natus Olympic Brainz Monitor User manual

Reference Manual

OBM Olympic Brainz Monitor Reference Manual 2
PN 027050 Rev 05 (Revision Date: December 2019)
Caution: Federal Law (U.S.) restricts this device to sale or use by or on the order of a physician (or properly
licensed practitioner).
© 2019 Natus Medical Incorporated. All rights reserved.
This manual may not be reprinted or copied in whole or in part without written consent from Natus Medical
Incorporated. The content of this manual may change without notice.
Natus Medical Incorporated
DBA Excel-Tech Ltd. (XLTEK)
2568 Bristol Circle
Oakville, Ontario
L6H 5S1 Canada
Telephone: [phone] (US/CAN)
Worldwide: [phone]
Technical Service [phone]
Technical Service Fax [phone]
E-mail: [email protected]
Customer Service [phone]
Customer Service Fax [phone]
E-mail: [email protected]
International Support - Please contact your local Distributor.
Distributor locations can be found at www.natus.com
European Authorized Representative
Natus Manufacturing Limited
IDA Business Park
Gort Co. Galway
Ireland

OBM Olympic Brainz Monitor Reference Manual 1
PN 027050 Rev 05
TABLE OF CONTENTS
INTRODUCTION...................................................................................................................................... 3
About This Manual .......................................................................................................................................... 3
Who Should Read This Manual........................................................................................................................ 3
Intended Use................................................................................................................................................... 3
Essential Performance..................................................................................................................................... 4
SAFETY INFORMATION........................................................................................................................ 4
Explanation of Terminology............................................................................................................................. 4
General Safety Information ............................................................................................................................. 4
Symbol Definitions .......................................................................................................................................... 8
Terms and Abbreviations............................................................................................................................... 11
OLYMPIC BRAINZ MONITOR SYSTEM OVERVIEW.................................................................... 12
Touch Screen Monitor ................................................................................................................................... 12
DAB ............................................................................................................................................................... 12
Connecting Cables ......................................................................................................................................... 12
Roll Stand ...................................................................................................................................................... 13
Other Items ................................................................................................................................................... 13
User Interface Screen .................................................................................................................................... 13
ASSEMBLY INSTRUCTIONS...............................................................................................................13
Olympic Brainz Monitor Packaging ................................................................................................................ 14
Assembling the Roll Stand ............................................................................................................................. 14
Attaching and Connecting the Components................................................................................................... 17
PREPARING THE OLYMPIC BRAINZ MONITOR FOR FIRST USE ...........................................19
Starting and stopping the Olympic Brainz Monitor........................................................................................ 19
Setting up the Olympic Brainz Monitor.......................................................................................................... 20
Changing the Language.................................................................................................................................. 20
Setting System Date and Time....................................................................................................................... 20
Activating and Configuring Detectors ............................................................................................................ 21
Selecting the Graphs to Display ..................................................................................................................... 21
Configuring Archive and Export Locations ..................................................................................................... 21
Checking for Normal Operation..................................................................................................................... 22
Adjusting screen brightness and audio volume ............................................................................................. 22
USING OLYMPIC BRAINZ MONITOR COMPONENTS .................................................................23
Moving the Olympic Brainz Monitor.............................................................................................................. 23
Adjusting the Touch Screen Monitor Position................................................................................................ 23
Using the Accessory Basket ........................................................................................................................... 24
Managing Cables ........................................................................................................................................... 24
RESTORING A SESSION AFTER AC POWER INTERRUPTION ................................................. 24
USING THE ONLINE HELP SYSTEM................................................................................................. 25

OBM Olympic Brainz Monitor Reference Manual 2
PN 027050 Rev 05
THE OLYMPIC BRAINZ VIEWER ......................................................................................................25
System Requirements.................................................................................................................................... 26
MAINTENANCE .....................................................................................................................................27
Checking for Normal Operation..................................................................................................................... 27
Cleaning ........................................................................................................................................................ 27
Routine Maintenance.................................................................................................................................... 28
Weekly Maintenance..................................................................................................................................... 28
Quarterly Maintenance ................................................................................................................................. 28
Annual Maintenance ..................................................................................................................................... 28
Calibrating the Olympic Brainz Monitor......................................................................................................... 29
Upgrading software....................................................................................................................................... 29
Servicing ........................................................................................................................................................ 30
SPECIFICATIONS .................................................................................................................................. 31
General Specifications ................................................................................................................................... 31
Display........................................................................................................................................................... 31
Accessory Basket ........................................................................................................................................... 31
Power Supply (External) ................................................................................................................................ 31
EEG Specifications ......................................................................................................................................... 31
Computed Parameters................................................................................................................................... 31
Display Modes............................................................................................................................................... 32
DAB Specifications......................................................................................................................................... 32
Environmental Specifications ........................................................................................................................ 32
STANDARDS COMPLIANCE AND NORMATIVE REFERENCES INFORMATION ..................33
Regulatory Standards of Compliance and Normative References .................................................................. 33
DECLARATION OF COMPLIANCE FOR IEC 60601-1-2 EDITION 4.0 ....................................34
Electromagnetic Emissions ............................................................................................................................ 34
Electromagnetic Immunity ............................................................................................................................ 34
DECLARATION OF COMPLIANCE FOR FCC...................................................................................36
REPLACEMENT PARTS....................................................................................................................... 37
AUTHORIZED SERVICE CENTERS ................................................................................................... 38
United States................................................................................................................................................. 38
Outside U.S.................................................................................................................................................... 38
APPENDIX A: ASSEMBLING THE TABLE STAND ........................................................................ 39

OBM Olympic Brainz Monitor Reference Manual 3
PN 027050 Rev 05
Introduction
About This Manual
This manual contains information that you need to assemble, configure, and safely operate
the Natus Olympic Brainz Monitor (OBM).
For instructions about operating the Olympic Brainz Monitor, applying a neonatal sensor set,
and checking for signal quality, see the Quick Start topic in the Olympic Brainz Monitor online
Help.
Important! It is important that you read the Quick Start section in the Olympic Brainz Monitor
Help before you use the neonatal sensor set.
Who Should Read This Manual
All users of the Olympic Brainz Monitor should read the Olympic Brainz Monitor Reference
Manual, particularly Safety Information on page 4.
Intended Use
The Olympic Brainz Monitor (OBM) is a three channel electroencephalograph (EEG)
acquisition system intended to be used in a hospital environment to record, collect, display
and facilitate manual marking of aEEG recordings.
•The signals acquired from P3-P4, C3-P3 and C4-P4 channels are intended for use
only with neonatal patients (defined as from birth to 28 days post-delivery, and
corresponding to a postconceptual age of 24 to 46 weeks) to display aEEG for
monitoring the state of the brain.
•The signals acquired from P3-P4 channel is intended to assist in the assessment of
Hypoxic-Ischemic Encephalopathy severity and long-term outcome, in full term
neonates (post-conceptual age of 37-46 weeks) who have suffered a hypoxic-
ischemic event.
•The RecogniZe seizure detection algorithm is intended to mark sections of
EEG/aEEG that may correspond to electrographic seizures in only the centro-parietal
regions of full term neonates (defined as from birth to 28 days post-delivery and
corresponding to a postconceptual age of 37 to 46 weeks). EEG recordings should be
obtained from centro-parietal electrodes (located at P3, P4, C3 and C4 according to
10/20 system). The output of the Recognize algorithm is intended to assist in post hoc
assessment of EEG/aEEG traces by qualified clinical practitioners, who will exercise
professional judgment in using the information.
•The Background Pattern classification algorithm is intended for neonatal patients,
defined as from birth to 28 days post-delivery, and corresponding to a post-conceptual
age of 37 to 46 weeks, in clinical environments such as the intensive care unit,
operating room, and for clinical research.
•To analyze and identify background patterns in aEEG, including continuous and
discontinuous activity, burst suppression, low voltage, and inactive patterns. The
aEEG must be obtained from a pair of parietal electrodes located at positions
corresponding with P3 and P4 of the International 10/20 System. The output of the

OBM Olympic Brainz Monitor Reference Manual 4
PN 027050 Rev 05
background pattern classification algorithm must be reviewed and interpreted by
qualified clinical practitioners.
The Olympic Brainz Monitor does not provide any diagnostic conclusion about the patient's
condition.
Essential Performance
This device is defined as continuous-use EEG equipment. Locating the equipment near a
source of electromagnetic interference may result in degradation of recorded EEG data. If
EEG data appears noisy, move the device farther from the source of the interference.
Safety Information
Explanation of Terminology
This manual presents three types of precautionary information. The three types of statements
carry equal weight; that is, they are of equal importance to the safe and effective use of the
device.Each statement is categorized by using an introductory word in boldface as follows:
Warning! Identifies conditions or practices that might present danger or possible injury to
the patient and/or user.
Important! An instruction provided to help ensure correct clinical results and provide quality
assurance to the device’s procedures.
Caution: An instruction that, if not followed, can result in a condition that could damage
the device.
Note:Information in this category is not considered precautionary, it is background
information provided to clarify a particular step or procedure.
General Safety Information
Before using the Olympic Brainz Monitor, read all sections of this manual carefully. Observe
all precautions to ensure the safety of the patient and those near the instrument. In addition,
please refer to your hospital policy and procedure for EEG administration.
Warnings!
Explosion hazard
•Do not use the Olympic Brainz Monitor in a flammable atmosphere (for example,
where concentrations of flammable anesthetics may be present).
Electrical shock hazard
•Do not open the enclosures of the touch screen monitor or DAB, especially when they
are connected to the AC supply outlet.
•Do not attempt to connect or disconnect the Olympic Brainz Monitor’s AC supply
cable with wet hands. Make certain your hands are clean and dry before touching the
AC supply cable.

OBM Olympic Brainz Monitor Reference Manual 5
PN 027050 Rev 05
•Disconnect the Olympic Brainz Monitor from any AC supply outlet before cleaning. Do
not use liquid or spray detergents.
•Take care to avoid spilling liquid into any opening in any part of the Olympic Brainz
Monitor. Do not submerge any component in liquid. This may cause fire or electrical
shock.
AC Supply Outlet
•Class 1 Device “WARNING: To avoid the risk of electric shock, this equipment must
only be connected to a supply mains with protective earth.” If a three-wire, grounded
supply outlet is not available, do not operate the Olympic Brainz Monitor.
Note: US only: Grounding reliability can be achieved only when the Olympic Brainz
Monitor is connected to a supply outlet marked “Hospital Only” or “Hospital Grade.”
•User is not to position ME equipment in such a way as to make it difficult to operate
the disconnection device.
Supply Voltage
•Make sure the supply voltage is correct before connecting the Olympic Brainz Monitor
to the AC supply outlet.
Power Cable
•Position the AC power cable so that it will not be stepped on or rolled over by wheeled
equipment.
Mounting on Roll Stand
•The Olympic Brainz Monitor utilizes a certified medical panel PC designed to
accommodate the standard VESA 75/100 mm mounting configuration. When
assembled as noted in the Technical Reference Manual and attached to the optional
roll stand (PN OBM00003) it is tested to meet the standards stated in this manual. It
is the customer’s responsibility to correctly assemble and attach the Olympic Brainz
Monitor (PN OBM00401) to the roll stand or any other mounting solution that meets
the same standards.
Loading of Accessory Basket
•The accessory basket attached to the Olympic Brainz Monitor Roll Stand is designed
to carry a load of no more than 4-1/2 lbs. (2 kg). Do not apply a load exceeding this
amount. To ensure stability, the accessory basket must be mounted within 32” (80
cm) of the floor.
Loading of Roll Stand
•The roll stand is designed to carry a load equal to the standard Olympic Brainz
Monitor components and any Natus-recommended optional accessories. Do not apply
a load exceeding the sum weight of these items.
Transporting the Olympic Brainz Monitor
•Before moving the Olympic Brainz Monitor, lower the touch screen monitor to its
lowest position on the roll stand and lock it firmly in position.
Use with High Frequency Electrosurgical Equipment
•Do no connect the Olympic Brainz Monitor to the patient while using
diathermy/electrosurgery or defibrillation equipment on the patient
Use with MRI or CT Scanners

OBM Olympic Brainz Monitor Reference Manual 6
PN 027050 Rev 05
•Do not use the Olympic Brainz Monitor in the vicinity of MRI or CT systems.
Personal Injury Hazard
•Ensure that the touch screen monitor is securely mounted on the roll stand to avoid
personal injury.
Patient strangulation hazard
•To minimize the risk of patient strangulation, position the DAB so as to minimize any
risk of the cables becoming wrapped around the patient’s throat.
Use of Accessory Equipment
•Use of accessory equipment that is not approved by Natus Medical Incorporated or
that does not comply with safety standards equivalent to those met by the Olympic
Brainz Monitor may lead to a reduced level of safety of the resulting system or failure
of the Olympic Brainz Monitor to operate correctly.
Connection to Accessory Equipment
•Accessory equipment connected to any accessory port of the touch screen monitor
unit (including USB ports and Ethernet connections) must be certified to applicable
IEC standards (IEC 60950 for data processing equipment and IEC 60601-1 for
medical equipment). All configurations shall comply with the medical electrical
systems standard IEC 60601-1-1. Anyone who connects additional equipment to such
an accessory port configures a medical system, and is responsible for ensuring that
the system complies with the requirements of the medical electrical systems standard
IEC 60601-1-1. If in doubt, contact an Authorized Service Center or Natus Medical
Incorporated.
Note: Ethernet connections and associated network infrastructure must not exceed
levels as defined in 60950-1.
•Network cables must be less than 3 meters in length.
Indications for Servicing
If any of the following situations occurs, stop using the Olympic Brainz Monitor immediately
and have it checked by your healthcare institution’s service personnel.
•The AC supply cable or attachment plug is damaged.
•The equipment has been exposed to moisture.
•The equipment does not work well, or does not work in the way described by this
document.
•The equipment has been dropped and damaged.
•The equipment has obvious signs of breakage.
Care when Touching Patient
•Do not touch any exposed metal parts at the rear panel of the touch screen monitor
unit (including connectors) while simultaneously touching a patient.
Electrical Stimulator Hazard
•Do not use the Olympic Brainz Monitor simultaneously with electrical stimulators.
Electromagnetic Immunity

OBM Olympic Brainz Monitor Reference Manual 7
PN 027050 Rev 05
•Use of this equipment adjacent to or stacked with other equipment should be avoided
because it could result in improper operation. If such use is necessary, this equipment
and the other equipment should be observed to verify that they are operating
normally.
•Use of accessories, transducers and cables other than those specified or provided by
the manufacturer of this equipment could result in increased electromagnetic
emissions or decreased electromagnetic immunity of this equipment and result in
improper operation.
•Portable RF communications equipment (including peripherals such as antenna
cables and external antennas) should be used no closer than 30 cm (12 inches) to
any part of the OBM Olympic Brainz Monitor , including cables specified by the
manufacturer. Otherwise, degradation of the performance of this equipment could
result.
Note: The Olympic Brainz Monitor is intended for use in an electromagnetic
environment in which radiated Electromagnetic disturbances are controlled; proper
precaution should be taken to prevent adverse events to Patient and Operator.
Olympic Brainz Monitor can help prevent electromagnetic interference by maintaining
a minimum distance of 30 cm (12 inches).
Cautions:
Read All Documentation
•Read this document, and any other operating instructions or other documentation
packed with the Olympic Brainz Monitor, carefully before operating the instrument in a
clinical setting. Keep this document for future use.
Do Not Autoclave
•Do not autoclave any component of the Olympic Brainz Monitor, as serious and
irreversible damage may result.
Ventilation
•Do not obstruct the passage of air behind or around the touch screen monitor or block
the ventilation inlet holes at its rear.
Indoor Use Only
•The Olympic Brainz Monitor is intended for indoor use only.
Conductive Parts
•Do not allow the conductive parts of the electrodes and associated connectors,
including the Reference (or neutral) electrode, to contact other conductive parts,
including ground, while the Olympic Brainz Monitor is being used for a monitoring
session.
Electrostatic Discharge
•Pins of connectors identified with the ESD warning symbol shall not be touched.
Disconnection of Cables or AC Supply
•Do not disconnect any of the cables connecting the Olympic Brainz Monitor’s
components, operate the power switch, or disconnect the AC supply, while the
Olympic Brainz Monitor is in use. If any of these conditions occurs accidentally,

OBM Olympic Brainz Monitor Reference Manual 8
PN 027050 Rev 05
reconnect the cables (if necessary) and resume the current recording session. See
Restoring a Session after AC Power Interruption on page 24.
Cleaning the Olympic Brainz Monitor
•Do not clean with concentrated bleach, corrosive chemicals, or abrasive cleaning
compounds.
Servicing the Olympic Brainz Monitor
•Do not open the enclosures of the touch screen monitor or DAB for any reason. If any
component is faulty, contact your healthcare institution’s service personnel or an
Authorized Service Center. See Authorized Service Centers on page 38.
Disconnect when not in Use
•If the equipment is not to be used for a long time, disconnect it from the AC supply
outlet to avoid damage by transient over-voltage.
Electromagnetic Compatibility
The Olympic Brainz Monitor complies with the electromagnetic compatibility requirements of
IEC 60601-1-2 along with particular standard requirements of IEC 60601-2-26. Operation of
the device may affect, or be affected by, nearby equipment, due to the effects of
electromagnetic interference. If this happens:
•Increase the separation between the Olympic Brainz Monitor and the other device.
•Reroute the device cabling.
•Plug the devices into AC supply outlets on separate circuit branches.
Operation of the Olympic Brainz Monitor may be affected by mobile and portable RF
communications equipment.
Refer to the Olympic Brainz Monitor Technical Manual (027051) for further compliance
information and advice relating to electromagnetic interference.
Symbol Definitions
Symbol
Standard
Reference
Standard Title Symbol Title Explanatory Text
IEC 60417-
5009
Graphical symbols for use
on equipment
Stand-by
Standby (power
on/off)
IEC 60417-
5031
Graphical symbols for use
on equipment
Direct current Direct current
IEC 60417-
5334 Graphical symbols for use on equipment
Defibrillation-
proof type BF
applied part
Defibrillation-proof
type BF applied part
equipment
ISO 7010-
M002
Graphical symbols - Safety
colours and safety signs -
Registered safety signs
Refer to
instruction
manual/booklet
Refer to operating
instructions manual
ISO 7000-
1641
Graphical symbols for use
on equipment - Registered
symbols
Operator's
manual; operating
instructions
Operating
instructions
ISO 7000-
0434A
Graphical symbols for use
on equipment - Registered
symbols
Caution Caution

OBM Olympic Brainz Monitor Reference Manual 9
PN 027050 Rev 05
Symbol
Standard
Reference
Standard Title Symbol Title Explanatory Text
ISO 7010-
W001
Graphical symbols - Safety
colours and safety signs -
Registered safety signs
General warning
sign Warning
21 CFR 801
Title 21 – Food and Drugs –
Chapter 1 – Food and Drug
Administration, Department
of Health and Human
Services (Continued) –
Subchapter H – Medical
Devices – Part 801 –
Labeling
Rx Only
US only: Caution:
US federal law
restricts this device
to sale by or on the
order of a physician
EN 50419
Marking of electrical and
electronic equipment in
accordance with Article
11(2) of Directive
2022/96/EC (WEEE)
WEEE markings
EU only: Do not
dispose of the
Olympic Brainz
Monitor as unsorted
municipal waste
IEC 60417-
5021 Graphical symbols for use on equipment Equipotentiality Equipotentiality
ISO 7000-
3650
Graphical symbols for use
on equipment - Registered
symbols
Universal Serial
Bus (USB),
port/plug
USB (e.g.,
connection to the
DAB, USB flash
drive, etc.)
ISO 7000-
3082
Graphical symbols for use
on equipment - Registered
symbols
Manufacturer Manufacturer
ISO 15223-
1 Clause
5.1.2
Medical devices - Symbols
to be used with medical
device labels, labelling and
information to be supplied -
Part 1: General
requirements
Authorized
representative in
the European
Community
Authorized
representative in the
European
Community
ISO 7000-
2497
Graphical symbols for use
on equipment - Registered
symbols
Date of
manufacture Date of manufacture
ISO 7000-
2607
Graphical symbols for use
on equipment - Registered
symbols
Use by date Use-By-Date
ISO 7000-
2492
Graphical symbols for use
on equipment - Registered
symbols
Batch code Batch code
ISO 7000-
2493
Graphical symbols for use
on equipment - Registered
symbols
Catalogue
number Catalogue number
ISO 7000-
2498
Graphical symbols for use
on equipment - Registered
symbols
Serial number Serial number
ISO 15223-
1 Annex B.2
Medical devices - Symbols
to be used with medical
device labels, labelling and
information to be supplied -
Part 1: General
requirements
Negation symbol Product was not made with natural
rubber latex

OBM Olympic Brainz Monitor Reference Manual 10
PN 027050 Rev 05
Symbol
Standard
Reference
Standard Title Symbol Title Explanatory Text
ISO 7000-
1051
Graphical symbols for use
on equipment - Registered
symbols
Do not re-use Do no re-use
ISO 7000-
2606
Graphical symbols for use
on equipment - Registered
symbols
Do not use if
package is
damaged
Do not use if
package is damaged
ISO 7000-
0624
Graphical symbols for use
on equipment - Registered
symbols
Keep away from
sunlight Keep away from sunlight
ISO 7000-
0626
Graphical symbols for use
on equipment - Registered
symbols
Keep away from
rain Keep dry
ISO 7000-
0623
Graphical symbols for use
on equipment - Registered
symbols
Temperature limit Temperature limit
ISO 7000-
2620
Graphical symbols for use
on equipment - Registered
symbols
Humidity
limitation Relative humidity limit
ISO 7000-
2621
Graphical symbols for use
on equipment - Registered
symbols
Atmospheric
pressure
limitation
Atmospheric
pressure limitation
ASTM
F2503
Table 1
Symbol 3
Standard Practice for
Marking Medical Devices
and Other Items for Safety
in the Magnetic Resonance
Environment
MR Unsafe Not safe to use in an
MR environment
Disposal of Equipment:
When the equipment comes to the end of its operating life, it should be disposed of in
accordance with local waste regulation authority, which is typically within the local government
office.

OBM Olympic Brainz Monitor Reference Manual 11
PN 027050 Rev 05
Terms and Abbreviations
The following table describes the terms and abbreviations used on the Olympic Brainz Monitor
and its packaging, or in this manual and other documentation.
Term or
Abbreviation
Meaning
Amplitude-
integrated
electroencephalogr
aph (aEEG)
A time-compression technique for presenting long EEG
recordings, using an asymmetrical filter, peak detector, rectifier,
and semi-logarithmic amplifier.
Artifact
Any electrical signal from an extra- cerebral source (for example,
electrode or cable movement, AC supply noise, ventilator noise).
Session
In this document, the term session refers to an examination of a
patient’s EEG activity using the Olympic Brainz Monitor.
Channel
A complete system for the amplification and conditioning of
electrical signals from two or more electrodes.
Data acquisition
box (DAB)
The DAB contains the interface between the low-level analog
signals detected by the neonatal sensor set and the digital
processing software of the Olympic Brainz Monitor. The DAB also
contains the medical isolation circuitry used to protect both the
patient and the instrument in the unlikely event of an electrical
fault. The DAB is normally positioned close to the patient, often
hung at the side of an incubator or cot.
Electrode
Conductor applied over, or inserted into, a region of the scalp to
detect electrical activity of the brain.
Electroencephalogr
aph (EEG)
Medical electrical equipment used to produce graphical recordings
and/or a visual display of electrical activity of the brain.
Frequency
The number of complete cycles of repetitive waves in one second,
measured in Hertz (Hz).
Impedance
The opposition to the flow of an electric current through a
conductor, which gives a measurement of the quality of contact
between the electrode and scalp. Impedance is measured in
kOhms (kΩ).
Neonatal sensor
set
A proprietary, non-invasive, self-adhesive sensor array used to
collect EEG signals from a neonate’s brain.
Reference
electrode
An electrode used as a reference point for the suppression of
interfering signals detected by other electrodes or their cables.
Sagittal suture
A serrated line at the top of the skull that is the junction of the two
parietal bones.
Tragus
The prominence in front of the external opening of the ear.
ESD
Electro Static Discharge – Electro static discharge is defined as
the transfer of electro static charges between bodies at different
potential caused by direct contact or induced by electro static field.

OBM Olympic Brainz Monitor Reference Manual 12
PN 027050 Rev 05
Olympic Brainz Monitor System Overview
The Olympic Brainz Monitor, a Cerebral Function Monitor (CFM), is a three-channel
electroencephalograph (EEG) that detects and records small electrical signals from both
hemispheres of the patient’s brain.
Figure 1: Olympic Brainz Monitor System
Touch Screen Monitor
The touch screen monitor processes the digital signal from the data acquisition box (DAB) and
displays the results on a touch-screen unit that allows you to control the Olympic Brainz
Monitor. The touch screen monitor is equipped with a medical-grade power supply.
DAB
The DAB converts the EEG signals from the sensors to digital form for processing. The DAB
also contains circuitry that protects both patient and equipment in the unlikely event of an
electrical fault.
Connecting Cables
The DAB is equipped with a permanently affixed USB 2.0 cable that provides a data circuit
between the DAB and the touch screen monitor. The USB 2.0 cable also provides the DAB
with DC power.

OBM Olympic Brainz Monitor Reference Manual 13
PN 027050 Rev 05
Roll Stand
The roll stand provides an adjustable mounting platform for Olympic Brainz Monitor
components and accessories. The roll stand features an adjustable pole, lockable wheels, and
an accessory basket.
Other Items
Other items supplied with the Olympic Brainz Monitor include the following:
•Data transfer accessories for transferring files to removable media.
•Literature and software that describe how to assemble and use the Olympic Brainz
Monitor.
•Disposable starter materials to help you learn how to apply a neonatal sensor set.
•Other items that can be used as optional accessories include the following:
•Printer (recommended: network printer).
User Interface Screen
The main user interface screen appears when you turn on the Olympic Brainz Monitor. This
screen displays the graphs, including aEEG, EEG, and Impedance. For more information
about these graphs, see online Help.
By touching the buttons displayed at the bottom of the screen, you can access the major
functions of the Olympic Brainz Monitor. The functions you can control from the main user
interface screen are:
•Patient — Examine previously recorded sessions, create a new session, and update
patient information for the current session.
•Markers — Add markers, navigate through a session to specific markers, and use
manual scoring tools to mark regions of the session for background patterns and
suspected seizure activity.
•Reports — Create snapshots of a session, print snapshots, and export session data in
comma-separated value (CSV) or European Data Format (EDF+) format so that it can
be imported into various data analysis tools.
•Tools — Manage session data, import sessions from and export sessions to external
media such as USB flash drives and network locations, manage session archiving,
configure various display settings, exit to the maintenance utility, and shut down the
Olympic Brainz Monitor.
•Help — View the Help system for conceptual and procedural information.
•Start and stop session recording.
Assembly Instructions
Note: Read this section as you unpack the Olympic Brainz Monitor from its shipping
packaging and before you begin to assemble the device.

OBM Olympic Brainz Monitor Reference Manual 14
PN 027050 Rev 05
Olympic Brainz Monitor Packaging
Depending on final configuration the Olympic Brainz Monitor is supplied in the following
separate packages:
•A large, narrow box that contains the roll stand components (extendable pole, base
with casters, power adapter/cable cleat, accessory basket assembly, and tilt mounting
bracket).
•A wide box that contains the touch screen monitor.
•A small box that contains the DAB with integrated USB 2.0 cable.
•A package that contains the AC power cable.
•A package that contains the RecogniZe Seizure Detection Software Kit,
•A small box that contains Olympic Brainz Monitor documentation, the Olympic Brainz
Viewer CD, a box of sensors, and a sensor application kit.
Assembling the Roll Stand
Stage 1: Unpacking the components
1. Unpack the components of the roll stand onto a large flat work surface. Keep the
contents of each carton separate.
2. Check the cartons carefully for fastenings and accessories (normally packed in small
plastic bags).
Stage 2: Attaching the accessory basket
Warning! To ensure stability, the accessory basket must be mounted within 32” (80 cm)
of the floor.
1. Clip one of the plastic mounting brackets onto the long side of the accessory basket
with the extra horizontal reinforcing. See Figure 2on page 15.
2. Slide the mounting bracket up the vertical ribs of the accessory basket.
3. Clip the other mounting bracket directly underneath the first one and slide into
position.
4. Locate the extendable pole.
5. Slide the accessory basket onto the bottom of the extendable pole, positioning it on
the lower part of the pole, within 32” (80 cm) of the floor.
6. Tighten the two Phillips screws to fasten the accessory basket to the extendable pole.

OBM Olympic Brainz Monitor Reference Manual 15
PN 027050 Rev 05
Figure 2: Assembling the accessory basket
Stage 3: Attaching the base to the extendable pole
1. Insert the bottom end of the pole in the base, ensuring that the locator pin is seated in
the slot provided.
2. Lay the roll stand on its side on an empty, flat work surface.
3. Align the two mounting holes in the foot pedal assembly with the two threaded
mounting holes in the bottom of the pole, ensuring that the foot pedal is positioned
between two legs of the base. See Figure 3on page 15.
4. Using the 3/16” hex key, fasten the pedal assembly to the pole with the two 1/4-20 x
3/4” socket head cap screws.
5. Turn the roll pole upright and check that the roll stand is steady. If it is unsteady, re-
tighten the socket head cap screws.
Figure 3: Assembling the base
Stage 4: Attaching the AC power and adapter cable cleat
Attach the two parts of the power adapter/cable mounting bracket to the extendable pole and
tighten the two Phillips screws. See Figure 4on page 16.

OBM Olympic Brainz Monitor Reference Manual 16
PN 027050 Rev 05
Figure 4: Attaching the power adapter/cable mounting bracket
Stage 5: Attaching the handle
Attach the two parts of the handle assembly to the extendable pole and tighten the two Phillips
screws. See Figure 5on page 16.
Figure 5: Attaching the AC handle
Stage 6: Attaching the tilt mounting bracket
1. Place the tilt mounting bracket on top of the extendable pole and position it on the
side facing the basket. Tighten the three Phillips screws. See Figure 6on page 17.
2. Affix the adhesive plastic screw cover to the top of the tilt mounting bracket.
3. Tighten the tilt adjustment lever.

OBM Olympic Brainz Monitor Reference Manual 17
PN 027050 Rev 05
Figure 6: Attaching the tilt mounting bracket
Attaching and Connecting the Components
Stage 1: Attaching the touch screen monitor
Warning! Before attaching the touch screen monitor, ensure that the height adjustment
knob and the tilt adjustment lever are firmly tightened.
The touch screen monitor is packaged in a separate carton.
1. Unpack the touch screen monitor and remove the plastic wrapping. Place the touch
screen monitor face down on a clean, smooth work surface.
2. Locate the four M4 x 16mm screws packaged with the tilt mounting bracket.
3. Attach the VESA mounting adapter to the back of the touch screen monitor using the
four M4 x 16mm screws. See Figure 7on page 17.
Figure 7: Attaching VESA mounting adapter to the touch screen monitor

OBM Olympic Brainz Monitor Reference Manual 18
PN 027050 Rev 05
4. Thread two M4 x 8mm screws into the two top threaded holes of the VESA mounting
plate, leaving 4mm of thread exposed. See Figure 8on page 18.
5. Slide the tilt mounting bracket on the roll stand such that the slots slide under the
screw heads. Note the roll stand is not shown to simplify the Figure. Thread the two
screws through the two holes on the bracket into the monitor. See Figure 8on page
18.
Figure 8: Attaching VESA mounting adapter to the touch screen monitor
6. Fully tighten all the screws.
Stage 2: Connecting the components
Using the Figure 9on page 19 as a guide, connect the:
•DAB to the touch screen monitor using the DAB’s integrated USB 2.0 cable (by using
one of the four USB 2.0 ports on the back of the touch screen monitor or one of the
two USB ports located under the side panel).
•Power adapter to the touch screen monitor.
Note: An equipotentiality terminal is provided to optionally connect to a hospital ground/earth
system.
