Nautilus Be Strong F3WT User manual

Model: F3WT
P/N: 001-4100 Rev A (03/20/07)
Assembly Manual
Commercial Free Weights
Weight Tree
Be Strong.™

2
PREFACE/TABLE OF CONTENTS
Thank you for purchasing the Nautilus
®
Commercial Free Weights Weight Tree. For more than 30 years
Nautilus
®
has been producing the world’s finest fitness equipment used in health clubs and homes
around the globe. We hope this product exceeds your expectations and is a valuable tool for your facility.
Please carefully read through this manual to familiarize yourself with the operation of your new Nautilus
®
Commercial Free Weights Weight Tree. Doing so will help to insure that your users get the most out of
your Weight Tree, enjoying safe and effective workouts ahead.
Nautilus, Inc.
World Headquarters
16400 SE Nautilus Drive
Vancouver, Washington, USA 98683
1-800-NAUTILUS
www.nautilus.com
TABLE OF CONTENTS
Safety Precautions/
Product Specifications ..............................3
Before You Assemble.................................4
Hardware and Tools ...................................5
Box Contents ...............................................6
Assembly Guide ..........................................7
Assembly Complete....................................10
Companion Exercise Equipment...............11
Limited Warranty.........................................12
Important Contact Numbers .....................13

3
Nautilus® Commercial Free Weights Weight Tree Assembly Manual
SAFETY PRECAUTIONS/PRODUCT SPECIFICATIONS
IMPORTANT SAFETY INSTRUCTIONS
The following definition applies to the word “WARNING” when used in this manual:
Used to call attention to POTENTIAL hazards that could result in personal
injury or loss of life.
READ ALL INSTRUCTIONS BEFORE USING THE MACHINE.
PRODUCT SPECIFICATIONS
User Weight Capacity: 350 lbs / 158.7 kg
Dimensions (assembled): 38.7”w x 34”l x 37”h / 98.2 cm x 86.3 cm x 93.9 cm
Shipping Weight: 77.1 lbs / 35 kg
Net Weight: 70.5 lbs / 32 kg
Power Requirements: Self Generating
7!2.).'
!44%.4)/.
$!.'%2
)--%$)!4%!#4)/.2%15)2%$
#!54)/.
7!2.).'
!44%.4)/.
$!.'%2
)--%$)!4%!#4)/.2%15)2%$
#!54)/.
7!2.).'
!44%.4)/.
$!.'%2
)--%$)!4%!#4)/.2%15)2%$
#!54)/.
For your safety, perform
all assembly steps in the
sequence given. Improper
assembly can lead to injury.
Some components can
be heavy or awkward
to handle. Get help if
necessary.

4
BEFORE YOU ASSEMBLE
Note: Throughout this manual, all references to the left or right
side and to the front or back are made as if you were standing on
a level surface and facing the Weight Tree.
Basic Assembly Principals
Here are few basic assembly tips that can make assembly of your
Nautilus®Commercial Free Weights Weight Tree quick and easy.
1. You can make the assembly process go faster by gathering the
pieces you need for each step prior to starting the step.
2. As a general rule, and for all fasteners on your Nautilus®
Commercial Free Weights Weight Tree , turning toward the right
will tighten, turning towards the left will loosen. An easy way to
remember this is by remembering the expression, “Lefty loosey,
righty tighty.”
3. Not all of the tools needed to assemble your Nautilus®
Commercial Free Weights Weight Tree are provided. Refer to
the Tool List. You may find the use of a utility knife or scissors
beneficial during the unpacking and assembly process.
4. It is recommended that you use two people to assemble your
Nautilus® Commercial Free Weights Weight Tree .
Positioning Your Nautilus® Commercial Free Weights Weight
Tree
Take great care when moving your Commercial Free Weights
Weight Tree into place prior to assembly.
The Weight Tree heavy and requires at least two people to safely
move from one location to another.

5
Nautilus® Commercial Free Weights Weight Tree Assembly Manual
REF # DESCRIPTION QTY
1 SCW-BHCS 0500-13x1.25 G2-BlkZ 6
2 WSH-FLAT 0500 REGULAR BLKZ 6
3 WRENCH, ALLEN HEX 5/16 BLK 1
HARDWARE CARD
HARDWARE NOT TO SCALE



HARDWARE AND TOOLS

6
BOX #1
REF # DESCRIPTION QTY
3ASSY, BRKT LOWER SUPPORT 1
4WEIGHT HORN, LONG 6
5MAIN LEG WELD 3
6ASSY, BRKT UPPER SUPPORT 1
7BUMPER, WEIGHT HORN 6
8HDWR CARD, F3WT 1
9F3WT ASSY INSTRUCTIONS 1
BOX CONTENTS
3
4
5
6
8
9
7

7
Nautilus® Commercial Free Weights Weight Tree Assembly Manual
Step 1: Attach Leg Weldments, Bottom Plate, and
Bottom Weight Horns
Locate the following for this step:
Parts:
• Ref 5, Leg Weldment Qty. 3
• Ref 4, Weight Horn Assembly Qty. 3
• Ref 3, Bottom Plate Qty 1
Hardware:
• Ref 1, 1/2’ x 1 1/4” Button Head Bolt Qty. 3
• Ref 2, 1/2” Washers Qty. 3
Tools:
• Ref 3, 5/16” Allen Wrench
Refer to Figure 1:
1-1 Insert the Weight Horn, open end first, into the
bottom hole of the Leg Weldment.
1-2 Using the Weight Horn as the nut, loosely fasten
the Bottom Plate using the 1/2” hardware.
1-3 Attach all three legs to the Bottom Plate in the
same manner.
The following instructions provide direction in assembling the Leg Weldments, Bottom and Top Plates, and Bottom and Top Weight
Horns and Bumpers for the Nautilus® Commercial Free Weights Weight Tree. All instructions in the manual are given with the
orientation of standing on a level surface and facing the machine.
Figure 1:
ASSEMBLY GUIDE

8
Step 2: Attach Top Plate and Top Weight Horns to Leg
Weldments
Locate the following for this step:
Parts:
• Ref 5, Leg Weldment Qty. 3
• Ref 4, Weight Horn Assembly Qty. 3
• Ref 6, Top Plate
Hardware:
• Ref 1, 1/2 “ x 1 1/4” Button Head Bolt Qty. 3
• Ref 2, 1/2” Washers Qty. 3
Tools:
• Ref 3, 5/16” Allen Wrench
• 3/4” Wrench
Refer to Figure 2:
2-1 Insert the Weight Horn, open end first, into the
top hole of the Leg Weldment.
2-2 Using the Weight Horn as the nut, loosely fasten
the Top Plate using the 1/2” hardware.
2-3 Attach all three legs to the Top Plate in the same
manner.
2-4 With all three feet flat with the level surface,
securely fasten the hardware from Steps 1 and 2.
Figure 2:
ASSEMBLY GUIDE

9
Nautilus® Commercial Free Weights Weight Tree Assembly Manual
Step 3: Place Weight Horn Bumpers on Weight Horns
Locate the following for this step:
Parts:
• Ref 7, Weight Horn Bumper Qty. 6
• Ref 4, Weight Horn Assembly Qty. 6
Hardware:
• None
Tools:
• None
Refer to Figure 3:
3-1 Slide the Weight Horn Bumper over the Weight Horn
up to the Leg Weldment.
Figure 3:
ASSEMBLY GUIDE

10
Step 4: Inspect Assembly
Congratulations!
4-1 Assembly of your Nautilus
®
Commercial Free
Weights Weight Tree is now complete.
Be sure to fully inspect your Nautilus
®
Commercial
Free Weights Weight Tree before using
it for the first time.
7!2.).'
!44%.4)/.
$!.'%2
)--%$)!4%!#4)/.2%15)2%$
#!54)/.
Failure to visually check and
test the assembly before use can
cause damage to the Nautilus®
Commercial Free Weights Weight
Tree and serious injury to us-
ers and bystanders and can also
compromise the effectiveness of
your exercise program.
ASSEMBLY COMPLETE
