National Instruments CMS-9024 User manual

For information about configuring specific server and device settings, browse to
http://serverHostname:81 and click Help to launch the NI InsightCM Server
Configuration and Monitoring Help.
Useful Resources
For a complete list of documentation for NI InsightCM Enterprise, visit ni.com/info and
enter the Info Code insightcmdocs.
Services & Support
ni.com/services
CompactRIO Specifications and Module Pinouts
Visit ni.com/info and enter insightcmdocs
AI1
AI2
AI3
AI4
AI5
1
2
3
4
5
NI CMS-9024 and CMS-9068
Quick Start
NI Condition Monitoring Systems for NI InsightCM™Enterprise
376270A-01 Nov14
© 2014 National Instruments
All rights reserved.
Caution Before installing your device, read all product
documentation to ensure compliance with safety, EMC, and
environmental regulations.
Documentation
Ethernet Cable CMS-9024 or
CMS-9068
Blank USB Drive
Power Supply
Screwdriver
What You Need
Connect the controller to an Ethernet network using Ethernet port 1 on the
controller front panel.
Use a standard Category 5 (CAT-5) or better Ethernet cable to connect the controller
to an Ethernet hub.
You can start setting up devices independently from NI InsightCM Server. However, to
complete the setup, NI InsightCM Server must be online. The following flowchart shows
how the device setup depends on NI InsightCM Server.
This document prompts you to complete the server-related steps when necessary to
continue setting up the device.
1. This document assumes the device is mounted as desired. For physical dimensions and
mounting instructions, refer to the Maintaining Hardware document, available by visiting
ni.com/info and entering insightcmdocs.
2. This document assumes the device is unwired. If the device is already connected to
the network, a power source, and sensors, proceed to step 4.
1
1
Where to Go Next
Connect to Network
Before You Begin
Software
installation
Device added
to server
Verify device
and prepare for
provisioning
Additional system
configuration
NI InsightCM
Server Setup
Connect to network
and sensors
Connect to power
Provision device
Verify connectivity
Device
Setup
Refer to the NI Trademarks and Logo Guidelines at ni.com/trademarks for more information on National
Instruments trademarks. Other product and company names mentioned herein are trademarks or trade names of their
respective companies. For patents covering National Instruments products/technology, refer to the appropriate
location: Help»Patents in your software, the patents.txt file on your media, or the National Instruments
Patents Notice at ni.com/patents. You can find information about end-user license agreements (EULAs) and
third-party legal notices in the readme file for your NI product. Refer to the Export Compliance Information at ni.com/
legal/export-compliance for the National Instruments global trade compliance policy and how to obtain relevant
HTS codes, ECCNs, and other import/export data. NI MAKES NO EXPRESS OR IMPLIED WARRANTIES AS TO THE
ACCURACY OF THE INFORMATION CONTAINED HEREIN AND SHALL NOT BE LIABLE FOR ANY ERRORS. U.S.
Government Customers: The data contained in this manual was developed at private expense and is subject to the applicable
limited rights and restricted data rights as set forth in FAR 52.227-14, DFAR 252.227-7014, and DFAR 252.227-7015.

For information about configuring specific server and device settings, browse to
http://serverHostname:81 and click Help to launch the NI InsightCM Server
Configuration and Monitoring Help.
Useful Resources
For a complete list of documentation for NI InsightCM Enterprise, visit ni.com/info and
enter the Info Code insightcmdocs.
Services & Support
ni.com/services
CompactRIO Specifications and Module Pinouts
Visit ni.com/info and enter insightcmdocs
AI1
AI2
AI3
AI4
AI5
1
2
3
4
5
NI CMS-9024 and CMS-9068
Quick Start
NI Condition Monitoring Systems for NI InsightCM™Enterprise
376270A-01 Nov14
© 2014 National Instruments
All rights reserved.
Caution Before installing your device, read all product
documentation to ensure compliance with safety, EMC, and
environmental regulations.
Documentation
Ethernet Cable CMS-9024 or
CMS-9068
Blank USB Drive
Power Supply
Screwdriver
What You Need
Connect the controller to an Ethernet network using Ethernet port 1 on the
controller front panel.
Use a standard Category 5 (CAT-5) or better Ethernet cable to connect the controller
to an Ethernet hub.
You can start setting up devices independently from NI InsightCM Server. However, to
complete the setup, NI InsightCM Server must be online. The following flowchart shows
how the device setup depends on NI InsightCM Server.
This document prompts you to complete the server-related steps when necessary to
continue setting up the device.
1. This document assumes the device is mounted as desired. For physical dimensions and
mounting instructions, refer to the Maintaining Hardware document, available by visiting
ni.com/info and entering insightcmdocs.
2. This document assumes the device is unwired. If the device is already connected to
the network, a power source, and sensors, proceed to step 4.
1
1
Where to Go Next
Connect to Network
Before You Begin
Software
installation
Device added
to server
Verify device
and prepare for
provisioning
Additional system
configuration
NI InsightCM
Server Setup
Connect to network
and sensors
Connect to power
Provision device
Verify connectivity
Device
Setup
Refer to the NI Trademarks and Logo Guidelines at ni.com/trademarks for more information on National
Instruments trademarks. Other product and company names mentioned herein are trademarks or trade names of their
respective companies. For patents covering National Instruments products/technology, refer to the appropriate
location: Help»Patents in your software, the patents.txt file on your media, or the National Instruments
Patents Notice at ni.com/patents. You can find information about end-user license agreements (EULAs) and
third-party legal notices in the readme file for your NI product. Refer to the Export Compliance Information at ni.com/
legal/export-compliance for the National Instruments global trade compliance policy and how to obtain relevant
HTS codes, ECCNs, and other import/export data. NI MAKES NO EXPRESS OR IMPLIED WARRANTIES AS TO THE
ACCURACY OF THE INFORMATION CONTAINED HEREIN AND SHALL NOT BE LIABLE FOR ANY ERRORS. U.S.
Government Customers: The data contained in this manual was developed at private expense and is subject to the applicable
limited rights and restricted data rights as set forth in FAR 52.227-14, DFAR 252.227-7014, and DFAR 252.227-7015.

2
1
The rest of the setup process requires assistance from a server administrator with
permission to add and configure devices in NI InsightCM Systems Manager:
1. Ask the server administrator to add the device to Systems Manager.
2. Ask the administrator if you need to manually provision the device with an IP address
or credentials. If so, obtain a USB drive that contains the connection information file.
Wire sensors to C Series modules installed in the device chassis.
In a CMS-9024 device, only connect tachometers to the module in slot 1.
2
2
When you apply power to the controller, it starts up:
1. The POWER LED is lit while the device is powered on to indicate that the power
supply connected to the chassis is adequate.
2. After the device boots, the USER1 LED flashes steadily to indicate normal operation.
If you have access to NI InsightCM Systems Manager, make sure the device connects to
NI InsightCM Server successfully:
1. Browse to http://serverHostname:81 in a web browser on the same network
as NI InsightCM Server.
2. Log in to Systems Manager.
3. Click the Dashboard button, and then click the Devices tab. Verify the device appears
with a status of Online.
+
–
3
3
1. Connect the chassis grounding terminal to the grounding electrode system of your facility.
2. Connect the positive lead of the power source to either V terminal on the power
connector plug, and the negative lead to the C terminal.
If instructed by the server administrator, complete the following steps to manually
provision the device:
1. Insert the USB drive with the connection information in the USB port on the controller.
2. The USER1 LED lights solid, which indicates that the device is reading network and
connection properties.
You can remove the USB drive when the USER1 LED returns to blinking steadily.
4
4
5
5
6
6
Verify Device Is Added
to Server
Connect Sensors
to Modules
Provision Device Verify Connectivity
Verify Controller PowerConnect to Power
7
7
Caution The C terminals are internally connected to each other.
For instructions for these tasks, refer to the Getting Started with NI InsightCMTM
Server document (gettingStarted_InsightCMServer.pdf). To access this
document, visit ni.com/info and enter insightcmdocs or browse for
the file on the NI InsightCM Server USB installation media.
Refer to the module operating instructions manual for signal connections.
For a list of these documents, visit ni.com/info and enter insightcmdocs.

2
1
The rest of the setup process requires assistance from a server administrator with
permission to add and configure devices in NI InsightCM Systems Manager:
1. Ask the server administrator to add the device to Systems Manager.
2. Ask the administrator if you need to manually provision the device with an IP address
or credentials. If so, obtain a USB drive that contains the connection information file.
Wire sensors to C Series modules installed in the device chassis.
In a CMS-9024 device, only connect tachometers to the module in slot 1.
2
2
When you apply power to the controller, it starts up:
1. The POWER LED is lit while the device is powered on to indicate that the power
supply connected to the chassis is adequate.
2. After the device boots, the USER1 LED flashes steadily to indicate normal operation.
If you have access to NI InsightCM Systems Manager, make sure the device connects to
NI InsightCM Server successfully:
1. Browse to http://serverHostname:81 in a web browser on the same network
as NI InsightCM Server.
2. Log in to Systems Manager.
3. Click the Dashboard button, and then click the Devices tab. Verify the device appears
with a status of Online.
+
–
3
3
1. Connect the chassis grounding terminal to the grounding electrode system of your facility.
2. Connect the positive lead of the power source to either V terminal on the power
connector plug, and the negative lead to the C terminal.
If instructed by the server administrator, complete the following steps to manually
provision the device:
1. Insert the USB drive with the connection information in the USB port on the controller.
2. The USER1 LED lights solid, which indicates that the device is reading network and
connection properties.
You can remove the USB drive when the USER1 LED returns to blinking steadily.
4
4
5
5
6
6
Verify Device Is Added
to Server
Connect Sensors
to Modules
Provision Device Verify Connectivity
Verify Controller PowerConnect to Power
7
7
Caution The C terminals are internally connected to each other.
For instructions for these tasks, refer to the Getting Started with NI InsightCMTM
Server document (gettingStarted_InsightCMServer.pdf). To access this
document, visit ni.com/info and enter insightcmdocs or browse for
the file on the NI InsightCM Server USB installation media.
Refer to the module operating instructions manual for signal connections.
For a list of these documents, visit ni.com/info and enter insightcmdocs.
