NATHAN JAMES Keanu Media Unit 75101 User manual

Keanu Media Unit
Let’s build the
23-0208
Scan me!
Free Lifetime
Warranty
45
4
5
M
I
N
U
T
E
A
S
S
E
M
B
L
Y
SKU 75101

2
This should be easy, just follow
our instructions and you will be
back to Netflix in no time.
Ok, let’s
get rolling
What’s included
What you need
• Some of your favourite bubbly
or your preferred relaxant
• Use the packaging carton as
a working surface to prevent
product damage during assembly
• Phillips head screwdriver
• 5/16” Drill bit
Description Qty
ATop 1
B Left Side Panel 1
C Right Side Panel 1
D Middle Panel 1
E Left Back Corner 1
F Right Back Corner 1
G Back Panel 1
H Bottom Panel 1
I Door 1
J Shelf 2
K Wall Cleat 1
45:00
Estimated time for assembly
100
lbs
Weight Limitation
Toll-free at 1-866-619-1004
[email protected]
Nathanjames.com/help Scan me!
Free Lifetime
Warranty

3
What’s included cont.
Description Qty
1 Cam Bolt 6
2 Cam Lock 6
3 6 x 30mm Wooden Dowel 16
4 ⁄ x 1 ⁄ inch Hex Button Head Bolt 10
5 ⁄ inch Flat Washer 10
6 1/4 inch Lock Washer 10
7T Nuts 6
8 Allen Key 1
9 Shelf Pin 8
10 Non-Drywall Wall Anchor 4
11 Drywall Wall Anchor 4
12 M4x50mm Screw 4

4
The goods
IMPORTANT
1. Do not tighten bolts / screws completely until all bolts / screws are lined up and
inserted into holes.
2. Do not over tighten screws and bolts to avoid stripping.
3. Please use hand tools to assemble this product. Do not use power tools.
1 2 3 4 5 6
7 8 9 10 11 12
A
K
E
B
H
D
I
G
F
C
J
J

5
Let’s get this thing fired up! Secure the
Cam Bolts (1) into the Top Panel (A).
Step 1
A
A
1
1
1
1
1
1
1

6
Next, attach the Right Back Corner (E) to the Right Side Panel (B). Attach
the Left Back Corner (F) to the Left Side Panel (C). Align the holes with the
Wooden Dowels (3) and ⁄ x 38mm Bolts (4). Insert the Flat Washers (5)
and Lock Washers (6) to the Bolts (4) before assembling. Tighten to 100%
using the Allen Key (8).
Step 2
CF E
3
5
6
4
8
B
8

7
Next, attach the Left Side Panel (B), Right Side Panel (C) and
Middle Panel (D) to the Top (A). Align the holes with the Wooden
Dowels (3) and the Cam Bolts (1) you inserted in Step 1, then secure
with the Cam Locks (2) and the Bolts (4). Insert the Flat Washers (5)
and Lock Washers (6) to the Bolts (4) before assembling. Tighten to
100% using the Allen Key (8).
Step 3
C
A
D
8
4
2
8
A
6
5
B
3
3
1

8
Now slide the Back Panel (G) into the slits of the Right
Side Panel (C), Left Side Panel (B) and Top (A). Then
insert the Wooden Dowels (3) and T Nuts (7) to secure.
Step 4
3
3
7
7
B
D
G
C

9
Attach the Bottom Panel (H) to the rest of the unit. Align the holes with the
Wooden Dowels (3). Using the 1/4 x 38mm Bolts (4) with the Flat Washers (5)
and Lock Washers (6), secure the panel in place and tighten to 100% using
the Allen Key (8). Once tightened, carefully flip the unit over so it’s upright.
Flip over
Top
Back
Step 5
H
8
4
6
5
H

10
You’re over halfway done! Now would be a good
time to call in that pizza order.
Now let’s get those shelves in. Insert the Shelf
Pins (9) into the Left Side Panel (B), Right Side
Panel (C) and Middle Panel (D). Then slide the
Shelves (J) into place.
Step 6
J
J
99

11
Okay, time to attach the Door (K) to the rail. Before assembling, press down the
guide pins at the top of the Door. Then, align the wheels at the bottom of the Door
into the V-rail before aligning the guides at the top of the door with the U-rail at the
top of the cabinet. Once the door is aligned to both rails, press the guide button to
lock in place.
Step 7
Slide guide pins down
I
I

12
After attaching the Door, adjust the
height of the casters to ensure the
door slides smoothly.
Adjust for
door height
Slide guide pins
up and into rail
Step 8

13
Choose your desired media unit location on your wall. Using the wall anchor spacing
dimensions graphic below, begin to line up and mark where you will need to drill holes
for the Wall Anchors (10) or (11). You can also use the Wall Cleat (K) as a guide for
marking the hole locations.
Using a ⁄” drill bit, drill holes on the marks you made on your wall, then push the Wall
Anchors (1) or (11), for the proper wall type, into the holes.
Reminder:
Part 10 is for non-drywall
applications.
Part 11 is for drywall applications.
Helpful Tip:
You can use part K (Wall Cleat) as a guide
when marking the locations to drill.
273mm
273mm
273mm
700mm
Step 9: Wall Mounting
11
10

14
How to use drywall anchors
1. Drill hole with ⁄” drill bit. 2. Pinch and insert.
4. Anchor is secure when screw is
tightened to 100%.
3. Align the Wall Cleat (K) holes over the Wall
Anchors (10) or (11). Then tighten the screws into
place until secure.

15
Almost done! That pizza shoudl be here any minute…
Attach the Wall Cleat (K) to the wall, making sure the holes in the Cleat align with the
Wall Anchors (10) or (11). Use the M4 x 50mm Screws (12) to attach the Cleat to the wall,
leaving a small gap between the wall and the back of the screw for the unit to hang on.
Step 10
12
K
K
K

16
Finally, guide the unit onto the Wall Cleat
(K) to secure to the wall.
Time to enjoy your new media unit, and
that pizza!
Step 11

17
Give us a call 1-866-619-1004 or shoot us a message
at [e-mail] we will issue you a free
replacement with zero hassle.
We really don’t want you to go through the hassle of re-packaging your item
and sending it back, because let’s be honest…nobody has time for that.
No heartburn,
when we handle the return
Our way Their way
Give us a call
Replacement
Replacement
You
Re-package item
Schedule pick up
Track package
You

18
We want your product to last as long as possible, so we recommend that you
tighten the screws 2 weeks after assembly and for added safety check the
tightness of all screws every 2 months.
For proper care and treatment, please check our website
at NathanJames.com/products
DO NOT use for commercial purposes
DO NOT frolic on media unit
DO NOT use media unit as foot stool
DO NOT leave spilled liquid on media unit
DO NOT use media unit if damaged
DO NOT make temporary repairs
DO NOT use outdoors
Proper use
Safety first, fun later
Safe use of this product
starts with you.
Use this product responsibly with the primary
concern for your safety. Follow assembly
instructions carefully and inspect product upon
receipt and each use.
Nathan James and its parent companies cannot
be held legally responsible for any injuries or
death resulted from failure to follow instructions
or improper use of this product.
Do not modify the
structure of this
product in any way.
Our products have been tested to meet specific
safety measures as they were originally
intended to be sold. Any modifications will
present the risk of creating significant safety
issues which NJ will not be responsible for.

19
