Nautilus NS 600X User manual

Be Strong.™
Model: NS 600X
P/N: 001-7002 Rev A (09/29/2006)
NS 600X
Assembly Manual

2
TABLE OF CONTENTS
Before You Assemble.................... 3
Product Specifications .................. 4
Product Features ........................... 4
Parts List / Box Contents ............. 5
Exploded View............................... 6
Hardware and Tool List ................ 7
Assembly Guide ............................ 8
Warranty Information ................... 20
Contacting Nautilus ...................... 21

3
Nautilus NS600X
BEFORE YOU ASSEMBLE
• At least 2 persons reccomended for assembly and installation.
Familiarize yourself with the illustrations to understand what the assembled NS600X will look like.
Select where you are going to locate your NS600X carefully. Assemble your NS600X in the location
and position where you intend to use it. You will need at least 36 inches (.91 meters) on each side of
the NS600X and 36 inches (.91 meters) behind your NS600X during assembly. The rear of the NS600X
can be closer to the wall during use but it is difficult to move after assembly and some room is needed
during assembly.
BASIC ASSEMBLY PRINCIPLES
Here are a few basic tips that will aid in the assembly of the Nautilus® NS600X. By using these
principles, you can simplify each process and save yourself extra time and effort.
1. To make the assembly process go faster, gather the pieces you need for each step and
thoroughly read the assembly instructions for that step prior to starting assembly for the step.
2. When tightening a locknut on a bolt, use a combination wrench to grip the locknut and ensure
that it is fastened securely.
3. When attaching two pieces, gently lift and look through the bolt holes to help guide the bolt
through the holes.
4. As a general rule, and for all bolts and nuts on your NS600X Home Gym, turn bolts or nuts
toward the right to tighten and left to loosen. Or you can remember the mnemonic: “Righty
tighty, lefty loosey.”
BEFORE YOU ASSEMBLE

NS600-X
REF# PART# DESCRIPTION
1 001-3474 . . . . . BASE MAIN NS 600 NS-X
3 001-3444 . . . . . Frame Top NS-X
4 001-3475 . . . . . UPRT FRNT NS 600 NS-X
5 001-3493 . . . . . ASSY LEG EXT FRM NS-X
6 001-3513 . . . . . MOUNT PULY NS-X
7 001-3426 . . . . . Frame Lower Pulley Calf Raise NS-X
8 001-3425 . . . . . Frame Top Stck Support NS-X
9 001-3433 . . . . . Cable Housing NS-X
10 001-3422 . . . . . Plate Backing 2 In NS-X
11 001-3420 . . . . . Plate Backing 3 In NS-X
12 001-3429 . . . . . Assy Press Arm Support NS-X
13 001-3428 . . . . . Press Arm NS-X
14 001-3430 . . . . . Handle Press Arm Right NS-X
15 001-3431 . . . . . Handle Press Arm Left NS-X
17 001-3472 . . . . . CAM PEC FLY NS-X
20 001-3450 . . . . . Pec Fly Handle NS-X
21 001-3471 . . . . . BRKT PEC FLY PULY NS-X
22 14128 . . . . . ADJUSTMENT,SEAT,NS CHROME
23 001-3421 . . . . . Tube Seat Cross NS-X
25 14456 . . . . . ADJUSTMENT BACKREST
26 001-3501 . . . . . PLATE BACKREST ADJ NS-X
27 001-3441 . . . . . Seat Pad NS-X
28 001-3440 . . . . . Back Pad NS-X
29 001-3432 . . . . . Floating Pulley Bracket NS-X
30 001-3434 . . . . . Double Floating Pulley Bracket NS-X
31 001-3434 . . . . . Double Floating Pulley Bracket NS-X
32 001-3506 . . . . . Guide Rod Holder NS-X
33 001-3470 . . . . . CVR LOW PULY NS-X
34 001-3419 . . . . . Back Pad Adjustment pop pin NS-X
35 14493 . . . . . ROLLER PU
36 95262 . . . . . NS Foam Roller 8"L
37 001-3480 . . . . . ENDCAP PU ROLLER NS-X
38 001-3462 . . . . . Leg Ext. Roller End Cap NS-X
39 92058 . . . . . 2 3/8" Plastic Washer
40 14460 . . . . . BAR LOCKING ROLLER
41 14100 . . . . . Bar Roller
42 001-3466 . . . . . Plastic Cap NS-X
43 14173 . . . . . 3 1/2" Pulley
44 14185 . . . . . 4 1/2" Pulley
45 14111 . . . . . Shaft Press Arm Support
46 14110 . . . . . Shaft Press Arm Pivot
47 001-3468 . . . . . Snap Cap Large NS-X
48 14205 . . . . . Top Weight
49 14427 . . . . . Wt Plate Each NS 10LB Gray
50 001-3507 . . . . . Plate Weight Stack Bottom NS-X
51 14176 . . . . . Weight Stack Cushion
52 14102 . . . . . Guide Rod
53 14791 . . . . . CBL PULLDOWN
54 14792 . . . . . CBL AB CRUNCH
55 14793 . . . . . CBL LOW ROW
56 14794 . . . . . CBL PEC FLY
57 901-7714 . . . . . BOLT HEX 1/2X3-1/4 NS-X
58 901-7654 . . . . . Hex Bolt 3/8" x 4 1/2"L NS-X
59 901-7653 . . . . . Hex Bolt 3/8" x 4 1/4"L NS-X

NS600-X
REF# PART# DESCRIPTION
60 901-7652 . . . . . Hex Bolt - 3/8" x 4"L NS-X
61 901-7649 . . . . . Hex Bolt - 3/8" x 3 1/4"L NS-X
62 901-7648 . . . . . Hex Bolt 3/8" x 3"L NS-X
63 901-7647 . . . . . Hex Bolt 3/8" x 2 3/4"L NS-X
64 901-7645 . . . . . Hex Bolt 3/8" x 2 1/4"L NS-X
65 901-7644 . . . . . Hex Bolt 3/8" x 2"L NS-X
66 901-7643 . . . . . Hex Bolt 3/8" x 1 3/4"L NS-X
67 901-3678 . . . . . BOLT HEX 3/8X1 - WLCKTITE NS-X
68 901-8025 . . . . . Cap Head Screw 1"L w/ locktite NS-X
69 902-6620 . . . . . BH dia 1/4" - 20 UNC x 1/2"L, with thread lock NS-X
70 901-8109 . . . . . Button Head Screw 1 3/4"L NS-X
71 902-6681 . . . . . BH Screw 1"L w/locktite NS-X
72 14476 . . . . . WSH FLAT 1 11/32" X 1"
73 902-2657 . . . . . Flat Washer 1" x 1/2" NS-X
74 902-3648 . . . . . WASHER FLAT 3/8 NS-X
75 92164 . . . . . Shim Washer
76 902-2909 . . . . . 1/2" Lock Nut NS-X
77 902-2905 . . . . . NS LOCK NUT HEX NYLON 3/8" NS-X
78 92122 . . . . . Pulley Spacer 1"L
79 92331 . . . . . Step Spacer 5/8"H
80 14795 . . . . . SPACER STEP 1"
81 901-6563 . . . . . Set Screw 5/16 x 1/4"L NS-X
82 902-8334 . . . . . SET SCREW 5/16X1/4 LCKTITE NS-X
83 001-3423 . . . . . Rower Bar NS-X
84 14215 . . . . . AB Strap
85 14217 . . . . . Felt Back Ankle Strap
86 14384 . . . . . Handle Strap with 2 rings
87 92053 . . . . . CHAIN WTSTK 12 LINK
88 001-3437 . . . . . Lat Bar NS-X
89 92054 . . . . . CABLE CLIP WTSTK LG
90 001-3443 . . . . . Weight Selector Pin NS-X
95 001-3394 . . . . . PAINT TOUCH UP NS-X
96 14535 . . . . . PAINT TOUCH UP GRAY
97 001-3669 . . . . . KIT,OM/AM NSX600
98 001-3588 . . . . . NS 600 Decal Kit
99 001-3657 . . . . . NS-X CURVED WASHER M10.5x23x2T
14160 . . . . . Pec Fly Bumper
14161 Lat Bar Hook Cover
14175 Top weight Bushing
14178 Press Arm Stop
14179 Back Adjustment Stop
14180 Back Adjustment Handle Cover
14184 Protection Label
14201 Step Spacer 31.1x25.1x47.5h
14206 GRIP TAP[E 8" X 6"
14271 6905 Bearing
14429 DECAL WEIGHT PLATE
14432 Spacer 35x36x2T
14433 Washer Spacer 25.5*41.5*1T
14449 SHAFT STEEL PULY
14450 SHAFT PIVOT LEG EXT
14452 ASSY SEAT
14468 BRKT SMALL PULY
14470 PULY LT STEEL

NS600-X
REF# PART# DESCRIPTION
14474 . . . . . PULY RT STEEL
14477 . . . . . SPACER PULLEY 35X26X12.8T
14478 . . . . . PIN DBLE PULY LOCKPIN W/CLIPS
14482 . . . . . PULY 6"
14484 . . . . . ASSY DBLE PULY
14487 . . . . . PULY SMALL
14489 . . . . . Hand Grip 6"L
14490 . . . . . Hand Grip 7 1/2"L
14491 . . . . . SPACER STEP 25X17X25.7H
14497 . . . . . CABLE,PULLEY
14508 . . . . . BEARING 6205
14530 . . . . . BOLT FLAT HD 3/8X3 LCKTITE
14621 . . . . . 1 3/8" Plastic Washer
14796 . . . . . NS 600 Step Spacer 21/32"H
17057 . . . . . 1/4" Lock Nut
92189 . . . . . Step Spacer 31 x 25.1 x 20h
93472 . . . . . SPACER STEP 19.45X12.8X18H
98780 . . . . . Nautilus Logo Plate
000-6953 . . . . . BUSHING WT PLATE
001-3393 . . . . . Foot Cap NS-X
001-3419 . . . . . Back Pad Adjustment pop pin NS-X
001-3445 . . . . . Handle,Pop Pin,NS-X Series
001-3454 . . . . . CAP PLSTC NS-X
001-3458 . . . . . 1 3/4" Square End Cap NS-X
001-3459 . . . . . End Cap, 2" Square NS-X
001-3460 . . . . . End Cap, 1" x 2" Rectangular NS-X
001-3461 . . . . . Roller End Cap NS-X
001-3463 . . . . . ENDCAP 1-1/2X2 NS-X
001-3464 . . . . . End Cap, 2" x 3" Rectangular NS-X
001-3465 . . . . . End Cap, 1 3/4" x 2" Rectangle NS-X
001-3467 . . . . . Snap Cap NS-X
001-3469 . . . . . PLATE CVR LEG EXT NS-X
001-3476 . . . . . ASSY LEG EXT NS-X
001-3477 . . . . . BRACKET LEVER NS-X
001-3478 . . . . . PIN LOCKING LEG HOLD DOWN NS-X
001-3479 . . . . . POP PIN LEG EXT NS-X
001-3482 . . . . . Press Arm Seat Pad NS-X
001-3508 . . . . . SHROUD,RR,NS200,300,600X
001-3662 . . . . . BRKT SMALL PULY
901-7216 . . . . . BH #8 x 5/8"L NS-X
901-7251 . . . . . BH Allen Screw 1/4" x 3/4" NS-X
901-7308 . . . . . BOLT HEX 3/8X3/4 NS-X
901-7312 . . . . . BOLT HEX 3/8X1-1/2 NS-X
901-8114 . . . . . Cap Head Screw 3"L w/locktite NS-X
901-8155 . . . . . Cap Head Screw 7/16 x 1 1/2"L NS-X
902-2949 . . . . . NUT HEX 1/2X11T 13UNC NS-X
902-3638 . . . . . Flat Washer 1/4" NS-X
902-6679 . . . . . BOLT BTN HD 3/8X3/4 LCKTITE NS-X
902-8333 . . . . . SET SCREW 3/8X1 LCKTITE NS-X

4
PRODUCT SPECIFICATIONS
NOTE: All instructions in the manual are given with the orientation
of sitting on the machine ready to exercise.
User Weight Capacity: 300lbs / 136.1Kg
Dimensions: 47”w x 72”l x 83”h / 119 cm x 183 cm x 211cm
Shipping Weight: 474.4 lbs / 215.2 kg
Net Weight: 408.3 lbs / 185.2 kg
PRODUCT FEATURES
Primary Weight Stack
Lat Pulldown Bar
Adjustable Seat Back
Leg Extension
Multi Handle Grip
Press Arm Adjustment
Seat Height Adjustment
Workout Placard

6
EXPLODED VIEW
A. Compare the Bill of Materials to the box contents to insure that all parts are present before installation begins.
B. Unpackage parts and place them near the final asssembled location to avoid moving the gym when fully assembled.
51
50
49
48
47
46
45
75
42
41
40
39
38 37
36
35
34
33
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
44b
83
87
84
86
85
90
43
44
88
89
52

7
Nautilus NS600X
HARDWARE AND TOOLS
1” 2” 3” 4” 5”
Hex Bolt
Button Head
Cap Head
Shim Washer
Lock Nut
Flat Washer
Step Spacer
Cable Clip
Required Tools:
9/16” or 14mm Wrench or Socket (Two Required)
3/4” Wrench or Socket
Adjustable Wrench
4, 5, 6 and 8mm Allen Wrenches (Included w/ Gym)
Flat Head
Self Drilling

20
Nautilus Fitness Products warrants to the original purchaser
of this Nautilus Home Gym to be free from defects in
materials or workmanship, with the exceptions stated below.
This warranty is not transferable or applicable to any person
other than the original purchaser.
What Is Covered
Nautilus Home Gyms
The frame and welds of the Nautilus Home Gyms are
warrantied to the original purchaser for life from date of
original purchaser. Upholstery, pulleys, bushings and
bearings are warrantied for ten years to the original
purchaser from date of purchase. Cables, grips, and all other
parts are warrantied to the original purchaser for a period of
1 year from date of purchase.
Warranties Do Not Cover
• A machine purchased for commercial or institutional use.
• Damage due to use by persons who weigh more than 300
pounds.
• Damage due to abuse, misuse, accident or acts of God
(such as floods).
• Consequential or incidental damages.
Some states do not allow the exclusion or limitation of inci-
dental or consequential damages, so the above limitation or
exclusion may not apply to you.
What We Will Do
Nautilus Fitness Products will repair any product that proves
to be a defect in materials or workmanship. In the event repair
is not possible, Nautilus Fitness Products, at its option, will
either replace your Nautilus Home Gym or refund your
purchase price.
To obtain service for a Nautilus Fitness Product, contact an
authorized Nautilus Fitness Retailer. You may also contact a
Nautilus company representative at 800-864-1270 to help you
locate a dealer in your area.
How To Get Service
This warranty gives you specific legal rights, and you may also
have other rights which vary from state to state.
How State Law Applies
WARRANTY INFORMATION

21
Nautilus NS600X
If you need assistance, please have both the serial number of your machine and the date of purchase available when you
contact the appropriate Nautilus office listed below.
WORLDWIDE CUSTOMER SERVICE
• NORTH AMERICA OFFICE
Nautilus, Inc.
World Headquarters
16400 S.E. Nautilus Drive
Vancouver, Washington, USA 98683
Phone: 800-NAUTILUS (628-8458)
Fax: [phone]
e-mail: [e-mail]
• NAUTILUS INNOVATION CENTER
Nautilus, Inc.
1886 Prairie Way
Louisville, Colorado, USA 80027
Phone: [phone]
Fax: [phone]
• CORPORATE HEADQUARTERS
Nautilus, Inc.
World Headquarters
16400 S.E. Nautilus Drive
Vancouver, Washington, USA 98683
Phone: 800-NAUTILUS
INTERNATIONAL CUSTOMER SERVICE
• INTERNATIONAL OFFICE
Nautilus International S.A.
Rue Jean Prouvé 6
1762 Givisiez / Switzerland
Tel: [phone]
Fax: [phone]
E-mail: [e-mail]
INTERNATIONAL OFFICES:
• SWITZERLAND OFFICE
Nautilus Switzerland S.A.
Tel: [phone]
Fax: [phone]
• GERMANY and AUSTRIA OFFICE
Nautilus GmbH
Tel: [phone]
Fax: [phone]
• ITALY OFFICE
Nautilus Italy s.r.l.
Tel: [phone]
Fax: [phone]
• UNITED KINGDOM OFFICE
Nautilus UK Ltd.
Tel: [phone]
Fax: [phone]
• CHINA OFFICE
Nautilus Representative Office
Tel: [phone]
Fax: [phone]
IMPORTANT CONTACT NUMBERS

22
Be Strong.™
For more information about our Nautilus Home Gyms or other Nautilus®
equipment for your home, visit www.Nautilus.com.
© 2006 Nautilus, Inc. All rights reserved. Nautilus, the Nautilus logo, My Nautilus, Heart Strong, Changing the Game in Health and Fitness, REACT, ROC, Remote Operation Control, SuperSoft, Hyperdrive, Be Strong
are either registered trademarks or trademarks of Nautilus, Inc.
Nautilus, Inc. World Headquarters, 16 400 SE Nautilus Drive, Vancouver, Washington, USA 98683, 1-800-628-8458, www.Nautilus.com.
