Bio-logic®AuDX®PRO quick start
Quick start guide
Doc. No.7-26-1385-EN/00
Part No.7-26-13805-EN
Bio-logic®

Quick Guide:
Bio-logic®AuDX®PRO Quick start
Otometrics - Next generation Bio-logic products
2
Bio-logic®
Note: this screen (test options) can vary depending on your set up
Turning On/Off and changing the device
Start menu
On/off button
on right side
Power supply
connector
Battery statusCurrent time
Customize settings
Turn off device
Select patient
View test result history
for selected patient
Additional information
about options for current
screen

Quick Guide:
Bio-logic®AuDX®PRO Quick start
Otometrics - Next generation Bio-logic products
3
Bio-logic®
Testing: Distortion Product Otoacustic Emissions (DPOAE) Screening
Connect the probe to the red connector.
Select one of the Presets for DPOAE Screening
Select the appropriate ear tip size and place it on the probe tip.
Insert the probe in the ear making sure that the ear tip fits tightly into the ear canal.
Select the test ear by pressing either the Right or Left button.
Cartoon mode will start the test showing a cartoon instead of the progress bar.

Quick Guide:
Bio-logic®AuDX®PRO Quick start
Otometrics - Next generation Bio-logic products
4
Bio-logic®
A calibration will be performed prior to measurement.
A green light indicates successful calibration (below left).
After successful ear probe calibration, the test will start automatically.
Probe fit override for patients
with PE tubes or tympanic
membrane perforation
Progress for each
test frequency
Overall test
progress
Noise floor
level

Quick Guide:
Bio-logic®AuDX®PRO Quick start
Otometrics - Next generation Bio-logic products
5
Bio-logic®
Overall screening
test result
Green check marks
indicate valid response.
Red circles indicate no
valid response
Red (right ear) or blue
(left ear) bars show
response amplitude.
Grey bars show noise
amplitude
Retest frequencies
that did not pass
Print results to a
label or to a pdf file
Test other ear
Switch to results of the other ear
after both ears have been tested
Note: These circles indicate that
other screens are available to view.
Swipe your finger right or left to
get other views.
DPOAE screening test results

Quick Guide:
Bio-logic®AuDX®PRO Quick start
Otometrics - Next generation Bio-logic products
6
Bio-logic®
Select the appropriate ear tip size and place it on the probe tip.
Insert the probe in the ear making sure that the ear tip fits tightly into the ear canal.
Select the test ear by pressing either the Right or Left button. Select Cartoon mode to start the test showing
a cartoon instead of the progress bar. This can be changed during the test by tapping on the plane
icon at the bottom of the device screen.
DPOAE diagnostic / high reolution
Connect the probe to the red connector.
Select one of the Presets for DPOAE Diagnostic.

Quick Guide:
Bio-logic®AuDX®PRO Quick start
Otometrics - Next generation Bio-logic products
7
Bio-logic®
A calibration will be performed prior to measurement. A green light indicates successful calibration. After
successful ear probe calibration, the test will start automatically. Please note that the presets for DPOAE
diagnostics are HiRes, which allows testing frequencies in 10 Hz increments or up to 30 points per octave.
Probe fit override for patients
with PE tubes or middle ear
perforations
Noise
floor level
Overall test
progress
Progress for each
test frequency
Skip a
frequency
Stop test
Resume test
Switch to
cartoon mode

Quick Guide:
Bio-logic®AuDX®PRO Quick start
Otometrics - Next generation Bio-logic products
8
Bio-logic®
Note: These circles indicate
that other screens are
available to view. Swipe
your finger right or left to
get other views.
Green check marks
indicate valid response
Red or blue bars indicate
response, grey bars
indicate noise
Print results to a
label or to a pdf file
Outcome for each test
sorted by f2 and L2.
Multilevel test results
shown. Tap on screen
to view details for each
level tested.
High resolution test results
(4 PPO)
Test
other
ear
Numeric values shown in
table format
DPOAE diagnostic test results

Quick Guide:
Bio-logic®AuDX®PRO Quick start
Otometrics - Next generation Bio-logic products
9
Bio-logic®
Quick Guide Information
Release date: 2017-01-11
Revision: 02
Valid from: Firmware Rev. 2.1, Mira PC Software Rev. 1.6.4
