louvre brack-
ets over the hinge screen.
AB
TO INSTALL THE UP-
PER LOUVRES: Insert
the upper louvres into
the slots on both brack-
ets. Press the top flange
of the hood into the four
clips located along the
top of the unit as shown.
TO INSTALL THE
LOWER LOUVRE AS-
SEMBLY: Attach each
hinge to the firebox with
2 screws.
FIGURES29
LOWER LOUVRE BRACKETS & HINGE SCREEN
GVFL INSTALLATION
ACLIPS
CENTRE
SLOT
FLANGE
When using a non-combustible finishing material, the
stand-offs may be removed, by removing the set screw in
the centre and sliding the stand-offs out of the mounting
clips.
HEAT SHIELD STAND-OFF
REMOVAL
HEAT SHIELD
STAND-OFFS
END HEAT SHIELD SHOWN
FIGURE33
FIGURE34
LOUVRE
HOOD
SLOT
BRACKET
30
LOWER LOUVRES
(VALVE CONTROLDOOR)
31

16
W415-0319/D/08.03.05
Notes:
Ornamental insets can not be used in conjunction
with the catalytic door
When using a catalytic door, glassed doors must
be used on all other side or end openings.
This unique patented catalytic system was designed to
provide unparalleled safety and peace of mind. The top of
the door contains four catalytic tiles which are designed to
filter out combustion gases and limit the carbon monox-
ide output. It is likely that with the fireplace in operation, the
catalytic tiles will actually scrub the carbon monoxide nor-
mally found in the room and reduce it to a lower level. The
tiles must not be altered or removed. They are not field
serviceable and must be tested annually. The hood sup-
plied with the unit must be disgarded and replaced with
the hood designed for use with the catalytic door.
The heater with an optional catalytic door in place must
not be operated when using any products such as paint,
paint thinner, adhesives, etc. These products will perma-
nently affect the catalytic tiles’ ability to scrub the air.
1. The mesh must be removed if the catalytic door is used.
Remove the centre bracket and bend the curtain rod slightly
to disengage the rod from either side.
2. Remove the curtain support plate. Remove the two latch
securing screws, already installed, position latch as shown
in and re-secure with the screws.A ¼” socket ratchet is
recommended for this.
Repeat at the bottom. For location, see .
3. Screw the door hinge
ontothe heaterby firststart-
ing each of the five ma-
chine screws and then
tightening all screws.
4. & 5. Secure the door using the two latches.
Install the appropriate hood by hooking it over the top lip of
the door assembly.
The heater must not be used when the hood is removed.
TOP DOORLATCH
4
BOTTOMDOOR LATCH
5
4
5
CURTAIN SUPPORT PLATE
LATCH SCREW
LOCATION
2The upper louvres must
be removed to allow the
catalytic door to be
opened or closed. To ac-
cess the lower door latch,
open the valve control
door. Release the top and
bottom door latches, lo-
cated at the right side of
the door.
CURTAIN ROD
BRACKET
1
FIGURES35
Care must be taken when closing and opening the cata-
lytic door to avoid damaging the catalytic tiles.
OPTIONS
GVF103-KT - PATENTED CATALYTIC
DOOR INSTALLATION
DOOR
HINGE
3
DOOR OPENING AND CLOSING
DOORLATCH
HOOD
UPPERLOUVRE
36
FLANGE CLIP

17
W415-0319/D/08.03.05
Remove the thermodisc bracket from the top of the firebox.
Remove the thermodisc from the bracket supplied in the
blower kit and install the thermodisc into the fireplace
bracket. Then replace the bracket in the location it was
removed.
Connect the two ends of the unattached wires by the bracket
to the thermodisc.
Connect the opposite ends of the wires to the red and black
leads of the blower harness.
The wire harness provided in this kit is a universal har-
ness. When installed, ensure that any excess wire is
contained,preventing itfrom makingcontact withmov-
ing or hot objects.
Drywalldustwillpenetrateintotheblowerbearings,caus-
ingirreparable damage.Care must be taken to prevent
drywalldust from cominginto contact withthe blower or
itscompartment. Any damage resultingfrom this condi-
tion is not covered by the warranty policy.
Becausethe blower is thermallyactivated, when turned
on, it will automatically start approximately 10 minutes
afterlighting the fireplaceand will runfor approximately
30 - 45 minutes after the fireplace has been turned off.
Use of the fan increases the output of heat.
INSTALLATION TO BE DONE BY A QUALIFIED IN-
STALLER and must be electrically connected and
grounded in accordance with local codes. In the absence
of local codes, use the current ANSI/NFPA 70 NATIONAL ELEC-
TRICAL CODE in the United States.
Remove the
blower from its
mounting bracket
and attach to the
bracket supplied
with the fireplace.
This bracket is
found secured on
the mounting stud
located at the bot-
tom of the vent
side wall.
red
white
black
Position the vibration reducing pad, centred, onto the
threaded stud, piercing a hole into the pad. The blower
must be able to be positioned entirely onto the pad.
Tilt the blower onto its side and slide it past the controls.
Position the blower under the clip and onto the stud. Se-
cure with a wing nut.
FIGURE40
FIGURE37
FIGURE39
FIGURE41
FIGURE38
The blower bracket contains two holes that allow the blower
to be positioned away from the intended gas supply hole.
THIS BLOWER IS NOT RECOMMENDED FOR THE 4 SIDED INSTALLATION.
THERMODISCBRACKET
THERMODISCWIRESTOBLOWER
OPTIONAL BLOWER INSTALLATION

18
W415-0319/D/08.03.05
When lighting and re-lighting, the gas knob cannot be
turned from pilot to off unless the knob is depressed.
1. STOP! Read the above safety information on this la-
bel.
2. Set the thermostat to lowest setting.
3. Turn off all electric power to the fireplace.
4. Open the control door. Turn the gas knob clockwise
to off.
5. Wait five (5) minutes to clear out any gas. If you smell
gas including near the floor, STOP! Follow "B" in the
above safety information on this label. If you don't smell
gas go to the next step.
6. Find pilot located in front of the back log.
7. Turn gas knob counter-clockwise to pilot.
A. This fireplace is equipped with a pilot which must be
lit by hand while following these instructions exactly.
B. Before operating smell all around the fireplace area
for gas and next to the floor because some gas is
heavier than air and will settle on the floor.
C. Use only your hand to push in and turn the gas control
knob. Never use tools. If the knob will not push in and
turn by hand, do not try to repair it. Call a qualified
service technician. Force or attempted repair may re-
sult in a fire or explosion.
D. Do not use this fireplace if any part has been under
water. Immediately call a qualified service technician to
inspect the fireplace and replace any part of the control
system and any gas control which has been under water.
• Do not try to light any appliance.
• Do not touch any electric switch; do not use any phone
in your building.
• Immediately call your gas supplier from a neighbour's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire de-
partment.
ARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLO-
SION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.
GAS KNOB
OXYGENDEPLETIONSENSOR
If heater shuts off, do not relight until you provide
fresh air. If heater keeps shutting off, have it serv-
iced. Keep burner and control compartment clean.
When lit for the first time, the fireplace will emit a slight
odour for a few hours. This is a normal temporary condi-
tion caused by the curing of the logs and the "burn-in" of
internal paints and lubricants used in the manufacturing
process and will not occur again.
After extended periods of non-operation such as following
a vacation or a warm weather season, the fireplace may
emit a slight odour for a few hours. This is caused by dust
particles burning off. In both cases, open a window to suf-
ficiently ventilate the room.
Purge the gas line with the glass door open. Assure
that a continuous gas flow is at the burner before clos-
ing the door.
P
I
N
O
L
O
T
F
F
O
8. Depress and hold gas knob while lighting the pilot
with the push button igniter. Keep knob fully depressed
for one minute, then release. If pilot does not continue
to burn repeat steps 3 through 7.
9. With pilot lit, turn gas knob counter-clockwise to
on. When the pilot has been turned off, ignition of the
main burner may be delayed from 1-2 minutes.
When the pilot has been left burning, ignition of the
main burner should occur almost immediatley.
10. If equipped with remote on-off switch, main burner
may not come on when you turn the valve to on. Re-
mote switch must be in the on position to ignite burner.
11. Turn on all electric power to the fireplace.
1. Turn off all electric power to the fireplace if service is to
be performed. 2. Push in gas control knob slightly and turn clock-
wise to off. Do not force.
O T
P
I
L
L
O
I
H
T
P
I
L
O
N
O
F
F
O
GAS KNOBAT OFF
OPERATION / MAINTENANCE
FOR YOUR SAFETY READ BEFORE LIGHTING:
LIGHTING INSTRUCTIONS
TO TURN OFF GAS
WHAT TO DO IF YOU SMELL GAS:

19
W415-0319/D/08.03.05
THIS PR CEDURE MUST BE PERF RMED BY A
QUALIFIED SERVICE PERS N!
Inspect the pilot for any visible contamination or debris
(usually lint, pet hair, spider webs, carpet fibre, etc.) and
remove.
Disconnect the pilot from the pilot tubing line. Using a
7
/
16
”
wrench, remove the injector from the pilot housing. Blow
out the housing in the same direction as the gas flow.
Re-install the injector and the pilot tube, turn on the gas
and check for leaks.
If this does not improve the performance, replace the pilot
with an exact replacement. The device is tamper resist-
ant with no field serviceable parts.
AIR SHUTTER ADJUSTMENT MUST ONLY BE DONE
BY A QUALIFIED GAS INSTALLER!
Closing the air shutter will cause a more yellow flame, but
can lead to carboning. WARNING: Carbon can be distrib-
uted in surrounding living area if the air shutter is improp-
erly adjusted.
Opening the air shutter will cause a more blue flame, but
can cause flame lifting from the burner ports. The flame
may not appear yellow immediately; allow 15 to 30 min-
utes for the final flame colour to be established.
Opening the air shutter will also reduce exhaust odours
smelled within the room. See Trouble Shooting Guide.
CORRECTPILOT
FLAME INCORRECTPILOT FLAME
AIRSHUTTEROPENINGS
TURN FF THE GAS AND ELECTRICAL P WER
BEF RE SERVICING THE FIREPLACE.
CAUTION: Label all wires prior to disconnection when
servicing controls. Wiring errors can cause improper and
dangerous operation. Verify proper operation after servic-
ing. This heater should be inspected and serviced before
use and at least annually by a qualified service person.
The fireplace area must be kept clear and free of combus-
tible materials, gasoline or other flammable vapours and
liquids. The flow of combustion and ventilation air must
not be obstructed.
1. In order to properly clean the burner and oxygen deple-
tion sensor system, remove the logs to expose both as-
semblies.
2. Keep the control compartment, logs, burner, air shutter
opening and the area surrounding the logs clean by vacu-
uming or brushing, at least once a year.
3. Check to see that all burner ports are burning. Clean
out any of the ports which may not be burning or are not
burning properly.
4. Check to see that the pilot flame is large enough to
engulf the thermocouple and thermopile and promptly ig-
nites the main burner.
5. Replace the cleaned logs.
6. Check to see that the main burner ignites completely
on all openings when the gas knob for the burner is turned
on. A 5 to 10 second total light-up period is satisfactory. If
ignition takes longer, consult your Napoleon dealer / dis-
tributor.
7. If using an optional catalytic door, check that the
gasketing on the sides, and top of the door is not broken
or missing. Replace if necessary.
The catalytic tile is not field serviceable. It may only be
handled or replaced by a qualified service person familiar
with the specific characteristics of the appliance. Both room
values and output from the catalytic tiles must be checked.
Check the room value with the heater off. Check the fire-
place value after 10 minutes of heater operation to allow
the tiles to come up to temperature.
In both cases the value of CO should not exceed 9ppm.
Catalytic output must be checked annually at the
beginning of the heating season.
FIGURES43
FIGURES44
NG 1/4"
LP 7/16"
FIGURE42
CATALYTICTILE
VENTURI
MAINTENANCE OXYGEN DEPLETION SENSOR PILOT
CLEANING
VENTURI ADJUSTMENT
CATALYTIC TILE MAINTENANCE

20
W415-0319/D/08.03.05
Contact your dealer for questions concerning prices and
availability of replacement parts. Normally all parts can be
ordered through your Napoleon dealer or distributor.
# PART No. DESCRIPTION
1* W361-0016 GLOWING EMBERS
2* W550-0001 CHARCOAL EMBERS
3* GD660 STANDARD WALL SWITCH & 20FT OF WIRE
4* W385-0245 NAPOLEON LOGO
5 GL-634 BGD40LOGSET
6 W135-0153 LOG#1
7 W135-0154 LOG#2
8 W135-0155 LOG#3 - PIECE A
9 W135-0156 LOG#3 - PIECE B
10 W135-0157 LOG#4
11 W135-0158 LOG#5 - PIECE A
12 W135-0159 LOG#5 - PIECE B
13 W475-0259 END FIBRE BRICK PANEL - FOR BURNER
14 W475-0260 END FIBRE BRICK PANEL - FOR BURNER
15 W475-0278 SIDE FIBRE BRICK PANEL - FOR BURNER
16 W475-0262 SIDE FIBRE BRICK PANEL - FOR BURNER
17 W080-0519 BOTTOMLOUVRE BRACKET
18 W335-0024 HOOD
19 W565-0058 CURTAIN MESH
20 W555-0033 CURTAIN ROD
21 W080-0357 CURTAIN ROD BRACKET
22 W630-0010 BLACKTASSELS
23 W500-0194 CURTAIN SUPPORT PLATE
24 N010-0279 SIDE LOUVRE HOOD W/ LOUVRE BRACKETS
25 W200-0114 SIDE DOOR COVER
26 N010-0327 SIDE DOOR HEAT SHIELD
27 W475-0263 SIDE BRICK PANEL - FOR WALL
28 W500-0192 SIDE BRICK PANEL RETAINER
29 W335-0027 SHORT HOOD
30 W565-0060 SHORT CURTAIN MESH
31 W555-0039 SHORT CURTAIN ROD
32 N010-0310 END LOUVRE HOOD W/ LOUVRE BRACKETS
33 W585-0126 END DOOR HEAT SHIELD
34 N010-0323 END DOOR COVER
35 W500-0192 END BRICK PANEL RETAINER
36 W475-0265 END BRICK PANEL
33 W585-0126 END DOOR HEAT SHIELD
34 N010-0323 END DOOR COVER
35 W500-0192 END BRICK PANEL RETAINER
36 W475-0265 END BRICK PANEL
29 W335-0027 SHORT HOOD
30 W565-0060 SHORT CURTAIN MESH
31 W555-0039 SHORT CURTAIN ROD
32 N010-0310 END LOUVRE HOOD W/ LOUVRE BRACKETS
33 W585-0126 END DOOR HEAT SHIELD
34 N010-0323 END DOOR COVER
35 W500-0192 END BRICK PANEL RETAINER
36 W475-0265 END BRICK PANEL
329 W335-0027 SHORT HOOD
30 W565-0060 SHORT CURTAIN MESH
31 W555-0039 SHORT CURTAIN ROD
32 N010-0310 END LOUVRE HOOD W/ LOUVRE BRACKETS
37 W010-0997 REPLACEMENT BURNER
38 W662-0001 NATURAL GAS OXYGEN DEPLETION SENSOR SYSTEM
38 W662-0002 PROPANE GAS OXYGEN DEPLETION SENSOR SYSTEM
39* W660-0005 BURNER ON/OFF SWITCH
40* W680-0004 THERMOPILE
41* W357-0001 PIEZO IGNITER
42 W455-0026 #38 NATURAL GAS BURNER ORIFICE
42 W455-0059 #53 PROPANE GAS BURNER ORIFICE
43 W725-0030 NATURAL GAS VALVE
43 W725-0031 PROPANE GAS VALVE
REPLACEMENTS
When ordering replacement parts always give the follow-
ing information:
1. MODEL &SERIAL NUMBER OF FIREPLACE
2. INSTALLATION DATE OF FIREPLACE
3. PART NUMBER
4. DESCRIPTION OF PART
5. FINISH
6. TOP OR REAR VENT
COMPONENTS COMMON TO ALL UNITS
COMPONENTS UNIQUE TO OPEN END UNIT
COMPONENTS UNIQUE TO SEE-THRU UNIT
COMPONENTS UNI UE TO PENINSULA UNIT
BURNER COMPONENTS
COMPONENTS UNI UE TO ISLAND UNIT
ACCESSORIES
44 GVFLK LOUVRE KIT - BLACK
44 GVFLPB LOUVRE KIT - POLISHED BRASS
44 GVFLAB LOUVRE KIT - ANTIQUE BRASS
44 GVFLSS LOUVRE KIT - STAINLESS STEEL
45* BGDELK END LOUVRE KIT - BLACK
45* BGDELPB END LOUVRE KIT - POLISHED BRASS
45* BGDELAB END LOUVRE KIT - ANTIQUE BRASS
45* BGDELSS END LOUVRE KIT - STAINLESS STEEL
46 L36K LOUVRE KIT - UPPER & LOWER - BLACK
47* ELB40K END LOUVRE KIT - BLACK
48 HOIG-1 HERITAGE ORNAMENTAL INSET-GOLD PLATED
48 HOIKG-1 HERITAGE ORNAMENTAL INSET-BLACK GOLD PLATED
48 HOIBC-1 HERITAGE ORNAMENTAL INSET-BRUSHED COPPER PLATED
48 HOIBG -1 HERITAGE ORNAMENTAL INSET-BRUSHED GOLD PLATED
49* EHOIG -1 END HERITAGE ORNAMENTAL INSET-GOLD PLATED
49* EHOIKG-1 END HERITAGE ORNAMENTAL INSET-BLACK GOLD PLATED
49* EHOIBC-1 END HERITAGE ORNAMENTAL INSET-BRUSHED COPPER PLATED
49 EHOIBG -1 END HERITAGE ORNAMENTAL INSET - BRUSHED GOLD PLATED
50 DOIG-1 DIAMOND ORNAMENTAL INSET - GOLD PLATED
50 DOIKG-1 DIAMOND ORNAMENTAL INSET - BLACK GOLD PLATED
50 DOIBC-1 DIAMOND ORNAMENTAL INSET - BRUSHED COPPER PLATED
50 DOIBG-1 DIAMOND ORNAMENTAL INSET - BRUSHED GOLD PLATED
51* EDOIG-1 END DIAMOND ORNAMENTAL INSET - GOLD PLATED
51* EDOIKG-1 END DIAMOND ORNAMENTAL INSET - BLACK GOLD PLATED
51* EDOIBC-1 END DIAMOND ORNAMENTAL INSET - BRUSHED COPPER PLATED
51* EDOIBG-1 END DIAMOND ORNAMENTAL INSET - BRUSHED GOLD PLATED
52 GOIG-1 GOTHIC ORNAMENTAL INSET - GOLD PLATED
52 GOIKG-1 GOTHIC ORNAMENTAL INSET - BLACK GOLD PLATED
52 GOIBC-1 GOTHIC ORNAMENTAL INSET - BRUSHED COPPER PLATED
52 GOIBG-1 GOTHIC ORNAMENTAL INSET - BRUSHED GOLD PLATED
53* EGOIG-1 END GOTHIC ORNAMENTAL INSET - GOLD PLATED
53* EGOIKG-1 END GOTHIC ORNAMENTAL INSET - BLACK GOLD PLATED
53* EGOIBC-1 END GOTHIC ORNAMENTAL INSET - BRUSHED COPPER PLATED
53* EGOIBG-1 END GOTHIC ORNAMENTAL INSET - BRUSHED GOLD PLATED
54 SOIG-1 SEASHELL ORNAMENTAL INSET - GOLD PLATED
54 SOIKG-1 SEASHELL ORNAMENTAL INSET - BLACK GOLD PLATED
54 SOIBC-1 SEASHEL ORNAMENTAL INSET - BRUSHED COPPER PLATED
54 SOIBG-1 SEASHELL ORNAMENTAL INSET - BRUSHED GOLD PLATED
55* ESOIG-1 END SEASHELL ORNAMENTAL INSET - GOLD PLATED
55* ESOIKG-1 END SEASHELL ORNAMENTAL INSET - BLACK GOLD PLATED
55* ESOIBC-1 END SEASHEL ORNAMENTAL INSET - BRUSHED COPPER PLATED
55* ESOIBG-1 END SEASHELL ORNAMENTAL INSET - BRUSHED GOLD PLATED
56 EOIG-1 ECLIPSE ORNAMENTAL INSET - GOLD PLATED
56 EOIKG-1 ECLIPSE ORNAMENTAL INSET - BLACK GOLD PLATED
56 EOIBC-1 ECLIPSE ORNAMENTAL INSET - BRUSHED COPPER PLATED
56 EOIBG-1 ECLIPSE ORNAMENTAL INSET - BRUSHED GOLD PLATED
57* EEOIG-1 END ECLIPSE ORNAMENTAL INSET - GOLD PLATED
57* EEOIKG-1 END ECLIPSE ORNAMENTAL INSET - BLACK GOLD PLATED
57* EEOIBC-1 END ECLIPSE ORNAMENTAL INSET - BRUSHED COPPER PLATED
57* EEOIBG-1 END ECLIPSE ORNAMENTAL INSET - BRUSHED GOLD PLATED
58* W323-K STANDARD DOOR ASSEMBLY - FOR FACE C/WHOOD
59* W324-K STANDARD DOOR ASSEMBLY - FOR END C/WHOOD
FORFOR
FORFOR
FOR
WARRANTYWARRANTY
WARRANTYWARRANTY
WARRANTY
REPLREPL
REPLREPL
REPLAA
AA
ACEMENTCEMENT
CEMENTCEMENT
CEMENT
PP
PP
PARAR
ARAR
ARTSTS
TSTS
TS, ,
, ,
, AA
AA
A
PHOPHO
PHOPHO
PHOTT
TT
TOCOPYOCOPY
OCOPYOCOPY
OCOPY
OFOF
OFOF
OF
THETHE
THETHE
THE
ORIGINALORIGINAL
ORIGINALORIGINAL
ORIGINAL
INVOICEINVOICE
INVOICEINVOICE
INVOICE
WILLWILL
WILLWILL
WILL
BEBE
BEBE
BE
REQUIREDREQUIRED
REQUIREDREQUIRED
REQUIRED
TOTO
TOTO
TO
HONOURHONOUR
HONOURHONOUR
HONOUR
THETHE
THETHE
THE
CLAIMCLAIM
CLAIMCLAIM
CLAIM..
..
.
* IDENTIFIES ITEMS WHICH ARE NOT ILLUSTRATED. FOR FURTHER INFORMATION, CONTACT YOUR NAPOLEON DEALER.
