Naxa NAP-20 User manual
CANTEEN 4000 Portable Battery Pack
NAP-20
Instruction Manual
Please read carefully before use and keep for future reference.
Pagina 2 Naxa Electronics
Thank You
We know you have many choices when it comes to
technology; thank you for choosing us here at Naxa
Electronics. Established in 2001 in Los Angeles, Califor-
nia, we are dedicated to delivering products that en-
tertain and delight.
We trust that you will be happy with your purchase.
Please read this manual carefully and save it for refer-
ence. You may also nd the latest FAQ, documentation,
and other product material at our website. Come visit
us on the web at www.naxa.com and see all that we
have to offer!
In the Box
Please take a moment to make sure that you have ev-
erything in the list below. Although we make every ef-
fort to ensure that each Naxa device is securely packed
and sealed, we know a lot can happen in between us and
you. If anything is missing, check back with your local
retailer to get immediate assistance. If they cannot help
you, please contact our Naxa Support team at www.
naxa.com/naxa_support.
•NAP-20 Portable Power Pack
•USB charging cable
•Instruction manual
•Warranty card
www.naxa.com Pagina 3
Key Features
•Portable battery pack provides 4000 mAh of power
when you need it most
•Slim design makes it easy to keep power with you
always
•USB port provides DC 5 V / 1.0 A power for your de-
vices
• Four-stage battery status indicator
• Handy built-in LED ashlight
•Recharge the battery pack with the included micro
USB cable
•Power Input: DC 5 V / 1.0 A (max)
Before You Start
Safety Instructions
1. Keep the unit from heat sources, direct sunlight,
humidity, water or any other form of liquid.
2. Do not operate the unit if it has been wet or ex-
posed to moisture to prevent electric shock, ex-
plosion, and/or injury to yourself or damage to the
unit.
3. Do not use the unit with wet hands.
4. Keep the unit free from dust, lint and other small
particles.
5. Do not use the unit for anything other than its in-
tended use.
6. Keep the unit out of reach of children. This unit is
not a toy.
Care and Maintenance
Read the following recommendations before using the
portable battery pack.
1. Do not expose the battery to liquid, moisture or
humidity. This may adversely affect the internal
circuit of the device.
2. Do not use abrasive cleaning solvents to clean the
device.
3. Do not expose the device to extremely high or low
Pagina 4 Naxa Electronics
temperatures. Extreme temperatures may destroy
the battery or distort some of the plastic parts.
4. Do not incinerate or otherwise dispose of the de-
vice in re as it may result in an explosion.
5. Do not expose the device to contact with sharp to
prevent scratches and other damage.
6. Do not drop the device. Drops and otherhard shocks
may damage the internal circuit.
7. Do not attempt to disassemble the device. There
are no user-serviceable parts inside.
At a Glance
6
1
2
3
4
5
1. Status LEDs
Flashes while the battery is charging.
Lights up to indicate how much charge is remaining
2. Function button
Press to check the battery level.
Press and hold to turn the ashlight on or off.
3. USB Input (micro type B)
www.naxa.com Pagina 5
4. Flashlight
5. USB Power Output
6. Battery
Using the Battery Pack
Getting Started
1. Remove the battery pack from the box.
2. Remove any packaging from the product such as
tape or protective lm.
3. Check to see if everything is included in the box.
Retain all packaging for future use.
4. Charge the battery pack.
Charging the Battery Pack
1. Use the included USB charge cable to charge your
device from any USB port on a computer. You may
also use the included cable to charge your device
with a USB power adapter (optional). When using
a power adapter, make sure that its rated output
matches your device. (Please refer to the Specica-
tions section for your device’s Power rating.)
2. The Status LED will ash red while the battery pack
is charging. It will turn off when the battery pack is
fully charged.
Although the battery pack is charged fully
at the time of manufacture, it is still a good
idea to give it a charge before using your
device for the rst time. Fully charging your
battery using it can help its performance
and lifespan.
Pagina 6 Naxa Electronics
Charging your iPhone®, Android™,
smartphone, or other USB Device
To charge a USB device with the battery pack:
1. For best performance, make sure that the battery
pack is fully charged.
2. Use the USB cable that was provided with your
device to connect it to the USB output port of the
battery pack. Connect the other end of the cable to
your device.
www.naxa.com Pagina 7
Warnings and Precautions
The lightning ash with arrowhead symbol within an equilateral
triangle is intended to alert the user to the presence of unin-
sulated “dangerous voltage” within the product’s enclosure that
may be of signicant magnitude to constitute risk of electric
shock
The exclamation point within an equilateral triangle is intended
to alert the userto the presence of important operation and ser-
vicing instructions in the literature accompanying the appliance.
Important Safety Information
1. Read Instructions: All the safety and operating instructions should be
read before the product is operated.
2. Retain Instructions: The safety and operating instruction should be
retained for future reference.
3. Heed Warnings: All warnings on the product and in the operating in-
structions should be adhered to.
4. Follow Instructions: All operating and usage instructions should be
followed.
5. Cleaning: Unplug this product from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for
cleaning.
6. Attachments: Use only attachments recommended by the manufac-
turer. Use of other attachments may be hazardous.
7. Water and Moisture: Do not use this product near water (e.g., near a
bathtub, washbowl, kitchen sink, laundry tub, in wet basements, or
near a swimming pool and the like).
8. Ventilation: Slots and openings in the cabinet are provided for ven-
tilation to ensure reliable operation of the product and to protect it
from overheating. These openings should never be blocked by placing
the product on a bed, sofa, rug, or other similar surface. This product
should not be placed in a built-in installation such as a bookcase or
rack unless proper ventilation is provided or the manufacturer in-
structions have been adhered to.
9. Power Sources: This product should be operated only from the type of
power source indicated on the rating label. If you are not sure of the
type of power supply to your home, consult your product dealer or
local power company. For products intended to operate from battery
power or other sources, refer to the operating instructions.
10. Grounding or Polarization: This product may be equipped with a po-
larized alternating-current line plug that has one blade wider than
the other. This plug will only t into the power outlet in one direction.
This is a safety feature. If you are unable to insert the plug fully into
the outlet, try reversing the direction of the plug. If the plug should
Pagina 8 Naxa Electronics
still fail to t, contact an electrician to replace the obsolete outlet. Do
not defeat the safety purpose of the polarized plug.
11. Power-Cord Protection: Power supply cords should be routed so that
they are not likely to be walked on or pinched by items placed upon
or against them, paying particular attention to cords at plugs, conve-
nience receptacles, and at the point which they exit from the product.
12. Protective Attachment Plug: The product may be equipped with an at-
tachment plug with overload protection. This is a safety feature. See
the operating instructions for replacement or directions to reset the
protective device. If replacement of the plug is required, be sure the
service technician has used a replacement plug that has the same over-
load protection as the original plug as specied by the manufacturer.
13. Lightning: For added protection for this product, unplug it from the
wall outlet during a lightning storm or when it is left unattended and
unused for long periods of time. This will prevent damage to the prod-
uct due to lightning or power-line surges.
14. Overloading: Do not overload wall outlets, extension cords, or inte-
gral convenience receptacles as this can result in a risk of re or elec-
tric shock.
15. Object and Liquid Entry: Never push objects of any kind into this prod-
uct through openings as they may touch dangerous voltage points or
short-out parts that could result in a re or electric shock. Never spill
liquid of any kind on the product.
16. Servicing: Do not attempt to service this product yourself as open-
ing or removing covers may expose you to dangerous voltage or other
hazards. Refer all servicing to qualied service personnel.
17. Damage Requiring Service: Unplug this product from the wall outlet
and refer servicing to qualied service personnel under the follow-
ing conditions: a) when the power-supply or plug is damaged; b) if
liquid has been spilled or if objects have fallen into the product; c) if
the product has been exposed to rain or water; d) if the product does
not operate normally by following the operating instructions. Adjust
only those controls that are covered by the operating instructions as
improper adjustment of other controls may result in damage and will
often require extensive work by a qualied technician to restore the
product to its normal operation; e) if the product has been dropped or
damaged in any way; f) when the product exhibits a distinct change in
performance—this indicates a need for service.
18. Replacement Parts: When replacement parts are required, be sure
that your service technician has used replacement parts specied
by the manufacturer or have the same characteristics as the original
part. Unauthorized substitutions may result in re, electric shock, or
other hazards.
19. Safety Check: Upon completion of any service or repairs to this prod-
uct, ask the service technician to perform safety checks to ensure
that the product is in proper operating condition.
20. Heat: The product should be situated away from heat sources such as
radiators,heat registers, stoves, or other products (including ampli-
ers) that produce heat.
WARNING
This product contains lead, a chemical known to the State of California to
cause cancer and birth defects or other reproductive harm. Wash hands
after handling.
FCC NOTICE
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the lim-
www.naxa.com Pagina 9
its for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful in-
terference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to ra-
dio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be de-
termined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAUTION ON MODIFICATIONS
Any changes or modications not expressly approved by the grantee of
this device may void the authority granted by the FCC to operate the
equipment.
Support
If you have problems with your device, please consult
the instructions in this manual. Please also visit us
on the web at www.naxa.com to get up to the minute
news, alerts, and documentation for your device. For
additional assistance, please contact Naxa Technical
Support.
NAXA Technical Support
2320 East 49th St.
Vernon, CA 90058
http://www.naxa.com/naxa_support/
MADE N CHINA
Pagina 10 Naxa Electronics
This manual suits for next models
2
Table of contents
Other Naxa Batteries Pack manuals
