neighbor Haven 5-Piece Symmetrical Sectional Teak Arm User manual

Assembly Guide
BOXES NEEDED:
(1)
(1)
(2)
(1)
(1)
(1)
(2)
(1)
Left Arm Module Cushions
Right Arm Module Cushions
Armless Module Cushions
Corner Module Cushions
Left Arm Module Frame
Right Arm Module Frame
Armless Module Frame
Corner Module Frame
The 5-Piece
Symmetrical
Sectional

Components Assembly Instructions Contact
02
Parts
1X Left Arm
Left Arm Module Frame Box
1X Corner Base
Corner Module Frame Box
2X Short Base
Armless Module Frame Box
2X Long Base
Left Arm Module Frame Box
Right Arm Module Frame Box
2X Large Roped Back
Left Arm Module Frame Box
Right Arm Module Frame Box
4X Small Roped Back
Armless Module Frame Box (2)
Corner Module Frame Box (2)
1X Corner Block Leg
Corner Module Frame Box
1X Left Arm Module Back Support
Left Arm Module Frame Box
1X Right Arm Module Back Support
Right Arm Module Frame Box
2X Armless Module Back Support
Armless Module Frame Box
1X Corner Module Back Support
Corner Module Frame Box
1X Right Arm
Right Arm Module Frame Box
4X Small Leg
Right Arm Module Frame Box (1)
Armless Module Frame Box (2)
Corner Module Frame Box (1)
1X Corner Leg
Corner Module Frame Box
4X Large Leg
Right Arm Module Frame Box (1)
Corner Module Frame Box (1)
Armless Module Frame Box (2)

Components Assembly Instructions Contact
03
Cushions
4X Base Cushion
All Cushion Boxes
1X Corner Base Cushion
Corner Module Cushion Box
1X Large Corner Back Cushion
Corner Module Cushion Box
1X Small Corner Back Cushion
Corner Module Cushion Box
2X Arm Cushion
Left Arm Module Cushion Box
Right Arm Module Cushion Box
4X Back Cushion
Left Arm Module Cushion Box (1)
Right Arm Module Cushion Box (1)
Armless Module Cushion Box (2)

Components Assembly Instructions Contact
04
Hardware
64X Hex Bolt
All Frame Boxes
4X Long Hex Bolt
Corner Module Frame Box
2X L-Bracket
Left Arm Module Frame Box
Right Arm Module Frame Box
8X Screw
Left Arm Module Frame Box
Right Arm Module Frame Box
Tools
1X Allen Wrench
All Frame Boxes
Phillips Head Screwdriver
*Not included

Components Assembly Instructions Contact
05
Assembly Tips
Exercise caution while lifting
Two-person lift is recommended. Both the
boxes and the product itself are large and heavy
and awkward to lift alone.
Lay everything out before you begin
Spreading out all of the components prior to
assembling them will help you find the parts
you are looking for and will make for a faster
and easier assembly process!
Assemble on a soft surface
We recommend assembling your furniture on a
soft surface such as a rug(s) or a towel(s). The wood
frame can scratch easily if accidentally rubbed
against harsh textures like brick or concrete.
Loose first, then tight
Do not fully tighten hex bolts when assembling.
Insert them loosely first. After the modules are
fully assembled, then tighten the bolts firmly.
Differing humidity levels can slightly affect how
the pieces fit together and this strategy should
alleviate that.
Product Care
Caring for teak
Unfinished teak will gradually change color
from a honey gold to a silver-grey patina.
We encourage allowing the teak to turn color
naturally and cleaning it annually or bi-annually.
As for cleaning, we recommend Golden Teak
Cleaner, which is specifically designed to kill
mould and mildew spores inside teak.
Avoid prolonging mildew growth. If left in the
shade for extended periods of time, this can be
common.
Covering your furniture for extended periods of
time, especially if enduring consistent inclement
weather will greatly prolong the lifespan of the
wood.
Caring for cushion cover fabric
One of the best ways to keep your Sunbrella
fabric looking good is to brush off dirt before
it becomes embedded in the fabrics and wipe
up spills or clean soon after a stain occurs. The
quicker you clean spills and stains, the easier
they can be to remove.
When removing stains, typically these are the
steps you should try:
• Blot (don’t rub) liquid spills with a clean, dry
cloth. For oil-based spills, apply an absorbent
such as corn starch, then remove with a
straight edge.
• Spray on a mild cleaning solution of soap
(such as Woolite® or Dawn®) and water.
• Rinse the fabric thoroughly to remove all
soap residue.
• Air dry.
Avoid scrubbing, hard bristle brushes or any
other abrasive cleaning method.
Sunbrella should only be allowed to air dry.
Protect the area around your Sunbrella fabric
when using bleach or other chemical solvents
that may discolor non-Sunbrella fabrics. Always
rinse Sunbrella thoroughly.
Bleach can have harmful effects on the natural
environment around you. Please follow all safety
and environmental precautions according to the
bleach label.
If fabric has some wrinkling, use an iron on the
synthetic setting. As iron temperatures may
vary, first test a small inconspicuous area before
ironing the entire piece.
DO NOT use a steamer or an iron set to the
steam setting.

Components Assembly Instructions Contact
06
Building your sectional
Your 5-Piece Symmetrical Sectional can be assembled in
sections. Start by first assembling the armless/corner section,
then work outward to the arm components.
Step 1
Armless/Corner
(p. 11)
Step 2
Armless/Right Arm
(p. 19)
Step 3
Left Arm
(p. 7)

Components Assembly Instructions Contact
07
Left Arm

Left Arm
Components Assembly Instructions Contact
08
Connect large
base to left arm
Place the left arm component on a soft surface,
verifying that the two screw holes inside the
arm are facing upward. Gently insert the long
base into the arm’s inner slots located on the
inside of the two leg components.
1

Left Arm
Components Assembly Instructions Contact
09
2x
Fasten large base
to left arm
Using the Allen wrench, fasten the large base to
both leg components with four hex bolts.
2

Left Arm
Components Assembly Instructions Contact
10
Fasten small leg to
large base
Using the Allen wrench, fasten the small leg
to the large base with two hex bolts. Be sure
to leave two threaded holes on the small leg
exposed as demonstrated.
3

Components Assembly Instructions Contact
11
Armless/
Corner

Components Assembly Instructions Contact
12 Armless/Corner
Fasten legs to
corner base
Using the Allen wrench, fasten
two large legs and the assembled
corner block leg onto the corner
base with hex bolts. Use two long
hex bolts when fastening corner
base to corner leg.
2X Long Hex Bolt
Corner Block
1

Components Assembly Instructions Contact
13
Fasten legs to left
side of short base
With the Allen wrench, thread two hex bolts
through the holes in the front left side of the short
base. Fasten to the short leg. Repeat this with the
large leg on the back left corner of the small base.
Armless/Corner
2

Components Assembly Instructions Contact
14 Armless/Corner
Connect small base
with corner base
Gently slide small base into the grooves located on
the large leg and corner block of the corner base.
Align the holes located on the small base with the
corresponding threaded holes on the corner base.
3

Components Assembly Instructions Contact
15 Armless/Corner
Fasten small base to
corner base
Secure the two bases by inserting four bolts
through the holes on the small base. With the Allen
wrench, gently fasten them to the four threaded
holes located on the corner base.
4

Components Assembly Instructions Contact
16
Drain hole faced down
Armless/Corner
Secure roped
backs to bases
Insert the lower brackets of the small roped
back components into the slots of the short and
corner base.
5

Components Assembly Instructions Contact
17 Armless/Corner
Attach back
supports to
roped backs
Insert armless module back support and
corner module back support onto the
top brackets located on roped backs by
inserting them into corresponding slots
underneath the back supports.
6

Components Assembly Instructions Contact
18
2X Long Hex Bolt
Armless/Corner
Fasten backs to
large legs
With your Allen wrench, gently fasten
armless back support and corner module
back support onto the threaded holes on
the top of the large legs with hex bolts. Use
two long hex bolts in the back in the far
corner of the corner module back support.
7

Components Assembly Instructions Contact
19
Armless/
Right Arm

Armless/Right Arm
Components Assembly Instructions Contact
20
Connect large base to
right arm
Place the right arm component on a soft surface,
verifying that the two screw holes are facing upward.
Gently insert the long base into the arm’s inner slots.
1
