NEC Series3800/S120R-2 User manual

Key Features
Quad-Core or Dual-Core Intel ® 64-bit Xeon®
with 667 / 1066 / 1333 MHz FSB
Up to  32GB DDR2 667 & 533 SDRAM Fully Buffered
DIMM (FB-DIMM)
2 (x8) & 1 (x4) PCI-Express, 2x 64-bit 133MHz PCI-X, 1x 64-bit
100MHz PCI-X
Low-prole Expansion Slots 
Intel ® (ESB2/Gilgal) 82563EB Dual-port Gigabit Ethernet Controller
8 x 3.5” Hot-swap SAS Drive Trays with SES2
Processor / Cache
CPU Supports up to two Intel• ®64-bit Xeon processor(s) of the same
type
Quad-Core Intel Xeon processor 5400/5300 sequence
(Harpertown/Clovertown processor) up to 3.16 GHz
System Bus 1333 / 1066 / 667 MHz system bus•
Operating System Software
Software Red Hat• ®Linux®ES 3 (Update 4 & 5)
MS• ®Win 2003 Server Standard Edition
MS Win 2003 Server Enterprise Edition•
MS Win 2003 Server Enterprise Edition x64•
SuSE• ®Linux®SLES 9.0 & +SP2
VMware• ®ESX 3 & 3.5
System Memory
Memory Capacity Eight 240-pin DIMM sockets•
Supports up to 32 GB 667 / 533MHz DDR2 ECC FB-DIMM•
memory
Dual branch memory bus•
Memory must be populated in pairs•
Memory Mirroring supported•
Memory Type 667 / 533MHz FB-DIMM (Fully Buffered DIMM) ECC DDR2•
SDRAM 72-bit, 240-pin gold-plated DIMMs
DIMM Sizes 512 MB, 1GB, 2GB, 4GB•
Series3800/S120R-2
Powerful ServerS at excePtional value
On-Board Devices
SATA Intel ESB2 SATA 3.0Gbps controller•
RAID 0, 1, 5, 10 support (Windows Only)•
RAID 0, 1, 10 support (Linux)•
SAS Adaptec AIC-9410 Serial-Attached SCSI (SAS) Controller•
SAS Dual-Channel (internal)•
Each SAS channel supports up to 4 SAS / SATA drives for a total of•
up to 8 SAS or SATA hard drives
Host RAID 0, 1, & 10 support•
RAID Support for Zero-Channel RAID with optional card•
IPMI Support for Intelligent Platform Management Interface v.2.0•
200-pin IPMI slot (SIMLP) as option•
Network
Controllers
Intel (ESB2/Gilgal) 82563EB Dual-Port Gigabit Ethernet Controller•
Supports 10BASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output•
Intel I/OAT support for fast, scaleable, and reliable networking•
Graphics ATI ES1000 controller with 16 MB of video memory•
I / O Winbond 83627HG chip•
Input / Output
SAS Eight SAS / SATA (internal) ports•
Up to 8 SAS / SATA hard drives supported•
Serial ATA Six Serial ATA ports•
Six SATA hard drives supported•
IDE Single EIDE channel supports up to two UDMA IDE devices•
(IDE-M, IDE-S) including CF (Compact Flash) card
Compact Flash (40-pin connector, IDE 1, single channel) slot•
Supports UDMA Mode 5, PIO Mode 4, and ATA/100•
Floppy 1 Floppy controller: 1.44 MB, 2.88 MB•
LAN 2x RJ45 LAN ports•
USB 2x USB rear ports•
3x USB internal headers•
Total 5 USB 2.0 Compliant / 1.1 Compliant•
VGA 1x VGA Port•
Keyboard / Mouse PS/2 keyboard and mouse ports•
Keyboard and optical mouse optional•

NEC Corporation of America
Departmental Servers Division
2880 Scott Blvd.
Santa Clara, CA 95050
www.necam.com/servers
1 866 632-3226
1 408 844-1299
© 2008 NEC Corporation of America. All rights reserved. Specications are
subject to change without notice. NEC is a registered trademark and Empowered
by Innovation is a trademark of NEC Corporation. All other trademarks are the
property of their respective owners. (021-160_052108)
Serial Port /
Header
1 Fast UART 16550 serial port•
1 Fast UART 16550 serial header•
Parallel Port 1 ECP / EEP parallel port•
Chassis
Form Factor 2u Rackmount•
Expansion Slots
PCI-Express 2 (x8) PCI-e slots•
1 (x4) PCI-e (using x8) slot•
1 SEPC (Supermicro PCI-e Power Connector) slot for 2u active•
riser cards with a power extension (i.e. CSE-RR2UE-AX)
PCI-X 2x 64-bit 133MHz PCI-X (3.3V) slots•
1x 64-bit 100MHz PCI-X (3.3V) slot•
System BIOS
BIOS Type 8MB Flash EEPROM with Phoenix® BIOS•
BIOS Features Plug and Play (PnP)•
SMBIOS 2.3•
DMI 2.1•
PCI 2.2•
ACPI 1.0•
USB Keyboard support•
Hardware BIOS Virus protection•
Management
Software Optional IPMI (Intelligent Platform Management Interface) 2.0•
SuperDoctor III•
Watch Dog•
NMI•
Power
Configurations
ACPI Power Management•
Main Switch Override Mechanism•
Wake-On-Ring (WOR) header•
Wake-On-LAN (WOL) header•
Power-on mode for AC power recovery•
Internal / External modem remote ring-on•
PC Health Monitoring
CPU Monitors for CPU Cores, +3.3V, +5V, ±12V, +1.2V•
5-Phase-switching voltage regulator with auto-sense from•
0.8375V-1.60V
FAN Total of four 3-pin and four 4-pin fan headers supporting up to•
8 fans
8x fans with tachometer status monitoring•
Status monitor for speed control•
Status monitor for on/off control•
Low noise fan speed control•
Pulse Width Modulated (PWM) fan connectors•
Temperature Monitoring for CPU and chassis environment•
CPU thermal trip support•
Thermal Control for 8x fan connectors•
PSU I2C temperature sensing logic•
Thermal Monitor 2 (TM2) support•
LED CPU / System Overheat LED•
Other Features Chassis intrusion detection•
Chassis intrusion header•
SDDC Support•
Dimensions
Height 3.5” (89mm)•
Width 17.2” (437mm)•
Depth 25.5” (648mm)•
Gross Weight 53 lbs (24.0kg)•
Front Panel
Buttons Power On/Off button•
System Reset button•
LEDs Power LED•
Hard drive activity LED•
2x network activity LEDs•
System overheat LED / fan fail LED•
Power fail LED•
Ports 2x USB & DB9 COM port•
Drive Bays
Hot-swap 8 x 3.5” Hot-swap SAS drive trays•
Peripheral Drives
DVD-ROM Slim 8x DVD, 24x CD, DVD-ROM drive•
Floppy Slim 1.44MB Floppy Drive (Optional)•
SAS / SATA Backplane
1x SAS / SATA backplane•
System Cooling
Fans 3x 80mm 6300 RPM fans•
Shroud 1x Air Shroud•
Power Supply
700W (1 + 1) Redundant AC-DC high-efficiency power supply w/ PFC
AC Voltage 100 - 240V, 60-50Hz•
Operating Environment / Compliance
RoHS -RoHS Compliant 5/6, Server Exemption
Environmental Spec.
Operating Temperature: 10°to 35°C (50°to 95°F)
Non-operating Temperature: -40°to 70°C (-40°to 158°F)
Operating Relative Humidity: 8% to 90% (non-condensing)
