NEC MultiSync M700 User manual

NEC Storage M700 Disk Array Unit
Setup Guide
Please read this document first.
This document describes the operating procedure based on the “NEC Storage
M700 Disk Array Unit User’s Guide”.
For details, please see the pages indicated by in the “Disk Array Unit User’s
Guide”.
・Before using this unit, please read the “Safety Precautions” attached to the unit.
・If the setup operation for this unit is performed by a maintenance service company,
check with maintenance personnel regarding the scope of work to be performed.
856-857541-101-A
12/2012 Ver.1

１Starting the Setup: Preparation and Procedure
ProcedurePreparation
◆Make sure the following items are available:
・Application server, and client machine
・Installation CD
・LAN cable (shielded)
・Interface cable for connecting the application server
・IP addresses (for disk array unit and connection
ports)
・Network equipment (if necessary)
◆Perform the following procedure:
1) Starting the setup – Preparation and Procedure
2) Checking the package
3) Checking appearance and features
4) Installation
5) Connection – connecting the cables
6) Turning the power on
・Tool (Phillips screwdriver)
・At least three disk drives
・Operators (a minimum of two workers)
(When using PathManager)
◆Perform the following setup operations with respect to
the application server to which this unit is to be connected:
- Acquiring a host adapter WWPN
- Mounting the host bus adapter
- Installing the host bus adapter driver
- Installing PathManager
“NEC Storage M700 Disk Array Unit User’s Guide”, 3-1 Preparation
“NEC Storage M700 Disk Array Unit User’s Guide”, Ch. 2, Workflow - Installation to Operation
7) Installing and setting up the software
7-1 Preparation
7-2 Specifying the IP address
7-3 Installing NEC Storage Manager Agent Utility
8) Initializing the disk array unit
8-2 Initializing and configuring the disk array
8-3 Verifying the connection
9) Finish – setup complete
8-1 Collecting host information
7-4 Starting iSM client

２Checking the package
When opening the boxes, check the enclosed “Packing list” and make sure that all the listed items are
accounted for.
If there is any missing or damaged item, contact the sales department that services your account or the dealer
from which the system was purchased.

３Part Name – Checking Appearance and Features
Check the mount positions for the components and LED.
Disk array unit
[Front view] [Rear view]
電源ボタン
STANDBY LED (White)
POWER LED (Green)
SERVICE LED (Amber)
UID LED (Blue)
HOST PORT EXTENSION (HPE#3)
HOST PORT EXTENSION (HPE#1)
DISK PORT EXTENSION (DPE#1)
HOST/DISK PORT EXTENSION (HPE#9/DPE#5)
MANAGEMENT CARD (MNG#1)
POWER SUPPLY (PS#1)
DISK PORT EXTENSION (DPE#3)
HOST/DISK PORT EXTENSION (HPE#B/DPE#7)
HOST PORT EXTENSION (HPE#7)
HOST PORT EXTENSION (HPE#5)
POWER SUPPLY (PS#3)
“NEC Storage M700 Disk Array Unit User’s Guide”, 1-2-1 Disk Array Controller
[the four sets of FC 4-port HPE and
the four sets of DPE mounted]
FAN (#0)
FAN (#1) FAN (#3)
FAN (#2)BBU (#0)
BBU (#1)
BBU (#2)
BBU (#3)
HOST PORT EXTENSION (HPE#2)
HOST PORT EXTENSION (HPE#0)
HOST/DISK PORT EXTENSION (HPE#8/DPE#4)
DISK PORT EXTENSION (DPE#0)
MANAGEMENT CARD (MNG#0)
POWER SUPPLY (PS#0)
DISK PORT EXTENSION (DPE#2)
HOST/DISK PORT EXTENSION (HPE#A/DPE#6)
HOST PORT EXTENSION (HPE#4)
HOST PORT EXTENSION (HPE#6)
POWER SUPPLY (PS#2)

[Front view] [Rear view]
Disk enclosure
(1) Power (PS1) (1) Power (PS0)
(2) Adapter (ADP1) (2) Adapter (ADP0)
[AC power]
(5) Disk drive/Dummy carrier
(4) STANDBY LED (3) POWER LED
(1) ID LED (2) SERVICE LED
[2.5-inch disk drive-mounting model]
“NEC Storage M700 Disk Array Unit User’s Guide”, 1-2-2 Disk Enclosure
[DC power]
(5) Disk drive/Dummy carrier
(2) SERVICE LED
(3) POWER LED
(4) STANDBY LED
[3.5-inch disk drive-mounting model]
(1) ID LED

４Installation
Perform the installation safely by reading the following safety precautions.
Mounting the disk array unit and the disk enclosure on the rack
Step 1
・The disk array unit weighs 48 kg; the disk enclosure (with a 3.5-inch disk drive), 29 kg.
・Mount the disk array enclosure and the disk array unit, top-down, in the indicated order.
・Mounting the unit on the rack should be performed by two or more persons working together.
・See the “Disk Array Unit Installation Guide”.
“NEC Storage M700 Disk Array Unit User’s Guide”, 3-2-1 Mounting a Disk Array unit on a Rack
“NEC Storage M700 Disk Array Unit User’s Guide”, 3-2-2, Mounting a Disk Enclosure on a Rack
“NEC Storage M700 Disk Array Unit User’s Guide”, 3-2 Installation
Step 2 Installing the disk drive
・On each disk drive, affix a location label.
・Disk drives are electronic devices.
・As system disks, install three disk drives, in locations 00, 01, and 02.
When handling a disk drive, take anti-static measures, such as wearing a wrist strap.
On each disk drive, affix a system disk label. Do not remove more than one drive at a time.
・Store the removed dummy carrier in a safe place.
Install the disk drive if it is not already mounted on the disk array unit or the disk enclosure.
“NEC Storage M700 Disk Array Unit User’s Guide”, 3-2-3 Installing Disk Drives

５Connection – connecting the cables
■Connect the cables by checking the locations of cables (see figure below) .
Disk array unit Note: Connect the power cable to the outlet after the connection of other cables is completed.
Host Port
(HPx)
Power
Connector
Disk Port
(DP0-DP3)
Management
Port
[the four sets of FC 4-port HPE and
the four sets of DPE mounted]
To Outlet
To Outlet
“NEC Storage M700 Disk Array Unit User’s Guide”, 3-3 Connection
To Disk Enclosure
Connect other controllers in the same way.
FC 4-port HPE: HP0-HP3
1G iSCSI 2-port HPE: HP0-HP1
10G iSCSI 2-port HPE: HP0-HP1
To Client Machine
To Application Server

Disk enclosure
[AC power-mounting model]
Note: Connect the power cable to the outlet after the connection of other cables is completed.
Power connector
To disk array unit or disk
Disk port (DP-IN)
To power outlet
Connect non-AC
power, if any, the
same way.
“NEC Storage M700 Disk Array Unit User’s Guide”, 3-3 Connection
Disk port (DP-OUT)
To Disk Enclosure on
next level
To disk array unit or disk
enclosure closest to disk
array unit

■Connecting the SAS cables Note: Figure is a case of DPE0-3 DP0,DP1 port connection.
Connect DE00 necessarily.
For wiring, see the User’s Guide.
3.5-inch type DE:
Connectable to
maximum of 5.
2.5-inch type DE:
Connectable to
maximum of 3.
DP0 DPE1DPE3
DE 08
DE 09
DE 29
DE 28
DE 0A
or
DE 0C
DE 2A
or
DE 2C
DP1
“NEC Storage M700 Disk Array Unit User’s Guide”, 7-3-4 Disk Enclosures
DP-IN
DE 00
DPE0DPE2
DE 01
DE 20
DE 21
DE 02
or
DE 04
DE 22
or
DE 24
DAC
DP-OUT

Power up the system, referring to the following section:
Turning the Power On
“NEC Storage M700 Disk Array Unit User’s Guide”, 1-3-1 Powering on the Disk Array System
６
Installing and Setting Up the Software
７
7-1 Preparation
Install the software required to prepare and set up the iSM client.
Prepare the client machine on which the iSM client will be used. See the following section:
“NEC Storage M700 Disk Array Unit User’s Guide”, 1-3 Basic Operation
“NEC Storage M700 Disk Array Unit User’s Guide”, 4-2 Before Starting NEC Storage Manager Client
“NEC Storage M700 Disk Array Unit User’s Guide”, 4-3-1 Installing the Network Setting Tool
7-2 Specifying the IP address
“NEC Storage M700 Disk Array Unit User’s Guide”, 4-4 Installing NEC Storage Manager Agent Utility on the Application Server
7-3 Installing NEC Storage Manager Agent Utility
Install the network setup tool and then specify the IP address for the disk array. See the following sections:
Install NEC Storage Manager Agent Utility on the application server. See the following section:
“NEC Storage M700 Disk Array Unit User’s Guide”, Chapter 4, NEC Storage Manager
7-4
“NEC Storage M700 Disk Array Unit User’s Guide”, 4-3-2 Configuring IP Addresses by Using Network Setting Tool
“NEC Storage M700 Disk Array Unit User’s Guide”, 4-3-3 Setting a Time Zone of the Disk Array
“NEC Storage M700 Disk Array Unit User’s Guide”, 4-5 Starting NEC Storage Manager Client
Starting iSM client
Start the iSM client on the client machine. See the following section:
