NavLinkz CI-VL1-CCC User manual

Version 25.02.2022 HW: V65 CI-VL1-CCC
Video-inserter
CI-VL1-CCC
BMW vehicles
with Professional navigation CCC,
Business navigation M-ASK or radio
Monitor sizes: 6.5inch or 8.8inch
Mini vehicles
with Professional navigation CCC infotainment
Monitor size: 6.5inch monitor
Video-inserter with 2 video inputs + rear-view camera input
Product features
Video-inserter for factory-infotainment systems
1 CVBS Rear-view camera video-input
2 CVBS video-inputs for after-market devices (e.g. USB-Player, DVB-T2 tuner, ...)
Automatic switching to rear-view camera input on engagement of the reverse gear
Video-in-motion (ONLY for connected video-sources)
Video-inputs PAL and NTSC compatible
Ultra-wide picture mode 24:9 (only with ultra-wide screen 8.8")

Version 25.02.2022 HW: V65 CI-VL1-CCC
Page2
Contents
1. Prior to installation
1.1. Delivery contents
1.2. Checking the compatibility of vehicle and accessories
1.3. Connectors –Video interface
1.4. Dip-switch settings –interface
1.4.1. Enabling the interface’s video inputs (dip 2-3)
1.4.2. Rear-view camera setting (dip 5)
1.4.3. Monitor specific settings
2. Installation
2.1. Place of installation
2.2. Connection schema
2.3. Connection –6pin interface cable
2.4. Connection –picture signal cable
2.5. Connection –video sources
2.6. Audio-switch and audio-insertion
2.7. After-market rear-view camera
2.8. Connection –video interface to external keypad
2.9. Picture settings
3. Video interface operation
3.1. By infotainment button
3.2. By external keypad
3.3. By white wire of the 6pin cable
4. Specifications
5. FAQ –Trouble Shooting-Interface functions

Version 25.02.2022 HW: V65 CI-VL1-CCC
Page3
Legal Information
By law, watching moving pictures while driving is prohibited, the driver must not be
distracted. We do not accept any liability for material damage or personal injury resulting,
directly or indirectly, from installation or operation of this product. Apart from using this
product in an unmoved vehicle, it should only be used to display fixed menus or rear-view-
camera video when the vehicle is moving (for example the MP3 menu for DVD upgrades).
Changes/updates of the vehicle’s software can cause malfunctions of the interface. Up to
one year after purchase we offer free software-updates for our interfaces. To receive a free
update, the interface has to be sent in at own cost. Wages for de-and reinstallation and
other expenditures involved with the software-updates will not be refunded.
No liability for vehicle wire colours and pin definition!
Changes by the vehicle manufacturer are possible. The given information has to be verified
by the installer.
1. Prior to installation
Read the manual prior to installation. Technical knowledge is necessary for installation. The
place of installation must be free of moisture and away from heat sources.
1.1. Delivery contents
Take down the serial number of the interface and store this manual for support
purposes: ____________________

Version 25.02.2022 HW: V65 CI-VL1-CCC
Page4
Requirements
Brand
Compatible vehicles
Compatible systems
BMW
3series (E90/E91/E92/E93)
5series (E60/E61)
6series (E63/E64)
X5 (E70)
X6 (E71)
Professional navigation CCC,
Business navigation M-ASK,
radios -
with 6.5inch or 8.8inch monitor
Mini
From about 10/2006 until about 08/2010
Professional navigation CCC
with 6.5inch monitor
Send VIN and picture of main-menu for
identification
Limitations:
Video only The interface inserts ONLY video signals into the infotainment. For inserting Audio
signals either the possibly existing factory audio AUX input, a FM-modulator or the
AUX-In Interface AUX-110 (BMW only) can be used. The factory audio AUX input can
be coded by dealership, too. If 2 AV sources shall be connected, the CAB-FV-AUDIO
audio cable is optionally available for audio switching.
Factory rear-view camera Automatically switching-back from inserted video to factory rear-view camera is only
possible while the reverse gear is engaged. To delay the switch-back an additional
electronic part is required.
Factory-OPS-display While reverse gear is engaged ONLY the picture of the after-market rear-view
camera is visible!
Ultra-wide mode Only available for ultra-wide screens 8.8”
1.2. Checking the compatibility of vehicle and accessories

Version 25.02.2022 HW: V65 CI-VL1-CCC
Page5
1.3. Connectors –Video interface
The video-interface converts the video signals of connected after-market sources in a factory
monitor compatible picture signal which is inserted in the factory monitor, by using separate
trigger options.
1.4. Dip-switch settings –interface
Some settings have to be selected by the dip-switches on the
video interface. Dip position down is ON and position up is OFF.
After each Dip-switch-change a power-reset of the Can-box has to be performed!
See the following chapters for detailed information.
Dip
Function
ON (down)
OFF (up)
1
No function
set to OFF
2
CVBS AV1-input
enabled
disabled
3
CVBS AV2-input
enabled
disabled
4
No function
set to OFF
5
Rear-view cam type
after-market
factory or none
6
No function
set to OFF
7
No function
set to OFF
8
Monitor
adjustments
8.8inchmonitor
6.5inchmonitor

Version 25.02.2022 HW: V65 CI-VL1-CCC
Page6
1.4.1.1. Enabling the interface’s video inputs (dip 2-3)
Only the enabled video inputs can be accessed by switching through the interface’s video
sources. It is recommended to enable only the required inputs, because the disabled inputs
will be skipped while switching through the video interfaces inputs.
1.4.1.2. Rear-view camera setting (dip 5)
If set to OFF, the interface switches to factory LVDS picture while the reverse gear is engaged
to display factory rear-view camera or factory optical park system picture.
If set to ON, the interface switches to its rear-view camera input while the reverse gear is
engaged.
1.4.1.3. Monitor specific settings (dip 8)
Dip 8 customizes the monitor-specific video settings.
Dip switch setting ON will support the 8.8inch monitor.
Dip switch setting OFF will support the 6.5inch monitor.
Note: Dip 1, 4, 6 and 7 are out of function and have to be set to OFF.

Version 25.02.2022 HW: V65 CI-VL1-CCC
Page7
2. Installation
To install the interface, first switch off the ignition and disconnect the vehicle’s battery.
Please read the owner`s manual of the car, regarding the battery`s disconnection! If
required, enable the car`s Sleep-mode (hibernation mode)
In case the sleep-mode does not succeed, the disconnection of the battery can be done
with a resistor lead.
If the necessary stabilized power supply for the interface is not taken directly from the
battery, the chosen connection has to be checked for being constantly stabile.
The interface needs a permanent 12V source!
2.1. Place of installation
The interface box is prepared to be connected behind the vehicle`s monitor. The monitor
has to be removed for the installation

Version 25.02.2022 HW: V65 CI-VL1-CCC
Page8
2.2. Connection schema

Version 25.02.2022 HW: V65 CI-VL1-CCC
Page9
2.3. Connection –6pin interface cable
Connect the white female 6pin connector of the 6pin interface cable to the male 6pin
connector of the video interface.
Connect the green wire of the 6pin interface cable to +12V of the reverse gear signal.
(e.g. reversing light).
If desired, the white wire of the 6pin interface cable can be used alternatively to the
external button to switch the video sources (12V pulse for 2-3 seconds).
Connect the black wire of the 6pin interface cable to vehicle ground.
Connect the red wire of the 6pin interface cable to +12V ACC terminal 15.
Connect the yellow wire of the 6pin interface cable to +12V ACC (300mA).
Note: The connection of the green wire (Reverse signal) will be described in chapter
“After-market rear-view camera”. The white wire, can be used by +12V impulse to
switch the enabled video sources , same as the keypad (see chapter “video interface-
operation”).

Version 25.02.2022 HW: V65 CI-VL1-CCC
Page10
2.4. Connection - picture signal cable
Disconnect the factory picture signal cable’s female 10pin connector which is coming
from the head unit at the rear side of the factory monitor and connect it to the male
10pin HSD connector (LVDS OUT) of the video interface.
Attention: The factory picture signal cable mustn’t be disconnected for the installation!
Connect the enclosed picture signal cable’s female 10 pin connector to the male
10pin connector of the video interface.
Connect the picture signal cable’s opposite female 10pin connector to the previously
become free male 10pin connector of the video interface.
