TROB24 Series Thermostat
BACnet®Communication Module
User Guide
TROB24 SERIES-BACNET-USER GUIDE
TROB24-120926-EUL.doc

TROB24 Series Thermostat
Page | 1
Table of Contents
TROB24 Series Thermostat....................................................................................................1
Table of Contents ....................................................................................................................1
Introduction..............................................................................................................................2
BACnet®Overview..................................................................................................................2
Getting Started.........................................................................................................................3
Quick Setup ............................................................................................................................3
Manual Setup..........................................................................................................................3
Copy Config............................................................................................................................4
MAC address and Max_Master..............................................................................................4
Device Object Properties........................................................................................................5
Object Types Supported.........................................................................................................6
Out of Service.........................................................................................................................6
TROB24 Series Objects Table................................................................................................7

TROB24 Series Thermostat
Page | 2
Introduction
This document provides information on using the Neptronic thermostat communications feature. This product
provides a BACnet®network interface between BACnet®client devices and Neptronic products. It uses the
BACnet®Master Slave/Token Passing (MS/TP) protocol at the BACnet®MAC layer.
This document assumes you are familiar with BACnet®and BACnet®terminology.
BACnet®Overview
Performance
The thermostat uses a synchronous implementation for BACnet®messages. Each BACnet®confirmed service
request is answered as quickly as possible without using Reply Postponed. In particular, MS/TP implementation
performs within Tusage_delay of 15ms in order to assure Tusage_timeout values within 20ms.
Support for MS/TP
The thermostat supports a Full Master Node state machine for MS/TP. All parameters are configured via the
thermostat menu or via the BACnet®WriteProperty service. Changes made via the WriteProperty take effect
immediately and does not require a restart of the thermostat. For more information on the configurable
properties, please refer to the Getting Started section on page 3. For more information on the thermostat menu,
please refer to the thermostat’s Specification & Installation Manual for more details.
BIBB Support
The thermostat generally behaves as a B-ASC type profile server. The following specific BIBBs are supported
per their relevant definitions in Annex K to BACnet®: DS-RP-B, DS-RPM-B, DS-WP-B, DS-WPM-B, DM-DDB-B,
DM-DOB-B, DM-DCC-B
Object Support (in general)
The thermostat supports a table-based fixed list of BACnet®-visible values which appear as Present_Values of
various BACnet®standard object types, in addition to a Device object.
Alarms
Although the thermostat supports the ability to indicate various alarm conditions through value changes in
properties of several of its objects, it does not generate BACnet®Event Notifications.
Features
Neptronic thermostats also offer the following time-saving features.
Auto Baud Rate Detection
The thermostat automatically configures its baud rate by detecting the network speed upon connection.
Auto Device Instance Configuration
The thermostat automatically configures its device instance to 153000 + MAC address.
Copy Configuration
Copy the thermostat’s entire configuration and broadcast it to other thermostats of the same type on the
same network.

TROB24 Series Thermostat
Page | 3
Getting Started
The following BACnet®properties are configurable and may need to be modified to effectively establish
communication on the network and to guarantee uniqueness of each device in a BACnet®system.
MAC Address (Default: 001)
Set to between 000 and 254 via thermostat menu* (128-254 represent MS/TP non-token-passing slave
devices).
Device Instance (Default: Auto)
The thermostat automatically configures its device instance to 153000 + MAC address. Can also be set
manually via thermostat menu* or through the WriteProperty service to Device Object.Object_Identifier.
The device’s Object_Identifier is a combination of the Device Object_Type (8) and the Device_Instance
(0-4194302), therefore its decimal or hexadecimal representation tends to be incomprehensible. For
example, the Device_Instance=1000 has an equivalent Object_Identifier of 0x020003E8 hexadecimal or
33555432 decimal. While it’s the device’s Object_Identifier property that can be changed using a
BACnet®WriteProperty service, this document refers mostly to Device_Instance.
Baud Rate (Default: 0 = Auto)
The thermostat automatically configures its baud rate by detecting the network speed upon connection.
Can also be set manually via thermostat menu* or through the WriteProperty service to Device
Object.proprietary property #1001. This value is Unsigned type, and available values are 9600, 19200,
38400, 76800.
Max_Master (Default: 127)
To increase network efficiency or if there are less than 127 devices on the network, the Max_Master
value can be configured through WriteProperty service to the Device Object.Max_Master. For more
information, refer to the MAC address and Max_Master section on page 4.
Device Object.Object_Name
Name of device, for example TROB24T4XYZ1. This value can be configured through WriteProperty
service to the Device Object.Object_Name.
* NOTE: When referring to the thermostat menu in this section, it includes the Quick Access Menu when in
operation mode (RUN) and the Installer Menu when in programming mode (PGM).Refer to the thermostat’s
Specification & Installation Manual for more details.
Quick Setup
Take advantage of the Auto Baud Rate Detection, Auto Device Instance Configuration, and default Max_Master
value, to get up and running with no programming.
1) Connect the thermostat to the network and then power up the thermostat. The thermostat automatically
configures the baud rate and device instance.
2) If you need to set a unique MAC address (default 001), continue to step 3. If not, setup is complete.
3) With the thermostat in Operation Mode (jumper = RUN), go to the Quick Access Menu by pressing and
holding both function buttons on the thermostat for 5 seconds. Refer to the thermostat’s Specification &
Installation Manual for more details.
4) Enter the password (637).
5) Set a unique MAC address.
6) Power down and then power up the thermostat
Manual Setup
If your site has more than one TROB24 network and/or you wish to use a Device_Instance other than 153,000,
follow these instructions.
1) With the thermostat in Operation Mode (jumper = RUN), go to the Quick Access Menu by pressing and
holding both function buttons on the thermostat for 5 seconds. Refer to the thermostat’s Specification &
Installation Manual for more details.

TROB24 Series Thermostat
Page | 4
2) Enter the password (637).
3) In this mode you can manually configure the MAC address, Device Instance and Baud Rate.
4) Power down the thermostat, connect the thermostat to the network and then power up the thermostat.
5) Repeat steps 1 to 4 for each.
6) To increase network efficiency or if there are less than 127 devices on the network, the Max_Master
value can be configured through WriteProperty service to the Device Object.Max_Master. For more
information, refer to the MAC address and Max_Master section on page 4.
Copy Config
Copy the thermostat’s entire configuration and broadcast it to other devices of the same type on the same
network.
1) With the thermostat in Operation Mode (jumper = RUN), go to the Quick Access Menu by pressing and
holding both function buttons on the thermostat for 5 seconds. Refer to the thermostat’s Specification &
Installation Manual for more details.
2) Enter the password (637).
3) Scroll to “Copy Config” and select yes. Follow onscreen instructions.
MAC address and Max_Master
The MAC address must be unique on the entire MS/TP network. However, having a unique MAC address and a
high baud rate does not guarantee efficient operation of the thermostat and other MS/TP units on the MS/TP
network. Some MAC address and Max_Master combinations are more efficient than others. BACnet®requires
token-passing units to occasionally “poll” for other masters based on the MAC address and Max_Master. A
“poor” combination of MAC addresses and Max_Master can lead to a slower network due to lost time polling for
masters that are not present. Unless there are 126 other units on the MS/TP network, the default Max_Master
of 127 is not the most efficient choice for the thermostat. The Max_Master default of 127 was selected to ensure
that any master, specifically a BACnet®client, can be found when the thermostat is first started.
Example 1:
This example is slow and inefficient because every time either unit is required to find another master unit it has
to poll 126 units until it finds the right one to pass the token.
MAC=0. Max_Master=127
MAC=1, Max_Master=127
Example 2:
This example is better but it’s still slower. The Max_Master is set to the most efficient value; however because
of the gap between the two MAC addresses, each unit must poll 4 units until it finds the right one to pass the
token.
MAC=0. Max_Master=5
MAC=1 to MAC=4 are not used
MAC=5, Max_Master=5
Example 3:
This example is an incorrect configuration. The MAC=0 will never find MAC=2 because it will never poll for the
master MAC address=2.
MAC=0. Max_Master=1
MAC=2, Max_Master=2
Example 4:
As a general guideline, the most efficient set up for an MS/TP network is one in which the units are
consecutively numbered starting at MAC address 0 and all have Max_Master=the maximum MAC address in
the system. If consecutive numbering is not possible, then the next most efficient set up is one in which all units
have Max_Master=the maximum MAC address in the system.
MAC=0. Max_Master=3
MAC=1, Max_Master=3
MAC=2, Max_Master=3
MAC=3, Max_Master=3

TROB24 Series Thermostat
Page | 5
Device Object Properties
The following table lists all the BACnet®properties supported for the device object. The “W” indicates if the
property is writable using the BACnet®WriteProperty service.
Property Value Writable
Object_Identifier Programmable where the instance part of the Object_Identifier is in
the range of 0-4194302. The device instance must be unique system-
wide. The default value for the device instance=153001
(Vendor_Identifier*1000)
W
Object_Name Programmable up to 32 characters. The device name must be unique
system-wide. The default value is Model_Name. W
Description Programmable up to 32 characters. The default value= "BACnet
thermostat" W
Object_Type 8
System_Status Non-Operational if major error on device.
Vendor_Identifier Always 153
Vendor_Name Always “National Environmental Products Ltd”
Model_Name Example : “TROB24T4XYZ1”
Firmware_Revision currently “1.18”
Application_Software_Version currently “1.08”
Protocol_Version Always 1
Protocol_Revision Always 4
DataBase_Revision Default = 0, will be incremented if Object_Name and/or
Odject_Identifier is modified
Max_APDU_Length_Accepted Always 235
Segmentation_Supported (3) = No Segmentation
APDU_Timeout 3000
Number_of_APDU_Retries Always 0
Protocol_Services_Supported Always 0x00 0x09 0x40 0x02 0x60
(i.e. a bitstring in BACnet® order)
- writeProperty, readProperty
- deviceCommunicationControl
- unconfirmedPrivateTransfer
- who-Is, who-Has
Protocol_Object_Types_Supported Always 0x00, 0xB4, 0x80, 0x10
(i.e. a bitstring in BACnet®order)
- analog-input, analog-value, binary-input, binary-value
- device
- multi-state-value
Object_List Per the standard. Because of restrictions on the size of the transmit
buffers, the entire Object_List cannot be returned at once, rather the
Object_List must be read, one-at-a-time.
Device_Address_Binding Always empty.
Max_Master Programmable in the range of 0-127. Default value=127 W
Max_Info_Frames Always 1
Proprietary property #1000 Programmable. This proprietary property represents the MS/TP MAC
address in the range of (0-254). Values 128 to 254 represent MS/TP
non-token-passing slave devices. Default value=1
W
Proprietary property #1001 Programmable. This proprietary property represents the MS/TP baud
rate. This value is Unsigned type, and available values are 9600,
19200, 38400, 76800. Writing 0 will activate auto baud rate
functionality. Reading this property will always return actual baud rate.
Default : Auto* (Auto Baud Rate Detection requires V1.18 and up)
W
Proprietary property #1002 Programmable. This proprietary property represents that period of
time that an object in/out of service will automatically return to normal.
Range = 0-120 minutes (unsigned type). Writing 0 means no
automatic return to normal. Default: 15 minutes.
W

TROB24 Series Thermostat
Page | 6
Object Types Supported
A complete list of all BACnet®objects for the thermostat is listed in the following section:
The Device Object has already been described. The following tables list all the BACnet®properties supported
for each object type. Most of the properties are locked in. The exception is Present_Value, which represents the
dynamic operating values of the device, and the Status_Flag, Event_State and Reliability properties which
reflect the availability of the Present_Value. Unless otherwise specified, properties are not changeable.
Object Type Supported Optional Properties
Supported Writable Properties If “Out of Service” is True
Analog Input 
Reliability
Description
Min_Present_Value
Max_Present_Value
Resolution
Out_of_Service Present_Value
Status_Flag
Analog Value Reliability
Description Present_Value1
Out_of_Service2Present_Value
Status_Flag
Binary Input 
Reliability
Active_Text
Inactive_Text
Description
Out_of_Service Present_Value
Status_Flag
Binary Value 
Reliability
Active_Text
Inactive_Text
Description
Present_Value3
Out_of_Service4Present_Value
Status_Flag
Device 
Max_Master
Max_Info_Frame
Description
#1000 (MAC ADD)
#1001 (BAUD RATE)
#1002 (TIME OUT)
Object_Identifier
Object_Name
Max_Master
Description
#1000
#1001
#1002
N/A
Multi-State Value5Description
Reliability
States_Text Present_Value6N/A
Out of Service
Neptronic thermostats offer the use of the “Out of Service” writable property. When set to true, this property
disconnects the object from the physical input, enabling you to input other values. This could be useful for
special applications or when troubleshooting. For example, you can ignore the temperature read from a sensor
and input the desired temperature value in order to perform specific tests.
For security reasons there is a timeout that will set the Out of Service property back to false after 15 minutes.
This value can be modified to between 0 and 120 minutes (see proprietary property #1002).
1Present_Value property is writable for every AV object except: AV.1, AV.2, AV.3, AV.42, AV.46, AV.49, AV.68, AV.69
2 Out_of_Service property is writable for objects that Present_Value is not writable: AV.1, AV.68, AV.69. Object will automatically return to
normal after a programmable period of time. See Proprietary property #1002 of Device object.
3Present_Value property is writable for every BV object except: BV.7
4Out_of_Service property is writable for objects that Present_Value is not writable. See list above. Object will automatically return to normal
after a programmable period of time. See Proprietary property #1002 of Device object.
5MSV object states number and text can vary depending of system set-up. Use carefully.
6Present_Value property is writable for every MSV object except: MSV.9

TROB24 Series Thermostat
Page | 7
TROB24 Series Objects Table
The TROB24 thermostat series of controllers use the following BACnet®object table. The type is the BACnet®
Object type, the instance is the BACnet®Object. Together the type and instance form the BACnet®
Object_Identifier for an object according to the following C-language algorithm:
object_identifier=(unsigned long)((unsigned long)type<<22)+instance
ID7Name Writable
Property Notes
AI.1 InternTemp Out of service 0-50ºC or 32-122ºF, Resolution 0.01ºC/0.02ºF
AI.2 ExternTemp Out of service -40-100ºC or -40-212ºF, Resolution 0.01ºC/0.02ºF
AI.3 ChangeOverTemp Out of service -40-100ºC or -40-212ºF, Resolution 0.01ºC/0.02ºF
AI.10 PressureSensor Out of service 0-10.00 Volt, Resolution 0.01 Volt
AV.1 ControlTemp Out of service -40-100ºC or -40-212ºF, Resolution 0.01ºC/0.02ºF
AV.2 HeatingDemand1 N/A 0-100%, Resolution 0.1%
AV.3 CoolingDemand1 N/A 0-100%, Resolution 0.1%
AV.5 InternTempOffset Present Value ±5.0ºC, Resolution 0.1ºC
AV.6 ExternTempOffset Present Value ±5.0ºC, Resolution 0.1ºC
AV.7 TempSetPointDay Present Value AV.8 to AV.9, Resolution 0.5ºC/1ºF
AV.8 MinSetPointDay Present Value 0 to AV.9 , Resolution 0.5ºC/1ºF
AV.9 MaxSetPointDay Present Value AV.8 to 40ºC or 104ºF, Resolution 0.5ºC/1ºF
AV.10 TempSetPointCoolNight Present Value AV.11 to 40ºC or 104ºF, Resolution 0.5ºC/1ºF
AV.11 TempSetPointHeatNight Present Value 10.0ºC or 50ºF to AV.10, Resolution 0.5ºC/1ºF
AV.12 CoolingPropBand1 Present Value 0.5-5ºC or 1-10ºF, Resolution 0.5ºC/1ºF
AV.13 HeatingPropBand1 Present Value 0.5-5ºC or 1-10ºF, Resolution 0.5ºC/1ºF
AV.14 CoolingDeadBand1 Present Value 0.3-5ºC or 0.6-10ºF, Resolution 0.1ºC/0.2ºF
AV.15 HeatingDeadBand1 Present Value 0.3-5ºC or 0.6-10ºF, Resolution 0.1ºC/0.2ºF
AV.23 ChangeOverSetPoint Present Value 10-40ºC or 50-104ºF, Resolution 0.5ºC/1ºF
AV.24 NightSetBackDelay Present Value 0-180 minutes, Resolution 15 minutes
AV.26 IntTimeFactor Present Value 0-250 seconds, Resolution 5 seconds
AV.27 CoolingAntiCycleDelay Present Value 0-15 minutes, Resolution 1 minute
AV.31 FloatingMotorTiming1
8
Present Value 15-250 seconds, Resolution 5 seconds
AV.42 CoolingDemand2 N/A 0-100%, Resolution 0.1%
AV.43 CoolingPropBand2 Present Value 0.5-5ºC or 1-10ºF, Resolution 0.5ºC/1ºF
AV.44 CoolingDeadBand2 Present Value 0.3-5ºC or 0.6-10ºF, Resolution 0.1ºC/0.2ºF
AV.46 HeatingDemand2 N/A 0-100%, Resolution 0.1%
AV.47 HeatingPropBand2 Present Value 0.5-5ºC or 1-10ºF, Resolution 0.5ºC/1ºF
AV.48 HeatingDeadBand2 Present Value 0.3-5ºC or 0.6-10ºF, Resolution 0.1ºC/0.2ºF
AV.49 ChangeOverDemand N/A 0-100%, Resolution 0.1%
AV.50 ChangeOverPropBand Present Value 0.5-5ºC or 1-10ºF, Resolution 0.5ºC/1ºF
AV.51 ChangeOverDeadBand Present Value 0.3-5ºC or 0.6-10ºF, Resolution 0.1ºC/0.2ºF
AV.52 AnalogOutput1Min Present Value 0 Volt to AV.54, Resolution 0.1 Volt
AV.53 AnalogOutput2Min Present Value 0 Volt to AV.55, Resolution 0.1 Volt
AV.54 AnalogOutput1Max Present Value AV.52 to 10.0 Volt, Resolution 0.1 Volt
AV.55 AnalogOutput2Max Present Value AV.53 to 10.0 Volt, Resolution 0.1 Volt
AV.56 AnalogOutput1MinPos Present Value 0-100%, Resolution 5%
AV.57 AnalogOutput2MinPos Present Value 0-100%, Resolution 5%
AV.58 FloatingMotorTiming2
9
Present Value 15-250 seconds, Resolution 5 seconds
AV.61 PressureNumFilter Present Value 1-10 seconds, Resolution 1 second
AV.62 AirFlowVnomOrKFactor Present Value 100-9995, Resolution 5
AV.63 AirFlowCoolMin Present Value 0 to AV.64, Resolution 5
AV.64 AirFlowCoolMax Present Value AV.63 to AV.62, Resolution 5
AV.65 AirFlowHeatMin Present Value 0 to AV.66, Resolution 5
AV.66 AirFlowHeatMax Present Value AV.65 to AV.62, Resolution 5
AV.67 AirFlowIntFactor Present Value 0-60 minutes, Resolution 1 minute
AV.68 ActualAirFlow OutOfService 0 to AV.62, Resolution 1
AV.69 AirFlowSetPoint OutOfService 0-9999, Resolution 1
AV.71 AdjustAirFlowKFactor
10
Present Value 0-9999, Resolution 1
AV.72 AnalogOutput1
11
N/A 0-10V
AV.73 AnalogOutput2
12
N/A 0-10V
AV.160 AirFlowOffset Present Value ±500
BI.1 UIxContactInput Out of service
0= Open
1= Close
7ID is equal to ObjectType.Instance
8Used if MSV.22 and MSV.23 are in Floating mode.
9Used if MSV.24 and MSV.25 are in Floating mode.
10 Writable only if system is in balancing, BV.14 is set to “Enable” and BV.15 is set to “Maximum”
11 Writable if MSV.16 is set OFF. Off means no internal process affected to this output.
12 Writable if MSV.17 is set OFF. Off means no internal process affected to this output.

TROB24 Series Thermostat
Page | 8
ID7Name Writable
Property Notes
BV.1 TempUnit Present Value
0= Celsius
1= Fahrenheit
BV.2 TempSetPointLock Present Value
0= Disable
1= Enable
BV.3 UserControlOffMode13 Present Value
0= Enable
1= Disable
BV.6 ControlTempSource Present Value
0= Intern.Sensor
1= Extern.Sensor14
BV.7 ChangeOverMode Out of service
0= Cooling
1= Heating
BV.14 AirFlowBalancing Present Value
0= Disable
1= Enable
BV.15 AirFlowBalMode Present Value
0= Minimum
1= Maximum
BV.16 AntiFreezeProtection15 Present Value
0= Off
1= On
BV.17 FloatingMotor1Direction Present Value
0= Direct
1= Reverse
BV.18 FloatingMotor2Direction Present Value
0= Direct
1= Reverse
BV.29 OnOffOutput116 Present Value 0= Off
1= On
BV.30 OnOffOutput217 Present Value 0= Off
1= On
BV.31 OnOffOutput318 Present Value 0= Off
1= On
BV.32 OnOffOutput419 Present Value 0= Off
1= On
MSV.1 UniversalInput1Function20 Present Value
1= Off
2= Extern.Sensor
3= ChangeOverSensor
4= Ch.Ov.ContactNorm.Cool
5= Ch.Ov.ContactNorm.Heat
6= NightSetBack
7= Pressure0-10V
8= AirFlow0-10V
MSV.3 UserControlMode Present Value
States available if MSV.4 is set to “Auto”
1= Auto,
2= Heating
3= Cooling
4= Off (only if BV.3 is set to “Enable”)
States available if MSV.4 is set to “Cool”
1= Cooling
2= Off (only if BV.3 is set to “Enable”)
States available if MSV.4 is set to “Heat”
1= Heating
2= Off (only if BV.3 is set to “Enable”)
States available if MSV.4 is set to “HeatingOrCooling”
1= Heating
2= Cooling
3= Off (only if BV.3 is set to “Enable”)
MSV.4 ControlMode21 Present Value
1= Auto
2= Heating
3= Cooling
4= HeatingOrCooling
MSV.9 NightSetBack Out of service
1= Day
2= Night
3= Override
13 Enable or Disable “off” state of UserControlMode (MSV.3).
14 It can be set to “Use Extern.Sensor” only if one object MSV.1, MSV.12 or MSV.15 is set to “Extern.Sensor”
15 Available on version 1.03 and above.
16 Writable if MSV.18 is set OFF. Off means no internal process affected to this output.
17 Writable if MSV.19 is set OFF. Off means no internal process affected to this output.
18 Writable if MSV.20 is set OFF. Off means no internal process affected to this output.
19 Writable if MSV.21 is set OFF. Off means no internal process affected to this output.
20 Activating external temperature does not automatically modify the control source; it is necessary to also modify BV.6 to control by external
temperature. Pressure0-10V and AirFlow0-10V are available on version 1.03 and above.
21 Locks user options. MSV.3, UserControlMode, will be affected or even locked in one state.

TROB24 Series Thermostat
Page | 9
ID7Name Writable
Property Notes
MSV.12 UniversalInput2Function22 Present Value
1= Off
2= Extern.Sensor
3= ChangeOverSensor
4= Ch.Ov.ContactNorm.Cool
5= Ch.Ov.ContactNorm.Heat
6= NightSetBack
7= Pressure0-10V
8= AirFlow0-10V
MSV.13 NightSetBackMode23 Present Value
1= Locally
2= Day
3= Night
MSV.15 UniversalInput3Function24 Present Value
1= Off
2= Extern.Sensor
3= ChangeOverSensor
4= Ch.Ov.ContactNorm.Cool
5= Ch.Ov.ContactNorm.Heat
6= NightSetBack
7= Pressure0-10V
8= AirFlow0-10V
MSV.16 AnalogOutput1Source Present Value
1= Off
2= ChangeOverDemand
3= CoolingDemand1
4= CoolingDemand2
5= HeatingDemand1
6= HeatingDemand2
MSV.17 AnalogOutput2Source Present Value
1 = Off
2= ChangeOverDemand
3= CoolingDemand1
4= CoolingDemand2
5= HeatingDemand1
6= HeatingDemand2
MSV.18 TO1Source Present Value
1= ChangeOverDemand
2= CoolingDemand1
3= CoolingDemand2
4= HeatingDemand1
5= HeatingDemand2
States available if MSV.22 is set to “Pulsing”:
1= HeatingDemand1
2= HeatingDemand2
MSV.19 TO2Source Present Value
1= ChangeOverDemand
2= CoolingDemand1
3= CoolingDemand2
4= HeatingDemand1
5= HeatingDemand2
States available if MSV.23 is set to “Pulsing”:
1= HeatingDemand1
2= HeatingDemand2
MSV.20 TO3Source Present Value
1= Off
2= ChangeOverDemand
3= CoolingDemand1
4= CoolingDemand2
5= HeatingDemand1
6= HeatingDemand2
States available if MSV.24 is set to “Pulsing”:
1= HeatingDemand1
2= HeatingDemand2
MSV.21 TO4Source Present Value
1= Off
2= ChangeOverDemand
3= CoolingDemand1
4= CoolingDemand2
5= HeatingDemand1
6= HeatingDemand2
States available if MSV.25 is set to “Pulsing”:
1= HeatingDemand1
2= HeatingDemand2
22 Activating external temperature does not automatically modify the control source; it is necessary to also modify BV.6 to control external
temperature. Pressure0-10V and AirFlow0-10V are available on version 1.03 and above.
23 Selecting “Locally” enables the thermostat to manage the day or night status for energy conservation. The other 2 statuses force the
thermostat into a specific state.
24 Activating external temperature does not automatically modify the control source; it is necessary to also modify BV.6 to control external
temperature. Pressure0-10V and AirFlow0-10V are available on version 1.03 and above.

TROB24 Series Thermostat
Page | 10
ID7Name Writable
Property Notes
MSV.22 TO1Mode Present Value
1= On_Off
2= Pulsing
3= Floating
MSV.23 TO2Mode Present Value
1= On_Off
2= Pulsing
States available if MSV 22 is set to “Floating”
1= Floating
MSV.24 TO3Mode Present Value
1= On_Off
2= Pulsing
3= Floating
MSV.25 TO4Mode Present Value
1= On_Off
2= Pulsing
States available if MSV 24 is set to “Floating”
1= Floating
MSV.26 TO1ClosePos Present Value
Ignored if MSV.22 is other than “On_Off”
1= 20%
2= 40%
3= 60%
4= 80%
MSV.27 TO2ClosePos Present Value
Ignored if MAV.23 is other than “On_Off”
1= 20%
2= 40%
3= 60%
4= 80%
MSV.28 TO3ClosePos Present Value
Ignored if MSV.24 is other than “On_Off”
1= 20%
2= 40%
3= 60%
4= 80%
MSV.29 TO4ClosePos Present Value
Ignored if MSV.25 is other than “On_Off”
1= 20%
2= 40%
3= 60%
4= 80%
MSV.31 PressureIndOutput Present Value
if MSV.22 and MSV.24 are set to “Floating”
1= Floating1
2= AnalogOutput1
3= AnalogOutput2
4= Floating2
if MSV.22 is set to “Floating”
1= Floating1
2= AnalogOutput1
3= AnalogOutput2
if MSV.24 is set to “Floating”
1= AnalogOutput1
2= AnalogOutput2
3= Floating2
if MSV.22 and MSV.24 are other than “Floating”
1= AnalogOutput1
2= AnalogOutput2
MSV.33 ChangeOverControlMode25 Present Value
1= Locally
2= Cooling
3= Heating
All objects related to pressure independent are available in version 1.03 and above.
AI.10, AV.61 to AV.71, BV.14, BV.15, MSV.31
25 Selecting “Locally” enables the thermostat to manage the cooling or heating status for change over ramp. The other 2 statuses force the
thermostat into a specific state.

400 Lebeau Blvd, Montreal, Qc, H4N 1R6, CANADA
www.neptronic.com
Toll free in North America: 1 800 361-2308
Tel.: [phone]
Fax: [phone]
Customer service Fax: [phone]
Business hours: from Monday to Friday, 8:00am to 5:00pm (Eastern time)
