Nautilus Be strong NS 700X User manual

Be Strong.™
Model: NS 700X
P/N: 001-7001 Rev A (09/28/2006)
NS 700X
Assembly Manual

2
TABLE OF CONTENTS
Before You Assemble.................... 3
Product Specifications .................. 4
Product Features ........................... 4
Parts List / Box Contents ............. 5
Exploded View............................... 6
Hardware and Tool List ................ 7
Assembly Guide ............................ 8
Warranty Information ................... 24
Contacting Nautilus ...................... 25

3
Nautilus NS700X
BEFORE YOU ASSEMBLE
• At least 2 persons reccomended for assembly and installation.
Familiarize yourself with the illustrations to understand what the assembled NS700X will look like.
Select where you are going to locate your NS700X carefully. Assemble your NS700X in the location
and position where you intend to use it. You will need at least 36 inches (.91 meters) on each side of
the NS700X and 36 inches (.91 meters) behind your NS700X during assembly. The rear of the NS700X
can be closer to the wall during use but it is difficult to move after assembly and some room is needed
during assembly.
BASIC ASSEMBLY PRINCIPLES
Here are a few basic tips that will aid in the assembly of the Nautilus® NS700X. By using these
principles, you can simplify each process and save yourself extra time and effort.
1. To make the assembly process go faster, gather the pieces you need for each step and
thoroughly read the assembly instructions for that step prior to starting assembly for the step.
2. When tightening a locknut on a bolt, use a combination wrench to grip the locknut and ensure
that it is fastened securely.
3. When attaching two pieces, gently lift and look through the bolt holes to help guide the bolt
through the holes.
4. As a general rule, and for all bolts and nuts on your NS700X Home Gym, turn bolts or nuts
toward the right to tighten and left to loosen. Or you can remember the mnemonic: “Righty
tighty, lefty loosey.”
BEFORE YOU ASSEMBLE

4
PRODUCT SPECIFICATIONS
Primary Weight Stack
Lat Pulldown Bar
Adjustable Seat Back
Leg Extension
Multi Handle Grip
Press Arm Adjustment
Seat Height Adjustment
Dual Floating Pulley System
Exercise Placard
NOTE: All instructions in the manual are given with the orientation
of sitting on the machine ready to exercise.
User Weight Capacity: 300lbs / 136.1Kg
Dimensions: 96”w x 76”l x 83”h / 244 cm x 193 cm x 211cm
Shipping Weight: 672 lbs / 304.8 kg
Net Weight: 599.8 lbs / 272.1 kg
PRODUCT FEATURES

5
Nautilus NS700X
PARTS LIST / BOX CONTENTS
1 Rear Base Frame.................................................................1
2 Rear Top Frame ...................................................................1
3 Rear Support Upright A .....................................................1
4 Rear Support Upright B .....................................................1
5 Rear Upright ........................................................................1
6 Top Beam ............................................................................. 1
7 Front Upright ....................................................................... 1
8 Leg Extension Frame .......................................................... 1
9 Main Base ........................................................................... 1
10 Backing Plate ...................................................................... 3
11 Corner Plate ........................................................................ 1
12 Connecting Plate A ............................................................ 1
13 Connecting Plate B ............................................................ 1
14 Connecting Plate C .............................................................1
15 Connecting Plate D ............................................................ 1
16 Connecting Plate E .............................................................1
17 Pec Fly Mount .....................................................................1
18 Pec Fly Cam ......................................................................... 2
19 Left Pec Fly Arm .................................................................. 1
20 Right Pec Fly Arm ...............................................................1
21 Pec Fly Handle ....................................................................2
22 Press Arm Support Assembly .......................................... 1
23 Press Arm ............................................................................1
24 Right Press Arm Handle ....................................................1
25 Left Press Arm Handle ....................................................... 1
26 Press Arm Support Shaft .................................................. 1
27 Press Arm Pivot Shaft ........................................................ 1
28 Seat Pad ............................................................................... 1
29 Back Pad .............................................................................. 1
30 T handle Pop Pin ................................................................. 1
31 Seat Adjuster ...................................................................... 1
32 Seat Cross Tube ................................................................. 1
33 Back Pad Tube .................................................................... 1
34 Back Pad Adjustment ........................................................1
35 Back Pad Adjustment Plate ..............................................1
36 Pulley Bracket ..................................................................... 1
37 Pec Fly Pulley Bracket ....................................................... 1
38 Locking Roller Bar .............................................................. 1
39 Roller Bar ............................................................................. 1
40 Plastic Washer ................................................................... 2
41 PU Roller ..............................................................................2
42 8”L Foam Roller ................................................................... 2
43 PU Roller End Cap .............................................................. 2
44 Round End Cap .................................................................... 2
45 Power Spring Assembly ....................................................1
46 Front Plate ........................................................................... 1
47 Guide Tube .......................................................................... 2
48 High/Low Pulley Adjuster .................................................. 1
49 Swivel Arm Assembly ........................................................ 2
50 Guide Rod Holder ............................................................... 2
51 Guide Rod ............................................................................ 4
52 Top Weight ..........................................................................2
53 Selector Stem ..................................................................... 2
54 TopWeight/SelectorRodAssembly(52/53) ......................2
55 Weight Stack Bottom Plate ..............................................2
56 Weight Stack Bumper ....................................................... 4
57 6” Pulley ............................................................................... 1
58 41/2” Pulley .......................................................................... 27
59 Shroud ..................................................................................1
59a Accessory Hook ..................................................................3
60 Low Pulley Cover ................................................................ 2
61 Double Floating Pulley Bracket ........................................2
62 Cable Retaining Bracket ................................................... 2
63 Top Weight Pulley Housing .............................................. 1
64 Connecting Bench Bracket ..............................................1
65 Bench Connecting Plate ...................................................1
66 Weight Plate ........................................................................ 38
67 Plastic Cap ........................................................................... 4
68 Snap Cap .............................................................................. 2
Cable
69 #1 - Pull down Cable 263.75”L .......................................... 1
70 #2 - High/Low Pulley Cable 355.5”L ..................................1
71 #3 - Pec Fly Cable 150.5”L .................................................1
72 #4 - Secondary Cable 179.5”L............................................ 1
Hardware
73 Hex Bolt - 1/2” x 5 1/4”L ..................................................... 2
74 Hex Bolt - 1/2” x 3 1/4”L ..................................................... 1
75 Hex Bolt - 3/8” x 4 3/4”L ..................................................... 1
76 Hex Bolt - 3/8” x 4 1/4”L ..................................................... 5
77 Hex Bolt - 3/8” x 3 1/2”L ..................................................... 1
78 Hex Bolt - 3/8” x 3 1/4”L ..................................................... 8
79 Hex Bolt - 3/8” x 3”L ........................................................... 34
80 Hex Bolt - 3/8” x 2 3/4”L ..................................................... 6
81 Hex Bolt - 3/8” x 2 1/4”L ..................................................... 3
82 Hex Bolt - 3/8” x 2”L ........................................................... 17
83 Hex Bolt - 3/8” x 1 3/4”L ..................................................... 4
84 Hex Bolt - 3/8” x 1 1/2”L
with thread lock .................................................................. 3
85 Cap Head Allen Screw
3/8” x 3”L with thread lock ................................................ 2
86 Cap Head Allen Screw
1/4” x 1”L with thread lock ................................................ 4
87 Cap Head Allen Screw
1/4” x 1/2”L with thread lock ............................................ 2
88 Button Head Allen Screw
3/8” x 1 3/4”L ....................................................................... 2
89 Button Head Allen Screw
3/8” x 1”L (half threads) ..................................................... 1
90 Button Head Allen Screw
3/8” x 3/4”L .........................................................................4
91 Button Head Allen Screw
3/8” x 1/2”L with thread lock ............................................ 4
91a Button Head Self Tapping Screw 5/8” L.........................6
92 5/16” Set Screw 1/4”L ........................................................ 6
93 1 11/32 x 1/2” Flat Washer ................................................. 4
94 1/2” Flat Washer ................................................................. 6
95 3/8” Flat Washer ................................................................. 154
96 1/2” Lock Nut ....................................................................... 7
97 3/8” Lock Nut ....................................................................... 76
98 3/8” x 9/32t Lock Nut ..........................................................1
99 Shim Washer ....................................................................... 4
100 Step Spacer 19/32”H ..........................................................8
101 Pulley Spacer 1/2”L ............................................................4
114 3/8” Curved Washer............................................................4
Accessories
102 Lat Bar .................................................................................. 1
103 AB Strap ............................................................................... 1
104 Felt Back Ankle Strap ........................................................1
105 Handle Strap with 2 rings ..................................................2
106 Cable Clip ............................................................................. 3
107 Weight Selector Pin ...........................................................2
108 M4 Allen Wrench ............................................................... 1
109 M5 Allen Wrench ............................................................... 1
110 M6 Allen Wrench ............................................................... 1
111 M8 Allen Wrench ............................................................... 1
112 Weight Stack Decals .........................................................38
113 Shoulder Strap ....................................................................2
# DESCRIPTION QTY # DESCRIPTION QTY

6
24
EXPLODED VIEW
A. Compare the Bill of Materials to the box contents to insure that all parts are present before installation begins.
B. Unpackage parts and place them near the final asssembled location to avoid moving the gym when fully assembled.

7
Nautilus NS700X
HARDWARE AND TOOLS

8
# Component Qty
1 Rear Base Frame 1
2 Rear Top Frame 1
3 Rear Support Upright A 1
4 Rear Support Upright B 1
10 Backing Plate 2
11 Corner Plate 1
12 Connecting Plate A 1
14 Connecting Plate C 1
15 Connecting Plate D 1
78 Hex Bolt - 3/8” x 3 1/4”L 4
79 Hex Bolt - 3/8” x 3”L 8
95 3/8” Flat Washer 24
97 3/8” Lock Nut 12
Step 1 Components: Procedure:
A. Set the Rear Base Frame (1) in a position close to the gym’s final position.
B. Attach Rear Support Upright A and B (3) (4) to Rear Base Frame (1) using the
hardware shown. Do not tighten hardware. NOTE: Rear Support Upright A (3) is
the longer piece.
C. Attach Rear Top Frame (2) to Rear Support Upright A and B (3) (4) using Backing
Plate (10) and the hardware shown. Tighten all hardware securely.
D. Attach Corner Plate (11) and Connecting Plate D (15) to the Rear Base Frame (1)
using the hardware shown. Do not tighten hardware.
E.Attach Connecting Plate A and C (12) (14) to Rear Top Frame (2) using the
hardware shown. Do not tighten hardware.
ASSEMBLY
STEP 1

9
Nautilus NS700X
# Component Qty
5 Rear Upright 1
6 Top Beam 1
7 Front Upright 1
8 Leg Extension Frame 1
9 Main Base 1
10 Backing Plate 1
13 Connecting Plate B 1
16 Connecting Plate E 1
76 Hex Bolt - 3/8” x 4 1/4”L 5
79 Hex Bolt - 3/8” x 3”L 13
95 3/8” Flat Washer 36
97 3/8” Lock Nut 18
Step 2 Components: Procedure:
A. Attach Main Base (9) to Rear Base Frame (1) using Connecting Plate E (16) and the
hardware shown. Do not tighten hardware.
B. Attach Rear Upright (5) to Rear Base Frame (1) and Rear Top Frame (2) using
Connecting Plate B (13) and the hardware shown. Do not tighten hardware.
C. Attach Leg Extension Frame (8) to Main Base (9) usingthe hardware shown. Tighten
hardware securely.
CAUTION: Leg Extension Frame (8) is heavy. Use two people to assemble this
component.
D. Attach Front Upright (7) to Leg Extension Frame (8) using the hardware shown.
Tighten hardware securely.
E. Attach Top Beam (6) to Front Upright (7) and Rear Top Frame (2) using Backing
Plate (10) and the hardware shown. Tighten all frame hardware securely..
ASSEMBLY
STEP 2

10
# Component Qty
17 Pec Fly Mount 1
18 Pec Fly Cam 2
19 Left Pec Fly Arm 1
20 Right Pec Fly Arm 1
21 Pec Fly Handle 2
37 Pec Fly Pulley Bracket 1
67 Plastic Cap 4
78 Hex Bolt - 3/8” x 3”L 2
87 Cap Head Allen Screw
1/4” x 1/2”L with thread lock 2
93 1 11/32 x 1/2” Flat Washer 4
95 3/8” Flat Washer 8
96 1/2” Lock Nut 4
97 3/8” Lock Nut 4
99 Shim Washer 4
Step 3 Components: Procedure:
A. Attach Pec Fly Pulley Bracket (37) to Leg Extension Frame (8) using the hardware shown.
Tighten hardware securely.
B. Attach Pec Fly Mount (17) to Main Base (9) using the hardware shown.
Tighten hardware securely.
C. Slide Pec Fly Cam (18) onto Left Pec Fly Arm (19) paying close attention to the orientation
shown above. Attach the Left Pec Fly Arm (19) to the Pec Fly Mount (17) using the hardware
shown. Tighten hardware securely making sure that the Pec Fly Arm can rotate freely.
D. Repeat Step C using Right Pec Fly Arm (20).
E. Install Pec Fly Handle (21) in Left Pec Fly Arm (19) using the hardware shown. Tighten
hardware securely making sure that the Pec Fly Handle (21) can rotate freely. Install Cap
Head Allen Screw (87) to Pec Fly Handle (21) as shown. Tighten firmly.
NOTE: Make sure that the path of the Pec Fly Handle has a similar path shown in the TOP VIEW.
F. Repeat Step E using the Right Pec Fly Arm (20).
G. Install Plastic Cap (67) in the four locations shown. The Plastic Cap (67) should snap into place
locking around the Shim Washer (99).
ASSEMBLY
STEP 3

11
Nautilus NS700X
# Component Qty
22 Press Arm Support Assembly 1
23 Press Arm 1
24 Right Press Arm Handle 1
25 Left Press Arm Handle 1
26 Press Arm Support Shaft 1
27 Press Arm Pivot Shaft 1
90 Button Head Allen Screw
3/8” x 3/4”L with thread lock 4
59a Accessory Hook 3
91a Self Tapping Screw 5/8” L 6
114 3/8” Curved Washer 4
92 5/16” Set Screw 1/4”L 6
Step 4 Components: Procedure:
A. Attach Press Arm Support Assembly (22) to the Top Beam (6) using the Press Arm
Support Shaft (26). Align shaft and tighten the 4 Set Screws (92) firmly.
B. Remove Pop Pin from Press Arm (23). Attach Press Arm (23) to Press Arm Support
Assembly (22) using the Press Arm Pivot Shaft (27). Align shaft and tighten the two
Set Screws (92) firmly.
C. Attach Press Arm Handles (24) (25) using hardware shown. Tighten hardware
firmly.
D. Attach three Accessory Hooks (59a) Using the self tapping screws (91a) shown.
Tighten the hardware securly.
ASSEMBLY
STEP 4
114
59a
91a

12
# Component Qty
28 Seat Pad 1
29 Back Pad 1
30 T handle Pop Pin 2
31 Seat Adjuster 1
32 Seat Cross Tube 1
33 Back Pad Tube 1
34 Back Pad Adjustment 1
35 Back Pad Adjustment Plate 1
74 Hex Bolt - 1/2” x 3 1/4”L 1
79 Hex Bolt - 3/8” x 3”L 2
81 Hex Bolt - 3/8” x 2 1/4”L 2
83 Hex Bolt - 3/8” x 1 3/4”L 3
94 1/2” Flat Washer 3
95 3/8” Flat Washer 9
96 1/2” Lock Nut 2
97 3/8” Lock Nut 2
Step 5 Components: Procedure:
A. Attach Seat Cross Tube (32) to Seat Adjuster (31) using hardware shown. Tighten hardware
securely.
B. Attach Seat Pad (28) to Seat Cross Tube (32) and Seat Adjuster (31) using hardware shown.
Tighten hardware securely.
C. Install Seat Adjuster (31) in Leg Extension Frame (8) in the slot shown. Install Pop Pin (30)
using an adjustable wrench.
NOTE: Pop Pin is threaded so that the seat can be locked into position.
D. Attach Back Pad Tube (33) to Back Pad (29) using hardware shown. Tighten hardware
securely.
E. Attach Back Pad Tube (33) to Back Pad Adjuster (34) using hardware shown. Tighten
hardware securely making sure that the Back Pad Tube can rotate freely.
F. Attach Back Pad Adjustment Plate (35) to Back Pad Tube (33) using hardware shown, making
sure that the Back Pad Adjustment Pin rests inside the slot of the Back Pad Adjustment Plate
(35). Tighten hardware securely make sure the Back Pad Adjustment Plate can rotate freely.
G. Install Back Pad Adjuster (34) in Front Upright (7) in the slot shown. Install Pop Pin (30) using
an adjustable wrench.
ASSEMBLY
STEP 5

13
Nautilus NS700X
# Component Qty
38 Locking Roller Bar 1
39 Roller Bar 1
40 Plastic Washer 2
41 PU Roller 2
42 8”L Foam Roller 2
43 PU Roller End Cap 2
44 Round End Cap 2
Step 6 Components: Procedure:
A. Slide Roller Bar (39) through the Leg Extension Tube. Either of the bottom two holes
can be used depending on the best fit for the user.
B. Slide a Plastic Washer (40) followed by a Foam Roller (42) on the Roller Bar (39).
Press the Roller End Cap (44) firmly into the Roller Bar (39). Repeat for the opposite
side.
C. Slide the Locking Roller Bar (38) through the Leg Extension Tube as shown making
sure that it is centered. Slide the Eccentric Roller (41) on the Locking Roller Bar
(38). Press the Locking Roller End Cap (43) into the Locking Roller Bar (38). Repeat
for the opposite side making sure that the Eccentric Rollers are aligned.
ASSEMBLY
STEP 6

14
# Component Qty
45 Power Spring Assembly 1
46 Front Plate 1
47 Guide Tube 2
48 High/Low Pulley Adjuster 1
49 Swivel Arm Assembly 2
73 Hex Bolt - 1/2” x 5 1/4”L 2
75 Hex Bolt - 3/8” x 4 3/4”L 1
79 Hex Bolt - 3/8” x 3”L 6
80 Hex Bolt - 3/8” x 2 3/4”L 2
89 Button Head Allen Screw
3/8” x 1”L (half threads) 1
94 1/2” Flat Washer 2
95 3/8” Flat Washer 18
97 3/8” Lock Nut 9
98 3/8” x 9/32t Lock Nut 1
Step 7 Components: Procedure:
A. Place Guide Tubes (47) side by side on the floor with the adjustment holes facing each other.
Slide the Hi/Low Pulley Adjuster (48) onto the Guide Tubes (47) making sure that the Guide
Tubes are even and the Hi/Low Pulley Adjuster is locked into the middle adjustment holes.
Make sure that the plastic sleeves are still properly attached to the Hi/Low Pulley Adjuster
(48).
B. Attach the Guide Tubes (47) to the Rear Base Frame (1) using the hardware shown. Do not
tighten hardware. Carefully slide the Hi/Low Pulley Adjuster (48) to the bottom adjustment
hole. Align the guide rods and snug the hardware but do not tighten.
C. Attach the Power Spring Assembly (45) and Front Plate (46) to the Rear Top Frame (2) and
Guide Tubes (47) using the hard ware shown. Once assembled, tighten all hardware except
for the four bolts attaching the Guide Tubes (47) to the plates. Carefully raise the Hi/Low Pul
ley Adjuster (48) to the top adjustment hole. Align the guide rods and snug the hardware
but do not tighten.
D. Connect the Hi/Low Pulley Adjuster (48) to the Power Spring Cable using the hardware
shown. Tighten hardware securely.
E. Slide the Hi/Low Pulley Adjuster (48) up and down the Guide Tubes (47) making sure that it
does not bind. If necessary, loosen the connecting hardware for the Guide Tubes (47) and
reposition for better alignment. Once the Guide Tubes (47) are well aligned, tighten hardware
securely.
F. Attach the Swivel Arms (49) to the Hi/Low Pulley Adjuster (48) using the hardware shown.
Tighten hardware securely but allowing the Swivel Arms to rotate freely.
ASSEMBLY
STEP 7

15
Nautilus NS700X
# Component Qty
36 Pulley Bracket 1
50 Guide Rod Holder 2
51 Guide Rod 4
52 Top Weight 2
53 Selector Stem 2
55 Weight Stack Bottom Plate 2
56 Weight Stack Bumper 4
66 Weight Plate 38
86 Cap Head Allen Screw
1/4” x 1”L with thread lock 4
94 1/2” Flat Washer 1
96 1/2” Lock Nut 1
107 Weight Selector Pin 2
Step 8 Components: Procedure:
A. Slide Weight Stack Cushion (56) on two Guide Rods (51) allowing approximately 3” of Guide
Rod showing below the Weight Stack Cushion. Insert Guide Rods (51) into the holes in the
Rear Base Frame (1) as shown.
B. Slide Weight Stack Bottom Plate (55) on top of Weight Stack Cushions (56).
C. Place nineteen Weight Plates (66) and the Selector Rod/Top Plate Assembly (52 & 53) on the
Guide Rods (51) as shown. Install Weight Plates (66) so that the selector pin hole faces for
ward and is located on the bottom of the plate. Install the Selector Rod/Top Plate Assembly
(52 & 53) so that the head of the bolt is facing forward. This gym is supplied with individual
weight plate numbering decals that should be applied to the gym after the
weight stack is assembled.
D. Slide Guide Rod Holder (50) on the top of the Guide Rods (51) and attach the Guide Rod Holder
(50) to the Rear Top Frame (2) using the hardware shown. Tighten hardware securely.
E. Place Weight Selector Pin (107) in the bottom weight plate.
F. Repeat Steps A-E for the second weight stack.
G. Attach Pulley Bracket (36) to Rear Top Frame (2) using the hardware shown. Do not tighten
hardware.
ASSEMBLY
STEP 8

16
# Component Qty
58 4 1/2” Pulley 4
62 Cable Retaining Bracket 1
70 Cable #2 - High/Low Pulley Cable
356”L 1
79 Hex Bolt - 3/8” x 3”L 1
82 Hex Bolt - 3/8” x 2”L 2
84 Hex Bolt - 3/8” x 1 1/2”L
with thread lock 1
95 3/8” Flat Washer 7
97 3/8” Lock Nut 3
101 Pulley Spacer 1/2”L 2
Step 9 Components: Procedure:
A. Remove the Ball, Washer, and U-Bracket from one side of Cable #2 (70).
B. Route Cable #2 (70) through the Pulleys in the left Swivel Arm as shown. Continue to route
Cable around the two pulleys connected to the Rear Base Frame and then around the pulleys
located in the Rear Top Frame as shown.
C. Loop Cable #2 (70) around a 4 1/2” Pulley (58) and attach pulley to the Top Weight Pulley
Housing (63) using the hardware shown
in detail A. Tighten hardware securely. Attach the Top Weight Pulley Housing (63) to the
Selector Rod/Top Weight Assembly (52 & 53). Do not tighten hardware.
D. Loop Cable #2 (70) over a 4 1/2” Pulley (58) and attach pulley to the Rear Top Frame using the
hardware shown. Loop cable around a 4 1/2” Pulley (58) and attach pulley to the Rear Top
Frame using the Cable Retaining Bracket (62) and the hardware shown. Tighten hardware
securely.
E. Route Cable #2 (70) through the top tube of the Rear Top Frame making sure that the cable is
above the bolts. Remove bolt if necessary Loop Cable around a 4 1/2” Pulley (58) and attach
pulley using the hardware shown in detail B. Tighten hardware securely.
F. Route Cable #2 (70) around the pulley located on the Hi/Low Pulley Adjuster and continue to
route cable through the pulleys in the right swivel arm as shown.
G. Re-Install the Ball, Washer, and U-bracket to Cable #2 (70).
ASSEMBLY
STEP 9

17
Nautilus NS700X
# Component Qty
58 4 1/2” Pulley 14
61 Double Floating Pulley Bracket 2
62 Cable Retaining Bracket 1
68 Snap Cap 2
69 Cable #1 - Pull down Cable 263.75”L 1
80 Hex Bolt - 3/8” x 2 3/4”L 4
82 Hex Bolt - 3/8” x 2”L 8
85 Cap Head Allen Screw 3/8” x 3”L
with thread lock 2
95 3/8” Flat Washer 16
97 3/8” Lock Nut 12
100 Step Spacer 19/32”H 8
Step 10 Components: Procedure:
A. Thread one end of Cable #1 (69) into the Selector Rod/Top Plate Assembly as shown in
Detail A. Do not tighten locking nut.
B. Draw Cable #1 (69) over a 4 1/2” Pulley (58) and place it in the Pulley Bracket (36) making sure
that the lower section on the Pulley Bracket is between the guide rods. Attach the Pulley to
the Pulley Bracket using the hardware shown. Tighten hardware securely.
C. Loop Cable #1 (69) around a 4 1/2” Pulley (58) and attach the pulley to the Rear Top Frame (2)
using the Cable Retaining Bracket (62) and the hardware shown. Tighten hardware securely.
D. Loop Cable #1 (69) around a 4 1/2” Pulley (58) and attach the pulley to the bracket on the Rear
Top Frame (2) using the hardware shown. Proceed by looping the cable around another 4 1/2”
Pulley (58) and attaching it to inner hole of the Double Floating Pulley Bracket (61) using the
hardware shown. Tighten hardware securely.
E. Loop Cable #1 (69) around a 4 1/2” Pulley (58) and attach the pulley to the second bracket on
the Rear Top Frame (2) using the hardware shown. Proceed by looping the cable around
another 4 1/2” Pulley (58) and attach it to the top bracket on the Front Upright (7) using the
hardware shown. Tighten hardware securely.
F. Loop Cable #1 (69) around a 4 1/2” Pulley (58) and attach the pulley to the bracket on the Top
Beam (6) using the hardware shown. Proceed by looping the cable around another 4 1/2” Pul
ley (58) and attaching it to the outer hole of the Double Floating Pulley (61) using the hardware
shown. Tighten hardware securely.
G. Draw Cable #1 (69) over a 4 1/2” Pulley (58) and place the pulley in the slot on the Front Up
right (7) using the lower hole. Attach the pulley with the hardware shown in Detail B. Tighten
hardware securely.
H. Loop Cable #1 (69) around a 4 1/2” Pulley (58) and place it in the Press Arm Support
Assembly (22). Attach the pulley using the lower hole with the hardware shown in Detail B.
Tighten Hardware securely.
I. Loop Cable #1 (69) around a 4 1/2” Pulley (58) and place the pulley in the slot on the Front
Upright (7) using the upper hole. Attach the pulley using the hardware shown in Detail B.
Proceed by looping the cable around another 4 1/2” Pulley (58) and attaching the pulley to the
top hole in the Press Arm Support Assembly (22) using the hardware shown in Detail B.
Tighten hardware securely.
J. Loop Cable #1 (69) around a 4 1/2” Pulley (58) and attach the pulley to the Top Beam (6) using
the hardware shown in Detail C. Tighten hardware securely. NOTE: Leave the end of the cable
inside the Top Beam tube.
K. Feed Cable #1 (69) through the Top Beam tube and out the front slot. Draw cable around a 4
1/2” Pulley (58) and attach the pulley in the front slot using the hardware shown in Detail C.
Tighten hardware securely.
L. Attach Snap Caps (68) in the Press Arm Support Assembly (22) as shown.
ASSEMBLY
STEP 10
(See Diagram On Next Page)

18
NS700X Press Arm
ASSEMBLY
STEP 10

19
Nautilus NS700X
NS700X Press Arm
# Component Qty
58 4 1/2” Pulley 5
72 Cable #4 - Secondary Cable 179.5”L 1
77 Hex Bolt - 3/8” x 3 1/2”L 1
81 Hex Bolt - 3/8” x 2 1/4”L 1
82 Hex Bolt - 3/8” x 2”L 4
83 Hex Bolt - 3/8” x 1 3/4”L 1
95 3/8” Flat Washer 14
97 3/8” Lock Nut 7
101 Pulley Spacer 1/2”L 2
Step 11 Components: Procedure:
ASSEMBLY
STEP 11
A. Attach the looped end of Cable #4 (72) to the side of the Rear Upright (5) using the hardware
shown in Detail A. Tighten hardware securely, but do not overtighten.
B. Loop Cable #4 (72) around a 4 1/2” Pulley (58) and attach the pulley to the lever bracket on the Leg
Extension Frame (8) using the hardware shown. Tighten hardware securely.
C. Loop Cable #4 (72) around a 4 1/2” Pulley (58) and attach the pulley to the lower bracket on the
Rear Upright (5) using the hardware shown. Proceed by looping the cable around a 4 1/2”
pulley (58) and attaching the pulley to the bracket on the Rear Base Frame (1) using the hardware
shown. Tighten hardware securely.
D. Loop Cable #4 (72) around a 4 1/2” Pulley (58) and attach it to the lower hole in the Double
Floating Pulley (61) using the hardware shown. Proceed by looping the cable around a 4 1/2”
Pulley (58) and attach the pulley to the angled bracket on the Rear Base Frame (1) using the
hardware shown. Tighten hardware securely.
E. Attach the looped end of Cable #4 (72) to the bracket on the Rear Upright (5) using the hardware
shown. Tighten hardware firmly, but do not overtighten. NOTE: This cable termination can be
used for exercise attachments such as the leg press. If an attachment is installed, attach the
looped end of the Cable #4 (72) to the coupling on the attachment cable. Please refer to
attachment instructions for more details.

20
# Component Qty
57 6” Pulley 1
58 4 1/2” Pulley 4
60 Low Pulley Cover 2
71 #3 Pec Fly cable 150.5”L 1
82 Hex Bolt - 3/8” x 2”L 3
84 Hex Bolt - 3/8” x 1 1/2”L
with thread lock 2
88 Button Head Allen Screw
3/8” x 1 3/4”L 2
95 3/8” Flat Washer 12
97 3/8” Lock Nut 5
Step 12 Components: Procedure:
ASSEMBLY
STEP 12
A. Attach two 4 1/2” Pulleys (58) to the Pec Fly Pulley Bracket (37). Attach two 4 1/2” Pulleys (58) to
either side of the Leg Extension Frame (8) using the Low Pulley Cover (60) and the hardware
shown. Note the orientation of the Low Pulley Cover. Attach 6” Pulley (57) to the lower hole of the
Double Floating Pulley Bracket (61) using the hardware shown. Tighten all hardware securely.
B. Attach Cable #3 (71) termination to the left Pec Fly Cam (18) using the hardware shown. Be sure
to place the groove on the termination bracket against the Pec Fly Cam as shown in Detail A.
Tighten hardware securely
C. Draw Cable #3 (71) around the left pulley in the Pec Fly Pulley Bracket (37) as shown. Proceed by
looping the cable around the pulley on the left side of the Leg Extension Frame (8) as shown.
Be sure that the Low Pulley Cover does not interfere with the cable.
D. Loop Cable #3 (71) around the 6” Pulley in the Double Pulley Bracket (61) as shown. Proceed by
looping the cable around the pulley on the right side of the Leg Extension Frame (8) as shown.
Be sure that the Low Pulley Cover does not interfere with the cable.
E. Draw Cable #3 (71) around the right pulley in the Pec Fly Pulley
Bracket (37) as shown and attach the cable termination to the right Pec Fly Cam (18) using the
hardware shown. Be sure to place the groove on the termination bracket against the Pec Fly
Cam as shown in Detail A. Tighten hardware securely. NOTE: If
the cable termination does not reach the connection hole on the Pec Fly Cam, adjust the Pulleys
(58) in the Double Floating Pulley Brackets (61) to increase cable length.
