SPEED 2100 Installation and Operation ManualNAVMAN
2
FCC Statement
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a normal installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an output on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced technician for help.
A shielded cable must be used when connecting a peripheral to the serial ports.

3
SPEED 2100 Installation and Operation Manual
NAVMAN
Contents
1 Operation ......................................................................................................... 4
Simulation ........................................................................................................ 4
Modes .............................................................................................................. 4
Trip Logreset ................................................................................................... 5
TotalLog reset.................................................................................................. 5
2 Instrument Setup ............................................................................................. 5
Selectingunitsof measure ............................................................................... 5
CalibratingSPEEDagainsta known preference .............................................. 5
CalibratingDISTANCEagainst a known preference ......................................... 5
°F / °C selection ............................................................................................. 6
Temperaturecalibration ................................................................................... 6
3 Installation ....................................................................................................... 7
Location ........................................................................................................... 7
Mounting.......................................................................................................... 7
Wiring connection ............................................................................................ 8
Appendix A - Specifications .............................................................................. 9
Appendix B - Troubleshooting Chart.............................................................. 10
Appendix C - How to contact us ..................................................................... 59
Important
Itistheowner’ssoleresponsibilitytoinstallanduse the instrument and transducer/sinamannerthat will
not cause accidents, personal injury or property damage. The user of this product is solely responsible
for observing safe boating practices.
NAVMANNZLIMITED DISCLAIMSALLLIABILITYFORANYUSEOFTHIS PRODUCTINAWAYTHAT
MAYCAUSEACCIDENTS, DAMAGE OR THAT MAYVIOLATE THE LAW.
This manual represents the SPEED 2100 as at the time of printing. Navman NZ Limited reserves the
right to make changes to specifications without notice.
GoverningLanguage:Thisstatement,any instructionmanuals,userguidesand otherinformationrelating
to the product (Documentation) may be translated to, or has been translated from, another language
(Translation). In the event of any conflict between any Translation of the Documentation, the English
language version of the Documentation will be the official version of the Documentation.
Copyright©2002NavmanNZLimited,NewZealand.Allrightsreserved.NAVMANisaregisteredtrademark
of Navman NZ Limited.

SPEED 2100 Installation and Operation ManualNAVMAN
4
Simulation
This feature demonstrates the operation of the
instrument. In this mode the digits randomly count
up and down.
To activate this mode:
1. Power up the instrument
2. Press and hold the key for 15 seconds
until is displayed. The display will start
counting randomly.
Press for 15 Seconds
3. To disable the simulation mode, press and
hold the key for 15 seconds until is
displayed again. The display will revert to 0.0.
Press for 15 Seconds
The instrument always powers up into the SPEED
mode.
Modes
Pressthe keytotogglebetweentheSPEEDand
TRIP LOG modes.
SPd
Log
>/
>/
Press and hold the key to display the TOTAL
LOG, release to show the temperature.
oF oC
796
>/
>/
1 Operation



5
SPEED 2100 Installation and Operation Manual
NAVMAN
Trip Log Reset
Select theTRIP LOG mode. Press and hold the
key until the display resets to zero.
Press and hold
Information will now be indicated in the selected
display unit.
Calibrating SPEEDAgainst a Known
Reference
1. Select SPEED mode
2. Press and hold the and keys for 5
seconds.
3. Release both keys when the display shows the
following:
CAL
4. While travelling at the known speed , press the
key to increase the displayed speed or the
key to decrease the reading.
5. When the correct reading is indicated, press
and hold the and keys again for two
seconds.
6. Release both keys when the display shows the
following:
SPd
Calibrating DISTANCEAgainst a
Known Reference
1. Select the TRIPLOG mode.
2. Press and hold the and keys for 5
seconds.
The instrument must be calibrated after installation
to ensure accurate speed readings.
Selecting units of measure
The SPEED 2100 will indicate boat speed in Knots
(nautical miles), MPH (statute miles) or KPH
(kilometres). To change the current setting perform
the following steps:
1. Power up the unit while holding down the key.
Hold down during power up
2. When the unit is on, release the key. The
display will indicate the current display unit with:
Knots (nautical miles)
MPH (statute miles)
KPH (kilometres)
3. To select the display unit desired, use the
and keys to change the value.
4. To exit this mode, press and hold both the
and keys simultaneously for one second.
Press and hold to exit
Total Log Reset
Press and hold the and / keys while powering
up and hold for at least 30 seconds until the
TOTAL LOG is reset.
Press for 30 seconds
2 Instrument Setup






SPEED 2100 Installation and Operation ManualNAVMAN
6
°F / °C Selection
Press and hold the key while powering up the
instrument. The display will indicate the current unit
of measure.
oF oC
Press either the or keyuntilthedesiredunit
ofmeasureisdisplayed.Press andholdthe and
keys for two seconds. The current temperature
will be displayed.
TemperatureCalibration
To calibrate the TEMPERATURE:
1. Select the TEMP mode.
2. Press and hold the and keys for 5
seconds.
3. Release both keys when the display shows the
following:
Press for 5 seconds
CAL
3. Release both keys when the display shows the
following:
CAL
4. The TRIP LOG reading will reset to 0.0.
5. Travel a known distance.
6. If the display indicates a reading different from
the known distance, press the key to
increase the reading or the key to
decrease the reading.
7. When the correct reading is indicated, press
and hold the and keys again for two
seconds.
8. Release both keys when the display shows the
following:
LOg
4. If the temperature reading indicated is
incorrect, press the key to increase the
reading or the key to decrease the
reading.
5. When the correct reading is indicated, press
and hold the and keys again for two
seconds.
6. Release both keys when the display shows the
following:
oF oC



7
SPEED 2100 Installation and Operation Manual
NAVMAN
Location
The SPEED 2100 is designed for above or below
deck installation. Select a position that is:
• On a flat surface
• At least 300mm (12”) from a compass
• At least 500mm (20”) from any radio
• Easy to read by the helmsman and crew
• Protected from physical damage
• Accessible to electrical cable connections
Mounting
The instrument panel must be 3mm to 19mm
(1/8” to 3/4”) in thickness.
• Drill a 51mm (2”) hole in the instrument panel.
• Remove brackets and insert the instrument so
the back is flush with the instrument panel.
• Slide the bracket over the instrument and
tighten the mounting nut until secure.
Instrument
Panel
Mounting
Bracket
Mounting Nut
Instrument
51mm (2”)
Hole
Sealing
Gasket
3 Installation

SPEED 2100 Installation and Operation ManualNAVMAN
8
WiringConnection
• Keep electrical and transducer cables away
from alternator or other noise generating
electrical cables. Avoid connecting the
instrument to power circuits that share loads
with ignition, alternators, inverters and radio
transmitters. Electrical power supply
connections should always be as short as
possible.
• Connect the red wire to the positive supply via
a 1 amp fuse or a 1 amp circuit breaker.
Connect the black wire to the electrical ground.
• Connect the 4 pin Fuji connector to the speed
and temperature transducer cable connector.
Extension cables are available if the
transducer cable is too short.
600mm (24”)
POWER CORD
BRACKET
BUZZER
RED
(+) TERMINAL BLACK
(-) TERMINAL
4 PIN
CONNECTOR

9
SPEED 2100 Installation and Operation Manual
NAVMAN
• Size
Mount
51mm diameter hole
Depth behind face plate
95mm max.
Display
3-character LCD
• Colour
Black with texture on bezel.
• Backlighting
Red coloured diffused lighting for display.
• Water Integrity
Front will withstand direct water spray.
• Impeller
• Speed units and resolution
0-19.9 and then 20-50 in knots, MPH or KPH
(depending on transducer type),
• Trip Log
0-999 miles, non-volatile, resetable
(0.00-9.99 read in hundredths, 10.0-99.9 read in
tenths, 100-999 read in whole numbers).
• Total Log
0-999 miles, non-volatile, resetable
(0.00-9.99 read in hundredths, 10.0-99.9 read in
tenths, 100-999 read in whole numbers).
• TemperatureSensor
10 Kohm thermistor at 25°C.
• Temperature Range
0.0°C to 37.7°C (32.0°F to 99.9°F).
• Operating Voltage
8 VDC to 16.5 VDC.
• Operating Temperature
0°C to 50°C (32°F to 122°F).
• Current Drain
70mAmax.
• RF Interference
<6 dB quieting on any marine radio channel
(with 3 dB gain antennae) within one metre of
the SPEED 2100. Complies with CE EMC
standards EN50081-1 and EN50082-1.
SPEEDPower
888
>/
Change Value Down
Display is backlit for
Night Operation
Change Value Up
NAVMAN
Appendix A - Specifications

SPEED 2100 Installation and Operation ManualNAVMAN
10
No display:1. CheckDCpower connectionsandDC polaritywithvoltmeter.
2. Checkfuse.
No speed or log readings:
Check and make sure that the paddlewheel on the impeller is not
stuck or fouled with growth.
Inaccurate speed readings:
1. Re-calibrate
2. Checkpaddlewheel
Erratic speed readings while moving:
1. Checktomakesure thattheimpeller is alignedforeand aft.
2. Reviewtheinstallationforpossibleerraticwaterflowovertheimpeller.
Erratic readings only while engine is running:
1. Re-route power and transducer cables away from engine, ignition
wiresandbatterycables.
2. Addfeed-throughfiltercapacitoronthepositive terminaloftheignition
coil.
3. Addanalternatorwhinefiltertoalternator.
4. Replacesparkplugwirewithresistivetype.
No temperature reading or is inaccurate:
1. Checkcalibration.
2. Checkfor break in cable.
Simulation mode:
At power up, if all the segments display for 5 seconds then the
instrumentisinsimulationmode.
Appendix B - Troubleshooting Chart
