CALIBRATION PROCEDURE
SCXI -1125
Introduction
This document contains information and step-by-step instructions for
verifying and calibrating the National Instruments SCXI-1125 signal
conditioning module.
What Is Calibration?
Calibration is a procedure of reading offset and gain errors from a device
and updating special analog calibration circuitry that corrects these errors.
National Instruments calibrates every SCXI-1125 module at the factory.
During the factory calibration process, the calibration constants are stored
in the non-volatile memory of the device. These values are loaded from
memory and used as needed by the device.
Why Should You Calibrate?
Offset and gain errors drift with time and temperature changes, which could
invalidate the factory-set calibration of a device and increase measurement
uncertainty. Calibration restores the device to its specified accuracy.
How Often Should You Calibrate?
The measurement accuracy requirements of your application
determine how often you should calibrate your SCXI-1125 module.
National Instruments recommends you perform a complete calibration
at least once every year. You can shorten this interval to six months or
90 days, based on the demands of your application.
™

SCXI-1125 Calibration Procedure 2 ni.com
Equipment and Other Test Requirements
This section describes the equipment, software, documentation, and test
conditions required for calibrating the SCXI-1125.
Test Equipment
Calibration requires a high-precision voltage source with at least 50 ppm
accuracy, a multiranging 5 1/2 digit digital multimeter (DMM) with
15 ppm accuracy, and a National Instruments E Series DAQ device.
National Instruments recommends the following instruments for
calibrating the SCXI-1125:
• Calibrator—Fluke 5700A
• DMM—NI 4060 or HP 34401A
• National Instruments E Series DAQ device
If these instruments are not available, use the accuracy requirements listed
above to select a substitute calibration standard.
Note If you do not have custom connection hardware, you will need a connector block
such as the National Instruments SCXI-1320, a shielded 68-pin connector cable, a 50-pin
ribbon cable, a 50-pin breakout box, and an SCXI adapter. These components give easy
access to the individual pins on the SCXI-1125 front and rear connectors.
Software and Documentation
You will need the following software and documentation to calibrate
the SCXI-1125 signal conditioning modules. You can find these on the
National Instruments Web site at ni.com/calibration:
• The latest version of the National Instruments NI-DAQ driver
•NI-DAQ Function Reference Online Help file
• NI-DAQ User Manual for PC Compatibles
Software
The SCXI-1125 calibration procedure requires the latest version of the
National Instruments NI-DAQ driver on the calibration system. The driver
supports a number of programming languages, including LabVIEW,
LabWindows/CVI, Microsoft Visual C++, Microsoft Visual Basic, and
Borland C++. When you install the driver, you only need to install support
for the programming language you will use.

©National Instruments Corporation 3 SCXI-1125 Calibration Procedure
Documentation
The NI-DAQ Function Reference Online Help file and NI-DAQ User
Manual for PC Compatibles containdetailedinformationonusingthe
NI-DAQ driver. The function reference online help file includes detailed
information on the driver functions. You can access the online help by
clicking Start»Programs»National Instruments DAQ»NI-DAQ Help.
The user manual provides instructions on installing and configuring
National Instruments DAQ devices. This manual also includes detailed
information on creating applications that use the NI-DAQ driver. These are
your primary references for writing your calibration utility. For further
information on the products you are calibrating, refer to your device user
manuals.
Test Conditions
Follow these guidelines to optimize the connections and the environment
during calibration:
•Keep connections to the SCXI module short. Long cables and wires act
as antennae, picking up extra noise and thermal offsets that can affect
measurements.
•Use shielded copper wire for all cable connections to the device.
Use twisted-pair wire to eliminate noise and thermal offsets.
•Maintain the temperature between 18 and 28 °C.
•Keep relative humidity below 80%.
•Allow a warm-up time of at least 15 minutes for the SCXI module and
30 minutes for the E Series device to ensure the measurement circuitry
is at a stable operating temperature.
Calibration
The calibration process consists of the following steps:
1. Setting up the device for testing.
2. Verifying the existing operation of the device to determine whether it
is operating within its specifications.
3. Adjusting the device with respect to a known voltage source.
4. Verifying that the device is operating within its specifications after
adjustments.

SCXI-1125 Calibration Procedure 4 ni.com
Setting Up Your Module
Complete the following steps to set up your module for testing:
1. Install the SCXI-1125 in slot 1 of the SCXI chassis.
2. Connect a 68-to-68-pin cable between the SCXI module and the
E Series DAQ device installed in the host computer.
3. Configure the hardware with Measurement & Automation Explorer
(MAX). For more information on configuring the system, refer to the
E Series device and SCXI module documentation.
Verifying Gain and Offset Errors
The verification procedure determines how well the SCXI-1125 module is
meeting its specifications. You can use this information to select the
appropriate calibration interval for your application.
Complete the following steps to verify gain and offset errors in the
SCXI-1125:
1. Read the Test Conditions section earlier in this document.
2. Refer to the specifications in Table 1 at the end of this document.
3. Connect the E Series device to the SCXI-1125.
4. Call Calibrate_E_Series to minimize the uncertainty associated
with the E Series device measurements. Set the following parameters:
•deviceNumber—The value assigned by MAX
•calOp—ND_SELF_CALIBRATE
•setOfCalConstants—ND_USER_EEPROM_AREA
•calRefVolts—0.0
5. Call AI_Configure to put the E Series device in bipolar mode. Set the
following parameters:
•deviceNumber—The value assigned by MAX
•chan—0
•inputMode—0
•inputRange—0
•polarity—0
•driveAIS—0
6. Call MIO_Config to enable dithering on the E Series device. Set the
following parameters:
•deviceNumber—The value assigned by MAX
•dither—1
•useAMUX—0

©National Instruments Corporation 5 SCXI-1125 Calibration Procedure
7. Connect the calibrator to the appropriate analog input, starting
with channel 0. Refer to Figure 1 to determine which pins on the
96-pin front connector correspond to the positive and negative inputs
of the specified channel. For example, the positive input for channel 0
(CH0+) is pin A32. The negative input for channel 0 (CH0–)ispin
C32. If you are using an SCXI-1320 terminal block connected to the
SCXI-1125, connect the calibrator to the CH0+ and CH0–inputs.
8. Call SCXI_Single_Chan_Setup to configure the module for
single-channel measurements. Set the following parameters:
•SCXIchassisID—The value assigned by MAX
•moduleSlot—1
•moduleChan—The same channel number from step 7
•DAQdeviceNumber—The device number assigned by MAX for
the E Series DAQ device
9. Call SCXI_Set_Gain to set the gain you want to test on the module.
Set the following parameters:
•SCXIchassisID—The ID obtained when the chassis is configured
with MAX
•moduleSlot—1
•channel—The channel number from step 7
•gain—The first gain value you want to test—you can find this
gain value in Table 1.
10. Call SCXI_Configure_Filter to configure the filter setting on the
module. Set the following parameters:
•SCXIchassisID—The ID obtained when the chassis is configured
with MAX
•moduleSlot—1
•channel—The channel number from step 7
•filterMode—1
•cutoffFrequency—10,000
11. Set the calibrator to output the test point voltage from Table 1.
12. Call DAQ _Op. Set the following parameters:
•deviceNumber—ThedevicenumberoftheDAQdevice
•channel—0
•gain—1 for 16-bit E Series devices or –1 for 12-bit E Series
devices
•count—5,000
•sampleRate—10,000

SCXI-1125 Calibration Procedure 6 ni.com
13. Call SCXI_Scale. Set the following parameters:
•SCXIChassisID—The value assigned by MAX
•moduleSlot—1
•channel—The same channel number from step 7
•SCXIgain—The same gain value from step 9
•TBgain—1
•DAQboard—The device number for the DAQ device
•DAQChannel—0
•DAQgain—1 for 16-bit devices, –1 for 12-bit devices
•numPoints—5.000
•binArray—The array returned from the DAQ_Op function
The result is a set of scaled voltages that you read from the SCXI
module.
14. Average the results returned from the SCXI_Scale function. Compare
the averaged result to the upper and lower limits in Table 1. If the result
falls within these limits, your module has passed this portion of the
test. If it does not, your module needs to be adjusted using the steps in
the next section, Adjusting for Gain and Offset Errors.
15. Repeat steps 8 through 14 for the remaining gains.
16. Repeat steps 7 through 15 for the remaining channels.
You have now finished verifying your SCXI-1125.
Note If all channels fall within the upper and lower limits, your device does not need to
be adjusted.
Adjusting for Gain and Offset Errors
The following two sections explain how to determine the gain and offset
errors of your SCXI-1125 and how to adjust the calibration constants to
correct for these errors.
Determining Gain and Offset Errors
Complete the following steps to determine the gain and offset errors of the
SCXI-1125:
1. Read the Test Conditions section.
2. Connect the E Series device to the SCXI-1125.
3. Call Calibrate_E_Series to minimize the uncertainty associated
with the E series device measurements. Set the following parameters:
•deviceNumber—The value assigned by MAX

©National Instruments Corporation 7 SCXI-1125 Calibration Procedure
•calOp—ND_SELF_CALIBRATE
•setOfCalConstants—ND_USER_EEPROM_AREA
•calRefVolts—0.0
4. Call AI_Configure to put the E Series device in bipolar mode. Set the
following parameters:
•deviceNumber—The value assigned by MAX
•chan—0
•inputMode—0
•inputRange—0
•polarity—0
•driveAIS—0
5. Call MIO_Config to enable dithering on the E Series device. Set the
following parameters:
•deviceNumber—The value assigned by MAX
•dither—1
•useAMUX—0
6. Call SCXI_Single_Chan_Setup to configure the module for
single-channel measurements. Set the following parameters:
•SCXIchassisID—The value assigned by MAX
•moduleSlot—1
•moduleChan—The channel you want to adjust
•DAQdeviceNumber—The device number assigned by MAX for
the E Series DAQ device
7. Call SCXI_Set_Gain.Set the following parameters:
•SCXIchassisID—The ID of the SCXI chassis obtained when you
configure the chassis with MAX
•moduleSlot—1, because the SCXI-1125 should be installed in
slot 1
•channel—The same channel number from step 6
•gain—The gain value you want to adjust. Refer to Table 1 for
acceptable gain values
8. Call SCXI_Configure_Filter to configure the filter setting on the
module. Set the following parameters:
•SCXIchassisID—The ID of the SCXI chassis obtained when you
configure the chassis with MAX
•moduleSlot—1
•channel—The same channel number from step 7

SCXI-1125 Calibration Procedure 8 ni.com
•filterMode—1
•cutoffFrequency—10,000
9. Connect the calibrator to the analog input you want to adjust. Refer
to Figure 1 to determine the pins on the 96-pin front connector that
correspond to the positive and negative inputs of the specified channel.
For example, the positive input for channel 0 is pin A32, which is
labeled CH0+. The negative input for channel 0 is pin C32, which
is labeled CH0–. If you are using an SCXI-1320 terminal block
connected to the SCXI-1125, connect the calibrator to the CH0+
and CH0–inputs.
10. Connect the DMM to the positive output on pin 3 (MCH0+) and
negative output on pin 4 (MCH0–) on the rear panel connector.
Figure 2 shows the 50-pin rear panel connector.
Tip For easy access to individual pins, use a screw terminal adapter connected to a
50-pin terminal block.
11. Set the calibrator voltage to the positive test point value in Table 1.
12. Read the voltage from the DMM. Record the actual DMM reading,
which is output1, and the calibrator output voltage, which is volt1,for
later use.
13. Set the calibrator to the negative test point value for the same gain.
Skip any input limits that are specified as 0.0 V. You need only upper
and lower limits for adjustment.
14. Read the voltage from the DMM. Record the actual DMM reading,
output2, and the calibrator output voltage, voltage2.
You now have two pairs of data points, (volt1,output1) and (volt2,
output2), where volt is the calibrator reading and output is the DMM
reading.
15. Convert the DMM voltage readings (output1 and output2)tobinary
readings (binary1 and binary2) by using one of the following
equations:
For example, using a 12-bit product such as a PCI-MIO-16E-1 and
obtaining a DMM reading of –9.9 V, you would have the following
results:
binary reading =(–9.9/20) × 212 =–2027.52
binary reading for 12-bit E Series products (binary) output
20
-----------------


212
×=
binary reading for 16-bit E Series products (binary) output
20
-----------------


216
×=

©National Instruments Corporation 9 SCXI-1125 Calibration Procedure
16. Record binary1 with volt1 and binary2 with volt2 for later use.
17. Repeat steps 7 through 16 for the remaining gain values you want to
adjust on this channel.
18. Repeat steps 6 through 17 for the remaining channels you want to
adjust.
You have determined the new calibration constants. Use these values in the
the following section, Adjusting Calibration Constants.
Adjusting Calibration Constants
Complete the following steps to adjust the calibration constants on the
SCXI-1125:
1. Call SCXI_Cal_Constants to create and store the new calibration
constants in the SCXI-1125 memory. Set the following parameters:
•SCXIchassisID—TheIDassignedbyMAX
•ModuleSlot—1, because the SCXI-1125 should be installed in
slot 1
•channel—The channel on the SCXI-1125 you want to adjust
•OpCode—2
•calibrationArea—0
•rangeCode—0 (not used for the SCXI-1125)
•SCXIgain—The gain you want to adjust
•DAQboard—The device number assigned by MAX
•DAQChan —0
•DAQGain —1 for 16-bit devices, –1 for 12-bit devices
•Tbgain—1.0
•volt1 and volt2—The first and second voltage readings for the
gain values that you are about to save on the SCXI-1125
•binary1 and binary2—The first and second binary readings for
the gain values that you are about to save on the SCXI-1125
•calConst1 and calConst2—These are return values
2. Repeat step 1, changing calibrationArea to 1.
3. Repeat steps 1 and 2 for the next channel.
You have now finished adjusting the calibration constants of your
SCXI-1125.

SCXI-1125 Calibration Procedure 10 ni.com
Verifying Adjusted Values
After completing the adjustments to your SCXI-1125 module, it is
important that you verify the analog input operation by repeating the steps
listed in the Verifying Gain and Offset Errors section of this document.
Reverifying after adjustments ensures that your SCXI-1125 module is now
operating within its specifications.

©National Instruments Corporation 11 SCXI-1125 Calibration Procedure
Front and Rear Signal Connector Diagrams
Figure 1. Front Signal Connector Pin Assignments
CHSGND
+5 V
RSVD
CH7+
CH6+
CH5+
CH4+
CH3+
CH2+
CH1+
NC
NC
NC
NC
RSVD
CH0+
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
AB
RSVD
CJTEMP
RSVD
RSVD
CH7–
CH6–
CH5–
CH4–
CH3–
CH2–
CH1–
NC
NC
NC
NC
CH0–
C
This symbol indicates that no physical pin is present

SCXI-1125 Calibration Procedure 12 ni.com
Figure 2. Rear Signal Connector Pin Assignments
SERCLK
DIGGND
SLOT0SEL*
DAQD*/A
SERDATIN
OUTREF
MCH7+
MCH6+
MCH5+
MCH4+
MCH3+
MCH2+
MCH1+
MCH0+
AOGND
SCANCLK
SYNC
SERDATOUT
DIGGND
MCH7–
MCH6–
MCH5–
MCH4–
MCH3–
MCH2–
MCH1–
MCH0–
AOGND
49 50
47 48
45 46
43 44
41 42
39 40
37 38
35 36
33 34
31 32
29 30
27 28
25 26
23 24
21 22
19 20
17 18
15 16
13 14
11 12
910
78
56
34
12

©National Instruments Corporation 13 SCXI-1125 Calibration Procedure
Specifications
The following table contains the specifications you should use when
verifying and calibrating your SCXI-1125 module. If your device has been
calibrated within the last year, the test point value should fall between the
Upper Limit and Lower Limit values.
Table 1. SCXI-1125 Specifications at 25 °C ±10 °C
Gain Range Test Point Upper Limit (V) Lower Limit (V)
1 5 4.950000 4.9623181 4.9376819
1 0 0.000000 0.005002 –0.005002
1–5–4.950000 –4.9376819 –4.9623181
22.5 2.475000 2.4811601 2.4688400
2 0 0.000000 0.002502 –0.002502
2–2.5 –2.475000 –2.4688400 –2.4811601
5 1 0.990000 0.9924652 0.9875348
5 0 0.000000 0.001002 –0.001002
5–1–0.990000 –0.9875348 –0.9924652
10 0.5 0.495000 0.4962336 0.4937664
10 0 0.000000 0.000502 –0.000502
10 –0.5 –0.495000 –0.4937664 –0.4962336
20 0.25 0.247500 0.24811781 0.24688220
20 0 0.000000 0.000252 –0.000252
20 –0.25 –0.247500 –0.24688220 –0.24811781
50 0.1 0.099000 0.09924832 0.09875168
50 0 0.000000 0.000102 –0.000102
50 –0.1 –0.099000 –0.09875168 –0.09924832
100 0.05 0.0495000 0.04962516 0.04937484
100 0 0.000000 0.000052 –0.000052
100 –0.05 –0.049500 –0.04937484 –0.04962516
200 0.025 0.024750 0.02481358 0.02468642
200 0 0.000000 0.000027 –0.000027

SCXI-1125 Calibration Procedure 14 ni.com
200 –0.025 –0.024750 –0.02468642 –0.02481358
250 0.02 0.019800 0.01985126 0.01974874
250 0 0.000000 0.000022 –0.000022
250 –0.02 –0.019800 –0.01974874 –0.01985126
500 0.01 0.009900 0.00992663 0.00987337
500 0 0.000000 0.000012 –0.000012
500 –0.01 –0.009900 –0.00987337 –0.00992663
1000 0.005 0.00495 0.00496432 0.00493568
1000 0 0.000000 0.000007 –0.000007
1000 –0.005 –0.004950 –0.00493568 –0.00496432
2000 0.0025 0.002475 0.00248316 0.00246684
2000 0 0.000000 0.000005 –0.000005
2000 0.0025 –0.002475 –0.00246684 –0.00248316
Limits Valid for 4 Hz or 10 kHz Filter Settings
Valid when using an MIO device after performing an MIO internal calibration.
Valid for both filter settings with 5.000 point averaging at 10,000 samples per second.
Table 1. SCXI-1125 Specifications at 25 °C ±10 °C (Continued)
Gain Range Test Point Upper Limit (V) Lower Limit (V)
