Navig8r NAVC-ARECH163 User manual

User Manual
Add-on Reverse Camera
NAVC-ARECH163

WHAT’S IN THE BOX
Reversing camera
with mount
12V trigger cable
(connect to reverse
lamp)
6m video
extension cable
Mounting screws
and tape

WIRING DIAGRAM
The video signal from the camera is transferred
to the monitor via the 6m video extension cable
that will need to be run through the boot, the
passenger compartment and under the dash to
connect to the monitor.
At the back of the car, the reversing tail lamp
powers the camera.
CH1/ CH2/ CH3/ CH4/
Camera
Power connector
Positive wire connects
to reversing lamp
(Not included)
Monitor
6m video
extension cable

WIRING DIAGRAM
continued..
(Connects to AV In port)
MF
12V + Power connector
Positive wire connects to
reversing lamp (Trigger)
Ground
Negative wire connects to
chassis or negative of lamp
Male
Power
connector
(Black)
Female
Power
connector
(Red)
Female
RCA
(Yellow / Video Signal)
Male
RCA
(Yellow / Video Signal)
Male
3.5mm jack
Monitor/Display
(Not included)
Video adapter cable
Power Harness
Reversing
Camera
+
Green wire
Connects to
reversing lamp
(Trigger)

NOTE: To prevent potential electrical shorts,
it is essential to disconnect the ( - )
negative battery cable before installing
the product.
1. Mount the camera. When mounting, ensure
that the camera does not cover any part of
the license plate. Choose a position that
won’t prevent you from accessing the boot
release or tailgate latch.
2. Connect the GREEN wire of the 6m video
extension cable, and the RED wire of the
trigger cable to the wire supplying power to
the reversing lamp, which is energised only
when the car is put into reverse.
NOTE: Before making the electrical connection
to the reversing lamp, make sure the
camera is not connected.
INSTALLATION

INSTALLATION
3. Connect the BLACK wire of the trigger
cable to chassis or negative of lamp.
4. Connect the BLACK plug from the trigger
cable to the RED socket from the camera.
5. Connect the YELLOW RCA socket from the
camera to the YELLOW RCA plug from the
6m video extension cable.
6. Run the 6m video extension cable through
the boot, the passenger compartment and
under the dash to where the CarPlay screen
will be located.
7. Connect the 3.5mm AV plug to the AV IN
socket of the CarPlay screen or your own
monitor.
8. Reconnect the ( - ) negative battery cable.
continued...
Thank you
for your purchase!

Thank you
for your purchase!
Laser Corporation is 100% Australian owned
& operated. To get the most out of your
product please read the user manual
carefully and keep for future use.
For specic information relating to your product
such as Spare Parts, FAQs, Warranty claims, and
more, please scan the following QR code:
