NATHAN JAMES Wesley 74401 User manual

Wesley Media Console
Let’s build the
23-0323
Scan me!
Free Lifetime
Warranty
45
4
5
M
I
N
U
T
E
A
S
S
E
M
B
L
Y
SKU 74 401

2
• Somebubblyoryour
preferredrelaxant
• Usethepackagingcartonasa
workingsurfacetopreventproduct
damageduringassembly
• Phillipsheadscrewdriver
What’s included
Description Qty
ACam Bolt M6X35MM 8
BCam Lock M15X10MM 8
C Screw M4x35MM 12
D Screw M4x40MM 10
E Screw M4x25MM 16
F Bolt M6x60MM 8
G Magnetic Cabinet Catcher 2
H Wooden Dowel M6x30MM 28
I Allen Key 1
J Metal Pin Hinge 4
K Screw M3x14MM 4
L Screw M3x10MM 4
This should be easy, just follow
our instructions and you will be
back to Netflix in no time.
Ok, let’s
get rolling
What you need
• Some of your favourite bubbly
or your preferred relaxant
• Use the packaging carton as
a working surface to prevent
product damage during assembly
• Phillips head screwdriver
45:00
Estimated time for assembly
220
lbs table top
Weight Limitation
Toll-free at 1-866-619-1004
[email protected]
Nathanjames.com/help
Do not use a drill
Scan me!
Free Lifetime
Warranty
22
lbs per shelf

3
The goods
G
A
H
B
I
C
J
D
L
F
K
E
IMPORTANT
1. Do not tighten bolts / screws completely until all bolts / screws are lined up and
inserted into holes.
2. Do not over tighten screws and bolts to avoid stripping.
3. Please use hand tools to assemble this product. Do not use power tools.

4
What’s included
Description Qty
1 Top Panel 1
2 Bottom Panel 1
3 Left Side Panel 1
4 Right Side Panel 1
5 Back Panel 1
6 Middle Shelf 1
7 Left Cabinet Panel 1
8 Right Cabinet Panel 1
9 Left Cabinet Door 1
10 Right Cabinet Door 1
11 Feet 4
12 Front & Back Apron Panels 2
13 Apron Side Panels 2
14 Apron Corner Supports 4

5
The goods
1
5
3
7
2
9
10
6
8
4
11
12
13
14
14
13

6
How much wood could a
woodchuck chuck?…I apologize,
please insert Wooden Dowels (H)
into the Side Panels (3)(4)(6)(7)(8).
Helpful Tip: The zig-zag pattern
indicates an unfinished panel edge.
Step 1

7
Let’s get the shelf set up, you’re doing great! First, attach the Left Cabinet Panel (7) to the Middle
Shelf (6) using the M4x35mm Screws (C). Then attach the Right Cabinet Panel (8) to the other side
of the Middle Shelf (6) using the M4x35mm Screws (C). Be sure both cabinet panels align to the
holes and dowels in the Middle Shelf.
Step 2

8
Next, flip the shelf assembly (7 + 6 +
8) onto its front face; finished edges
face down with cord holes at the top.
Line up the Bottom Panel (2) with
the shelf assembly (7 + 6 + 8) with
its front facing down; back panel
groove at the top.
Secure shelf assembly to the Bottom
Panel (2) using the M4x35mm
Screws (C).
Step 3
Follow that up by
securing the Left Side
Panel (3) and Right
Side Panel (4) to the
Bottom Panel using the
M4x35mm Screws (C).

9
If you were able to believe in Santa
for 8 years, you can believe in
yourself to finish this assembly. Now
let’s get to inserting some Cam Bolts!
Insert the Cam
Bolts (A) into the
appropriate holes
in the Top Panel
(1). Then attach the
Magnetic Cabinet
Catcher (G) to the
Top Panel (1) using
the M3x14mm
Screws (K).
Let’s get those doors put
together.
Attach the Magnetic Door
Catch Plates (G) using the
M3x10mm Screws (L).
Step 4
Step 5

10
Flip the unit up onto the
bottom panel, then slide the
Back Panel (5) into place.
This next step will take a bit of
patience and coordination.
First, line up the holes and
hardware components
between the Top Panel (1) and
the rest of the unit.
Once aligned, you’ll want to
start getting your doors lined
up and in place by first pushing
the Metal Pin Hinges (J) into
place.
Next, you’ll want to be sure that
the Back Panel (5) is properly
set within its grooves on panels
1, 2, 3 and 4.
Finally, after everything is
aligned properly and sitting
flush, you will begin fastening
everything into place using the
Cam Locks (B).
See following page for Cam
Lock Assembly Quick Guide.
Step 6

11
How to use
cam locks
Did you know?
Cam locks are used to join two panels together,
usually the edge of one to the flat side of another.
If a cam lock seems to be spinning in place or is not “catching” or pulling the panels together as expected,
first remove the cam lock & try again while making sure that everything is properly positoned & oriented.
If you are still having issues getting things working as expected, first remove the cam lock then unscrew
the cam bolt slightly (less than 1 complete turn) to see if that helps with the alignment of the cam lock & bolt.
Still
having
issues?
First, your cam bolt (or cam pin) will need to be
properly inserted into the flat side of the board.
Important Note: Only tighten the cam bolt until
it is secure. Do not over-tighten.
Next, you will fit the proper hole on the edge of
the associated joining panel over the cam bolt.
Important Note: When installed properly, the
head of the cam bolt will be visible through the
larger hole on the side of the joining panel.
Next, you will notice the cam lock has a “C”
shaped back. Commonly, an arrow on the
front of the cam lock points in the same
direction as the open section on back.
Using these as your cue, insert the cam
lock into the large hole so the opening of
the “C” fits over the head of the cam bolt.
Using a screwdriver, you will turn the cam
lock until it stops, usually at 90º or 180º. You
will feel the panels pulling closer until they
are secured.
Important Note: Only turn the cam lock until
the panels are fully engaged & feel secure.
Turning too far may lead to hardware failure.

12
If not pizza, then Uber Eats? You’ve worked
hard enough today.
Using the Wood Dowels (H), fit the Front
and Back Apron Panels (12) and Apron
Side Panels (13) into place on the Bottom
Panel (2).
Important Note: Unfinished edges of all
the apron panels face downward, making
contact with the Bottom Panel (5).
Note: The hole position
should be pointed inward.
Step 7

13
Secure the apron to the body of the TV
stand using the M4x40mm Screws (D).
Step 8

14
Secure the Apron Corner
Supports (14) to the apron.
Step 9

15
Last but not least, attach the Legs
(11) using the M6x60mm Bolts (F).
Use the Allen Key (I) to tighten.
You’re done! Time to go enjoy
your well-deserved slice and
Netflix episode!
Step 10
2
11
11
11
I
F
F
11

16
Give us a call 1-866-619-1004 or shoot us a message
at [e-mail] we will issue you a free
replacement with zero hassle.
We really don’t want you to go through the hassle of re-packaging your item
and sending it back, because let’s be honest…nobody has time for that.
No heartburn,
when we handle the return
Our way Their way
Give us a call
Replacement
Replacement
You
Re-package item
Schedule pick up
Track package
You

17
We want your Wesley Media Console to last as long as possible, so we
recommend that you tighten the screws 2 weeks after assembly and for
added safety check the tightness of all screws every 2 months.
For proper care and treatment of wood please check our website
at NathanJames.com/products
DO NOT use for commercial purposes
DO NOT frolic on media console
DO NOT use console as foot stool
DO NOT leave spilled liquid on console top
DO NOT use console if damaged
DO NOT make temporary repairs
DO NOT use outdoor
Proper use
Safety first, fun later
Safe use of this product
starts with you.
Use this media console responsibly with
the primary concern for your safety. Follow
assembly instructions carefully and inspect
product upon receipt and each use.
Nathan James and its parent companies cannot
be held legally responsible for any injuries or
death resulted from failure to follow instructions
or improper use of this product.
Do not modify the
structure of this
product in any way.
Our products have been tested to meet specific
safety measures as they were originally
intended to be sold. Any modifications will
present the risk of creating significant safety
issues which NJ will not be responsible for.

18
Brooklyn Burdon
Founder, Nathan James
Did we do alright? Please spread the love!
If you are happy with your product, tell your friends
and family about us or even better leave us a review
online. Spreading the word gives us the opportunity
to make more people happy and keep our
prices low for your next purchase.
We are only in business
if you’re happy
For starters, thanks for being you.
Toll-free at 1-866-619-1004
[e-mail]
NathanJames.com/help
We do our best to ensure your furniture arrives without any problems, but occasionally mistakes
happen—as humans we are imperfect beings. In the event that a part is damaged or missing, we
will be more than happy to provide you with replacement part(s) for free.
Warranty
This product comes with a lifetime warranty from the date of purchase. Please use your phone to
scan the QR code to register your product or visit https://goo.gl/i9dk3q
