Installation Guide for
Fiber Tap HD8
800-0153-001 Doc. PUBTP800800XU Rev.D 11/11


Fiber Tap HD8
Contents
Introduction.....................................................1
Key Features ....................................................2
About This Guide ................................................3
Unpacking and Inspection..........................................3
Product Diagram .................................................4
Connecting to the Network .........................................5
Connecting to the Monitoring Device.................................6
Specications ...................................................7
Limitations on Warranty and Liability ................................8

Fiber Tap HD8
PLEASE READ THESE LEGAL NOTICES CAREFULLY.
By using a Net Optics Tap you agree to the terms and conditions of usage set forth by Net Optics, Inc.
No licenses, express or implied, are granted with respect to any of the technology described in this
manual. Net Optics retains all intellectual property rights associated with the technology described in
this manual. This manual is intended to assist with installing Net Optics products into your network.
Trademarks and Copyrights
© 2010 by Net Optics, Inc. Net Optics® is a registered trademark of Net Optics, Inc. Additional com-
pany and product names may be trademarks or registered trademarks of the individual companies and
are respectfully acknowledged.
Additional Information
Net Optics, Inc. reserves the right to make changes in specications and other information contained
in this document without prior notice. Every effort has been made to ensure that the information in this
document is accurate.

Fiber Tap HD8
1
Introduction
Get total trafc visibility for monitoring and security devices by placing
Net Optics Fiber Tap HD8 on critical network links. The all-optical design
of the Fiber Tap HD8 is optimized and tested for high-performance on ber
networks. Available for both singlemode and multimode ber, the GigaBit and
10 GigaBit Fiber Tap HD8 supports passive monitoring of ber optics links.
Slim Prole
Flat-out, the thinnest 8 station Fiber Tap HD8. The new slim prole of the
Fiber Tap HD8 saves rack space—install up to sixteen Taps in a one rack unit
panel.
All Optical Design
Requiring no power, Fiber Tap HD8 maintains permanent passive access ports
without introducing a point of failure or disturbing other network connections.
These passive Taps deliver full-duplex monitoring with zero impact on network
trafc around the clock.
Simply Plug It In
Full-duplex monitoring is a snap with a custom monitoring cable that sends
each side of the signal to a separate NIC on the monitoring device.
Security and Visibility
Without an IP address, monitoring devices are isolated from the network, dra-
matically reducing their exposure to attacks. However, the monitoring device
connected to the Tap still sees all full-duplex trafc as if it were in-line, including
Layer 1 and Layer 2 errors.

Fiber Tap HD8
2
Key Features
Passive, Secure Technology
• Provides passive access without data stream interference or introducing a
point of failure
• All-optical design is optimized and tested for ber networks
• Permanent in-line installation without affecting network performance
• Passes all full-duplex trafc (including errors) from all layers for
comprehensive troubleshooting
• No IP address is needed for the Tap or monitoring device, enhancing
monitoring security
• Completely transparent to the network and requires no power
• Fully RoHS compliant
Ease of Use
• Front-mounted connectors make installation and operation quick and easy
• Compatible with all major manufacturers’ monitoring devices, including
protocol analyzers, probes, and intrusion detection/prevention systems
Support
• Net Optics offers free technical support throughout the lifetime of your
purchase. Our technical support team is available from 8 am to 5 pm Pacic
Time, Monday through Friday at +1 (408) 737-7777 and via email at
at www.netoptics.com.

Fiber Tap HD8
3
About This Guide
Please read the guide before attempting to install Fiber Tap HD8. This guide
covers the following models:
Part Number Description Split Ratio
TP-800 GigaBit Multimode Fiber Tap HD8 (SX) 50/50
TP-803 GigaBit Multimode Fiber Tap HD8 (SX) 70/30
TP-805 GigaBit Multimode Fiber Tap HD8 (SX) 50µm 50/50
TP-807 GigaBit Multimode Fiber Tap HD8 (SX) 50µm 70/30
TP-810 GigaBit Singlemode Fiber Tap HD8 (LX) 50/50
TP-813 GigaBit Singlemode Fiber Tap HD8 (LX) 70/30
TP-800X 10 GigaBit Multimode Fiber Tap HD8 (SR) 50/50
TP-803X 10 GigaBit Multimode Fiber Tap HD8 (SR) 70/30
TP-805X 10 GigaBit Multimode Fiber Tap HD8 (SR) 50µm 50/50
TP-807X 10 GigaBit Multimode Fiber Tap HD8 (SR) 50µm 70/30
TP-810X 10 GigaBit Singlemode Fiber Tap HD8 (LR) 50/50
TP-813X 10 GigaBit Singlemode Fiber Tap HD8 (LR) 70/30
Unpacking and Inspection
Carefully unpack the Fiber Tap HD8 and check for damaged or missing parts.
The Fiber Tap ships with the following:
• Fiber Tap HD8
• Test report
• Installation Guide
You may have also ordered an extended warranty. Carefully check the packing
slip against parts received. If any part is missing or damaged, contact
Net Optics' Customer Service immediately.

Fiber Tap HD8
4
Product Diagram
Figure 1: Front Panel (all models)
LASER
CAUTION!
Splitter Tap HDSplitter Tap HD
www.netoptics.com
ABAA BB
OUT IN OUT IN OUT OUT
ABAA BB
OUT IN OUT IN OUT OUT
ABAA BB
OUT IN OUT IN OUT OUT
ABAA BB
OUT IN OUT IN OUT OUT
ABAA BB
OUT IN OUT IN OUT OUT
ABAA BB
OUT IN OUT IN OUT OUT
ABAA BB
OUT IN OUT IN OUT OUT
ABAA BB
OUT IN OUT IN OUT OUT
1 2 4 5 6 8
7
3
Network Port Segments
Monitor Ports Segments

Fiber Tap HD8
5
Connecting to the Network
1. Connect Network Port A to the appropriate network device using a Duplex
LC cable.
2. Connect Network Port B to the appropriate network device using a Duplex
LC cable.
3. Verify that the Tap Network Ports are cabled in-line between two devices.
4. Repeat steps 1-3 as needed for remaining segements.
Note:________________________________________________________________
The use of Singlemode (8.5µm) or Multimode (50µm or 62.5µm) cabling is
determined by the model purchased.
______________________________________________________________________
Figure 2: Connecting to the Network
To Network Device
To Network Device
Splitter Tap HD8Splitter Tap HD8
www.netoptics.com
ABAA BB
OUT IN OUT IN OUT OUT
A
BAA BB
OUT IN
OUT IN OUT OUT
ABAA BB
OUT IN OUT IN OUT OUT
1 2
4
3

Fiber Tap HD8
6
Connecting to the Monitoring Device
1. Connect to the Monitor Port using a Net Optics custom LC analyzer cable
2. Connect one side of the twin-duplex ber cable into a RX port on the
monitoring device to view one side of the full-duplex link.
3. Connect the other side of the twin-duplex ber cable into another RX port
on the monitoring device to view the other side of the full-duplex link.
4. Verify that the Tap Monitor Port is cabled to the monitoring device.
5. Repeat steps 1-4 as needed for remaining segements.
Note:________________________________________________________________
The connectors on the twin-duplex side of the custom analyzer cable contain
RX connections only. The empty TX sides are present to eliminate cabling
errors and should also be connected to the monitoring device.
______________________________________________________________________
Figure 3: Connecting the Monitoring Device
To Monitoring Device
Splitter Tap HD8Splitter Tap HD8
www.netoptics.com
ABAA BB
OUT IN OUT IN OUT OUT
ABAA
OUT IN OUT IN OUT OUT
ABAA
BB
OUT IN OUT IN OUT
OUT
ABAA BB
OUT IN OUT IN OUT OUT
1 2
4
3

Fiber Tap HD8
7
Specications
Splitter Specications
Fiber Type 10 Gigabit model:
Corning Multimode 50 or 62.5/125µm, wavelength 850nm
Split Ratio Network Port Insertion Loss Monitor Port Insertion Loss
50/50 ≤ 4.5 dB ≤ 4.5 dB
70/30 ≤ 2.4 dB ≤ 6.3 dB
Fiber Type 10 Gigabit model:
Corning Singlemode 8.5/125µm, wavelength 1310nm or 1550nm
Split Ratio Network Port Insertion Loss Monitor Port Insertion Loss
50/50 ≤ 3.7 dB ≤ 3.7 dB
70/30 ≤ 2.0 dB ≤ 6.1 dB
Fiber Type Gigabit model:
Corning Multimode 50 or 62.5/125µm, wavelength 850nm
Split Ratio Network Port Insertion Loss Monitor Port Insertion Loss
50/50 ≤ 4.5 dB ≤ 4.5 dB
70/30 ≤ 2.4 dB ≤ 6.3 dB
Fiber Type Gigabit model:
Corning Singlemode 8.5/125µm, wavelength 1310nm
Split Ratio Network Port Insertion Loss Monitor Port Insertion Loss
50/50 ≤ 3.7 dB ≤ 3.7 dB
70/30 ≤ 2.0 dB ≤ 6.1 dB
Environment
Operating Temperature: 0˚C to 40˚C
Storage Temperature: -55˚C to 85˚C
Relative Humidity: 10% min, 95% max, non-condensing
Mechanical
Dimensions: 0.875” high x 7” deep x 17” wide
Connectors
(8) Duplex LC connector (monitor port)
(8) Quad LC connectors (network ports)

Fiber Tap HD8
8
Limitations on Warranty and Liability
Net Optics offers a limited warranty for all its products. IN NO EVENT SHALL NET OPTICS, INC.
BE LIABLE FOR ANY DAMAGES INCURRED BY THE USE OF THE PRODUCTS (INCLUD-
ING BOTH HARDWARE AND SOFTWARE) DESCRIBED IN THIS MANUAL, OR BY ANY
DEFECT OR INACCURACY IN THIS MANUAL ITSELF. THIS INCLUDES BUT IS NOT LIM-
ITED TO LOST PROFITS, LOST SAVINGS, AND ANY INCIDENTAL OR CONSEQUENTIAL
DAMAGES ARISING FROM THE USE OR INABILITY TO USE THIS PRODUCT, even if Net
Optics has been advised of the possibility of such damages. Some states do not allow the exclusion
or limitation of implied warranties or liability for incidental or consequential damages, so the above
limitation or exclusion may not apply to you.
Net Optics, Inc. warrants this Tap to be in good working order for a period of ONE YEAR from the
date of purchase from Net Optics or an authorized Net Optics reseller.
Should the unit fail anytime during the said ONE YEAR period, Net Optics will, at its discretion,
repair or replace the product. This warranty is limited to defects in workmanship and materials and
does not cover damage from accident, disaster, misuse, abuse or unauthorized modications.
If you have a problem and require service, please call the number listed at the end of this section and
speak with our technical service personnel. They may provide you with an RMA number, which must
accompany any returned product. Return the product in its original shipping container (or equivalent)
insured and with proof of purchase.
Additional Information
Net Optics, Inc. reserves the right to make changes in specications and other information contained
in this document without prior notice. Every effort has been made to ensure that the information in
this document is accurate. Net Optics is not responsible for typographical errors.
THE WARRANTY AND REMEDIES SET FORTH ABOVE ARE EXCLUSIVE AND IN LIEU OF
ALL OTHERS, EXPRESS OR IMPLIED. No Net Optics reseller, agent, or employee is authorized
to make any modication, extension, or addition to this warranty.
Net Optics is always open to any comments or suggestions you may have about its products and/or
this manual.
Send correspondence to
Net Optics, Inc.
5303 Betsy Ross Drive
Santa Clara, CA 95054 USA
Telephone: +1 (408) 737-7777
Fax: +1 (408) 745-7719
All Rights Reserved. Printed in the U.S.A. No part of this publication may be reproduced, transmit-
ted, transcribed, stored in a retrieval system, or translated into any language or computer language,
in any form, by any means, without prior written consent of Net Optics, Inc., with the following
exceptions: Any person is authorized to store documentation on a single computer for personal use
only and that the documentation contains Net Optics’ copyright notice.

Fiber Tap HD8
9
Notes:

Fiber Tap HD8
10
Notes:


© 2010 by Net Optics, Inc. All Rights Reserved.
www.netoptics.com
Table of contents
Other Net Optics Network Hardware manuals

Net Optics
Net Optics iTap Port Aggregator User manual

Net Optics
Net Optics Link Aggregator Tap 10/100 In-Line to GigaBit with SFP Monitor... User manual

Net Optics
Net Optics TPA-CU3 User manual

Net Optics
Net Optics Phantom HD User manual

Net Optics
Net Optics 10/100BaseT Slim Tap User manual

Net Optics
Net Optics Smart Filtering none User manual

Net Optics
Net Optics 96542iTP User manual

Net Optics
Net Optics BPO-SX User manual

Net Optics
Net Optics OC-3 User manual

Net Optics
Net Optics RGN-50SR-IL8 User manual
